Intel Processor N50 or N97 touch Panel PCs feature 7-inch or 10-inch TFT color display

Intel N50 or N97 Panel PC 10-inch display

AAEON ACP-2106 and ACP-2076 are two fanless touch panel PCs powered by an Intel N50 or N97 Alder Lake-N processor with respectively 10-inch (1280 x 800) and 7-inch (1024×600) color TFT LCD displays with capacitive multi-touch support. Both models share the same key specifications with support for up to 32GB DDR5 SO-DIMM memory and a mPCIe socket for storage. They feature an HDMI 1.4 for dual display configuration for kiosks or other similar applications, two 2.5GbE ports, M.2 sockets for WiFi and 4G LTE/5G cellular connectivity, and more. AAEON ACP-2106 and ACP-2076 specifications: Alder Lake-N SoC (one or the other) Intel Processor N50 dual-core processor up to 3.4 GHz with 6MB cache, 16EU Intel UHD Graphics; TDP: 6W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel UHD Graphics; TDP: 12W Note: Turbo Mode is disabled by default. If enabling it, please ensure the system […]

AAEON ACP-1078 – A Rockchip RK3568-powered 7-inch touchscreen panel PC for manufacturing and logistics

AAEON ACP-1078 Rockchip RK3568 7-inch Panel PC

AAEON ACP-1078 is a 7-inch touchscreen panel PC powered by a Rockchip RK3568 quad-core Cortex-A55 AI SoC with 12V to 24V DC input, and an IP65-compliant aluminum front bezel suitable for manufacturing and logistics use cases. The fanless panel PC ships with up to 4GB RAM and 16GB eMMC flash and offers dual GbE networking, HDMI output, five USB ports, two COM ports, a microSD card slot, and a 3.5mm audio jack. AAEON ACP-1078 panel PC specifications: SoC – Rockchip RK3568 CPU – Quad-core Cortex A55 processor at up to 2.0 GHz GPU – Mali G52 GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 VPU 4Kp60 H.264, H.265, VP9, 1080p60 MPEG-4/-2/-1, VP8, and VC1 video decoder 1080p60 H.264/H.265 video encoder AI accelerator – 0.8 TOPS NPU System Memory – 2GB or 4GB LPDDR4 Storage 16GB eMMC flash MicroSD card socket mSATA socket Display 7-inch WSVGA (1024 x […]

Fanless Raspberry Pi CM4 panel PC features 15.6-inch touchscreen display, supports 9V-36V wide input voltage

Raspberry Pi CM4 Fanless Panel PC

EDATEC ED-HMI2320-156C is a fanless panel PC powered by a Raspberry Pi CM4 module with 15.6-inch capacitive touchscreen display and a metal enclosure ensuring cooling that’s built upon the previous Compute Module 4 smart displays from the company such as the 10.1-inch EDATEC ED-HMI2020-101C industrial panel PC and the ED-HMI2120-101C adding features such as 4G LTE, RS232 and RS485, M.2 NVMe SSD. The company’s latest HMI solution comes with two mSATA sockets, a 4K-capable HDMI 2.1 output port, two Gigabit Ethernet ports, optional WiFi 5, Bluetooth 5, and 4G LTE connectivity, as well as a few USB ports and DB9 serial ports. It can operate in the -25°C to +60°C temperature range and takes 9V to 36V DC input. EDATEC ED-HMI2320-156C specifications: System-on-Module (SoM) – Raspberry Pi CM4 SoC – Broadcom BCM2711 CPU – Quad-core Cortex-A72 processor @ 1.5GHz GPU – VideoCore VI conformant with OpenGL ES 3.1 & Vulkan […]

Raspberry Pi 5 industrial HMI displays gain M.2 NVMe SSD, RS232/RS485 interfaces, audio input/output jacks

Raspberry Pi 5 industrial HMI with RS232/RS485 audio input/output jacks

EDATEC ED-HMI3020 is a family of Raspberry Pi 5-based industrial HMI displays that build upon the earlier ED-HMI3010 panel PCs by adding an M.2 socket for NVMe SSD, RS232 and RS485 interfaces, as well as 3.5mm audio input and output jacks. The new models are still offered with either a 7-inch (1024×600) or 10.1-inch (1200×800) touchscreen display, a Raspberry Pi 5 with 4GB or 8GB RAM with all main ports (HDMI, Ethernet, USB) accessible externally, and support for an optional 8MP front-facing camera. ED-HMI3020 specifications with differences again ED-HMI3010 highlighted in bold or strikethrough: SoC – Broadcom BCM2712 CPU – Quad-core Arm Cortex-A76 processor @ 2.4 GHz with crypto extensions, 512KB per-core L2 caches, 2MB shared L3 cache GPU – VideoCore VII GPU @ 800 MHz with support for OpenGL ES 3.1, Vulkan 1.2, 4Kp60 HEVC decoder System Memory – 4GB or 8GB LPDDR4X-4267 SDRAM Storage MicroSD card socket M.2 […]

