M5Stack has recently launched the M5Stack ATOMIC Display Base, an HDMI display driver designed to emulate traditional SPI TFT-LCD data output using Gowin GW1NR-9C FPGA and a built-in LT8618SX RGB-to-HDMI chip and designed to work with the company’s Atom IoT controller family based on ESP32 wireless microcontrollers. The module supports up to 720p (1280×720) image output with a 24-bit color depth and has an average frame rate of 12–16 FPS. Additionally, it can be paired with ATOM series hosts for various memory and application needs. These features make this compact device suitable for industrial control displays, smart home information screens, educational and conference presentations, and remote monitoring displays. The only downside of this device is that it requires a display with adaptive resolution scaling to avoid compatibility issues. M5Stack ATOMIC Display Base (HDMI display driver) specifications FPGA – Gowin GW1NR-9C (PDF datasheet) FPGA with 8,640 LUTs used to simulate SPI TFT-LCD data […]
Jetway MF30 – A 3.5-inch SBC with 13th Gen Intel Core i5-1335U/1335UE Raptor Lake SoC, quad display support
The Jetway MF30 is a 3.5-inch subcompact board powered by 13th-generation Intel Core Raptor Lake-P U-series processors, including the Intel Core i5-1335U and Core i5-1335UE. Designed for embedded applications such as digital signage, control systems, gaming setups, and transportation hubs, the board supports versatile high-definition multi-screen configurations with two HDMI ports, two DisplayPorts, one Type-C DP, and one LVDS/eDP interface. For connectivity, the MF30 offers dual 2.5GbE ports, three USB 3.2 Gen2 ports, four USB 2.0 ports, and a USB Type-C port, while storage options include SATA III port and M.2 (2242/2280) sockets. Jetway is well known for its SBCs, and we’ve previously covered products like the JMTX-ADN8, JNUC-ADN1 mini-ITX motherboard, and JF35-ADN1 3.5-inch motherboard all powered by the Intel N97 CPU. Additionally, we’ve explored other SBCs and Mini PCs featuring 13th-gen Raptor Lake SoCs, including the iBASE IB961, GEEKOM GT13 Pro, Cincoze DV-1100, and LattePanda Sigma. If you’re interested […]
Rikomagic RKM MK42 Intel N100 mini PC targets business applications such as digital signage
Rikomagic RKM MK42 is yet another Intel Processor N100 mini PC but geared towards business applications such as digital signage, retail kiosks, or IoT gateway rather than home use. The mini PC ships with 12GB RAM and a 512GB SSD, and offers dual GbE, WiFi 6 and Bluetooth 5.2, dual 4K display setups through HDMI and DP++ ports, and five USB ports for expansion. Rikomaigc RKM MK42 specifications: SoC – Intel Processor N100 quad-core Alder Lake-N processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel HD graphics @ up to 750 MHz; TDP: 6W System Memory – 12GB RAM Storage – 512GB SSD Video Output HDMI 2.0 port up to 4Kp60 DisplayPort++ connector up to 4Kp60 Up to 2x independent 4K displays Audio – 3.5mm audio jack, digital audio output via HDMI and DP++ Networking 2x Gigabit Ethernet RJ45 ports Wi-Fi 6 and Bluetooth 5.2 USB – […]
14-Inch 4K ultra-wide touch display is optimized for Raspberry Pi and LattePanda boards, features USB Type-C and HDMI interfaces
DFRobot’s 14-inch ultra-wide IPS display offers narrow bezels, 4K (3840 x 1100) resolution, 10-point capacitive touch, and is designed for mounting single board computers such as LattePanda Sigma and Raspberry Pi 5. It can also be connected to other computers with dual USB Type-C and mini HDMI video input interfaces. With a unique 3.5:1 bar-shaped aspect ratio, this display can present information in an intuitive format for countertop advertising screens, measurement equipment, and smart terminals. DFRobot’s “14-inch 4K IPS bar touch display” specifications Display 14-inch ultra-wide, narrow bezel IPS bar touch display with 4K (3840×1100) resolution Ten-point capacitive touch support, offering precise input Aspect ratio – 3.5:1 Pixel – 0.08964(H) × 0.08964(V) mm Viewable area – 344.2(H)×98.6(V) mm with 170° viewing angle and ≥6H surface hardness Color Gamut – 72% Brightness – 300 cd/m2 Contrast Ratio – 1200:1 Refresh rate – 60Hz Transmittance – Greater than equals to 86% Driver […]
