NanoPi S2 Quad Core ARM Linux Board Comes with WiFi & BT Connectivity, HDMI, LVDS, and LCD Interfaces

FriendlyARM has released a bunch of Allwinner based NanoPi Allwinner boards recently, but they also have some Samsung/Nexcell S5P ARM Cortex A9 boards in their portfolio, and the latest is NanoPi S2 with Samsung S5P4418 quad core processor, three display interfaces, a camera interface, wireless connectivity through WiFi and Bluetooth 4.0, a 40-pin “Raspberry Pi” header, and more. NanoPi S2 specifications: SoC – Samsung/Nexcell S5P4418 quad core Cortex A9 processor @ 400 MHz to 1.4 GHz with Mali-400MP GPU System Memory – 1 GB DDR3 Storage – 8GB eMMC flash  + micro SD slot Video Output / Display I/F – micro HDMI port up to 1080p60, 24-pin LCD RGB interface, 24-pin LVDS interface Audio – 3.5mm audio jack, micro HDMI Camera – 24-pin DVP camera interface Connectivity – 802.11 b/g/n WiFi + Bluetooth 4.0 classic & LE (AP6212 module); IPEX/u.FL antenna connector USB – 1x USB 2.0 Host, 1x micro […]

FriendlyARM Introduces NanoPi NEO AIR Board with WiFi & BLE, Camera Interface and 8GB Storage for $17.99

FriendlyARM launched NanoPi NEO board with Allwinner H3 processor, Ethernet, and USB ports for $7.99 to $9.99 in July, and the company is back with a new board with the same form factor and processor, by trading Ethernet for WiFi, dropping one USB 2.0 port for a DVP camera interface, and adding an 8GB eMMC flash. NanoPi NEO AIR specifications: SoC – Allwinner H3 quad core Cortex A7 @ 1.2 GHz with an ARM Mali-400MP2 GPU up to 600 MHz System Memory – 512 MB DDR3 Storage – 8GB eMMC Flash (Samsung) + micro SD card slot Connectivity – WiFi 802.11 b/g/n and Bluetooth 4.0 LE (via Ampak AP6212 module) with IPEX antenna connector USB – 1x micro USB OTG port, 2x USB via headers Camera – 1x DVP camera interface with optional 5MP CAM500B camera Expansion headers 24-pin header with I2C, 2x UART, SPI, PWM, and power signals 12-pin […]

Smaller & Faster than Raspberry Pi Zero: Meet NanoPi NEO ARM Linux Development Board

Raspberry Pi Zero has two noticeable attributes compared to other Raspberry Pi boards: it’s smaller and it’s cheaper. FriendlyARM has now designed another model for their NanoPi family, that about 12% smaller, although not quite as thin at all due to its Ethernet jack and USB connector, and much faster than Raspberry Pi Zero, with NanoPi NEO board powered by Allwinner H3 quad core processor. NanoPi NEO specifications: SoC – Allwinner H3 quad core Cortex A7 @ 1.2 GHz with an ARM Mali-400MP2 GPU up to 600 MHz System Memory – 256 or 512 MB DDR3 Storage – micro SD card slot Connectivity – 10/100M Ethernet USB – 1x USB 2.0 host ports, 1x micro USB OTG port, 2x USB via headers Expansion headers 24-pin header with I2C, 2x UART, SPI, PWM, and power signals 12-pin header with 2x USB, IR pin, microphone and Line OUT signals Debugging – 4-pin […]

$35 NanoPi M3 Octa Core 64-bit ARM Development Board is Powered by Samsung S5P6818 Processor

A few weeks after introducing NanoPC-T3 single board computer based on Samsung S5P6818 octa-core Cortex A53 processor, FriendlyARM is now launching a cost-down version called NanoPi M3 for just $35 with 1GB RAM, and booting from a micro SD card. NanoPi M3 board specifications: SoC – Samsung S5P6818 octa core Cortex A53 processor @ up to 1.4GHz with Mali-400MP GPU System Memory – 1 GB 32-bit DDR3 Storage – 1x micro SD card slot Connectivity – Gigabit Ethernet (RTL8211E), 802.11 b/g/n WiFi and Bluetooth LE 4.0 (Ampak AP6212) with on-board chip antenna and IPX antenna connector Video Output / Display I/F – HDMI 1.4a up to 1080p60, LVDS, parallel RGB LCD Audio I/O – HDMI, 3.5mm audio jack, 7-pin I2S header Camera – 1x DVP interface USB – 2x USB 2.0 type A host ports; 1x micro USB 2.0 client port; 2x USB 2.0 host ports via 8-pin header Expansions […]

