e-con Systems Introduces a 360° Camera Kit for NVIDIA Jetson TX1/TX2 Development Boards

e-con Systems has previously launched MIPI cameras for Jetson TX1/TX2 development kit, but the company has now announced e-CAM30_HEXCUTX2, a kit with an adapter board, and six synchronized HD cameras connected that can be used for video surveillance, or robots requiring a 360° or “720°” field of view. The kit is comprised of the following elements: e-CAMHEX_TX2ADAP adapter board for connecting six cameras through Jetson boards’s J22 connector supporting up to 6x 2-lane MIPI CSI-2 cameras 6x 3.4MP MIPI CSI2 low light camera board with interchangeable S-mount lens, and featuring ON Semiconductor AR0330 color CMOS image sensor; each camera supports VGA to 1080p/3M resolution up to 30 fps 6x 30cm custom micro coaxial cable The kit operates at 5V, and requites between 5.33 to 8.10 watts, the later while streaming 6 Cameras on Jetson TX2. Software support is implemented through a Linux camera driver (V4L2) on top of NVIDIA’s JetPack […]

Embedded Linux Conference & Open Source Summit Europe 2017 Schedule

The Embedded Linux Conference & IoT summit 2017 took place in the US earlier this year in February, but there will soon be a similar event with the Embedded Linux Conference *& Open Source Summit Europe 2017 to take up in Europe on October 23 – 25 in Prague, Czech Republic, and the Linux Foundation has just published the schedule. It’s always useful to find out what is being discussed during such events, even if you are not going to attend, so I went through the different sessions, and compose my own virtual schedule with some of the ones I find the most interesting. Monday, October 23 11:15 – 11:55 – An Introduction to SPI-NOR Subsystem – Vignesh Raghavendra, Texas Instruments India Modern day embedded systems have dedicated SPI controllers to support NOR flashes. They have many hardware level features to increase the ease and efficiency of accessing SPI NOR […]

VIA Mobile360 ADAS System Includes a 4G Connected Rugged Computer, a 7″ Display and 4 to 6 Cameras

VIA Mobile360 ADAS (Advanced Driver Assistance System) System is a road safety-enhancing solution that supports Lane Departure Warning, Forward Collision Warning, Blind Spot Detection, Pedestrian Detection, Vehicle Detection and Classification for special vehicles, motorcycles, and bicycles, Speed Limit Detection, and Rear-end Collision Avoidance. The system is comprised of “Mobile360 System” rugged computer, 4 to 6 cameras, and an optional 7″ display. Mobile360 System computer specifications: SoC – Unnamed Octa-core big.LITTLE processor with four ARM Cortex-A17 cores @ 1.8GHz, and four Cortex A7 cores @ 1.4GHz (Likely Zhaxin ZX-5880 SoC also including Elite 2000 GPU supporting OpenGL ES 3.1, OpenVG 1.1 and OpenCL EP 1.1) System Memory – 2GB Mobile LPDDR3 1600MHz RAM (Package-on-Package with SoC) Storage – 1x 512GB Transcend 2.5″ MLC SSD (-40°C-90°C); 16GB eMMC Flash memory; 1x Micro SD card slot; 1x full size SD card slot Connectivity – Gigabit Ethernet, 1x 4G LTE module, 1x Wi-Fi 802.11b/g/n […]

Meizu Pro 7 is a Dual Camera Dual Display Android Smartphone

Smartphones with dual rear cameras are becoming more common, and we’ve see some smartphones in the past with an extra rear display such as Yotaphone 2. Meizu Pro 7 and Pro 7 Plus smartphones combines both features, but instead of using an E-Ink or other e-Paper display for the secondary display, Meizu used an 1.9″ AMOLED display that automatically turns on when you flip the phone, and can be used to check the time or notifications while the main display is still off. Meizu Pro 7 / Pro 7 Plus partial specifications: SoC – Mediatek Helio X30 deca-core processor with 2x cortex A73 cores @ up to 2.6 GHz, 4x cortex A53 cores @ up to 2.2 GHz, and 4x cortex A35 cores @ up to 2.0 GHz, as well as Imagination PowerVR 7XT GPU System Memory Pro 7 – 4GB LPDDR4x Pro 7 Plus – 6GB LPDDR4x Storage Pro […]

