Posted on by Jean-Luc Aufranc (CNXSoft) - 63 Comments on Xiaomi Mi WiFi 3 Router Unboxing, Teardown, and Serial Console

Xiaomi Mi WiFi 3 Router Unboxing, Teardown, and Serial Console

Mi WiFi 3 is the new low cost 802.11ac WiFi router by Xiaomi that sells for about $40. GearBest send my one sample for evaluation, and today, I’ve taken some photo of the device and board, and connected the UART pin to see if the serial console was accessible for people who want to try to port OpenWrt for example. Xiaomi Mi WiFi 3 Unboxing There’s some information on the package, but everything is in Chinese, except the part about AC1200 meaning it supports up to 867 Mbps with 802.11ac and 300 Mbps using 802.11n. The router comes with a 12V/1A power supply, and a user’s manual in Chinese only. There’s also a QR code inside the box linking to the Android and iOS apps,  available both in English and Chinese, so actually that one of the few Xiaomi product that should be easy to use outside of China without […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 33 Comments on Xiaomi Mi WiFi 3 AC1200 Router Gets 128 MB Storage, Sells for $40 Shipped

Xiaomi Mi WiFi 3 AC1200 Router Gets 128 MB Storage, Sells for $40 Shipped

The first Xiaomi Mi WiFi router brought the cost of 802.11ac WiFi to the masses, and it is now selling for less than $30 including shipping, but the company has now launched Xiaomi Mi WiFi 3 router with some improvements, including a total of 4 antennas and more storage, and sold on e-retailer such as GearBest and GeekBuying for just under $40. Xiaomi Mi WiFi 3 router specifications: Wi-Fi SoC – Mediatek MT7620A @ 580MHz System Memory – 128 MB DDR2 Storage – 128 MB SLC NAND Flash Wi-Fi Protocols – IEEE 802.11a/b/g/n/ac Transmission Rate – 300Mbps max @ 2.4GHz 2X2  MIMO, 867 Mbps max @ 5GHz 2X2  MIMO Wireless Security – WPA-PSK/WPA2-PSK encryption, wireless access control (black and white list), SSID hiding 2.4 GHz Channels: 1,2,3,4,5,6,7,8,9,10,11,12,13 5 GHz Channels: 149,153,157,161,165 5 GHz DFS (dynamic frequency selection) channels: 36,40,44,48,52,56,60,64; 4x external antennas Ethernet – 2x 10/100M Ethernet (LAN), 1x 10/100M […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 12 Comments on NXP Introduces QorIQ LS1046A Quad Cortex A72 Communication Processor with 10 GbE, SATA 3.0, PCIe 3.0, etc…

NXP Introduces QorIQ LS1046A Quad Cortex A72 Communication Processor with 10 GbE, SATA 3.0, PCIe 3.0, etc…

NXP has unveiled a new QorIQ communication processor with LS1046A based on quad ARM Cortex-A72 cores, and including 10GbE, PCIe Gen.3, SATA 3.0, and USB 3.0 interfaces. The processors targets CPE and vCPE (virtual Customer Premise Equipment), routers, NAS, and service provider gateways for the home and small office, as well as single board computers. QorIQ LS1046A key specifications: CPU – Four ARM Cortex -A72 cores with 2MB L2 cache; 32,000 CoreMarks. Memory  – 32-/64-bit DDR4 memory controller Storage – SATA 3.0 controller, quad SPI Connectivity 2x 10 Gigabit Ethernet controllers 1x 2.5 Gigabit Ethernet controller 4x Gigabit Ethernet controllers Other peripherals 3x PCIe 3.0 Controllers, x4, x2, x 1 3x USB 3.0 with integrated PHY 4x UART, 4x I2C, SPI, GPIO JTAG Support for hardware-based virtualization via ARM SMMU Packet processing acceleration –  Packet classification and distribution; hardware work scheduling, shaping, and buffer management. Integrated security engine – High-speed […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on GearBest 2nd Anniversary Promo Offers Cheap TV Boxes and Routers

GearBest 2nd Anniversary Promo Offers Cheap TV Boxes and Routers

GearBest has become fairly popular since it launched two years ago, mostly thanks to aggressive pricing, promotions, and coupons, and the company is celebrating its anniversary with some more discounts with recent TV boxes as low as $23, routers for $12 and up, and other accessories. Some potentially interesting deals include: Chiptrip MXV S805 TV box with Amlogic S805 and Android 4.4 for $29.99 Beelink X2 TV box with Allwinner H3 and Android 4.4 for $26.89 MX4 TV box running Android 4.4 on Rockchip RK3229 for $22.99 Xiaomi Mi WiFi mini 802.11ac router for $28.49 (Update: also found on eBay for  $21.70 shipped) oops that’s the Youth Edition, only 802.11n) EasyCast WiFi Display Dongle for $11.99 NEXX WT3020F OpenWrt compatible router for $12.74 Please note that some are flash sales with 100 to 300 pieces, and discounted prices may not be active right now. [Update: Finally, only the flash sales […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on The First Devices and Routers with WiFi 802.11ad Delivering Up 7Gbit/s Transfer Rates at 60 GHz Will Be Available This Year

