av1 News - CNX Software - Embedded Systems News

July 1, 2024July 1, 2024 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

Amlogic S905X5M vs S905X4 – Features and benchmarks comparison

Amlogic S905X5M is an update to the Amlogic S905X4 quad-core Cortex-A55 SoC with a higher 2.5 GHz CPU clock and a new generation Arm G310 CPU that delivers up to close to three times the performance of the Mali-G31 MP2 GPU for more advanced and smoother HDR user interfaces. The S905X5M and S905X4 share the same video decoding capabilities, notably AV1 and H265 up to 4Kp75, but the new S905X5M drops support for H.265 1080p60 video encoding, only keeping H.264 1080p30. One of the new features is the inclusion of an NPU designed specifically for Super Resolution enabling video upscaling with better image quality. You’ll find the differences between the Amlogic S905X5M and S905X5 processors in the comparison table below. The Amlogic S905X5M adds some HDMI 2.1 features that deserve an explanation: QMS (Quick Media Switching) – A source device can instantly switch its content’s resolution or frame rate without […]

June 8, 2024June 8, 2024 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

UP Xtreme i14 SBC offers Intel Core Ultra 5/7 Meteor Lake SoC, up to 64GB LPDDR5 for robotics and AIoT applications

AAEON has launched the UP Xtreme i14 SBC based on a choice of Intel Core Ultra 5/7 Meteor Lake SoCs, up to 64GB LPDDR5, M.2 PCIe sockets and a SATA port for storage, 2.5GbE and GbE interfaces, four 8K capable video output ports (HDMI, DP, and USB-C), a MIPI CSI camera interface, and more. The 14th Intel Core Ultra 5/7 SoC features up to 16 cores, Intel Arc graphics, and an Intel AI Boost NPU that deliver up to 32 TOPS combined and make the UP Xtreme i14 board especially suitable for applications such as Autonomous Mobile Robots (AMR), Smart Retail, and AI-assisted healthcare imaging. UP Xtreme i14 specifications: Meteor Lake-H/U SoC (one of the other) Intel Core Ultra 7 165H 16-core (6P+8E+2LPE) processor @ 1.4 / 5.0 GHz with 24MB cache, Intel 8Xe LPG graphics @ 2.3 GHz, Intel AI Boost NPU; TDP: 28W Intel Core Ultra 7 155H […]

March 7, 2024April 24, 2024 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

RealTek RTD1325 SoC shows up in Formuler Z mini 4K Android 12 dongle

Formuler Z mini is a 4K Android 12 TV dongle powered by the new RealTek RTD1325 SoC with a Mali-G57 MC1, 4K AV1 video processing unit, and support for features such as Quick Media Switching (QMS) from the HDMI 2.1 specifications. The Android TV dongle also comes with 2GB LPDDR4 memory, 8GB eMMC flash, an HDMI 2.1 port up to 4K resolution, WiFi 5 and Bluetooth 5.0 connectivity, Widevine L1 DRM, and a Bluetooth voice remote control. Formuler Z mini specifications: SoC – RealTek RTD1325 CPU – Quad-core Arm Cortex-A55 @ 1.7GHz with 512KB L3 cache [Updated on April 24, 2024 – See comments section] GPU – Arm Mali-G57 MC1 VPU – 4Kp60 10-bit AV1 video decoder System Memory – 2GB LPDDR4 @ 2400MHz Storage – 8GB eMMC flash Video Output – HDMI 2.1 up to 4K resolution (3840 x 2160) with 4K HDR (HDR10+, HLG), QMS support Networking – […]

December 30, 2023January 9, 2024 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Mixtile Core 3588E SoM review – Part 2: Ubuntu 22.04, hardware features, RK3588 AI samples, NVIDIA Jetson compatibility

