7-inch Raspberry Pi CM4-based industrial HMI offers gigabit Ethernet, RS485 Modbus, digital and analog inputs

NORVI RPI-HMI Industrial Controller

NORVI RPI-HMI is an industrial controller with a 7-inch touchscreen screen display powered by a Raspberry Pi CM4 and equipped with a range of interfaces including a gigabit Ethernet RJ45 port, a few USB ports, and several terminal blocks for RS485 (Modbus), digital and analog input, transistor outputs, and 24V DC power input. The new Raspberry Pi CM4-based HMI announcement follows the NORVI ESP32-HMI controller that was launched last December with an ESP32-S3 wireless microcontroller and a 5-inch LCD display with resistive touch. The NORVI RPI-HMI builds on that with a much faster Arm processor, a larger display with a capacitive touchscreen, gigabit Ethernet, and a wider range of I/Os that makes it suitable for various industrial HMI and PLC applications. NORVI RPI-HMI Industrial Controller specifications: SoM – Raspberry Pi CM4 SoC – Broadcom BCM2711 quad-core Cortex-A72 processor with VideoCore GPU System Memory – 1GB, 2GB, 4GB or 8GB LPDDR4-3200 […]

600 MHz STM32H7R/S Cortex-M7 MCUs feature 620KB SRAM, 64KB boot flash, optional NeoChrom GPU


STMicro has launched the high-performance 600 MHz STM32H7R/S Arm Cortex-M7 microcontrollers: the STM32H7R3/S3 General-purpose MCU lines, and STM32H7R7/S7 graphics MCU lines adding a NeoChrom 2.5D GPU. Both ship with a large 620KB SRAM and a small 64KB boot flash. The reason for the small boot flash is to have the application code and data stored off-chip memory ICs to provide more flexibility to customers when it comes to the choice of memory type and capacity to fulfill the application requirements and lower the BoM cost. The “S” in the STM32H7S microcontrollers stands for Security with a crypto/hash engine that can help the final product achieve SESIP Level 3 and/or PSA Certified Level 3 certifications. Many of the specifications are similar to the STM32H7 microcontrollers, but performance is better going slightly faster than the 550MHz STM32H7 MCUs added in 2020, and the STM32H7R/S adds some new features: 200 MHz Hexadeca SPI […]

HPMicro HPM6800 600 MHz RISC-V MCU comes with a Vivante 2.5D GPU with OpenVG support


HPMicro HPM6800 is a family of high-end RISC-V microcontrollers clocked up to 600 MHz integrating a VeriSilicon Vivante 2.5D GPU with support for the OpenVG 1.1 vector graphics API, and peripherals making it suitable for digital dashboard displays and human-machine interfaces (HMI). The family is comprised of three parts: the HPM6830 without video support, the HPM6850 with 2D graphics and video input/outputs, and the HPM6880 adding support for the 2.5D OpenVG GPU from VeriSilicon.  All variants come with 1064KB SRAM, support for external DDR2/DDR3/DDR3 memory, NOR, PSRAM and eMMC flash, audio interfaces, and a range of peripherals with eight CAN FD interfaces, gigabit Ethernet, USB high-speed, and many more. HPMicro HPM6800 specifications: CPU – Single core 32-bit RISC-V (RV32-IMAFDCP) processor @ 600MHz with 32KB I/D Cache (3390 CoreMark) Memory 1064 KB SRAM with 256KB ILM + 256KB DLM in the RISC-V core, 512KB AXI SRAM, 32KB AHB SRAM, and 8KB […]

Avnet MSC C10M-ALN – A COM Express Type 10 Mini Module with Intel Alder Lake-N CPU, LPDDR5 memory

MSC C10M ALN COM Express Type 10 Module

Avnet MSC C10M-ALN is a COM Express Type 10 module powered by the Alder Lake-N family of processors including the Intel Core i3, Intel Atom x7000E, and Intel Processor N-Series. The design allows for easy adaptation of applications between various Intel CPU models, ensuring compatibility across different performance and power needs. The module supports up to 16GB LPDDR5 memory with optional In-Band Error Correcting Code(IBECC), eMMC 5.1 storage, and features an Intel i226 2.5GbE controller. It can handle up to two 4K displays through DDI and eDP video outputs, ten USB ports including USB 3.2 Gen 2, and four PCI Express Gen 3 x1 slots for expanded connectivity options. Avnet MSC C10M-ALN Com Express Module Specification: Alder Lake-N SoC (one or the other) Intel Core i3-N305, eight-core, 1.0GHz/1.8GHz, 32EU Intel UHD Graphics, 9/15W, PUC (PC Client Use Conditions) Intel Atom x7425E, four-core, 1.5GHz, 24EU Intel UHD Graphics, TCC, 12W, EUC […]

Nuvoton MA35H0 is a cost-optimized dual Cortex-A35 MPU for industrial HMI applications

