Firefly-RK3399 Development Board Will Fly with Rockchip RK3399 Hexa-core Processor

ARM Cortex A72 class development boards are usually quite expensive, and cheaper boards like Mediatek X20 development board ($200) appears to be out of stock very often, and software support is limited to Android 6.0. But things look to improve soon, as T-Chip is about to release Firefly-RK3399 development board powered by Rockchip RK3399 hexa-core Cortex A72/A53 processor. Firefly-RK3399 (preliminary) specifications: SoC – Rockchip RK3399 hexa-core bit.LITTLE processor with dual core Cortex A72 up to 2.0 GHz and quad core Cortex A53 processor with ARM Mali-T860MP4 GPU with OpenGL 1.1 to 3.0 support, OpenVG 1.1, OpenCL and DX 11. System Memory – 2 to 4 GB DDR3 Storage – 16 to 32 GB eMMC flash + micro SD card Video Output & Display Interfaces – HDMI 2.0 up to 4K @ 60 Hz, eDP 1.2 interface, YUV interface, 1x MIPI DSI interface Video Decode – 4K VP9 and 10-bit H.265 […]

Multiple Videos Encoding and Decoding in Android on Firefly-RK3288 Development Board

Some applications like digital signage and video surveillance may require simultaneous video playback, and encoding to send over the network. ARM platforms may not be powerful enough to achieve those tasks with the processor only, but luckily many ARM SoCs include powerful video processing unit (VPU) capable of doing both hardware video encoding and decoding, leaving the CPU cores mostly free for other tasks. Firefly team has demoed such capabilities on their Firefly-RK3288 development board by displaying 7 videos on a single screen, including two previews from two USB cameras attached to the board, which are then encoded and decoded on the fly and displayed on the screen. The last three videos are played from 3 different files. So that means that 5 video decode and 2 video encode are running simultaneously.  The board can achieve 26 to 30fps with 720p videos, and around 13 to 15 fps with 1080p […]

Fireduino Arduino Compatible Board Features Rockchip RKnanoD Dual Core Cortex-M3 MCU (Crowdfunding)

Rockchip RKNanoD dual core Cortex M3 micro-controller was introduced last year for IoT and audio applications, and the Firefly team, known for their FirePrime or Firefly-RK3288 development boards, has designed an Arduino compatible board based on the MCU with lots of audio ports, Arduino headers, and WiFi connectivity. Fireduino specifications: MCU – Rockchip RKnanoD dual core ARM Cortex M3 MCU @ up to 250 MHz (system core) / 500 MHz (calculate core) with respectively 640 KB and 384 KB RAM Storage – 4 or 8MB SPI flash + micro SD slot Audio 24-bit/192 KHz audio codec (built in MCU) with HW accelerator for APE, FLAC, OGG, and MP3 audio decoding 1x 3.5mm analog audio jack 2x 3.5mm LINE In jacks 1x On-board microphone DLNA wireless audio support Connectivity – 802.11 b/g/n WiFi via Ampak AP6181 module Expansion Arduino header with I2C, SPI, ADC, GPIO, PWM, UART LCD interface (Intel 8080 […]

Firefly-RK3288 Reload Board Features a SoM + Baseboard Design, Supports SATA, Three HDMI Ports, and More

Firefly-RK3288 was one the first boards powered by Rockchip RK3288 quad core Cortex A17 processor, and now Firefly team, part of T-Chip technology, has provided a new version called Firefly-RK3288 Reload with the same processor, but more features, and thanks to design comprised of a carrier board and system-on-module (SoM) – connected via an MXM connector – suitable to people or companies wanting to create their own board without handing the complexity of the processor, memory, and storage part. The table below shows Firefly-RK3288 and Firefly RK3288 Reload specifications side-by side. Parameter Firefly-RK3288 (Plus) Firefly-RK3288 Reload SoC Rockchip RK3288 ARM Cortex-A17 quad core processor up to 1.8GHz with ARM Mali-T760 MP4 GPU RAM 2GB Dual-Channel DDR3 (Plus version is 4GB) 2GB Dual-Channel DDR3 Storage 16GB eMMC (Plus version is 32GB) MicroSD (TF) Card Slot 16GB eMMC MicroSD (TF) Card Slot SATA 2.0 (Suggest 2.5 inch SSD or HDD) PMU ACT8846 […]

