Posted on by Jean-Luc Aufranc (CNXSoft) - 7 Comments on SIM7020E 4G NB-IoT Mini Development Board Sells for Just $14

SIM7020E 4G NB-IoT Mini Development Board Sells for Just $14

Cheap-NB-IoT-Board

We now have plenty to choose from when it comes to NB-IoT development boards or shields, but so far pricing has not been very attractive, and the cheapest NB-IoT solution I found so far was probably Dragino NB-IoT Bee, a XBee compatible board going for $23. But this morning, I saw an even cheaper NB-IoT board with SIM7020E 4G NB-IOT Mini development board selling for $14.30 on Electrodragon. Not quite the price of 2G solutions, but we’re getting there. Board specifications: NB-IoT Module – SIMCom SIM7020E module working globally with B1/B3/B5/B8/B20/B28 bands supported Nano SIM card holder and u.FL connector for NB-IoT Expansion – 9-pin unpopulated 2.54mm pitch header with 2x UART (3.3V / 5V), ADC, Boot, 3.3V, 5V and GND USB – 1x micro USB port that can be recognized by PC, but as Electrodragon puts it: “not sure how to use it”. Misc – Net LED, power key […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on $6.10 Loraduino Board Combines LoRa and Atmega328P MCU

$6.10 Loraduino Board Combines LoRa and Atmega328P MCU

We’ve previoulsy seen low costs SX1278 LoRa modules @ 433 MHz  which you could connect to your own board, but Electrodragon is now selling Loraduino board with an Atmega328P MCU and SX1278 for just $6.10 / 5 Euros plus shipping, and using a layout similar to Arduino Pro Mini. Loraduino specifications: MCU – Microchip / Atmel Atmega328P MCU with Arduino pro mini bootloader Storage – 16Mbit SPI flash for data LoRa Semtech SX1278 IC with 433mhz, or 470mhz central frequency 10 km max range 20dbm max power rate (configurable by software) Tx current: 120 mA @ + 20 dBm; 90mA @ + 17dBm;  29mA @ + 13dBm Data Rate –  1.2K to 300Kbps with FSK;  18 bps to 37.5Kbps with LoRa Expansion SX1278 Lora: leadout for pins IO1, IO2, IO3 Atmega: 14x digital input/output pins (including 6x PWM outputs), 6x analog inputs (TBC) Misc – Programmable LED (D7),  power LED, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on Electrodragon WiFi IoT Relay Includes ESP8266 Module, AC Power, and Enclosure for $6

Electrodragon WiFi IoT Relay Includes ESP8266 Module, AC Power, and Enclosure for $6

Thanks to ESP8266, the cost of WiFi relays has dramatically come down, but so far, I could not find an all-in-one solution with ESP8266, relay, AC power and enclosure, and for example I’m still using NodeMCU board, a relay board, a USB power supply, and put all that into a plastic jar in order to control a water pump. It works but it’s not ideal, and solutions like Wemos D1 mini with relay shield improves things further, but Electrodragon has come with a connect-and-play WiFi IoT relay that integrates everything including the case for $6 + shipping. Wifi IoT Relay Board Based on ESP8266: WiFi module – ESP-12F based on Espressif ESP8266EX WiSoC Relays – 2x Songle SRD-05VDC-SL-C relays supporting 125VAC/10A, 250VAC/10A, 30VDC/10A, 28VDC/10A Input/Output – 3x terminal blocks for relay and power Expansion – 12-pin header with Rx/Tx,  GPIO4, Btn2, GPIO15, 5V/GND,  ADC, GPIO5, Btn1, OUTPUT1, and 3V3 Debugging […]
