ASUS PRIME N100I-D D4 – An Intel Processor N100 mini-ITX motherboard

ASUS PRIME N100I D D4

ASUS PRIME N100I-D D4 is a fanless mini-ITX motherboard based on the Intel Processor N100 quad-core “Alder Lake-N” processor with up to 16GB DDR4, M.2 NVME SSD and SATA storage, and three video outputs via HDMI, DisplayPort, and VGA ports. The motherboard also comes with a Gigabit Ethernet port, six USB 3.2/2.0 ports, a COM port, and a 3.5mm audio jacks combo with Line In, Line Out, and Microphone input, plus a PS/2 connector, and a 24-pin ATX connector for power. ASUS PRIME N100I-D D4 preliminary specifications: SoC – Intel Processor N100 quad-core Efficient “Alder Lake-N” processor clocked at up to 3.4 GHz with 24EU Intel UHD graphics up to 750 MHz System Memory – Up to 16B DDR4-3200 memory via DDR4 SO-DIMM slot Storage 1x M.2 2280 socket (PCIe Gen3 x2) for NVMe SSD 1x SATA3 6.0 Gb/s connector Video Output 1x HDMI 2.1 up to 4Kp60 resolution, HDCP […]

NVIDIA Jetson AGX Orin Industrial offers ECC memory, extended temperature range, improved robustness

NVIDIA Jetson AGX Orin Industrial

NVIDIA has recently introduced the Jetson AGX Orin Industrial module that comes with an extended temperature range, operating lifetime, shock and vibration specifications, as well as support for error correction code (ECC) memory, and delivers up to 248 TOPS of AI performance with power configurable between 15-75 W. The industrial-grade system-on-module is based on the Jetson AGX Orin 64GB module but with lower operating frequencies to enable a longer operating lifetime and improved endurance. It’s form-factor and pin-compatible with Jetson AGX Orin, and NVIDIA says it delivers more than eight times the AI performance of the 30 TOPS Jetson AGX Xavier Industrial introduced in 2021, but does not integrate Cortex-R5F cores. NVIDIA Jetson AGX Orin Industrial specifications: CPU – 12-core Arm Cortex-A78AE v8.2 64-bit processor @ 2.0 GHz with 2MB L2 + 4MB L3 cache GPU / AI accelerators NVIDIA Ampere architecture with 2,048 NVIDIA CUDA cores and 64 Tensor […]

Realtek WiFi 7 and WiFi 6 roadmap for routers and clients

Realtek Testbed WiFi 7

We’ve just written about Realtek 5 Gbps Ethernet chips, but the company also has some roadmaps for WiFi 6 and WiFi 7 router chips, and a WiFi 7 client module demonstrated at COMPUTEX 2023. The company’s roadmap include five WiFi 7 router solutions: WiFi 7 BE6500 router with a Realtek 8198DS dual Arm core processor @ 1.2 GHz with an RTL8952AR 2×2 MIMO 5 GHz and 6 GHz chip, RTL8902A 2×2 2.4 GHz chip, and an RTL8221B 2.5GbE PHY WiFi 7 BE9400 router with a Realtek 8198DS dual Arm core processor @ 1.2 GHz with an RTL8952AR 2×2 MIMO 5 GHz chip, RTL8902A 2×2 2.4 GHz chip, an RTL8934AR 4×4 MIMO 6 GHz chip, and an RTL8221B 2.5GbE PHY WiFi 7 BE3400 router with a Realtek 8198DS dual Arm core processor @ 1.2 GHz with an RTL8952AR 2×2 MIMO 5 GHz chip, and an RTL8221B 2.5GbE PHY WiFi 7 BE6400 […]

Realtek RTL8126, RTL8157, and RTL8251B 5Gbps Ethernet solutions showcased at COMPUTEX 2023

RTL8126 5GbE PCie Card prototype

I only upgraded my local network to 2.5 Gbps Ethernet last year, but 5 Gbps Ethernet is soon coming to the home as shown by Realtek at COMPUTEX 2023 with demonstrations of their RTL816, RTL8157, and RTL8251B 5GbE chips that were initially unveiled at CES 2022. The RTL8126-CG is a PCIe 3.0 x1 to 5GbE controller offered in a QFN56 8x8mm package that succeeds the RTL8125 chips, the RTL8157-CG is a USB 3.2 Gen2 to 5Gbps Ethernet controller in a 8x8mm QFN68 package providing an update the RTL8156(B)/(BG) 2.5GbE USB controllers, and the RTL8251B-CG is a single-port “PHYceiver” in a 8x8mm QFM56 package. All support 10/10/100/2500/5000 Mbps links and consumes under 1.5 watts, against 0.7W for 2.5 GbE networking. The same Cat5e cables can be used at the higher speed. The company did not just come with some slides to show and also showcased some test boards for each chip […]

