Ascella USB 3.0 Camera Reference Design Kit Supports 4K Recording at 30 fps

Cypress Semiconductor and THine Electronics have recently introduced Ascella USB 3.0 camera reference design kit based on Cypress EZ-USB CX3 USB 3.0 camera controller and THIne THP7312 ISP that supports 13-megapixel resolution at 21 frames per second, and 3840x2160p recording at 30 fps using MJPEG compression. The kit is composed of 5 boards with an OV13850 13MP camera board, an LED board, the ISP board, Cypress CX3 board, and a debug board with USB 3.0 and a debug interfaces. Main specifications and features:   Cypress EZ-USB CX3 ARM9 based Programmable MIPI CSI-2 to USB 3.0 Camera Controller THine THP7312 image signal processor based on a 32-bit RISC CPU OmniVision OV13850 Image sensor interfaced through a four-lane MIPI CSI-2 interface High Intensity LED Board for Low light environment SPI Flash for firmware storage Supports auto-focus, auto-exposure, auto-white-balance and the ability to select from 20 picture resolutions Support for streaming of live […]

Meet the First Affordable 360 Degrees Cameras: Gyroptic 360Cam and IC Realtech ALLIe

Last year, I discovered one company developing and selling 360 degrees video recording solutions, and you could then watch the videos using a VR Kit like vrAse, Google Cardboard, or Oculus Rift. It was all cool, but  involved a camera mount for 6 GoPro cameras with a total cost well over $2,000. This year, GoPro also unveiled their own camera array for 16 GoPro cameras, again very cool, but even less affordable to the masses. But thanks to two CES 2015 videos recently uploaded to, I found out about two interesting sub $500 cameras that can record 360 degrees videos at 1080p, which can then be optionally uploaded to YouTube 360˚,  and watched with a VR Kit, using a tablet, or on a touchscreen enabled video sphere. Gyroptic 360 Camera The cool looking 360 degrees camera comes with 3 lenses, a Nike+ Fuelband like display, WiFi or Ethernet connectivity […]

WRTnode2P, WRTnode2R and WRTnodeHi OpenWRT Boards to Feature M.2 & mini PCIe Edge Connectors, H.265 Camera Support, and More

WRTnode is a small and low cost development board powered by Mediatek MT7620N and running OpenWRT. The developers have been working on three new OpenWRT boards based on Mediatek or Hisilicon processor and featuring either an M.2 connector, a mini PCIe connector, or support for H.265 camera. The first board is WRTnode2P with the following specifications: SoC – Mediatek MT7628an MIPS 24KEc processor @ 575 MHz System Memory – 256 MB RAM Storage – 32MB Flash Connectivity – 802.11 b/g/n WiFi @ 300 Mbps (2T2R) I/Os via NGFF M.2 connector: PCIe X1, USB 2.0 host, SD-XC 5x 100M Ethernet switch I2S up to 192K/24-bit 2x UART, SPI, I2C 20x GPIO Dimensions – 42 x 22mm The second board, WRTNode2R, features a processor and a micro-controller, and can be connected to a mini PCIe port: SoC – Mediatek MT7688an MIPS24K Processor @ 580 MHz System Memory – 256 MB DDR2 Storage […]

Grain Media 8136S / 8138S are Low Cost HD IP Camera SoCs

A few times, my readers told me they really like comments on this blog, and they liked to check recent comments on the left sidebar, and some even subscribed to the Comments RSS Feed, although it might quite busy at times, especially during giveaways. Recently, an interesting conversation started in the comments section about low cost IP camera chips by Grain Media 8136S and 8138S SoCs respectively supporting 720p and 1080p video recording, and cheap enough to make a sub-$10 IP camera board (BoM cost). Beside the maximum resolution supported, GM8136S and GM8138S are mostly similar except the later also supports Gigabit Ethernet against Fast Ethernet for the lower end version, different clock speeds, and some other (minor?) differences. There’s also GM8135S with 512 Mbit RAM (SiP) against 1Gbit RAM (SiP) for GM8136S, and GM8138 including a DDR controller for external memory, while GM8138S including 1Gbit RAM (SiP). Grain Media […]