Portwell WEBS-21J0-ASL – A rugged embedded system with Intel Atom x7000RE Nano-ITX motherboard and Hailo-8 AI accelerator
Portwell’s WEBS-21J0-ASL is a fanless, rugged embedded system with a Nano-ITX motherboard powered by an Intel Atom x7000RE Series processor and optimized for industrial IoT applications. It features two 2.5Gbps Ethernet ports, dual 4K display support (DP/HDMI), and a serial port as well as M.2 E and B Key sockets for wireless and storage expansion. Designed for harsh environments, the WEBS-21J0-ASL operates in temperatures ranging from -20°C to 60°C. The system is equipped with DDR4 SO-DIMM memory (up to 16GB and 10Gbps USB 3.2 Gen 2 ports. It has passed vibration and shock tests for durability in rugged applications making it suitable for a wide range of industrial and automation systems. The WEBS-21J0-ASL also supports optional integration with the Hailo-8 AI acceleration module delivering up to 26 TOPS of AI performance for applications requiring advanced AI capabilities. This makes it an ideal solution for robotics, medical equipment, outdoor gateways, and […]
Intel Processor N50 or N97 touch Panel PCs feature 7-inch or 10-inch TFT color display
AAEON ACP-2106 and ACP-2076 are two fanless touch panel PCs powered by an Intel N50 or N97 Alder Lake-N processor with respectively 10-inch (1280 x 800) and 7-inch (1024×600) color TFT LCD displays with capacitive multi-touch support. Both models share the same key specifications with support for up to 32GB DDR5 SO-DIMM memory and a mPCIe socket for storage. They feature an HDMI 1.4 for dual display configuration for kiosks or other similar applications, two 2.5GbE ports, M.2 sockets for WiFi and 4G LTE/5G cellular connectivity, and more. AAEON ACP-2106 and ACP-2076 specifications: Alder Lake-N SoC (one or the other) Intel Processor N50 dual-core processor up to 3.4 GHz with 6MB cache, 16EU Intel UHD Graphics; TDP: 6W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics; TDP: 12W Note: Turbo Mode is disabled by default. If enabling it, please ensure the system […]
ASUS Tinker Board 3 – A credit-card sized Rockchip RK3566 SBC with 12V to 19V DC input
ASUS Tinker Board 3 is a credit card-sized SBC based on Rockchip RK3566 SoC with an HDMI port, a 3.5mm audio jack, gigabit Ethernet, an M.2 socket for WiFi and Bluetooth, four USB ports, and a 40-pin GPIO header with a layout similar to the Raspberry Pi 3 Model B. When I first wrote about the Tinker Board 3 in 2023, it was a larger (100 x 100 mm) SBC based on Rockchip RK3568 SoC that was later renamed to Tinker Board 3N, now also available as a complete rugged system (more about that in a subsequent post). The new Tinker Board 3 (2024) is a completely different design that competes against Radxa ROCK 3C and Orange Pi 3B boards also based on RK3566 and offered in a business card/credit card form factor similar to the Raspberry Pi 3B. Tinker Board 3 specifications: SoC – Rockchip RK3566 CPU – Quad-core […]
MSI MS-CF13 is a fanless mini-ITX motherboard powered by Intel N97, Core i3-N305, or Atom x7425E Alder Lake-N SoC
MSI MS-CF13 is a low-profile, low-power, fanless mini-ITX motherboard offered with a choice of Alder Lake-N processors namely Intel Processor N97, Intel Core i3-N305, or Intel Atom x7425E SoC. The motherboard supports up to 16GB DDR5 SO-DIMM memory and SATA III storage, features dual 2.5GbE, six internal COM ports, six USB interfaces, M.2 Key-B and Key-E sockets for wireless expansion, and supports up to three independent display through up to two DisplayPort, one HDMI, LVDS/eDP display interfaces, MSI MS-CF13 specifications: Alder Lake N-series SoC (one or the other) Intel Atom x7425E quad-core processor up to 3.4 GHz with 6MB cache, 24EU Intel UHD Graphics @ 1.00 GHz; TDP: 12W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics @ 1.20 GHz; TDP: 12W Intel Core i3-N305 octa-core processor up to 3.8 GHz with 6MB cache, 32EU Intel UHD Graphics @ 1.25 GHz; TDP: […]
