InfoTM C23 Processor is Designed for Camera Applications Including 360 Degrees Video Cameras

InfoTM (aka InfoTMIC) is a Shanghai based fabless silicon vendor established in 2008, and while I wrote about their iMAPx15 tablet processor a few years ago, you’d be forgotten if you’ve never heard about the company. One of their latest solution is InfoTM C23 processor designed for camera applications ranging from sports camera to car DVR and 360° / 720° cameras. InfoTM 23 specifications: CPU – 32-bit processor up to 600MHz Memory – Integrated 1Gb (128 MB) DRAM; supports 32-bit DDR2 / DDR3 / LPDDR2 533MHz Storage – SPI NOR Flash support “GPU”/ISP – ISP engine supporting up to 5MP sensors, 3D noise reduction, EIS, fish eyes, face recognition and other functions Video Processor – Full HD 1080p 30fps H.264 hardware decoding; 1080p 30fps H.264 hardware encoding Camera interfaces – ITU 601/656 & MIPI CSI Display Interface  – RGB888 / I80 display interface Audio – I2S / PCM input and […]

$99 Insta360 Air 360 Degrees Video Camera Works with your Android Smartphone and Laptop (Crowdfunding)

Insta360 Nano is a dual camera designed to take 360 degrees videos selling for $190 and up on Amazon US, but it only works on iPhone 6 & 7 series, so the company has designed a new model – Insta360 Air – specifically to work on Android phones with a micro USB or USB-C port, and packaged in a spherical shapes in order to be compatible with most, if not all, brands and models. It also works with laptops thanks to a rigid yet flexible USB cable. Insta360 Air specifications: 210° dual fish-eye lens; minimum Aperture F2.4 Photo Capture Resolution – 3008 x 1504 (3K) Video Capture  – 2560 x 1280 @ 30 fps (some smartphone models also support 3008×1504 @ 30 fps, e.g. Samsung S7, S7 edge, and Huawei P9) Connector – USB micro/Type-C Dimensions – 37.6mm Diameter Weight 26.5g The camera can be used with Insta360 Air app […]

Xiaomi WiFi IP Cameras Hacked to Run RTSP Server, Disable Cloud Service

Xiaomi 720p and 1080p IP cameras include night vision, motion detection, WiFi connectivity, and can save videos locally, and send them to a cloud server in China for you to check your camera from anywhere. The 720p camera sells for about $50, while the 1080p camera goes for around $30 on GearBest and other websites, but comes with less IR LEDs and no optical zoom. [Update: The black version of the 720p camera goes for $29.99 on Amazon US] They works fine, but you need a specific mobile app to configure and control the camera, and if you’d rather not have the videos streamed to some server outside of your local network, github user “Fritz” has developed a set of scripts for the camera to disable cloud service, run a standard RTSP server, as well as HTTP and FTP servers on the camera. He did his work on Yi Ants […]

Rockchip RV1108 Visual Processor is Designed for 1080p & 2K Camera Applications

Rockchip has joined other companies in developing camera SoCs with their RV1108 Visual Platform based on a single Cortex A7 core, a CEVA XM4 visual processing DSP, and capable of H.264 video encoding up to 1440p30 / 1080p60. Rockchip RV1108 main features and specifications: CPU – ARM Cortex A7 @ up to 1.0 GHz DSP – embedded CEVA XM4 vision processor up to 600MHz Video Encoder – 2K/H.264, high definition & low bit rate Camera – MIPI CSI and DVP interfaces Image processing – Low-light-level night vision imaging: 8MP professional image processing unit Audio Processing – Audio Codec supporting up to 8-way MIC array, 3A? phonetic algorithms, such as echo cancellation, noise suppression; Video Out/Input – HDMI OUT, CVBS OUT, MIPI DSI, CVBS IN Networking – 10/100 Ethernet PHY The processor is expected to be used in drones, IP cameras, car dashcams, sports/action cameras, as well as other applications such […]

Tiny Intrinsyc Open-Q 820 SoM Features Snapdragon 820 Processor, WiFi and Bluetooth

