DIY Raspberry Pi Compute Module 4 NAS supports up to four drives

DIY Raspberry Pi CM4 NAS

We previously noted it was possible to build a Raspberry Pi CM4 NAS using Wiretrustee carrier board with a built-in Marvell 88SE9215 PCIe to SATA controller and four SATA connectors. But Mebs just created his own Raspberry Pi Compute Module 4 four-bay NAS with his own carrier board equipped with a PCIe socket used to insert a PCIe SATA card, as well as a neat 3D printed enclosure that took 6 days to print. This carrier board design is actually derived from the official Raspberry Pi CM4 IO board with only the interfaces needed for the NAS to make it smaller and fit within the width of a standard 3.5″ hard drive. It was also made as simple as possible because it was Mebs’ first PCB design. This leaves the board with Gigabit Ethernet, one HDMI port, a USB 2.0 port, the PCIe 2.0 socket, as well as some headers for power (board and SATA), a small I2C OLED display, […]

Build a Raspberry Pi CM4 4-Bay NAS with Wiretrustee Carrier board

Wiretrustee SATA board Raspberry Pi Compute Module 4

Broadcom BCM2711 processor comes with a PCIe interface that is used for the USB ports on the Raspberry Pi 4 SBC, but that is exposed through the board-to-board connectors of Raspberry Pi Compute Module 4, aka Raspberry Pi CM4, and allows all sort of designs. So far we’ve mostly seen this PCIe interface used for M.2 expansion slots on devices ranging from industrial computers to carrier board such as Piunora or Gumstix Raspberry Pi CM4 development board. But Wiretrustee had a different idea and designed carrier board with Marvell 88SE9215 PCIe to SATA controller and offering four SATA connectors to build a 4-bay NAS with Raspberry Pi CM4 module. Wiretrustee carrier board specifications: Supported SoM – Raspberry Pi Compute Module 4 and 4 Lite Storage 4x SATA 2.0 via Marvell 88SE9215 (PCIe 2.0 x1 to 4 6Gb/s SATA ports, no HW RAID) chip tested at a write speed of ~220MB/s on each of the SATA ports (not simultaneously) MicroSD card […]

ClusBerry 9500-CM4 – A Raspberry Pi CM4 cluster, industrial style

ClusBerry Industrial Raspberry Pi CM4 Cluster

Raspberry Pi cluster boards / solutions pop-up from time to time. But so far, I think we’ve seen only one based on Raspberry Pi CM4 modules with the upcoming Turing Pi 2 mini-ITX cluster board supporting four of those. TECHBASE has now unveiled a different kind of Raspberry Pi CM4 cluster with ClusBerry 9500-CM4 integrating up to eight Raspberry Pi Computer Module 4 in a DIN-Rail housing for industrial applications. ClusBerry 9500-CM4 is designed to be customizable with a choice of Raspberry Pi CM4 based modules and I/O cards: Standard 9500-CM4 cluster module with Compute Module 4 and a selection of configuration that include: I/O Controller with DI, DO, AI, 1-Wire, RS-232/485 and CAN interfaces Communication Gateway with up to 2x Ethernet, serial ports, wireless connectivity: LTE-cat.M1, 4G, 5G, LoRa, ZigBee, Z-Wave, Wireless M-Bus AI Gateway with Coral Edge TPU via PCIe M.2, or up to 4x Coral Edge TPU via USB3.0 NAS File Server RPI CM4 module with 2x […]

ODROID-HC4 low-cost dual NAS comes with 4GB RAM, supports 2.5-inch and 3.5-inch SATA drives

Low-cost Linux NAS dual SATA Drive

[Edit: Hardkernel has now updated their documentation to clarify the NAS uses ASM1061 PCIe to SATA controller instead of JMB582] It’s hard to find low-cost NAS platforms often because of the mechanism to insert drives and the enclosure add to the cost. An alternative is to use boards like Hardkernel ODROID-HC1 for 2.5-inch drives or ODROID-HC2 for 2.5- and 3.5-inch drives, but each board supports only one drive. The designs are stackable, but you’d need one Linux board per drive, so it’s not ideal. The Korean company has now launched a new model with ODROID-HC4 powered by an Amlogic S905X3 processor and shipping with a case supporting two 2.5-inch or 3.5-inch SATA drives that will start selling later this month for just $65 and up. ODROID-HC4 specifications: SoC – Amlogic S905X3 quad-core Cortex-A55 processor @ 1.8 GHz with Mali-G31 MP2 GPU System Memory – 4GB DDR4 Storage 128 Mbit SPI flash for bootloader like Petitboot UHS-1 compatible MicroSD card slot […]

