2.5-inch “Industrial Pi” Pico-ITX SBC offers PoE , mini DP++ port

Taiwan based DFI has launched the AL05P “Industrial Pi + PoE” 2.5-inch Pico-ITX SBC powered by an Apollo Lake processor that reminds me of last year’s DFI GHF51 SBC based on AMD Ryzen Embedded R1606G processor but with a larger, and more standard form factor that’s also part of the “Industrial Pi” family. The board also comes with 4GB RAM, up to 64GB eMMC, a mini DisplayPort video output, two USB 3.1 ports, Gigabit Ethernet with isolated PoE, a mini-PCIe, and more. DFI AL05P SBC specifications: SoC (one or the other) Intel Atom x5-E3940 quad-core processor @ 1.6/1.8 GHz with 2MB cache, Intel HD Graphics; 9.5W TDP Intel Atom x5-E3930 dual-core processor @ 1.3/1.8 GHz with 2MB cache, Intel HD Graphics; 6.5W TDP Intel Pentium N4200 quad-core processor @ 1.1/2.5 GHz with 2MB cache, Intel HD Graphics; 6W TDP Intel Celeron N3350 dual-core processor @ 1.1/2.4 GHz with 2MB cache, Intel HD Graphics6W TDP System Memory – Up to 4GB […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Ready! Model 100 is a retro computer shell for Raspberry Pi, SBCs, Nano/Pico-ITX boards

We recently wrote about Devterm, a modular, retro-looking portable computer that looks like a typewriter with an extra-wide display, and takes Raspberry Pi CM3-series modules, or other compatible modules made by Clockwork based on Rockchip RK3399 or Allwinner H6. If you’re into this kind of device, but would like to use your own Raspberry Pi,  another SBC,  an Intel NUC motherboard, a Nano/Pico-ITX board, or even your smartphone, Ready! Model 100 single board computer expansion system may be worth looking into. Ready! Model 100 key features and specifications: Compatibility – Accommodates any hardware using 5V or 12V power input including smartphones, or arm or x86 SBCs such as Raspberry Pi 4, and compact motherboard following NUC, 4×4, 5×5, or Nano/Pico ITX form factors. Storage – Space for SSD Display – 8.8-inch 1920×480 “3xVGA” HDMI Touchscreen Video Output – HDMI (if dual HDMI supported on SBC) Audio – 10W stereo speaker system Connectivity  (varies depending on the board’s features) Ethernet Wireless […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Congatec Unveils Atom x6000E Elkhart Lake Powered Pico-ITX SBC, Qseven, SMARC, COM Express Modules

With the announcement of Intel Elkhart Lake IoT-optimized processors, we should expect embedded systems companies to unveil their own Atom x6000E and Celeron/Pentium Elkhart Lake powered products, and one of the first to do so is Congatec with the introduction of four different Elkhart Lake computers-on-module (CoM) following Qseven, SMARC, and COM Express standards, as well as a Pico-ITX SBC. conga-PA7 Atom x6000E SBC (with Celeron/Pentium J optional) Detailed specifications: SoC –  Choice of eight different Elkhart Lake processors from the 6W Atom x6211E dual-core processor to the 10W Intel Pentium J6425 quad-core processor up to 3.0 GHz, all with 10th Gen Intel UHD graphics System Memory – Up to 16GB quad-channel onboard LPDDR4x Storage 32GB or 64GB UFS 2.0 flash (optional up to 512GB) M.2 SATA/PCIe SSD support (see expansion) 32 MB serial flash for AMI Aptio UEFI firmware Video DisplayPort DP++ video output up to 4Kp60 1x USB-C port with DisplayPort Alt mode 1x LVDS 18/24-bit connector or […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

AAEON PICO-WHU4 Whiskey Lake Pico-ITX Board is Designed for AI and Edge Computing

AAEON has just launched a Whiskey Lake Pico-ITX SBC made for AI and edge computing with PICO-WH4 featuring a 15W Intel Core i3/i5/i7 or Celeron processor combined with up to 16GB DDR4 memory, The board offers dual Gigabit Ethernet connectivity, dual display support with HDMI connectors, USB 3.2 ports, SATA storage, as well as mPCIe and M.2 expansion slots. AAEON PICO-WHU4 specifications: SoC (one or the other; all Whiskey Lake U-series processors) Intel Celeron 4305UE dual-core processor @ 2.00 GHz (no turbo frequency) with Intel UHD Graphics 610 @ 300 MHz / 1.0 GHz (Turbo); 15W TDP Intel Core i3-8145UE dual-core/quad-thread processor @ 2.2 GHz / 3.9 GHz (Turbo) with Intel UHD Graphics 620 @ 300 MHz / 1.0 GHz (Turbo); 15 TDP Intel Core i5-8365UE quad-core/octa-thread processor @ 1.6GHz / 4.1GHz (Turbo) with Intel UHD Graphics 620 @ 300 MHz / 1.05 GHz (Turbo); 15 TDP Intel Core i7-8665UE quad-core/octa-thread processor @ 1.7GHz / 4.4GHz (Turbo) with Intel UHD […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

