medical News - CNX Software - Embedded Systems News

July 2, 2024July 2, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

Allwinner T527 digital signage and Smart Display board offers HDMI, eDP, MIPI DSI, and LVDS display interfaces

MYiR Tech’s MYD-LT527-SX is a board designed for digital signage and Smart Display applications based on the MYC-LT527 Allwinner T527 system-on-module from the company and offering a range of display interfaces namely HDMI, eDP, MIPI DSI and dual-channel LVDS. The digital signage board builds upon MYiR Tech’s MYD-LT527 development board with a larger design featuring many of the same ports (dual GbE, USB 3.0, audio jack, HDMI output), and plenty of connectors for expansion including additional USB 2.0 interfaces, speaker and microphone, RS232, RS485, CAN Bus, and more. MYiR Tech’s MYD-LT527-SX specifications: SoM – MYC-LT527 system-on-module with SoC – Allwinner T527 CPU Octa-core Arm Cortex-A55 processor with four cores @ 1.80 GHz and four cores @ 1.42GHz E906 RISC-V core up to 200 MHz DSP – 600MHz HIFI4 Audio DSP GPU – Arm Mali-G57 MC1 GPU System Memory – 2GB LPDDR4 Storage – 16GB eMMC flash, 32Kbit EEPROM 381-pad LGA […]

June 25, 2024June 24, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

2.5-inch Pico-ITX SBC features 13th gen Raptor Lake SoC up to Intel Core i7-1370PE

AAEON PICO-RAP4 is a 2.5-inch Pico-ITX SBC powered by Intel Raptor Lake processors from the penta-core Intel Processor 300U up to a 14-core Intel Core i7-1370PE, equipped with up to 32GB DDR5 SO-DIMM memory, and supporting M.2 NVMe, SATA, and mSATA storage devices. The Pico-ITX board also features two Ethernet ports (2.5GbE + GbE) with TCC and TSN support, HDMI and eDP/LVDS display interfaces, multiple USB ports, two RS232/RS422/RS485 interfaces, and I2C and GPIO interfaces for further expansion. AAEON PICO-RAP4 specifications: SoC – 13th gen Raptor Lake SoC (one or the other) – Note frequencies shown as base frequencies Intel Core i7-1370PE 14C/20T processor @ 1.9GHz with Intel UHD Graphics; PBP: 28W Intel Core i7-1370PRE 14C/20T processor @ 1.9GHz with Intel UHD Graphics; PBP: 28W Intel Core i5-1340PE 14C/16T processor @ 1.8GHz with Intel UHD Graphics; PBP: 28W Intel Core i3-1320PE 8C/12T processor @ 1.7GHz with Intel UHD Graphics; PBP: […]

May 29, 2024May 28, 2024 by Tomisin Olujinmi - No Comments

HealthyPi Move is an open-source nRF5340-powered biometric monitor worn like a watch (Crowdfunding)

The HealthyPi Move is the latest biometric monitor in the HealthyPi series from ProtoCentral. It is the first to come in a wearable form factor and can measure up to eight vital signs. It is powered by a Nordic Semiconductor nRF5340 dual-core SoC, with a Cortex-M33 application processor and a Cortex-M33 network processor. It features 128MB of flash memory connected through a high-speed QSPI interface that can store up to 10 days of processed data. It is capable of measuring galvanic skin response (EDA/GSR), electrocardiogram (ECG) signals, and photoplethysmogram (PPG) signals for determining blood oxygen level (SPO2), blood pressure, and heart rate variability. It also includes a body temperature sensor and inertial measurement unit (IMU) with a 6-axis accelerometer and gyroscope. HealthyPi Move targets medical and biotech applications, including personal health tracking, building healthcare devices, and even clinical research with approval from the FDA or IRB. We have previously covered […]

May 24, 2024May 24, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

50W high-power wireless charging boards target industrial, medical, and smart home applications

STMicro has introduced a combo of 50W wireless charging transmitter and receiver boards, namely the STEVAL-WBC2TX50 transmitter board and the STEVAL-WLC98RX receiver board, for the development of high-power wireless charging solutions such as medical and industrial equipment, home appliances, and computer peripherals. The transmitter board, based on the STWBC2-HP transmitter system-in-package (SiP), supports up to 50W of output power using the STMicro’s proprietary Super Charge (STSC) protocol, as well as the Qi 1.3 5W Baseline Power Profile (BPP) and 15W Extended Power Profile (EPP). The receiver board, based on the STWLC98 wireless power receiver IC, can handle up to 50W charging power through STSC, supports Qi BPP and EPP charging, and implements features such as Adaptive Rectifier Configuration (ARC) to extend charging distance by up to 50% and accurate voltage and current measurement for Foreign Object Detection (FOD). STEVAL-WBC2TX50 transmitter board highlights: STWBC2-HP wireless power transmitter chip MCU – STM32G071 […]