e-con Systems 13MP MIPI CSI-2 Camera Designed for Nvidia Jetson TK1 Board

e-con Systems has just introduced e-CAM130_CUTK1, a 13 MP MIPI CSI-2 camera board specifically designed for Nvidia Jetson TK1 development board powered by Nvidia Tegra K1 quad core Cortex A15 processor supporting up to Ultra HD (3840×2160) resolution @ 22 fps, or 1080p @ 30+ fps with MJPEG or YUV422 output. e-CAM130_CUTK1 camera board is comprised of a camera module and an adapter board that can be directly plug into Jetson TK1 board. Camera board key features and specifications: Camera Module e-CAM130_CUMI1820_MOD with S-mount lens holder based on Aptina AR1820HS sensor. Max S/N ratio: – 36.3 dB;  Dynamic Range: – 65.8 dB Interface – 4-lane MIPI CSI-2 interface Resolution / Frame rate – VGA @ 90 fps, 720p @ 60 fps, 1080p @ 30 fps, UltraHD (3840×2160) @ 22 fps, 13MP (4224×3156) @ 14 fps. Values are the same for MJPEG or YUV422. Connector – 125-pin connector for Jetson TK1 […]

Flex Cam PIC is both a Sports & Action Camera and a Selfie Stick (Crowdfunding)

Sports camera are quite popular these days, and so are selfie sticks for better or worse… So a Korean team had a simple-yet-clever idea to combine both into a flexible camera that can be used as a selfie stick, and an action camera that does not require any accessories. You just need bend and roll the “stick” around an object. It’s cute too. Meet Flex Cam PIC. Preliminary technical specifications of the camera: SoC – Unknown Storage – 16GB NAND flash Camera – 720p30, CCD sensor, 124″ wide angle, 5MP Connectivity – Bluetooth USB – micro? USB OTG port Misc – LED for battery level, button Battery – 300 mAh (Good for about 1 hour) IP Rating – IP7 (Water and splash proof). Certified for 30 minutes use under 1 meter of water The specifications are not overwhelming, but it still looks like a fun product. It’s also unclear whether […]

Ambarella Unveils SL2m IP Camera Reference Design Promising up to 6 Months of Battery Life

Ambarella S2Lm IP Camera SoC features a Cortex A9 CPU core, encodes video with H.264 up to 3Mp30 / 1080p30, and targets  consumer and entry-level IP Camera designs. The company recently launched a new battery-powered IP camera reference design based on the solution that promises up to 6 months battery life, and can record Full HD video in less than 500ms from wake up, making ideal for battery operated security cameras. A Linux SDK is also provided with reference implementations for low-power standby operation, wake-on-Wi-Fi and fast boot to Linux. Unfortunately, that’s about all we know about the reference design, so instead I’ll have a look at the processor, and SL2m IP camera evaluation board. Ambarella SL2m SoC specifications: CPU – ARM Cortex-A9 processor with 32KB/32KB I/D and 128 KB L2 Cache, NEON and FPU, Crypto Engine – AES/3/DES/SHA-1/MD5 DSP / VPU –  Ambarella Image and Video DSPs Sensor and […]

AtHome Video Streamer App Transforms Android TV Boxes into IP Security Cameras

Some Android mini PCs come with cameras, for example Measy U2C or CS928, but depending on firmware support, most will also take a USB webcam, and the obvious application is for video conferencing with Skype or Google Hangout. But I’ve just found out an app called “AtHome Video Streamer” can transform any Android device with camera support into as IP camera for security or monitoring. The app will show with the name AVS, and it should detect your camera automatically, and show a live feed. I installed the app in Zidoo X9 TV box to which I connected a UVC USB camera in order to monitor… my chameleon plush / pillow. X9 camera support might need to be improved, as I lost access to the webcam a few times. You don’t have many options in AVS app, except Dimming the screen, and change the streamer name, username and/or password. So […]