GIGABYTE GA-PICO3350 Apollo Lake Pico-ITX Board Comes with SO-DIMM RAM Slot, SATA and mSATA Storage

GIGABYTE Pico-ITX Motherboard

GIGABYTE GA-PICO3350 may be the smallest motherboard from the company so far. The Pico-ITX board comes with an Intel Celeron N3350 dual-core Apollo Lake processor with a SO-DIMM slot, SATA port, and mSATA socket that give you more options will selecting RAM and storage. GA-PICO3350 specifications: SoC – Intel Celeron N3350 dual-core Apollo Lake processor @ up to 2.4 GHz with 2 MB cache, Intel HD graphics; 6W TDP System Memory –  1 x DDR3L SO-DIMM socket supporting up to 8 GB DDR3L 1866/1600 MHz Storage- 1x SATA 6Gb/s connector,  1x mSATA connector (multiplexed with mPCIe), 128 Mbit flash for BIOS/UEFI Video Output HDMI 1.4 up to 3840×2160 @ 30 Hz 1x LVDS header 1x flat panel display header Audio – Realtek ALC887 codec, 1x front panel audio header Connectivity – Gigabit Ethernet port via Realtek PHY USB – 2x USB 3.0/2.0 ports on the back panel, 2x USB 2.0/1.1 ports available through the internal USB headers Expansion 1x M.2 […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Commell Unveils LP-178 Whiskey Lake Pico-ITX SBC

Whiskey Lake Pico ITX SBC

We’ve previously covered several Intel Whiskey Lake-U SBCs in various form factors such as the Commell LE-37N 3.5″ board, ASRock IMB-1216 mini-ITX motherboard, or UP Xtreme with a custom 122×120 form factor. But if your project or application requires a more compact form factor, Commell has just announced LP-178 Whiskey Lake Pico-ITX SBC with either  Intel Core i7-8665UE or Celeron 4305UE 8th generation embedded processor. LP-178 board  specifications: SoC (one or the other) Intel Core i7-8665UE quad-core/octa-thread processor @ 1.7GHz / 4.4GHz (Turbo) with Intel UHD Graphics 620; 8MB cache; 15W TDP Intel Celeron 4305UE dual-core processor @ 2.0GHz with Intel UHD Graphics 610; 2MB cache; 15W TDP FCBGA1528 package System Memory – SO-DIMM socket for up to 16GB DDR4 RAM Storage – 1x SATA 3.0 interface Video Output / Display I/F HDMI port up to 4K resolution DisplayPort output DP to VGA or LVDS via an optional adapter Triple independent display support Audio – Realtek ALC262 HD audio coded; […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

ASUS Tinker Edge R Pico-ITX Board to Feature Rockchip RK3399Pro SoC

ASUS Tinker Edge R

Just a few days ago, we wrote about ASUS Tinker Edge T board and other products from ASUS featuring Google Coral Edge TPU which were showcased at Computex 2019. It turns out the company is working on another Tinker with a processor featuring an neural network accelerator. Meet ASUS Tinker Edge R Pico-ITX SBC powered by Rockchip RK3399Pro hexa-core processor equipped with a 3.0 TOPS NPU. One of the reasons it did not get noticed is that ASUS may not have had a sample for display at the event, but instead only described the board in a brochure. [Update: ASUS Tinker Edge R was also showcased at Computex 2019] ASUS Tinker Edge R SBC preliminary specifications: SoC – Rochchip RK3399Pro hexa-core big.LITTLE processor with 2x Cortex A72 cores up to 1.8 GHz, 4x Cortex A53 cores @ 1.4 GHz, an Arm Mali-T860 MP4 GPU up to 800 MHz with OpenGL ES 1.1 to 3.2, OpenVG1.1, OpenCL 1.2 and DX 11 […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Kontron pITX-iMX8M Industrial Pico-ITX Motherboard is Powered by NXP i.MX8M Processor

pITX-imx8m

We’ve had a fair amount of boards and modules based on NXP i.MX 8M dual or quad core Cortex A53 processor this year, including one pico-ITX motherboard with F&S Elektronik ArmStone MXM8 supporting up to 8GB RAM. Another i.MX 8M pico-ITX board will soon be launch courtesy of Kontron. pITX-iMX8M will also features the dual or quad core version of the processor, but will differ thanks to the presence of dual Gigabit Ethernet, mini DP and HDMI video outputs, an M.2 PCIe/USB 3.0 socket, and built-in TPM 2.0 security. Kontron pITX-iMX8M preliminary specifications: SoC – NXP i.MX 8M Dual or QuadLite Arm Cortex A53 processor @ up to 1.5 GHz, Arm Cortex-M4 real-time core, and Vivante GC7000Lite GPU with support for OpenGL/Es 3.1, OpenGL 3.0, Vulkan System Memory – 4GB LPDDR4 Storage – 64GB eMMC 5.1 flash, micro SD card / SIM slot combo Video Output – mini DisplayPort, HDMI 2.0a, dual channel LVDS Video Playback – 4K UltraHD with […]