Cincoze P2202 Alder Lake-P embedded computer powers industrial panel PCs

Alder Lake-P industrial Panel PCs

Cincoze P2202 is an Intel Alder Lake-P embedded computer based on the Core i3-1215UE or Core i5-1245UE processor and designed for industrial, sunlight readable, or open-frame panel PCs from the company with sizes ranging from 12.1-inch to 24-inch. The P2202 supports up to 64GB DDR5 memory and two 2.5-inch SATA drives, and the system also offers four display interfaces including the company’s CDS (Convertible Display System) interface, two gigabit Ethernet ports, optional WiFi and 4G LTE/5G connectivity, multiple USB ports, four serial RS232/RS422/RS485 ports, digital I/Os, and various M.2, mPCIe, and PCIe sockets and slots for expansion. Cincoze P2202 specifications: Intel Alder Lake-P U-series SoC (one or the other) Intel Core i3-1215UE hexa-core processor up to 4.40 GHz with Intel UHD Graphics; TDP: 15W Intel Core i5-1245UE deca-core processor up to 4.40 GHz with Intel Iris Xe Graphics; TDP 15W System Memory – 2x DDR5 4800MHz SO-DIMM sockets for up […]

7-inch and 10.1-inch industrial panel PCs feature Raspberry Pi 5 SBC

Raspberry Pi 5 industrial Panel PCs

After introducing several Raspberry Pi CM4-based panel PCs over the years, EDATEC has launched its first industrial panel PCs based on the Raspberry Pi 5 SBC with the HMI3010-070C and HMI3010-101C equipped respectively with a 7-inch and 10.1-inch touchscreen display. Both HMI displays expose most I/Os and features from the Raspberry Pi 5 including the two micro HDMI ports, the USB-C port for power, the four USB Type-A connectors, and the gigabit Ethernet RJ45 jack. The company also offers an 8MP front-facing camera and/or PoE as options. EDATEC HMI3010 specifications: SoC – Broadcom BCM2712 CPU – Quad-core Arm Cortex-A76 processor @ 2.4 GHz with crypto extensions, 512KB per-core L2 caches, 2MB shared L3 cache GPU – VideoCore VII GPU @ 800 MHz with support for OpenGL ES 3.1, Vulkan 1.2, 4Kp60 HEVC decoder System Memory – 4GB or 8GB LPDDR4X-4267 SDRAM Storage – Optional 32GB or 64GB MicroSD card  Display […]

Raspberry Pi CM4-based industrial panel PC adds 4G LTE, RS232 and RS485, M.2 NVMe SSD

10.1-inch Raspberry Pi CM4 panel PC

EDATEC ED-HMI2120-101C is a Raspberry Pi CM4-based industrial panel PC with a 10.1-inch capacitive touchscreen display with plenty of interfaces to cater to a wide range of use cases from robotics to energy management and industrial automation. The panel PC builds upon the ED-HMI2020-101C introduced just a few months ago, but adds a range of features with dual Ethernet, RS485 and RS232 interfaces, and optional supports for an M.2 NVMe SSD and 4G LTE cellular connectivity. The device now supports an even wider DC input range from 9V to 36V and provides three 12V DC outputs to power external hardware such as an additional LCD. ED-HMI2120-101C specifications (with highlights in bold and strikethrough showing the differences against the earlier ED-HMI2020-101C model): System-on-Module (SoM) – Raspberry Pi CM4 SoC – Broadcom BCM2711 CPU – Quad-core Cortex-A72 processor @ 1.5GHz GPU – VideoCore VI conformant with OpenGL ES 3.1 & Vulkan 1.2 […]

EDATEC ED-HMI2020-101C – A 10.1-inch Raspberry Pi CM4-based industrial panel PC

10.1-inch Raspberry Pi CM4 industrial panel PC

EDATEC has launched yet another Raspberry Pi CM4-based platform for industrial applications with the ED-HMI2020-101C 10.1-inch panel PC with 1280×800 resolution, 9V to 28V wide power input, and support for an optional “extended display” via an HDMI FPC cable that also carries USB/I2C signal for the touchscreen. The system comes with up to 8GB RAM, 32GB eMMC flash, Gigabit Ethernet, optional WiFi 5 and Bluetooth 5.0, built-in stereo speakers, several other audio interfaces, as well as a 40-pin GPIO header for expansion. EDATEC ED-HMI2020-101C specifications: System-on-Module (SoM) – Raspberry Pi CM4 SoC – Broadcom BCM2711 CPU – Quad-core Cortex-A72 processor @ 1.5GHz GPU – VideoCore VI conformant with OpenGL ES 3.1 & Vulkan 1.2 VPU 4Kp60 H.265 video decoder 1080p60 H.264 video decoder 1080p30 H.264 video encoder System Memory – 1GB, 2GB, 4GB, 8GB LPDDR4-3200 SDRAM Storage – 8GB, 16GB, 32GB eMMC flash Wireless – Optional WiFi 5 and Bluetooth […]