Intrinsyc has unveiled a new smaller version of their Snapdragon 820 based Open-Q 820 system-on-module, simply called Open-Q 820 µSOM bringing the module size from 82 x 42mm to 50 x 25mm, while keeping many of the features of the large SoM with 3GB LPDDR4, 32GB UFS 2.0 flash, 802.11ac WiFi, and Bluetooth 4.1. It competes with other small Snapdragon 820 modules such as Inforce 6601 micro SoM. Open-Q 820 µSOM specifications: SoC – Qualcomm Snapdragon 820 quad core Kryo cores with 2x cores @ up to 2.2GHz, and 2x cores @ up to 1.6GHz, Adreno 530 GPU,  Hexagon 680 DSP System Memory – 3 GB LPDDR4 @ 1866 MHz Storage – 32 GB UFS 2.0 1-lane gear3 flash Connectivity – 802.11 b/g/n/ac 2×2 MU-MIMO, Bluetooth 4.1, Qualcomm IZat Gen 8C GPS 3x board-to-board connectors with the following interfaces: Display 2x MIPI-DSI 4-lane, 60fps, up to 2560×1600 (single port), 4096×2160 (dual port) […]

$55 OpenMV Cam M7 Open Source Computer Vision Board is Powered by an STM32F7 Cortex-M7 MCU

I wrote about Jevois-A33 computer vision camera based on Allwinner A33 quad core Cortex A7 processor last week, and today, I’ve come across OpenMV Cam M7 open source computer vision board based on a much less powerful STMicro STM32F7 ARM Cortex M7 micro-controller, but with the advantage of consuming less power, and exposing some extra I/Os. OpenMV Cam M7 board specifications & features: MCU – STMicro STM32F765VI ARM Cortex M7 @ up to 216 MHz with 512KB RAM, 2 MB flash. External Storage – micro SD slot Camera Omnivision OV7725 image sensor supporting 640×480 8-bit grayscale images or 320×240 16-bit RGB565 images at 30 FPS 2.8mm lens on a standard M12 lens mount USB – 1x micro USB port (Virtual COM Port and a USB Flash Drive) Expansion – 2x 8-pin headers with SPI, I2C CAN bus, asynchronous serial bus (Tx/Rx), 12-bit ADC, 12-bit DAC, 3x I/Os for servo control; interrupts and PWM on […]

Allwinner V3s Dual Camera SoC Comes with 64MB DRAM

Most SoCs have a very limited amount of internal SDRAM just enough to load the bootROM code, but a few integrated a few MB of RAM on-chip such as Renesas RZ/A1H with 10MB on-chip DRAM, in order to reduce costs for some applications that may not require external RAM. Allwinner V3s, designed for dual camera solutions, appeared to be such an SoC with 64MB (512Mbit) on-chip DDR2 RAM, but the block diagram seems to imply it is a System-in-Package (SiP) instead. Nevertheless you still get a single chip with an ARM Cortex A7 processor, two ISPs, a video engine, 64MB RAM, and more. Allwinner V3s main features & specifications: CPU – ARM Cortex-A7 @ up to 1.2 GHz Memory – Integrated 64MB DDR2 DRAM Storage I/F – SD 2.0, eMMC 4.41, SPI NAND flash, SPI NOR flash Audio Codec – 92dB audio codec supporting 2x ADC channels and 2x DAC […]

JeVois-A33 is a Small Quad Core Linux Camera Designed for Computer Vision Applications (Crowdfunding)

JeVois Neuromorphic Embedded Vision Toolkit – developed at iLab at the University of Southern California – is an open source software framework to capture and process images through a machine vision algorithm, primarily designed to run on embedded camera hardware, but also supporting Linux board such as the Raspberry Pi. A compact Allwinner A33 has now been design to run the software and use on robotics and other projects requiring a lightweight and/or battery powered camera with computer vision capabilities. JeVois-A33 camera: SoC – Allwinner A33  quad core ARM Cortex A7 processor @ 1.35GHz with  VFPv4 and NEON, and a dual core Mali-400 GPU supporting OpenGL-ES 2.0. System Memory – 256MB DDR3 SDRAM Storage – micro SD slot for firmware and data 1.3MP camera capable of video capture at SXGA (1280 x 1024) up to 15 fps (frames/second) VGA (640 x 480) up to 30 fps CIF (352 x 288) […]
