Posted on by Sayantan Nandy - No Comments on Raytac AN7002Q – A smaller nRF7002 Wi-Fi 6 module for industrial IoT applications

Raytac AN7002Q – A smaller nRF7002 Wi-Fi 6 module for industrial IoT applications

AN7002Q-P module

IoT solutions company Raytac has introduced the AN7002Q Wi-Fi 6 module series, which integrates Nordic Semiconductor’s nRF7002 chipset and is designed for Industrial IoT, smart home, healthcare, consumer electronics, and automotive applications. They can be paired with Raytac’s MDBT53 Bluetooth LE modules based on the nRF5340 multiprotocol SoC, supporting Wi-Fi and Bluetooth LE solutions. The AN7002Q is a low-power Wi-Fi 6 module supporting dual-band 2.4 GHz and 5 GHz operation with a maximum PHY data rate of 86 Mbps (MCS7). It is compatible with IEEE 802.11ax, a/b/g/n/ac standards, and connects to a host SoC or MCU via SPI or QSPI interfaces. The module also supports coexistence with Bluetooth LE, Thread, and Zigbee systems, making it ideal for IoT applications. Previously, we covered the Abluetech PTR7002, a low-power wireless module based on the Nordic Semiconductor nRF7002. The PTR7002 has a slightly larger size and offers more GPIO options, while the AN7002Q […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Abluetech PTR7002 WiFi 6 and PTR5302 WiFi 6 and BLE 5.4 modules feature Nordic Semi nRF7002/nRF5340 wireless chips

Abluetech PTR7002 WiFi 6 and PTR5302 WiFi 6 and BLE 5.4 modules feature Nordic Semi nRF7002/nRF5340 wireless chips

PTR5302 nRF7002 nRF5340 WiFi 6 BLE module

Shenzhen-based Abluetech has launched two low-power wireless modules based on Nordic Semi nRF7002 and nRF5340 wireless chips. The PTR7002 is a dual-band WiFi 6 module based on the nRF7002 chip, and the PTR5302 module combines the nRF7002 with the nRF5340 wireless microcontroller to offer dual-band WiFi 6 and Bluetooth LE 5.4 connectivity Abluetech PTR7002 dual-band WiFi 6 module with nRF7002 PTR7002 specifications: Chipset – Nordic Semi nRF7002 Wireless Dual-band Wi-Fi 6 Tx power  – Up to +21dBm Rx sensitivity –  -96.5dBm @ 2.4GHz / -90.5dBm @ 5GHz PHY bandwidth – Up to 86 Mbps (MCS7) 1SISO; 20MHz bandwidth Modes – Station, Wi-Fi Direct, Soft AP (Wi-Fi 4 operation only), simultaneous Station +Soft AP/Wi-Fi Direct/Station modes. 2.4GHz and 5GHz dual-band PCB antenna Range – Up to 300 meters Host interface – SPI / QSPI; AT command set Supply Voltage – 2.9 to 4.5V Power Consumption (@ 3.6V TBC) Tx peak current […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on ardEEG shield works with Arduino UNO R4 WiFi for biosignals measurement

ardEEG shield works with Arduino UNO R4 WiFi for biosignals measurement

ardEEG Shield Arduino UNO R4

PiEEG has launched the ardEEG shield specially designed for the Arduino UNO R4 WiFi and capable of measuring biosignals such as those used in electroencephalography (EEG), electromyography (EMG), and electrocardiography (ECG). PiEEG, led by Ildar Rakhmatulin, Research Associate at Heriot-Watt University in Edinburgh, launched the PiEEG shield for Raspberry Pi to enable brain-computer interfaces last year, and now the company has been working on the equivalent design for Arduino with the ardEEG shield equipped with eight channel taking input from wet or dry electrodes. ardEEG shield key features and specifications ADC – Texas Instruments ADS1299 Analog-to-Digital Converter for biopotential measurements Supported board – Arduino UNO R4 WiFi 8 channels for connecting wet or dry electrodes (Electrodes are positioned according to the International 10-20 system) Host interface – Arduino headers with SPI used for data transfer with a frequency from 250 SPS to 16 kSPS and a resolution of 24 bits […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on UP Squared Pro 710H Edge mini PC combines Processor N97 or Core i3-N305 CPU with 26 TOPS Hailo-8 AI accelerator

UP Squared Pro 710H Edge mini PC combines Processor N97 or Core i3-N305 CPU with 26 TOPS Hailo-8 AI accelerator

UP Squared Pro 710H Edge mini PC

AAEON UP Squared Pro 710H Edge is a mini PC with an onboard Hailo-8 edge 26 TOPS AI accelerator and an Intel Processor N97 or Core i3-N305 Alder Lake-N CPU designed for edge AI applications. The fanless Edge AI mini PC comes up to 16GB LPDDR5 soldered-on RAM, up to 128GB eMMC flash, and offers dual 4K video output through HDMI and DisplayPort connector, dual 2.5GbE, optional WiFi and cellular connectivity, two USB 3.2 ports, an RS232/RS422/RS485 COM port, a 40-pin female GPIO header, and a wide 12 to 36V DC input. UP Squared Pro 710H Edge specifications: Alder Lake N-series SoC (one or the other) Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics Gen 12 @ 1.2 GHz; TDP: 12W Intel Core i3-N305 octa-core processor up to 3.8 GHz with 6MB cache, 32EU Intel UHD Graphics Gen 12 @ 1.25 GHz; […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Firefly Core-3562JQ Rockchip RK3562J industrial SoM works in the -40 to +85°C temperature range