We’ve already had a look at the Mixtile Core 3588E NVIDIA Jetson Nano/TX2 NX/Xavier NX/Orin Nano compatible Rockchip RK3588 SO-DIMM system-on-module in the first part of the review with an unboxing and first boot with an Ubuntu 22.04 OEM installation. I’ve now had more time to play with the devkit comprised of a Core 3588 module in 16GB/128GB configuration and a Leetop A206 carrier board with low-level features testing, some benchmarks, multimedia testing with 3D graphics acceleration and video playback, some AI tests using the built-in 6 TOPS NPU and the RKNPU2 toolkit, and finally I also tried out the system-on-module with the carrier board from an NVIDIA Jetson Nano developer kit. Ubuntu 22.04 System info We had already checked some of the system information in the first part of the Mixtile Core 3588E review, but here’s a reminder:

jaufranc@Mixtile-RK3588E:~$ uname -a
Linux Mixtile-RK3588E 5.10.160-rockchip #18 SMP Wed Dec 6 15:11:42 UTC 2023 aarch64 aarch64 aarch64 GNU/Linux
jaufranc@Mixtile-RK3588E:~$ cat /etc/lsb-release
DISTRIB_ID=Ubuntu
DISTRIB_RELEASE=22.04
DISTRIB_CODENAME=jammy
DISTRIB_DESCRIPTION="Ubuntu 22.04.3 LTS"
jaufranc@Mixtile-RK3588E:~$ df -h
Filesystem      Size  Used Avail Use% Mounted on
tmpfs           1.6G  2.7M  1.6G   1% /run
/dev/mmcblk0p2  113G  7.5G  101G   7% /
tmpfs           7.7G     0  7.7G   0% /dev/shm
tmpfs           5.0M  8.0K  5.0M   1% /run/lock
tmpfs           4.0M     0  4.0M   0% /sys/fs/cgroup
/dev/mmcblk0p1  512M  101M  411M  20% /boot/firmware
tmpfs           1.6G   60K  1.6G   1% /run/user/0
tmpfs           1.6G   76K  1.6G   1% /run/user/130
tmpfs           1.6G   68K  1.6G   1% /run/user/1000
jaufranc@Mixtile-RK3588E:~$ free -mh
               total        used        free      shared  buff/cache   available
Mem:            15Gi       601Mi        13Gi        47Mi       1.4Gi        14Gi
Swap:          2.0Gi          0B       2.0Gi

jaufranc@Mixtile-RK3588E:~$ uname -a

Linux Mixtile-RK3588E 5.10.160-rockchip #18 SMP Wed Dec 6 15:11:42 UTC 2023 aarch64 aarch64 aarch64 GNU/Linux

jaufranc@Mixtile-RK3588E:~$ cat /etc/lsb-release

DISTRIB_ID=Ubuntu

DISTRIB_RELEASE=22.04

DISTRIB_CODENAME=jammy

DISTRIB_DESCRIPTION="Ubuntu 22.04.3 LTS"

jaufranc@Mixtile-RK3588E:~$ df -h

Filesystem Size Used Avail Use% Mounted on

tmpfs 1.6G 2.7M 1.6G 1% /run

/dev/mmcblk0p2 113G 7.5G 101G 7% /

tmpfs 7.7G 0 7.7G 0% /dev/shm

tmpfs 5.0M 8.0K 5.0M 1% /run/lock

tmpfs 4.0M 0 4.0M 0% /sys/fs/cgroup

/dev/mmcblk0p1 512M 101M 411M 20% /boot/firmware

tmpfs 1.6G 60K 1.6G 1% /run/user/0

tmpfs 1.6G 76K 1.6G 1% /run/user/130

tmpfs 1.6G 68K 1.6G 1% /run/user/1000

jaufranc@Mixtile-RK3588E:~$ free -mh

total used free shared buff/cache available

Mem: 15Gi 601Mi 13Gi 47Mi 1.4Gi 14Gi

Swap: 2.0Gi 0B 2.0Gi

I also ran inxi to check a few more details. […]

December 15, 2023December 20, 2023 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

COM Express Type 6 Compact module features 14th gen Intel Core Ultra “Meteor Lake” processor

