Posted on by Sayantan Nandy - No Comments on Portwell WEBS-21J0-ASL – A rugged embedded system with Intel Atom x7000RE Nano-ITX motherboard and Hailo-8 AI accelerator

Portwell WEBS-21J0-ASL – A rugged embedded system with Intel Atom x7000RE Nano-ITX motherboard and Hailo-8 AI accelerator

WEBS-21J0-ASL Nano-ITX embedded system

Portwell’s WEBS-21J0-ASL is a fanless, rugged embedded system with a Nano-ITX motherboard powered by an Intel Atom x7000RE Series processor and optimized for industrial IoT applications. It features two 2.5Gbps Ethernet ports, dual 4K display support (DP/HDMI), and a serial port as well as M.2 E and B Key sockets for wireless and storage expansion. Designed for harsh environments, the WEBS-21J0-ASL operates in temperatures ranging from -20°C to 60°C. The system is equipped with DDR4 SO-DIMM memory (up to 16GB and 10Gbps USB 3.2 Gen 2 ports. It has passed vibration and shock tests for durability in rugged applications making it suitable for a wide range of industrial and automation systems. The WEBS-21J0-ASL also supports optional integration with the Hailo-8 AI acceleration module delivering up to 26 TOPS of AI performance for applications requiring advanced AI capabilities. This makes it an ideal solution for robotics, medical equipment, outdoor gateways, and […]

Posted on by Sayantan Nandy - 3 Comments on ASUS X7433RE-IM-A 3.5-Inch motherboard features Intel Atom X7433RE Amston Lake SoC, dual Ethernet, three display interfaces

ASUS X7433RE-IM-A 3.5-Inch motherboard features Intel Atom X7433RE Amston Lake SoC, dual Ethernet, three display interfaces

X7433RE IM A

ASUS has launched the X7433RE-IM-A, a 3.5-inch industrial motherboard powered by an Intel Atom X7433RE Amston Lake SoC. The processor supports Intel Deep Learning Boost (DL Boost) and Intel AVX2 SIMD instructions to enhance AI processing and accelerate workloads at the IoT edge. The X7433RE-IM-A single-board computer supports up to 16GB of DDR5 4800MHz In-Band ECC memory via a SO-DIMM slot. The Intel Atom X7433RE processor, with integrated Intel UHD Graphics, supports up to three 4K displays through HDMI 2.0, DisplayPort 1.4, and LVDS/eDP 1.2. For storage, the board includes a SATA 3.0 interface and networking is implemented through two Ethernet controllers – Intel i210IT and i226IT (2.5GbE) – with WOL/PXE support. Previously, we covered the ASRock Industrial SBC-262M-WT, another Intel Atom X7433RE Amston Lake-based 3.5-inch motherboard. We also wrote about other 3.5-inch boards like the ECS ADLN-IE1S, Jetway MF32, ECS RK3568-IS, MSI MS-98M3, and several others. You can check […]

Posted on by Sayantan Nandy - 3 Comments on ASUS N97T-IM-A – A thin mini-ITX motherboard powered by an Intel Processor N97 Alder Lake-N CPU

ASUS N97T-IM-A – A thin mini-ITX motherboard powered by an Intel Processor N97 Alder Lake-N CPU

Asus N97T IM A

The ASUS N97T-IM-A is a thin Mini-ITX motherboard for industrial and embedded use, featuring the Intel N97 Alder Lake-N processor (4 cores, 2.0–3.6 GHz) with up to 16GB of DDR5 memory at 4800 MHz, and two gigabit Ethernet ports using Realtek RTL8111H controllers. The board also includes two SATA III 6Gbps ports, a PCIe 3.0/2.0 x1 slot, and dual M.2 slots for NVMe and Wi-Fi/Bluetooth. It supports HDMI 2.0, DP++, and LVDS video outputs, with optional eDP, and can handle resolutions up to 4K at 60 Hz. Built for durability, the N97T-IM-A is designed for demanding environments with a seven-year product lifecycle. In one of our last posts, we wrote about the Jetway JNUC-ADN1, another Intel N97-powered SBC, but in a smaller Next Unit of Computing (NUC) form factor and the Jetway JMTX-ADN8 another N97 mini-ITX motherboard. Other than that we have also written about similar motherboards in the mini-ITX form factor including […]

Posted on by Debashis Das - No Comments on Nano-ITX motherboard is powered by Intel Atom x7000RE Series “Amston Lake” SoC

Nano-ITX motherboard is powered by Intel Atom x7000RE Series “Amston Lake” SoC

NANO 6064 ASL An Intel Atom x7000RE Series SoC based NANO ITX Board with Triple Display, 2.5GbE LAN, USB 3.2 Gen2, M.2, SATA III