Nuvoton MA35H0 develoment board

Nuvoton MA35H0 is a 650 MHz dual-core Cortex-A35 MPU designed for industrial HMI applications with up to 1280×800 resolution that offers a cost-down alternative to the 800 MHz Nuvoton MA35D1 microprocessor handling up to 1920×1080 resolutions. The MA35H0 integrates 128MB DDR memory, supports 2D graphics acceleration, JPEG and H.264 video decoding up to 1280×800 at 60 FPS, and is equipped with a range of interfaces such as Fast Ethernet, CAN FD, UART, and up to 154 GPIOs. It is designed to operate in an extended temperature range between -40 and 125°C. Nuvoton NuMicro MA35H0 specifications: CPU sub-system – 2x Cortex-A35 cores running at up to 650 MHz Memory sub-system On-chip 384 KB SRAM 128MB Multi-Chip Package (MCP) DDR Storage Quad SPI NAND flash controller Secure Digital Host Controller (SDHC) Display and Video Sub-system 18-bit 24-bit RGB TFT-LCD display interface up to 1280×800 @ 60 Hz 2D Graphic Engine (GFX) H.264 […]

LILYGO T-Panel – A 4-inch HMI display and WiFi, BLE, and 802.15.4 gateway based on ESP32-S3 and ESP32-H2

T-Panel 4-inch ESP32-S3 and ESP32-H2 gateway

LILYGO T-Panel is both a 4-inch HMI display and IoT gateway based on ESP32-S3 WiFi 4 and Bluetooth LE 5 microcontroller and an ESP32-H2 module with Bluetooth LE 5 and an 802.15.4 radio for Zigbee, Thread, and Matter connectivity. Last year, Espressif introduced the ESP-Thread Board Router/Zigbee gateway board with ESP32-S3 and ESP32-H2 to show how both chips could be combined to create IoT gateways.  But I don’t think I had seen a company design a product based on both ESP32-S3 and ESP32-H2 until I saw the T-Panel which also includes an RS485 interface and Qwiic expansion connectors for good measure. T-Panel specifications: Wireless chips/modules Wireless SoC –  ESP32-S3R8 dual-core Tensilica LX7 microcontroller @ 240 MHz 2.4 GHz 802.11n WiFi 4 and Bluetooth 5.0 LE connectivity Memory – 8MB PSRAM Wireless module – ESP32-H2-MINI-1 module MCU – Espressif Systems ESP32-H2 32-bit RISC-V microcontroller at up to 96 MHz with 320 […]

Raspberry Pi 5 industrial HMI displays gain M.2 NVMe SSD, RS232/RS485 interfaces, audio input/output jacks

Raspberry Pi 5 industrial HMI with RS232/RS485 audio input/output jacks

EDATEC ED-HMI3020 is a family of Raspberry Pi 5-based industrial HMI displays that build upon the earlier ED-HMI3010 panel PCs by adding an M.2 socket for NVMe SSD, RS232 and RS485 interfaces, as well as 3.5mm audio input and output jacks. The new models are still offered with either a 7-inch (1024×600) or 10.1-inch (1200×800) touchscreen display, a Raspberry Pi 5 with 4GB or 8GB RAM with all main ports (HDMI, Ethernet, USB) accessible externally, and support for an optional 8MP front-facing camera. ED-HMI3020 specifications with differences again ED-HMI3010 highlighted in bold or strikethrough: SoC – Broadcom BCM2712 CPU – Quad-core Arm Cortex-A76 processor @ 2.4 GHz with crypto extensions, 512KB per-core L2 caches, 2MB shared L3 cache GPU – VideoCore VII GPU @ 800 MHz with support for OpenGL ES 3.1, Vulkan 1.2, 4Kp60 HEVC decoder System Memory – 4GB or 8GB LPDDR4X-4267 SDRAM Storage MicroSD card socket M.2 […]

LILYGO T4-S3 board combines 2.41-inch AMOLED touchscreen display with ESP32-S3R8 microcontroller

T4-S3 ESP32-S3 smart AMOLED display

LILYGO T4-S3 is yet another ESP32-S3 board with an integrated display, but the main difference here is the 2.41-inch AMOLED touchscreen display with brighter colors than typical TFT displays. It’s actually not the first ESP32-S3 board with an AMOLED display from LILYGO as we previously covered the T-Track and T-Display-S3 AMOLED boards from the company, but the new T4-S3 has a larger 2.41-inch display with touchscreen function and an aspect ratio that may make it more suitable for a wider range of HMI applications.   LILYGO T4-S3 specifications: SoC – Espressif ESP32-S3R8 CPU – Dual-core Tensilica LX7 microcontroller up to 240 MHz with vector instructions for AI acceleration Memory – 8MB PSRAM Wireless – WiFi 4 and Bluetooth 5.0 LE + Mesh connectivity Storage – 16MB SPI flash, MicroSD card socket Display – 2.41-inch RGB AMOLED touchscreen display with 600×450 resolution (QSPI controller) with 800cd/m2 brightness, 36.2 x 48.96mm active […]