NanoPC-T3 Octa-core Cortex A53 Single Board Computer Sells for $60

FriendlyARM launched NanoPC-T2 single board computer based on Samsung 5P4418 quad core Cortex A9 processor about 3 months ago, and the company has now an update based on Samsung S5P6818 Octa-Core A53 processor with the exact same interfaces and features including Gigabit Ethernet, WiFI, and Bluetooth, HDMI 1.4a, 30-pin expansion headers, etc… NanoPC-T3 specifications: SoC – Samsung S5P6818 octa core Cortex A53 processor @ up to 1.4GHz with Mali-400MP GPU System Memory – 1 or 2GB 32bit DDR3 RAM Storage – 8GB eMMC flash, and 1x SD card slot Connectivity – Gigabit Ethernet (RTL8211E), 802.11 b/g/n WiFi and Bluetooth LE 4.0 (Ampak AP6212) with on-board chip antenna and IPX antenna connector Video Output / Display I/F- 1x HDMI 1.4a, LVDS, MIPI DSI, parallel RGB LCD Audio I/O – HDMI, 3.5mm audio jack, on-board microphone Camera – 1x DVP interface, 1x MIPI CSI interface USB – 2x USB 2.0 type A host […]

Chromium OS for SBC Aims to Turn Popular Development Boards into Chromeboxes

A team of developer has come together last December in order to provide Chromium OS, the open source project which Chrome OS is based on, to single board computers such as Raspberry Pi boards. So far, they’ve provided Chromium OS images for Raspberry Pi 2 & 3, but more boards should be supported in the future. The latest version 0.5 release is said to be usable, but WiFi, Netflix, and HTML5 video are not working. The installation procedure is standard. You simply need to download and uncompress the archive (e.g. SamKinison_v0.5_Pi3_16GB.tar.xz), and dump it on a micro SD card with Win32DiskImage or dd. They have released different images for Raspberry Pi 2 & 3, and different SD card sizes (2GB and 16GB). Chromium OS is using 12 partitions, so that may be why they don’t provide a single image and resize the file system during the first time. You can […]

NanoPi M1 Allwinner H3 Development Board with HDMI, CVBS, Ethernet and 3 USB Ports Sells for $11 (Sort of)

FriendlyARM has been very busy since the beginning of the year, as they’ve already released NanoPi 2 Fire, NanoPC-T2, and NanoPi-M2 boards, all based on Samsung S5P4418 processor so far in 2016. But they’ve not stopped, as the company has now launched NanoPi M1 board powered by Allwinner H3 processor with a similar form factor as NanoPi-M2, similar features as Orange Pi One, except they added two extra USB ports, an AV port with composite video and stereo audio, an on-board microphone, and an IR receiver. NanoPi-M2 board specifications (highlights show improvements or differences over Orange Pi One): SoC – Allwinner H3 quad core Cortex A7 @ 1.2 GHz with an ARM Mali-400MP2 GPU up to 600 MHz System Memory – 512 MB DDR3 (1GB as option) Storage – micro SD card slot Video & Audio Output – HDMI and 3.5mm jack for CVBS (composite + stereo audio) Connectivity -10/100M […]

$30 NanoPi-M2 Board Packs Raspberry Pi 2 Hardware Features in a Smaller Form Factor

FriendlyARM had already launched two NanoPi boards powered by Samsung S5P4418 quad core processor, namely NanoPi 2 and NanoPi2 Fire, that were especially interesting due to their small size (75 x 40 mm) for the features including HDMI output, a camera interface, and either WiFi + Bluetooth or Ethernet. The company is now back with a third larger board, but still compact, removing the wireless module, but adding an audio jack and more USB ports, while keeping the price about the same. Meet NanoPi-M2: SoC – Samsung S5P4418 quad core Cortex A9 processor @ 400 MHz to  1.4GHz with Mali GPU including two pixel processors, and a geometry processor. System Memory – 1GB 32-bit DDR3 Storage – 1x Micro SD Slot Connectivity – Gigabit Ethernet RJ45 port (via RTL8211E) Video Output / Display I/F- 1x HDMI 1.4a, 0.5 mm pitch SMT FPC seat for type-A full-color LCD (RGB: 8-8-8) with […]
