March 11, 2025 by Debashis Das - No Comments

Infineon PSoC 4000T multi-sense low-power MCU features capacitive, inductive, hover, and non-contact liquid sensing

Infineon 4000T multi sense low power MCU

Infineon Technologies has introduced the PSoC 4000T Multi-Sense low-power MCU, along with the upcoming PSoC 4100T Plus which will feature higher memory and more I/Os. These MCUs integrate fifth-generation CAPSENSE technology along with Multi-Sense capabilities, including proprietary inductive sensing, and non-contact liquid sensing solutions. This combination makes it easy to develop advanced HMI applications, such as touch-over-metal, hover touch, and accurate liquid-level detection. The MCU also supports SmartSense auto-tuning which eliminates manual calibration. It supports Always-On sensing with 10x lower power consumption and 10x higher SNR than previous generations. Additionally, the MCU enables hover touch detection through 2 cm air gaps and supports capacitive, inductive, and liquid sensing in a single device. The device also supports waterproofing for harsh environments and reduces system complexity and cost by integrating multiple sensing technologies into a single chip. Infineon PSoC 4000T specifications: MCU Core – 48 MHz Arm Cortex-M0+ CPU Memory – Up […]

October 29, 2024October 31, 2024 by Debashis Das - 4 Comments

CodeCell is a ESP32-C3 mini development board for robots, wearables, smart home projects

CodeCell ESP32 C3 mini development board

Engineer and YouTuber Carl Bugeja recently developed CodeCell, a tiny ESP32-C3 development board designed as the brain for robots, wearables, and smart home devices. This module features a nine-axis inertial measurement unit (IMU) for motion fusion and an optional VCNL4040 light sensor. It includes a USB Type-C port for data and power as well as a lithium-polymer battery with a charging circuit. Measuring just 18.5 x 18.5mm this compact board is even smaller than other tiny ESP32 development boards such as Waveshare’s ESP32-S3-Zero and Seeed Studio’s XIAO ESP32S3. However, the Epi C3 is smaller at 23 x 12.75 mm, and so are the Unexpected Maker NANOS3 (25 x 10 mm) and Unexpected Maker OMGS3 (28 x 11 mm). CodeCel ESP32-C3 mini development board specification Microcontroller – ESP32-C3 RISC-V MCU 160MHz 32-bit RISC-V processor core 400kB SRAM, 4MB flash storage Wi-Fi 4 and Bluetooth Low Energy (BLE) connectivity Sensors Vishay VCNL4040 light […]

October 24, 2024November 25, 2024 by Debashis Das - No Comments

Renesas CCE4511 IO-Link master IC and ZSSC3286 IO-Link sensor signal conditioner IC are designed for industrial sensors and actuators

Renesas CCE4511 and ZSSC3286 IO Link ICs

Renesas has recently introduced the CCE4511 four-channel IO-Link master IC and the ZSSC3286 IO-Link-ready dual-channel sensor signal conditioner IC along with their development boards designed for harsh industrial environments. The CCE4511 master IC supports four channels with 500mA driving current, overvoltage detection, and overcurrent protection, Additionally, it has an integrated IO-Link Frame Handler that reduces microcontroller load. The ZSSC3286on is the first sensor signal conditioner with an integrated IO-Link compliant stack, meaning you don’t need a separate microcontroller for signal handling. Additionally, it features 24-bit ADCs and advanced diagnostic functions for advanced tasks. Both products are optimized for industrial automation, offering energy efficiency, smaller PCB sizes, and robust system diagnostics. CCE4511 IO-Link master and ZSSC3286 sensor signal conditioner IC Specifications CCE4511 IO-Link master Main Chip – CCE4511 4-Channel IO-Link Master PHY with integrated Frame Handler Number of Channels – 4 IO-Link master channels Frame Handler – Hardware frame handler for […]

September 19, 2024September 19, 2024 by Tomisin Olujinmi - 1 Comment

SparkFun’s $125 “Indoor Air Quality Combo Sensor” combines the SCD41 and SEN55 environmental sensors

SparkFun has released a new air quality multi-sensor board, the Indoor Air Quality Combo Sensor, which integrates the SCD41 and SEN55 sensors from Sensirion for measuring carbon dioxide, volatile organic compounds (VOCs), particulate matter, relative humidity, and temperature. The air quality multi-sensor board simplifies power management for the two sensors via onboard DC voltage conversion and allows a single Qwiic connection for power and communication. It features two Qwiic connectors and a 0.1”-space through-hole header for I2C and power. The board is not a complete solution for indoor air quality monitoring. It has to be connected to a Qwiic-enabled microcontroller such as SparkFun Thing Plus Matter, DataLogger IoT, and the ESP32 Qwiic Pro Mini. Users can install the required Arduino libraries — the Arduino Core library, Sensirion I2C SEN5x, and SparkFun SCD4x — either via the Arduino library manager or directly from SparkFun. The device is open-source, with hardware files, […]