Traverse Ten64 eight-core ARM64 10GbE networking platform runs mainline Linux (Crowdfunding)

Traverse Ten64 is a networking platform designed for 4G/5G gateways, local edge gateways for cloud architectures, IoT gateways, and network-attached-storage (NAS) devices for home and office use. Ten64 system runs Linux mainline on based NXP Layerscape LS1088A octa-core Cortex-A53 communication processor with ECC memory support, and offers eight Gigabit Ethernet ports, two 10GbE SFP+ cages, as well as mini PCIe and M.2 expansion sockets. Traverse Ten64 hardware specifications: SoC – NXP QorIQ LS1088 octa-core Cortex-A53 processor @ 1.6 GHz, 64-bit with virtualization, crypto, and IOMMU support System Memory – 4GB to 32GB DDR4 SO-DIMMs (including ECC) at 2100 MT/s Storage 8 MB onboard QSPI NOR flash 256 MB onboard NAND flash NVMe SSDs via M.2 Key M microSD socket multiplexed with SIM2 Networking 8x 1000Base-T Gigabit Ethernet ports (RJ45) 2x 10GbE SFP+ cages Optional wireless M.2/mPCIe card plus 3-choose-2 nanoSIM/microSD socket and up to 11x SMA connectors for antennas USB – 2x USB 3.0 ports, 1x USB 3.0 interface via […]

Beelink GS-King X Review with Android 9 – Video & Audio Playback, NAS/File Server Function, and Benchmarks

Beelink GS-King X Review Android 9

Last month I received Beelink GS-King X for review and started with an unboxing and teardown to check out the hardware. I’ve now had time to test the device with Android 9 including the file server function, a key selling point since of the device since it supports up to two 3.5″ SATA drives internally. A Tedious and Frustrating Start Eventually, I managed to boot the TV box and access the launcher, but it was no pleasure cruise. The first time, I connected the power, there was nothing at all, with the LED turned off, and no noise from the device. I thought the device was dead. The company asked me to check the power supply, and indeed a quick check with a multimeter confirmed it was dead despite the blue LED (on the power supply) implying the contrary. Nevermind, bad things happen, and the company sent me a new power supply, and the TV box could start… But… Oh […]

Beelink GS-King X Review – Part 1: Unboxing & Teardown

Beelink GS-King X Review

Beelink GS-King X is a 3-in-1 media center that works as an Android 9.0 TV box, a NAS with support for two 3.5″ hard drives, and a HiFi audio system with two ESS9018 audio DACs powering RCA and balanced audio outputs. The company sent a review sample, and I’ll start by checking out the hardware and accessories, show how to install the hard drive(s), and attempt to tear down the device to check what it’s really made of. Beelink GS-King X Unboxing There’s no mention of TV box nor Android on the package, just “STORAGE” and DTS plus Dolby Audio… The bottom of the package lists the Beelink GS-King X specifications which we already discussed in our previous articles. There’s a red ribbon that helps to take the device out of its package. I wish more companies would do this. Accessories include the voice remote control, an HDMI cable, a 19V/3A power supply, HDD brackets with screws, as well as […]

Beelink GS-King X Android TV Box, Dual HDD NAS & HiFi Audio System Launched for $250

buy Beelink GS-King X

Beelink GS-King X is an Android 9.0 TV box and a NAS with two 3.5″ SATA bays powered by Amlogic S922X-H processor combined with 4GB RAM and 64GB eMMC flash that was unveiled last month with some blurry renders. We now have for the details about the device, which has started to sell for $249.99 plus shipping on GeekBuying when using a “Fixed Priced” coupon, in my case 4ATAOTO6. Updated Beelink GS-King X specifications: SoC – Amlogic S922X-H hexa-core big.LITTLE processor with 4x Arm Cortex A73 cores @ up to 2.2 GHz, 2x Arm Cortex A53 cores @ 1.8 GHz, Arm Mali-G52MP4 GPU @ 846MHz; 12nm process System Memory – 4GB LPDDR4 RAM Storage – 64GB eMMC flash, microSD card slot, 2x 3.5″ SATA HDD drive bay for up to 32TB storage in total Video Output – HDMI 2.1 up to 4K @ 60 Hz with HDCP 2.2 Video – AVE-10 engine with 4K UHD H.265/VP9/AVS2 video decoding up to […]