USB type C to HDMI Cables Coming Soon thanks to HDMI Alt Mode for USB Type-C

Some devices already support video output over a USB type C connector, but they normally rely on DisplayPort over USB type C, so you’d either need a monitor that supports DisplayPort, or some USB Type C to HDMI converter. A DisplayLink dock is another solution, but again it converts video and audio signals. But soon you’ll be able to use a simple USB type C to HDMI cable between a capable device (camera, phone, computer, TV box…) and any HDMI TV or monitor. This is being made possible thanks to HDMI Alt Mode for USB Type-C  that supports all HDMI 1.4b features including: Resolutions up to 4K (@ 30 Hz) Surround sound Audio Return Channel (ARC) 3D (4K and HD) HDMI Ethernet Channel (HEC) Consumer Electronic Control (CEC) Deep Color, x.v.Color, and content types High Bandwidth Digital Content Protection (HDCP 1.4 and HDCP 2.2) There’s no video or audio conversion inside […]

GR-LYCHEE Development Board to Combine Renesas RZ/A1LU Processor, ESP32 Module, and a VGA Camera

Japanese semiconductor vendors have mostly stayed away from the maker market, at least outside Japan, as most people would be hard-pressed to come up with a hobbyist development board powered by processor or micro-controller from Toshiba, Sony, Renesas or other Japanese companies, despite the three aforementioned names being in the top 20 semiconductors companies. I can only remember having written about Fujitsu F-Cue 96Boards, as well as Renesas GR-PEACH mbed board since I started this blog 7 years ago. Renesas seems to be the only company to have a real community behind with their “Gadget Renesas” pink-colored development boards, and the latest and seventh board is GR-LYCHEE powered by Renesas RZ/A1LU ARM Cortex-A9  processor, and equipped with a WiFi & Bluetooth module, and a camera. Renesas GR-LYCHEE board preliminary specifications: Micro-processor – Renesas RZ / A1LU (R7S721030VCFP 176-pin QFP) ARM Cortex-A9 Processor  @ 384 MHz with 3MB on-chip SRAM Storage […]

HD3S Android-on-TV Box with HD Webcam is Powered by Amlogic S905X Processor

What I call “Android-on-TV” boxes are some sort of TV boxes, usually with a webcam, that are meant to be placed on top of the TV instead of on the furniture, and apart from being used to watch videos like other TV boxes, are also well-suited for videoconference over Skype or Google Hangout. Over the years. we’ve had a few of those products such as  HD23 TV box, but recently I don’t recall having seen new Android-on-TV boxes. That’s until today, and I found out about HD3S TV box running Android 6.0 on Amlogic S905X processor. HD3S specifications: SoC –  Amlogic S905X quad core ARM Cortex-A53 @ up to 1.5GHz with a penta-core Mali-450MP GPU System Memory – 1GB DDR3 Storage – 8GB eMMC flash + micro SD card slot up to 64GB Video Output – HDMI 2.0a up to 4K @ 60 Hz, and AV port (composite video) Audio […]

RAK WisCam is a $20 Arduino Compatible WiFi Camera Linux Board Powered by Nuvoton N32905 ARM9 Processor

A couple of weeks ago I wrote about Rakwireless’ RAK CREATOR Pro development board based on Realtek Ameba RTL8711AM Wireless MCU, and part of their Wiskey family of development boards. Sub-family include WisNode for IoT boards, WisAP for OpenWrt boards, WisPLC for PLC hardware, and WisCam for WiFi video camera boards. The company has recently introduced Wiscam RAK5281 Arduino compatible Linux board powered by a Nuvoton ARM9 MCU, and supporting a camera module or an SD card + USB module. RAK WisCam specifications: SoC –  Nuvoton N32905R3DN ARM926EJ processor @ 200 MHz with 8KB internal SRAM, 16KB IBR internal booting ROM, 16Mbit  x16  DDR2 memory Storage – 128 MBit SPI flash, included sub-module adds micro SD card Connectivity – 802.11 b/g/n WiFi via Realtek RTL8189FTV module Camera via sub-module 648×488 pixel VGA CMOS Image Sensor (GC0308); 102° FOV Video –  QVGA (320×240) 30FPS, VGA(640×480) 30FPS, MJPEG encoding Photo – JPEG, […]
