AAEON EPIC-TGH7 SBC supports up to Intel Xeon W-11865MRE (Tiger Lake H) processor

Intel Xeon SBC

It’s not often we come across an Intel Xeon SBC, but that’s just what AAEON EPIC-TGH7 single board computer offers thanks to a choice of Intel Tiger Lake H processors up to the Xeon W-11865MRE octa-core/16-thread processor. So far, we had only written about Tiger Lake H-based COM Express and COM HPC modules from companies such as ADLink, Congatec, and Portwell, and the EPIC-TGH7 is the first proper SBC we’ve seen with the industrial processors. It supports up to 64GB RAM through two SO-DIMM sockets, SATA and NVME storage, offers 2.5GbE and Gigabit Ethernet ports, five video interfaces, eight USB 3.2/2.0 interfaces, and more. AAEON EPIC-TGH7 specifications: Tiger Lake-H SoC (one or the other) Intel Xeon W-11865MRE 8-core/16-thread @  2.60GHz / 4.70GHz (Turbo) with 32 EU Intel UHD Graphics; TDP: 35-45W Intel Core i7-11850HE 8-core/16-thread processor @ 2.60GHz / 4.70GHz (Turbo) with 32 EU Intel UHD Graphics; TDP: 35-45W Intel […]

Acromag XMC-7A50-AP323 – An XMC module based on AMD Xilinx Artix-7 FPGA

Acromag XMC-7A50-AP323 is an XMC (Switched Mezzanine Card) module based on a Xilinx Artix-7 FPGA with 48 TTL I/O channels plus a 16-bit ADC for 20 differential or 40 single-ended analog inputs. Designed for commercial off-the-shelf (COSTS) applications, Acromag XMC modules are RoHS compliant, and suitable for automation applications, scientific development labs, as well as aerospace and military applications. Acromag XMC-7A50-AP323 module specifications: FPGA – AMD Xilinx Artix-7 (XC7A050) FPGA with 52,160 logic cells, 65,200 Flip flops, 2,700 kb block RAM, 120 DSP slices Storage – 32Mbit QSPI flash memory FPGA Digital I/O 48x I/O channels controlled in groups of eight channels, 5V tolerant TTL, RS485, and LVDS interface options: Build Option A: 24x EIA-485/422 channels Build Option B: 24x TTL and 12x EIA-485/422 channels Build Option C: 24x LVDS channels Analog Input 20 differential or 40 single-ended inputs Flexible scan control 16-bit A/D resolution 8μs conversion time FIFO buffer […]

XRF16 Gen3 SOM features Xilinx Zynq UltraScale+ ZU49DR RFSoC with up to 6GHz bandwidth

We’ve written about Xilinx Zynq UltraScale+ MPSoCs that combine Arm Cortex-A53/R5 cores and Mali-400 GPU with Ultrascale FPGA fabric several times over the course of a few years. But AMD-Xilinx also offers the Zynq UltraScale+ RFSoC single-chip adaptable radio platforms that support up to 7.125GHz analog bandwidth. The topic came to my attention because of an upcoming ZU49DR SoM from iWave Systems that seems to be under development but also noticed Avnet had launched a solution last year with the XRF16 Gen3 SoM featuring the same third-generation Zynq Ultrascale+ ZU49DR RFSoC with 16 RF-ADC, 16 RF-DAC channels, and 6GHz RF bandwidth. Avnet XRF16 specifications: Main chip – Xilinx Zynq UltraScale+ Gen3 ZU49DR RFSoC with Quad-core Arm Cortex-A53 processing subsystem Dual-core Arm Cortex-R5F MPCore up to 533MHz 16x ADCs, 14-bit up to 2.5 GSPS 16x DACs, 14-bit up to 9.85 GSPS (10 GSPS Available) 1 GbE, PCIe Gen1/2, SATA, USB2/3 UltraScale+ […]

Forlinx introduces Renesas RZ/G2L system-on-module and development board

Renesas RZ/G2L or RZ/V2L Cortex-A55/M33 processors have found their way into several system-on-modules and single board computers recently with the likes of Geniatech AHAURA board, Avnet RZBoard, or ARIES Embedded MSRZG2UL OSM module among others. Forlinx Embedded has joined the fray with the Renesas RZ/G2L-based FET-G2LD-C system-on-module, and a corresponding OK-G2LD-C development board with plenty of I/Os including dual Gigabit Ethernet, RS485 and CAN Bus interfaces, built-in WiFi and Bluetooth, plus an optional EC20 4G mini PCIe module. FET-G2LD-C system-on-module Specifications: SoC –  Renesas RZ/G2L (R9A07G044Lxx) dual or single-core Arm Cortex-A55 processor @1.2GHz, with real-tme Arm Cortex-M33 core @ 200MHz, Arm Mali-G31 GPU with OpenGL ES 1.1/2.0/3.1/3.2,Vulkan 1.1, OpenCL 2.0, 1080p30 VPU with H.264 AVC/MVC video encoding/decoding System Memory – 1GB / 2GB DDR4 Storage – 8GB or 16GB eMMC flash, 16MB QSPI NOR flash 3x 80-pin B2B connectors with MIPI-DSI and RGB interfaces up to 1920×1080, 2x 1000Mbps Ethernet […]