Portwell NANO-6064-ASL is an Intel Atom “Amston Lake” x7000RE-powered Nano-ITX motherboard. The board looks very similar to the Portwell Nano-6062 and features an operating temperature of -40°C to 85°C. The motherboard can support a max of 16GB DDR4 memory and features triple display output, dual 2.5Gbps Ethernet, USB, M.2, SATA, GPIO, and more, and takes power from a 12V external power input. Previously, we’ve written about a range of Nano-ITX boards and SoMs with Amston Lake SoCs, including the ASRock SBC-262M-WT, conga-SA8 SMARC modules, ADLINK Atom x7000RE & x7000C COM Express and SMARC 2.1 modules and others. If you’re looking for similar options, feel free to check out those articles. Portwell NANO-6064-ASL Specifications SoC (one or the other) Amstom Lake Intel Atom x7211RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 6W TDP Intel Atom x7213RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 9W TDP Intel Atom x7433RE […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Helix 511 fanless industrial embedded computer features Intel Celeron 7305 up to Core i7-12800HL CPU

Helix 511 fanless industrial embedded computer features Intel Celeron 7305 up to Core i7-12800HL CPU

Onlogic HX511

OnLogic Helix 511 edge computer features an Intel Alder Lake processor from Celeron 7305 up to a Core i7-12800HL CPU with up to 64GB DDR5, M.2 SATA or NVMe storage and designed for use in manufacturing, automation, energy management, and other edge and IoT applications. The fanless industrial embedded computer also comes with two 2.5GbE ports, support up to four independent displays via DisplayPort and Thunderbolt 4 connectors, is equipped with six USB 3.2 ports, as well as optional digital I/O or serial ports for expansion. Helix 511 specifications: Alder Lake SoC Intel Celeron 7305 penta-core processor @ 3.10GHz / 4.20GHz (Turbo) with 48EU Intel UHD graphics – PBP: 15W, up to 55W MTP Intel Core i3-12300HL octa-core/12-thread processor @ 2.00GHz  / 3.30GHz / 4.40GHz (Turbo) with Intel UHD graphics – PBP: 45W, up to 65W MTP Intel Core i5-12600HL 12-core/16-thread processor @ 2.70GHz / 3.30GHz / 4.50GHz (Turbo) with […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Intel NUC 13 Rugged “Bravo Canyon” fanless Alder Lake-N mini PC is designed for 24/7 operation

Intel NUC 13 Rugged “Bravo Canyon” fanless Alder Lake-N mini PC is designed for 24/7 operation

Intel NUC 13 Rugged

The Intel NUC 13 Rugged, codenamed “Bravo Canyon, is an upcoming fanless and dust-resistant mini PC powered by an Alder Lake-N processor and designed for 24/7 operation suitable for business and industrial applications, albeit just in a 0°C to 40°C or 50°C temperature range. The rugged computer is offered with either an external or internal heatsink, supports up to 16GB DDR5 memory, comes with 64GB eMMC flash, M.2 sockets for NVMe and/or SATA SSDs, two 4Kp60 capable HDMI 2.1 ports, two 2.5GbE networking interfaces, four USB 3.2/2.0 ports, and optional support for WiFi 6, 4G LTE cellular connectivity, and an internal expansion bay. Intel NUC 13 specifications: Alder Lake-N SoC (one or the other) Intel Atom x7425E quad-core processor up to 3.4 GHz with 6MB L3 cache, Intel UHD Graphics; 12W TDP Intel Atom x7211E dual-core processor up to 3.2 GHz with 6MB L3 cache, Intel UHD Graphics; 6W TDP […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 17 Comments on Companies Address Concerns related to Speculative Execution Exploits: Meltdown and Spectre

Companies Address Concerns related to Speculative Execution Exploits: Meltdown and Spectre

Yesterday, news surfaced about a “bug” in Intel processors that could be fixed at the operating system level at the cost of a decrease in performance for some tasks, from a typical, and barely noticeable 5% hit, to a more consequent 30% hit for some specific tasks, and as we discussed yesterday I/O intensive tasks are the most impacted by the changes. While Intel (and Arm) are impacted, AMD claims not to be, and the issue was reported by major news outlets and likely impacting the stock price of the companies with Intel stock losing 3.39%, and AMD stock gaining 5.19%, so obviously every company felt the need to answer, starting with Intel’s response to security research findings: Recent reports that these exploits are caused by a “bug” or a “flaw” and are unique to Intel products are incorrect. Based on the analysis to date, many types of computing devices […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 17 Comments on Red Hat Enterprise Linux 7.4 Now Fully Supports Arm servers

Red Hat Enterprise Linux 7.4 Now Fully Supports Arm servers

When hardware vendors announced Arm based servers they also claim support for operating systems such as Ubuntu 16.04 LTS and Red Hat Enterprise Linux, so I assumed software support was more or less where it needed to be with regards to Arm server. But apparently, it may not have been so, as Red Hat only announced full support for Arm servers in Red Hat Enterprise Linux for ARM a few days ago. It also started with SBSA (Server Base System Architecture) specifications in 2014, that aimed to provide a single operating platform that works across all 64-bit ARMv8 server SoCs that complies with the said specification. Red Hat then released a developer preview of the OS for silicon and OEM vendors in 2015, and earlier this week, the company released Red Hat Enterprise Linux 7.4 for Arm, the first commercial release for this architecture. RHEL 7.4 for Arm come with […]