ADLINK cExpress-MTL is a COM Express Type 6 Compact module based on the just-announced 14th gen Intel Core Ultra “Meteor Lake” processor family with up to fourteen CPU cores in 6P+8E configuration, eight Xe-cores (128 EUs), and an NPU (11pTOPS/8.2eTOPS) in a 15 or 28W TDP thermal configuration delivering up to 1.9x the GPU performance of the previous generation (Raptor Lake). The power consumption will also be lower thanks to Intel Core Ultra’s new Low-Power E-cores that are 30 to 50% more efficient than the E-cores in 13th gen Intel Core processors, and the faster GPU and built-in NPU will enable hardware-accelerated AV1 encoding/decoding and various devices leveraging AI such as portable medical ultrasound devices, industrial automation, autonomous driving, AI robots, and more. cExpress-MTL specifications: Meteor Lake-H/U SoC (one of the other) Intel Core Ultra 7 MS3 165H 16-core (6P+8E+2LPE) processor @ 1.4 / 5.0 GHz with 24MB cache, Intel […]

October 26, 2023October 26, 2023 by Jean-Luc Aufranc (CNXSoft) - 14 Comments

Qualcomm Snapdragon X Elite – A 4.3 GHz 12-core Arm AI processor for next gen PCs and laptops

Qualcomm has now provided Arm chips for mobile PCs (aka laptops) for several years, but apart from a 20-hour battery life, the performance and price of Snapdragon laptops have often been disappointing. The Snapdragon X Elite aims to change that at least on the performance front. The new Qualcomm 12-core 64-bit Arm processor is clocked at up to 3.8 GHz boosting to up to 4.3 GHz, and is said to deliver up to twice the CPU performance against the competition (Intel/AMD/Apple) or provides the same level of performance at a third of the power consumption. The SoC will also be able to run on-device generative AI with over 13B parameters thanks to 75 TOPS of AI performance and support the latest wireless connectivity technologies such as 5G and WiFi 7 through external chips from the company. Qualcomm Snapdragon X Elite specifications: CPU – 12-core 64-bit Armv8 Oryon processor clocked at […]

September 22, 2023September 22, 2023 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Amazon Fire TV Stick 4K Max (2023) features a 2 GHz MediaTek MT8696T CPU, support WiFi 6E

Amazon has recently introduced its second-generation Fire TV Stick 4K and Fire TV Stick 4K Max 2023 powered by MediaTek MT8696D and MT8696T Arm Cortex-A55 processors respectively and going for $49.99 and $59.99 on Amazon. The new Fire TV Stick 4K Max model is an incremental update compared to the Fire TV Stick 4K Max (2021) with basically the same processor but clocked slightly higher, twice the storage capacity, and WiFi 6E support instead of just WiFi 6. The Fire TV Stick 4K (2023) is a more notable update compared to the very first Fire TV Stick 4K launched in 2018. Amazon Fire TV Stick 4K / 4K Max (codenames: AFTKM and AFTKRT) specifications: SoC Fire TV Stick 4K (2023) – MediaTek MT8696D with quad-core Arm Cortex-A55 processor @ 1.7 GHz, Imagination GE9215 GPU @ 650MHz Fire TV Stick 4K Max (2023) – MediaTek MT8696T with quad-core Arm Cortex-A55 processor […]

September 18, 2023September 18, 2023 by Jean-Luc Aufranc (CNXSoft) - 20 Comments

Amlogic S905X5 Armv9 TV Box SoC supports AV1, H.266, Ai-SR

The Amlogic S905X5 may be first the Armv9 processor designed for set-top boxes (STB) and TV boxes, supports the latest AV1 and H.266 video codecs, and also comes with a 4 TOPS AI accelerator. We don’t have the full details yet, and the news comes from a tease from SEI Robotics which is about to unveil an Amlogic S905X5 AI-SR (AI Super Resolution) Android TV box at IBC 2023. Preliminary specifications for S905X5 SoC and SEI Robotics TV box: SoC – Amlogic S905X5 CPU – Quad-core Armv9 CPU (likely Cortex-A510 cores) delivering 40K+ DMIPS GPU – Arm Mali-G310 V5 entry-level GPU clocked at 1 GHz for 4K HDR user interfaces VPU – Up to 2x 4Kp60 10-bit H.266/VCC and AV1 video codecs, and the usual VP9, AVS3, H.265/HEVC, H.264 AI accelerator – 4 TOPS NPU enabling AI-SR Process – “Second generation” 6 nm process System Memory & Storage – TBD […]
