July 3, 2024July 16, 2024 by Sponsored Post - No Comments

PCBWay’s 10th anniversary event – Win coupon codes worth up to $249 and various prizes (Sponsored)

PCBWay, one of the most popular PCB manufacturers around the world, is now almost 10 years old, and the company has started a promotional event for the PCBWay’s 10th anniversary with discount coupon codes, free boards, modules, tools, or kits, charity sales, and more. To get started, go to the 10th anniversary page, and click Enter to log in with your existing credentials or sign up for a new account with your email address. If you are a new user, you’ll also receive a welcome email with a special $5 coupon offer for 10 pieces of an up to 2 layer board and a $29 special offer for 1-20 pcs assembly following a long-term price reduction to celebrate the company’s 10th anniversary. After a customized welcome message, you’ll get access to a range of coupon codes to get discounts from $5 up to $240 for your next PCB order or even […]

June 11, 2024 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

GateMate Integrated Logic Analyzer (ILA) deep dive

CNXSoft: This is a guest article by Dave Fohrn, Embedded Software Engineer at Cologne Chip AG, that goes into detail about the company’s open-source integrated logic analyzer (ILA) for GateMate FPGA chips. A field-programmable gate array (FPGA) is a highly flexible integrated circuit in which complex logic circuits can be configured. They are often used as custom computing units in digital circuits because of their ability to process data quickly and in parallel using individually configured circuits. The digital circuits designed specifically for FPGAs are usually developed in a hardware description language such as Verilog or VHDL and are known as gateware. The term “gate” refers to the configurable digital logic units in the FPGA on which the individual gate circuits are implemented. An effective design can accelerate the computing process by strategically utilizing the various resources available in the FPGA, processing data in parallel, and intelligent implementing pipelining. A […]

June 5, 2023 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Analog Discovery 3 – A 125 MS/s USB oscilloscope, waveform generator, logic analyzer, and variable power supply

Digilent Analog Discovery 3 is a USB oscilloscope with a sample rate of up to 125 MS/s, that can also be used as a waveform generator, logic analyzer, and/or a variable power supply up to 5V. Several other features are also enabled through its software and the USB-C oscilloscope can also act as a spectrum analyzer, a network analyzer, an impedance analyzer, a protocol analyzer, a data logger, a voltmeter, and supports in-app scripting. Analog Discovery 3 features highlights: Xilinx FPGA-based design Host interface – USB Type-C port Oscilloscope 2x differential channels with 14-bit resolution at up to 125 MS/s per channel with a +/-25 V input range, 30+ MHz bandwidth with BNC Adapter User-configurable input filters and lock-in amplifier FFT, Spectrogram, Eye Diagram, XY Plot views, and more Arbitrary Waveform Generator 2x channels with 14-bit resolution at up to 125 MS/s per channel with a +/-5 V output range, […]

July 12, 2022 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Using Raspberry Pi Pico as a logic analyzer

MCU boards, including the $1.5 BluePill board, have been used as cheap logic analyzers for years, notably with Sigrok open-source software. So it should come as no surprise the $4 Raspberry Pi Pico board can also be used as a logic analyzer, with one developer claiming it can deliver 100 Msps, or the performance obtained with a 1.6 GHz CPU, thanks to the PIOs from the Raspberry Pi RP2040. Hackaday reported about a Sigrok driver for the Pico last March, but the topic was brought to our attention via a post on Hackster.io about an open-source Windows program developed from scratch to transform the Raspberry Pi Pico board into a logic analyzer capable of 100 Msps. Agustín Gimenez Bernad (aka gusmanb)’s LogicAnalyzer program offers up to 24 digital channels, pre, and post-trigger sampling, edge trigger and pattern trigger up to 16 bits. It can work with the Raspberry Pi Pico […]