February 28, 2024February 28, 2024 by Tomisin Olujinmi - 5 Comments

STMicro VL53L9 is a high-resolution, direct Time-of-Flight 3D LiDAR sensor module

The STMicro VL53L9 sensor is the latest addition to the company’s FlightSense product family. The direct Time-of-Flight (ToF) 3D LIDAR (light detection and ranging) sensor offers a resolution of up to 2,300 zones. The module is described as all-in-one and easy to integrate. It comes in a small, reflowable package that contains all the necessary components for sensing objects and processing images. The sensor features an array of single photon avalanche diodes (SPADs) for photon detection, a post-processing SoC, and two vertical surface emitting lasers (VCSELs) powered by a dedicated bipolar-CMOS-DMOS (BCD) VCSEL. The VL53L9 is a multi-zone ToF sensor similar to the VL53L7CX and the VL53L8, meaning that it offers multi-zone distance measurements up to 54 x 42 zones with a wide 54° x 42° field-of-view. Unlike most IR sensors, the VL53L9 sensor uses backside illumination direct ToF technology to ensure absolute distance measurement, regardless of the target color […]

August 11, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

AquaPing is an open-source, battery powered acoustic water leak detector module (Crowdfunding)

The AquaPing is an open-source hardware, ultra-low power acoustic water leak detector sensor based on Texas Instruments MSP430 microcontroller and a microphone that can detect leaks without having to do any plumbing, instead capturing audio for water leak detection, and it even works for leaks behind walls. All signal processing and analysis occur on the MSP430 MCU, so no audio is streamed to the cloud and eavesdropping is impossible, plus the sensor only captures high frequencies out of the range of normal conversations, so eavesdropping is not feasible, plus those higher frequencies are also said to provide highest sensitivity and reliability. AquaPing specifications: MCU – Texas Instruments MSP430FR5994 microcontroller to perform FFT spectral analysis (10x faster/efficient than ARM-Cortex M0+) Audio capture – MEMS microphone covered by a small rectangular plastic structure to form a Helmholtz resonator. Minimum detectable leak rate – 0.01 gpm (gallon per minute) depending on stand-off distance […]

April 12, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

RAKwireless adds more Wisduo and Wisblock modules, launches WisToolBox configuration tool for IoT devices

RAKwireless have launched several Wisduo wireless modules, a dozen of Wisblock modules for IoT prototyping, updated WisDM, WisGateOS, and RUI3 software, and introduced WisToolBox mobile/desktop configuration tool for IoT devices as part of their spring launch 2022 even entitled “Empowering the Innovators: Making IoT your own”. Three new Wisduo modules RAK3172-SIP WisDuo SIP based on STM32WLE5 Wireless SoC with LoRa connectivity. Compared to the original RAK3172, it offers more IO pins, integrates a TCXO, and comes in a smaller size. The module supports LoRa P2P and complies with Class A, B, & C of LoRaWAN 1.0.3 specifications. Cost: $5.99. WisDuo RAK3272-SiP – That’s a breakout board for the RAK3172-SiP System-in-a-Package module for LoRaWAN and allows easy access to all pins via 2.54mm pitch headers. RAK4630 WisDuo Stamp Module – This module supports both LoRa/LoRaWAN and BLE 5.0, and comes with RUI V3 (RUI3) firmware. It can be deployed as an […]

February 25, 2022February 25, 2022 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

Dragino LDS02 LoRaWAN door and window sensor offers long range and battery life

Dragino LDS02 LoRaWAN door & window sensor

Home automation usually relies on short-range wireless standards such as Bluetooth LE, Zigbee, or WiFi, sometimes with the help of repeaters for larger houses. But if you need to monitor large houses, several houses on a piece of land, or apartments, you’d be glad that you can also do so, at least for doors and windows, with LoRaWAN using Dragino LDS02 sensor. The LDS02 sensor will work like your typical wireless door/window sensor, detection when those are opened and closed, and for how long, but will offer a much longer range of up to 2km in urban settings, as well as battery life meaning it could last for years depending on the frequency of door/window events, as well as uplink frequency configuration. Dragino LDS02 LoRaWAN door sensor specifications: Based on SX1262 LoRa transceiver LoRaWAN v1.0.3 Class A Bands – CN470, EU433, KR920, US915, EU868, AS923, AU915, IN865 Door Open/Close detection […]