Android 5.1 SDK Release for Rockchip RK3128 Based FirePrime Board

T-Firefly has just announced the release of Android 5.1 SDK for their newly announced Fireprime development board powered by Rockchip RK3128 quad core Cortex A7 processor. You can get the SDK (fireprime_android5.1_git_20150612.tar), a 6.1GB download with full source code for the board via Baidu or Google Drive, and then upgrade it to the latest version with git pull on the company’s bitbucket account as explained in the Wiki. The SDK must be specific to Fireprime board, but it should be feasible to use to create / modify Android 5.1 firmware for other RK3128 products. If you don’t need the source code, but would just like to install the firmware for Android 5.1, and the other image recently released (Ubuntu 15.04 Desktop or Server, or Android 5.1/Ubuntu 15.04 dual boot image)  via the links provided in the announcement. Thanks to Nanik for the tip. Jean-Luc Aufranc (CNXSoft)Jean-Luc started CNX Software in […]

Firefly introduces FireBLE Bluetooth Low Energy Board

So just as today I wrote about XBAND BLE Sensor board, the makers of Firefly-RK3288 also announced their own Bluetooth Low Energy board aptly named FireBLE, and also integrating a 6-axis gyroscope and accelerometer, but instead of being based on Nordic or Cypress, the company went with an NXP BLE chip. FireBLE board specifications: SoC – NXP QN9021 ARM Cortex M0 MCU @ 32MHz with 94KB ROM (protocol stack), 64 KB SRAM, 128KB flash Bluetooth – BT 4.0 single mode. Central and peripheral mode with up to 8 simultaneous connections. Sensors MPU-6050 3-axis gyroscope and 3-axis accelerometer with an on-board Digital Motion Processor (DMP) capable of processing 9-axis motion fusion algorithms. Battery and temperature sensor USB – micro USB port for power and programming Expansion – 3 expansion headers with access to SPI, UART, I2C, GPIO, and PWM, as well as OLED display interface. Debugging – JTAG, support SWD online […]

ARM Releases Kernel Drivers for Mali-T880 / T860 GPUs, User Space Drivers for Mali-T76x GPUs

ARM Mali GPU drivers includes both open source kernel drivers, and binary userspace drivers supporting framebuffer and/ior X11 implementation. The former is rarely an issue and is quickly released, but the latter requires porting and testing for a specific hardware platform, as well legal work, which greatly delay the releases. Mali-T880 GPU was announced at the beginning of the month together with ARM Cortex A72, and on February 17, 2015, ARM released an update to their Mali-T600 series, Mali-T700 series & Mali-T860/T880 GPU kernel device drivers with revision r5p1-00rel0 that adds supports to Mali-T860 and Mali-T880 GPU. These open source drivers are available for Android and Linux, and also support early Mali-T700 and T600 GPUs. Separately, the company has also released Mali-T76X GPU drivers for Firefly board powered by Rockchip RK3288 quad core Cortex A17 processor featuring a Mali-T764 GPU. The first release only supports the framebuffer driver, but ARM […]

Linux 3D GPU Acceleration Demo on Rockchip RK3288 based Firefly Board

Several devices and development boards based on Rockchip RK3288 processor already support Linux, usually with images based on Ubuntu, including Ugoos UM3 / UT3, Open Hour Chameleon, and Firefly-RK3288 among others. What these images lack however, is support for 2D and 3D graphics acceleration with the GPU, and hardware video decoding/encoding with the VPU. But Jas-hacks has made some progress with 3D graphics support. He has managed to add GPU acceleration via EGL/OpenGL ES bringing 3D acceleration to the platform, but 2D support is not there yet, meaning X11 still heavily relies on software rendering. But the implementation is still good enough to run the usual es2gears and glmark2-es2 benchmarks. as well as some WebGL demos in Chromium. Performance is currently underwhelming, with 50 points in glmark-es2, even a bit lower than the score (54 points) I got with ODROID-X board powered by Exynos 4412 SoC with a Mali-400MP4 GPU, […]