June 22, 2021June 24, 2021 by Saumitra Jagdale - 4 Comments

PC-based Logic Analyzers Comparison: PGY-LA-EMBD vs Logic16 Pro vs SP209

Comparison of PGY-LA-EMBD vs Logic16 Pro vs SP209

Building an embedded system requires multiple devices to communicate with the central processor, generally through an SPI or I2C bus. If your system is quite complex and things don’t work out as expected, then a Logic Analyzer might save your day. So, choosing the correct Logic Analyzer is critical to a successful project. This article gives a PC-based Logic Analyzers comparison, and we’ll compare products from three companies: Prodigy Technovations, Saleae, and Ikalogic. Factors to keep in mind while selecting a Logic Analyzer Before we dive into the comparison part, we should be aware of a few points based on which we’ll compare them. Logic analyzers come with a certain number of channels. The higher the number of channels is, the costlier is the product. So, select the number of channels appropriately depending on the size of your project. Several other technical specifications should also be considered, which are listed […]

December 2, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

Power Profiler Kit II measures power consumption in Nordic Semi based embedded systems

If you’re developing battery-powered products it’s important to optimize your application to consume as little power as possible to extend battery life. As we’ve seen with Qoitech Otii Developer Tool, getting the right tool for development can help developers work more efficiently, and save countless man hours. If you’re specifically working on products based on Nordic Semi nRF51, nRF52, nRF53 or nRF91 wireless chips, the company has just announced the Power Profiler Kit II (PPK2) that enables easy and affordable power measurement of average and dynamic power consumption in embedded solutions based on the aforementioned wireless SoC’s/SiP’s. Power Profiler Kit II key features: 200nA to 1A measurement range Resolution varies between 100nA and 1mA depending on the measurement range Instantaneous and average current measurement for all Nordic DKs, in addition to custom HW Ampere meter and source modes Built-in programmable regulator with a 0.8V to 5V output range and up […]

November 14, 2020November 14, 2020 by Jean-Luc Aufranc (CNXSoft) - 22 Comments

Turn $1.5 Blue Pill STM32 board into a Sigrok compatible logic analyzer

“Blue Pill” is a popular STM32 development board thanks to its low cost – now as low as $1.50 on Aliexpress – and Arduino compatibility via the STM32duino project. People have created all sorts of projects around the tiny STM32 board, but I find Mark (aka thanks4opensource) buck50 test and measurement firmware very interesting as it turns the Blue Pill board into a logic analyzer compatible with the open-source Sigrok command-line tool and PulseView GUI. Mark explains the firmware is still at the beta stage, so bugs will most likely have to be fixed. Nevertheless, Buck50 firmware should enable the following key features on the Blue Pill board: 8 channel, 6+ MHz logic analyzer Approx. 5K sample buffer depth Samples stored only at signal edges for efficient memory usage Complex triggering via user-defined state machine supporting combinations of sequential (“A then B then C”) and logical-OR (“A or B or […]

October 13, 2019October 12, 2019 by Ayo Ayibiowu - No Comments

Ellisys Bluetooth Vanguard is a Best-in-Class Bluetooth Protocol Analyzer

Ellisys Bluetooth Vanguard Advanced All-in-One Bluetooth® Analysis System

ARM TechCon is Arm’s premier industry event, where developers, analysts, and media gather from all around to hear the latest from the semiconductor giant. ARM TechCon 2019 has marked the 15th annual event hosted in San Jose. Arm TechCon 2019 showcased some of the industry’s best products and solutions in the market. Embedded Computing Design hosted a Best in Show Awards showing some of the most innovative solutions from the even. One of the notable award recipients is the Ellisys Bluetooth Vanguard Protocol Analysis System. Ellisys Bluetooth Vanguard Advanced All-in-One Bluetooth Analysis System is being regarded as the most advanced and comprehensive Bluetooth Protocol analyzer ever made mostly because it delivers new advances designed to ease the increasingly complex tasks of Bluetooth developers and many more. Building Bluetooth based applications can be a daunting challenge, especially when working with the wrong tools/equipment. Aside from Bluetooth wireless traffic debugging, other information […]