eEver EJ523D chip enables 4Kp60 video capture or streaming over USB 3.2

eEver EJ523D 4Kp60 HDMI USB video capture

eEver Technology, a subsidiary of eTron Technology, has launched the EJ523D 4Kp60 audio and video capture and streaming processor with a USB 3.2 interface, along with a reference platform currently showcased at COMPUTEX 2023. Over the last few years, we’ve covered some low-cost HDMI to USB 2.0 dongles that capture video up to 1080p30, followed by HDMI to USB 3.0 dongles handling up to 4Kp30, but the latest eEver EJ523D chip will be found in USB 3.2 adapters to capture at up to 4Kp60 resolution with H.265 encoding or 4Kp30 in the NV12 format. Some highlights of the EJ523D: Video capture resolution and frame rate 4K@ 30 fps or 2K @ 120 fps with NV12 4K @ 60 fps with H.265 10-bit HDR/H.264 encoding MJPEG encoding is also supported up to 4K @ 60 fps Integrated scaler – Full range up & down De-interlacing – De-interlace i to p mode […]

ECS RK3568-IS 3.5-inch SBC with Rockchip RK3568 SoC showcased at COMPUTEX 2023

ECS RK3568 SBC

ECS is better known for its LIVA mini PCs and x86 motherboards, but ECSIPC unveiled a 3.5-inch SBC powered by Rockchip RK3568 Arm SoC at Embedded World 2023. However, when I asked for photos or detailed specifications at the time, I was told by a company representative no further details were available. But we now have more information as the company is showcasing the RK3568-IS 3.5-inch SBC at COMPUTEX 2023, and I received some photos from their booth. ECS RK3568-IS specifications: SoC – Rockchip RK3568 quad-core Arm Cortex-A55 @ up to 2.0 GHz with ARM Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2. OpenCL 2.0. Vulkan 1.1, 0.8 TOPS NPU System Memory – 2GB, 4GB, or 8GB DDR3 or LPDDR4X Storage 8GB or 32GB eMMC flash M.2 socket for 2280 NVMe SSD MicroSD card slot Display HDMI 2.0 output eDP 1.3 LVDS or MIPI DSI interface I2C capacitive touch […]

USB4 docking station supports up to five 4K displays with 120 Hz refresh rate

USB4 Penta-4K120 Docking Station

Action Star Technology, a Taiwanese OEM/ODM of USB productivity solutions part of Qisda (BenQ group), has unveiled its USB4 penta-4K120 docking station at Computex 2023 with support for up to five 4K displays at a refresh rate of up to 120 Hz. The docking station is based on Synaptics chips, and besides support for up to five 4K displays, it can also handle up to three 8K displays at 60+ Hz, and offers Ethernet, audio, and 10 Gbps USB 3.2 interfaces. USB4 Penta-4K120 docking station specifications: USB4 docking station backward compatible with USB-C/USB 3.x Based on Synaptics VMM9430 DisplayPort 2.1 (DP 2.1) multi-stream transport (MST) hub and DisplayLink DL-7400 universal display docking solution. See the separate (January 2023) press release about the chips Display Support up to 5x 4K/120Hz video outputs 1x native DisplayPort up to 8K/85Hz using DSC (8K/75Hz for HDR) 4x DisplayLink outputs up to quad 4K/120Hz or […]

Zotac PI430AJ Pico mini PC features Airjet solid-state active cooling chips

ZOTAC Airjet mini PC

ZOTAC PI430AJ Pico is the first mini PC equipped with (two) Airjet solid-state active cooling chips introduced at CES 2023, doing without the metal case required by typical fanless systems, and instead relying on a plastic case. The PI430AJ Pico is powered by a recent 7W Intel Core i3-N300 octa-core Alder Lake-N processor coupled with up to 16GB LPDDR5 RAM and an M.2 NVMe SSD up to 1TB capacity. The mini PC is showcased at COMPUTEX 2023 with a transparent cover to showcase the two FRORE Systems Airjet mini PC, but it will eventually be sold with a black plastic enclosure. ZOTAC PI430AJ Pico preliminary specifications: SoC – Intel Core i3-N300 octa-core processor up to 3.8 GHz with 6MB cache, 32EU Intel UHD Graphics Gen 12 @ 1.25 GHz; TDP: 7W System Memory – Up to 16GB LPDDR5 Storage – Up to 1TB M.2 NVMe SSD, microSD card slot Video […]