Firefly Core-3562JQ Rockchip RK3562J industrial SoM works in the -40 to +85°C temperature range

Rockchip RK3562 system-on-module

Firefly Core-3562JQ is a system-on-module based on Rockchip RK3562J SoC – the industrial-grade version of the Rockchip RK3562 quad-core Cortex-A53 Tablet SoC – designed to operate in the -40 to 85°C industrial temperature range and suitable for digital signage, industrial control systems, industrial PLCs, energy data concentrators, smart healthcare, self-service terminals, and more. The CPU module features up to 8GB RAM, 64GB flash, and a Rockchip RK809-5A PMIC, plus three 80-pin board-to-board connectors exposing video output and input interfaces, audio (SPDIF, PDM, I2S) interfaces, networking (GbE and Fast Ethernet), various USB interface, a 1-lane PCIe 2.1 interface, and more. Firefly Core-3562JQ specifications: SoC – Rockchip RK3562J CPU – Quad-core Arm Cortex-A53 processor @ up to 1.2 GHz (against 2.0 GHz for the Rockchip RK3562) GPU – Arm Mali-G52 EE with support for OpenGL ES 3.2, Vulkan 1.1, OpenCL 2.0 AI accelerator – None listed in the specs (Rockchip RK3562 comes […]

Posted on by Debashis Das - No Comments on Quectel FGH100M Wi-Fi HaLow module based on Morse Micro MM6108 receives CE and FCC Certifications

Quectel FGH100M Wi-Fi HaLow module based on Morse Micro MM6108 receives CE and FCC Certifications

Quectel and Morse Micro's FGH100M Wi Fi HaLow Module

In a collaboration, Quectel Wireless Solutions and Morse Micro have developed the FGH100M a Wi-Fi HaLow module, powered by Morse Micro’s MM6108 SoC. This module has achieved CE certification in Europe and FCC approval in the US, meeting high safety and environmental standards. After reading through the press release, I initially thought the 802.11.ah WiFi, known as WiFi HaLow, would be similar to other LPWAN standards like LoRaWAN or Sigfox. However, further research showed that Wi-Fi HaLow, operating in the 900 MHz band, was first announced in 2014 and got its name in 2016. However, in the following years, there wasn’t much interest in this wireless standard. But starting from 2021, it’s becoming more popular, and we’ve seen many HaLow-based products like a mini PCIe card, a WiFi HaLow development board, and a gateway kit to extend the range of IP cameras, and also ALFA Network’s AHPI7292S Raspberry Pi HAT […]

Posted on by Tomisin Olujinmi - No Comments on Renesas releases the DA14592, a new dual-core Cortex-M33/M0+ BLE chip with integrated flash

Renesas releases the DA14592, a new dual-core Cortex-M33/M0+ BLE chip with integrated flash

DA14592 chip block diagram

The DA14592 System-on-Chip (Soc) is Renesas’ “lowest power consumption and smallest, multi-core Bluetooth LE device.” According to the company, this chip’s design was achieved by making careful tradeoffs between on-chip memory and die size. The chip offers an ultra-low power mode that uses only 2.3mA when transmitting radio signals at 0dBm and consumes 1.2mA to receive radio signals. It also supports a hibernation mode that uses about 90nA and can extend the operating life of battery-powered products. The active mode is best for processing-intensive products and uses 34µA for every MHz of CPU clock. Projected key applications for the DA14592 chip include crowd-sourced location (CSL) tracking as used in Apple’s Airtags, remote control units, human interface devices, asset tracking, IoT end nodes, data logging, connected health, and activity tracking. Renesas DA14592 specifications: CPU cores: Cortex-M33F running at up to 64MHz as application core Cortex-M0+ at 64MHz as configurable MAC Memory: […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on u-blox MAYA-W3 industrial wireless module supports WiFi 6/6E and Bluetooth 5.4 with LE Audio

u-blox MAYA-W3 industrial wireless module supports WiFi 6/6E and Bluetooth 5.4 with LE Audio

u-blox MAYA-W3

We’ve also covered two IoT-focused WiFi 6 and Bluetooth LE chips in the last week with Synaptics SYN43711 chipset and Gigadevice GD32VW553 RISC-V WiSoC, but there’s more and u-blox has recently introduced the MAYA-W3 WiFi 6/6E and Bluetooth 5.4 module with LE Audio support and designed for industrial applications. The MAYA-W3 module offers some flexibility as it’s designed on the upcoming Infineon AIROC CYW5551x WiFi 6E and Bluetooth 5.4 chip family supporting 2.4 GHz only (CYW55511), 2.4 GHz and 5 GHz (CYW55512), and a 2.4 GHz, 5 GHz, and 6 GHz with the tri-band CYW55512 chipset. u-blox also provides three antenna options for each model with two U.FL connectors, two antenna pin connectors, or an embedded PCB antenna. u-Blox MAYA-W3 specifications: Chipset – Infineon AIROC CYW5551x CYW55511 for 2.4 GHz WiFi 6 CYW55512 for 2.4 and 5 GHz WiFi 6 CYW55513 for 2.4, 5, and 6 GHz WiFi 6E Wireless […]