May 15, 2024May 14, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

ardEEG shield works with Arduino UNO R4 WiFi for biosignals measurement

PiEEG has launched the ardEEG shield specially designed for the Arduino UNO R4 WiFi and capable of measuring biosignals such as those used in electroencephalography (EEG), electromyography (EMG), and electrocardiography (ECG). PiEEG, led by Ildar Rakhmatulin, Research Associate at Heriot-Watt University in Edinburgh, launched the PiEEG shield for Raspberry Pi to enable brain-computer interfaces last year, and now the company has been working on the equivalent design for Arduino with the ardEEG shield equipped with eight channel taking input from wet or dry electrodes. ardEEG shield key features and specifications ADC – Texas Instruments ADS1299 Analog-to-Digital Converter for biopotential measurements Supported board – Arduino UNO R4 WiFi 8 channels for connecting wet or dry electrodes (Electrodes are positioned according to the International 10-20 system) Host interface – Arduino headers with SPI used for data transfer with a frequency from 250 SPS to 16 kSPS and a resolution of 24 bits […]

May 8, 2024May 7, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

GIGAIPC PICO-N97A is a Pico-ITX SBC powered by an Intel Processor N97 CPU

GIGAIPC PICO-N97A Pico-ITX SBC features an Intel Processor N97 quad-core Alder Lake-N processor coupled with up to 16GB DDR5 SO-DIMM memory and M.2 SATA or NVMe storage designed for passively cooled and enclosed systems for Industry 4.0 applications in the smart cities, retail, and healthcare sectors. The single board computer supports up to two independent displays via HDMI and LVDS interfaces. It also provides dual Gigabit Ethernet, two USB 3.1 ports, an additional M.2 Key-B socket for wireless, and various headers for RS232/RS422/RS485, GPIO, USB 2.0, and more. GIGAIPC PICO-N97A specifications: SoC – Intel Processor N97 CPU – Alder Lake-N quad-core/quad-thread processor @ up to 3.6 GHz Cache – 6MB cache GPU – 24 EU Intel UHD graphics @ up to 1.20 GHz TDP: 12W System Memory – Up to 16GB DDR5-4800 via a single SO-DIMM socket Storage – SATA or NVMe SSD via M.2 M-Key socket (See expansion) Video […]

May 6, 2024May 5, 2024 by Debashis Das - No Comments

Nano-ITX motherboard is powered by Intel Atom x7000RE Series “Amston Lake” SoC

NANO 6064 ASL An Intel Atom x7000RE Series SoC based NANO ITX Board with Triple Display, 2.5GbE LAN, USB 3.2 Gen2, M.2, SATA III

Portwell NANO-6064-ASL is an Intel Atom “Amston Lake” x7000RE-powered Nano-ITX motherboard. The board looks very similar to the Portwell Nano-6062 and features an operating temperature of -40°C to 85°C. The motherboard can support a max of 16GB DDR4 memory and features triple display output, dual 2.5Gbps Ethernet, USB, M.2, SATA, GPIO, and more, and takes power from a 12V external power input. Previously, we’ve written about a range of Nano-ITX boards and SoMs with Amston Lake SoCs, including the ASRock SBC-262M-WT, conga-SA8 SMARC modules, ADLINK Atom x7000RE & x7000C COM Express and SMARC 2.1 modules and others. If you’re looking for similar options, feel free to check out those articles. Portwell NANO-6064-ASL Specifications SoC (one or the other) Amstom Lake Intel Atom x7211RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 6W TDP Intel Atom x7213RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 9W TDP Intel Atom x7433RE […]

April 17, 2024April 17, 2024 by Tomisin Olujinmi - No Comments

congatec conga-SA8 Amston Lake SMARC modules are targeted at industrial edge applications

Congatec’s new conga-SA8 SMARC modules are powered by the Intel Atom x7000RE “Amston Lake” processors. With twice the processing cores and similar power consumption to the previous generation, congatec’s new credit-card-sized modules are “intended for future-facing industrial edge computing and powerful virtualization.” An Intel Core i3‑N305 Alder Lake-N processor is also offered as an alternative to the Intel Atom x7000RE series for high-performance IoT edge applications. The conga-SA8 modules support up to 16GB LPDDR5 onboard memory, 256GB eMMC 5.1 onboard flash memory, and offer several high-bandwidth interfaces such as USB 3.2 Gen 2, PCIe Gen 3, and SATA Gen 3. The integrated Intel UHD Gen 12 graphics processing unit has up to 32 execution units and can power three independent 4K displays. The conga-SA8 is described as virtualization-ready and has a hypervisor (virtual machine monitor) integrated into the firmware. The RTS hypervisor takes complete advantage of the eight processing cores […]