COM Express Type 6 module supports up to 64GB ECC RAM, 2.5GbE, 4 displays, and more

Here’s another Tiger Lake UP3 COM Express module courtesy of AAEON with the COM-TGUC6 COM Express Compact Type 6 modules equipped with a choice of Celeron. Core i3/i5/i7 embedded processors from the 11th generation Tiger Lake family. The module supports up to 64 GB ECC RAM via two SO-DIMM sockets, 2.5 Gpbs Ethernet, up to four independent displays via LVDS, VGA, and 4K DDI interfaces, SATA storage, PCIe Gen 3 & Gen4, and more for industrial. medical, and military applications. COM-TGUC6 specifications: Tiger Lake UP3 SoC (one or the other) Intel Core i7-1185G7E/GRE quad-core/octa-thread processor @ 1.8/4.4 GHz with 12 MB cache, 96 EU Intel Iris Xe graphics; TDP: 15W (Up to 28W) Intel Core i7-1145G7E/GRE quad-core/octa-thread processor @ 1.5/4.1 GHz with 8 MB cache, 80 EU Intel Iris Xe graphics; TDP: 15W (Up to 28W) Intel Core i3-1115G4E/GRE dual-core/quad-thread processor @ 2.2/3.9 GHz with 6 MB cache, 48 EU […]

Compact H.265 4K video encoder is made for embedded, medical, and military applications

US-based Z3 Technology has announced the Z3-Q603-RPS, a compact H.265 video encoder system capable of supporting 4K and HD resolutions for embedded, medical, and even military camera applications through NDAA (National Defense Authorisation Act) compliance. The board runs Linux on Qualcomm QCS603 IoT processor for AI and computer vision applications, which we previously found in Microsoft’s Vision AI Developer Kit, supports Ethernet and WiFI 5 connectivity, as well as features such as PTZ (Pan Tilt Zoom). Z3-Q603-RPS H.264 & H.265 video encoder system is comprised of an application board and a module with the following specifications: SoC – Qualcomm QCS603 (aka Qualcomm Vision Intelligence 300 Platform) with four Armv8 cores (2x 1.6GHz Kryo 300 Gold cores, 2x 1.7GHz Qualcomm Kryo 300 Silver cores ), Snapdragon neural processing engine, Adreno 615 GPU at 780 MHz System Memory – TBD Storage – NAND flash (capacity TBD) , MicroSD card socket Video Output […]

Embedded development board features Microchip PolarFire RISC-V FPGA SoC

Microchip/MicroSemi first introduced PolarFire RISC-V FPGA SoC at the end of 2018, with the chip being like the RISC-V equivalent of Xilinx Zynq Ultrascale+ Arm & FPGA MPSoC. The following year, ARIES Embedded unveiled the ARIES M100PF system-on-module and evaluation board, before Microchip launched PolarFire SoC Icicle 64-bit RISC-V and FPGA development board, followed by the more compact PolarBerry SBC in 2020. There’s now at least a fourth platform based on PolarFire SoC with Aldec TySOM-M-MPFS250 embedded development board.   Aldec TySOM-M-MPFS250 specifications: SoC – Microchip PolarFire MPFS250T-FCG1152 SoC  with 4x SiFive U54 RV64GC application cores (similar to Cortex-A35 performance), 1x SiFive E51 RV64IMAC monitor core, FPGA fabric with 254K logic cells, 17.6 Mb RAM System Memory 2GB (16Gbit) 32-bit DDR4 for the FPGA 2GB (16Gbit) 36-bit RAM with ECC for the RISC-V cores (aka MSS = Microprocessor Subsystem) Storage – MicroSD card socket, eMMC flash, SPI flash, 64 Kbit […]

Zoom i.MX 8M Mini Development Kit supports power usage monitoring

NXP i.MX 8M Mini 14nm Cortex-A53/M4 processor has been around for a couple of years, and several SoM-based development kits are available including Variscite Symphony starter kit, HummingBoard Ripple SBC, or congatec conga-SEVAL007010 evaluation board. Beacon EmbeddedWorks’ Zoom i.MX 8M mini development kit is based on the company’s i.MX 8M Nano System on Module (SOM) and offers features not found on most other devkits or single board computers such as power usage monitoring and control through their Wattson power measurement application. Zoom i.MX 8M mini development kit key features & specifications: System-on-Module SoC – NXP i.MX 8M Mini processor with up to four Arm Cortex-A53 cores @ up to 1.8 GHz, an Arm Cortex-M4 real-time core at up to 400 MHz, Vivante 3D & 2D GPU’s System Memory – Up to 8GB of 32-bit wide LPDDR4 memory Storage – eMMC flash, QSPI NOR flash Networking Gigabit Ethernet PHY Wireless module […]