The First Devices and Routers with WiFi 802.11ad Delivering Up 7Gbit/s Transfer Rates at 60 GHz Will Be Available This Year

802.11ad is the latest and fastest WiFi standard working in the 60 GHz band and delivering up to 7 Gbit per second data transmission rates. The 60 GHz  frequency band offers both advantages and disadvantages because it does not penetrate through walls nor water, meaning it can only be used within a room limiting the range, but at the same time it’s more secure since it cannot be snooped from the outside, and for people who worry about health effects it does not penetrate the human body. 802.11ad routers will also be able to switch to 2.4 and 5.0 GHz frequency bands in order to go through walls. The table above nicely summarize the key features of 802.11ad over 802.11ac and 802.11n, however the throughput row shows the theoretical maximum throughput, but in practice, using 802.11ac as example, clients are often limited to 433 or 866 Mbps, and distance and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on DAB Embedded OpenWrt Router Board Combines Atmel SAMA5D3 SoC and Altera MAX 10 FPGA

DAB Embedded OpenWrt Router Board Combines Atmel SAMA5D3 SoC and Altera MAX 10 FPGA

DAB Embedded, a Belgian engineering company specialized in research and development of electronic products, has designed DAB-OWT-SAM5 router board powered by Atmel SAMA5D36 Cortex-A5 processor and Altera MAX 10 FPGA, which runs OpenWrt or Windows Embedded Compact 7, and targets IoT applications. DAB-OWT-SAM5 board specifications: SoC – Atmel SAMA5D36 ARM Cortex-A5 processor @ 536MHz with Floating-Point Unit. FPGA – Altera MAX 10 FPGA with integrated ADC (Exact part number not disclosed) System Memory – Up to 512MB DDR2 Storage – Up to 2GB NAND flash, 1Mbit SPI flash, micro SD slot Connectivity – 2x Fast Ethernet ports, 802.11 b/g/n WiFi (Direct, station mode, and soft-AP) via Atmel ATWILC1000B module Display Interface – LVDS connected to FPGA USB – 1x USB 2.0 host, 1x USB 2.0 device Expansion Connectors Wired interfaces – RS232, CAN 2.0 A/B, KNX, RS-485/422, etc… Wireless connectivity – Zigbee, Z-Wave, KNX RF, etc… Power Supply – 5V DC […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 24 Comments on $98 Geek Force Mediatek MT7623 Router Board Features 6 GbE Ports, 3 mPCIe Slots for WiFi, 3G, or LTE (Crowdfunding)

$98 Geek Force Mediatek MT7623 Router Board Features 6 GbE Ports, 3 mPCIe Slots for WiFi, 3G, or LTE (Crowdfunding)

We’ve seen a few interesting and relatively powerful router board launched last year, with the likes of MQMaker WiTi or Turris Omnia, AsiaRF has now designed Geek Force board powered by Mediatek MT7623N/MT7623A quad core network processor combined with 2GB RAM, six Gigabit Ethernet ports, and optional 802.11ac and 3G connectivity via the three mPCIe slots available on the board. The board also features two HDMI ports, and supports multimedia capabilities such as H.264, MPEG-2, or VC-1 hardware video decoding. Geek Force board preliminary specifications: SoC – MediaTek MT7623A or MT7623N quad-core ARM Cotex-A7 @ 1.3GHz with Mali-450MP GPU (MT7623N only) System Memory – 2GB DDR3 Storage – 2GB eMMC or NAND Flash + SD card slot up to 128 GB, and maybe SATA via the mPCIe slots Connectivity – 6 Gigabit Ethernet ports (WAN / LAN behavior defined by firmware), 802.11 b/g/n WiFi & Bluetooth 4.0 via MT6625L with […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 17 Comments on Zsun Wifi Card Reader Can Now Run OpenWrt

Zsun Wifi Card Reader Can Now Run OpenWrt

Zsun Wifi card reader is a tiny micro SD card reader with WiFi connectivity, and while people managed to access the device serial console a few months ago, the plan was to eventually run OpenWrt since it’s based on the popular Atheros AR9331 WiSoC combined with 64MB RAM and 16MB SPI Flash. It would also be one the smallest OpenWrt capable device with dimensions of 30 x 33 mm. A team of Polish managed this feat, and have now posted instructions to install OpenWrt, as well as other documentation, for example a description of the board’s GPIOs. There are four methods to flash OpenWrt: Solder on an Ethernet jack and flash from the original uboot (hard but safe) Reflash the bootloader from the original firmware to one that supports upload over serial (less soldering but fatal if you mess up) Reflash the firmware from the original firmware using mtd_write (easy […]
