server

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Zimaboard 2 – An Intel N150 micro server and mini PC with dual SATA, dual 2.5GbE, PCIe slot, miniDP (Crowdfunding)

Zimaboard 2 – An Intel N150 micro server and mini PC with dual SATA, dual 2.5GbE, PCIe slot, miniDP (Crowdfunding)

ZImaboard 2

ZimaBoard 2 is a compact Intel Processor N150 “Twin Lake” mini PC and micro server with two 2.5Gbps Ethernet ports, two SATA ports, two USB 3.1 ports, and a 4K-capable miniDP video output. It built upon the company’s ZimaBoard introduced in 2021 with an Apollo Lake processor, but offers a much faster Intel N150 CPU, LPDDR5x memory, 2.5GbE networking instead of gigabit Ethernet, and a PCIe Gen 3.0 x4 slot as opposed to a PCIe Gen 2.0 x4 slot. Two variants are offered: one with 8GB RAM and 32GB eMMC flash and the other in a 16GB/64GB configuration. Zimaboard 2 specifications: SoC – Intel Processor N150 quad-core “Twin Lake” processor  @ up to 3.6 GHz (Turbo) with 6MB cache, 24EU Intel UHD graphics @ 1000 MHz; PBP: 6W (but set to 10W here) System Memory and Storage ZimaBoard 2 832 – 8GB LPDDR5X 4800MHz; 32GB eMMC flash ZimaBoard 2 1664 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Openviro Axe PoE is an RP2040-based environmental sensor for server rooms and cabinets (Crowdfunding)

Openviro Axe PoE is an RP2040-based environmental sensor for server rooms and cabinets (Crowdfunding)

OPENVIRO Axe PoE

Openviro Axe PoE is a rack-mountable, open-source environmental sensor designed to measure the temperature and humidity (and air pressure) in server rooms or cabinets with electrical equipment. The device is based on a Raspberry Pi RP2040 board with Ethernet connectivity housed in an aluminum enclosure and equipped with two RJ12 connectors for Bosch BME280 sensors with an accuracy of +/- 0.5°C. It provides better results than sensors placed in a machine that may be impacted by the internal components’ heat dissipation. For instance, the two sensor inputs can be used to measure the temperature and humidity of the intake and exhaust in a server rack. Openviro Axe PoE specifications: Microcontroller – Raspberry Pi RP2040 dual Arm Cortex-M0+ @133 MHz with 264 KB SRAM Storage – 16 MB flash memory Network – 10/100Mbps Ethernet RJ45 port via LAN8710Ai Expansion – 2x RJ12 connector for THP Probes Misc – 3x Buttons Power […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Build a four-wheel RC car with ESP32-CAM board and off-the-shelf parts

Build a four-wheel RC car with ESP32-CAM board and off-the-shelf parts

ESP32 CAM robot car with off-the-shelf parts

While there are plenty of ESP32-based wireless-controlled robot cars with a built-in camera, like the PiCar-X 2.0 or Zeus Car, it might be more fun and rewarding to build something yourself. That’s exactly what Matt Sroufe did by building his own RC car using off-the-shelf parts and an ESP32-CAM board and writing firmware for it. To get started with the build, you’ll need six main components: A 4-wheel car chassis – $47.49 on AliExpress Electronic speed controller  – $5.27 on AliExpress. Matt selected the 30A version with green PCB. Dual-battery holder for about $2 on AliExpress 2x 18650 3.6V cells or 7.4V batteries purchased locally ESP32-CAM board with an external antenna and the 160° FoV camera – About $14 with board, camera, and external antenna. Bluetooth gamepad such as a PS4 controller The total should be around $80 with the batteries assuming you already own a Bluetooth gamepad. You’ll need […]

Posted on by Sayantan Nandy - 4 Comments on Luckfox Pico WebBee – A Rockchip RV1103 USB & Ethernet development board for web servers, scripting, and Smart Home applications

Luckfox Pico WebBee – A Rockchip RV1103 USB & Ethernet development board for web servers, scripting, and Smart Home applications

Luckfox Pico WebBee Rockchip RV1103 development board

Luckfox has launched the Pico WebBee, a Linux-based micro development board powered by the Rockchip RV1103 Cortex-A7 SoC with 64MB of on-chip RAM. Externally, the Pico WebBee resembles a USB dongle enclosed in an ABS case with a USB Type-A port and a 100Mbps Ethernet RJ45 port. Additionally, it includes an internal microSD card slot and a boot button. The board is designed for applications such as lightweight web servers, USB scripting tools, and smart home devices. It’s not quite the first Rockchip RV1103 solution from Luckfox, as we previously covered the Luckfox Pico Mini Arm Linux camera board and the Luckfox Pico Plus camera board with an Ethernet port. The Pico WebBeee is quite different in its form factor (it’s a complete device), and it also lacks a camera interface. Luckfox Pico WebBee specifications: SoC – Rockchip RV1103 G1 CPU – Single-core Arm Cortex-A7 processor @ 1.2GHz + RISC-V […]

Posted on by Debashis Das - No Comments on Firefly’s CSB1-N10 series AI cluster servers can deliver up to 1000 TOPS of AI power with Rockchip or NVIDIA Jetson Modules

Firefly’s CSB1-N10 series AI cluster servers can deliver up to 1000 TOPS of AI power with Rockchip or NVIDIA Jetson Modules

CSB1 N10 series AI cluster servers

Firefly has recently introduced the CSB1-N10 series AI cluster servers designed for applications such as natural language processing, robotics, and image generation. These 1U rack-mounted servers are ideal for data centers, private servers, and edge deployments. The servers have multiple computing nodes, featuring either energy-efficient processors (Rockchip RK3588, RK3576, or SOPHON BM1688) or high-performance NVIDIA Jetson modules (Orin Nano, Orin NX). With 60 to 1000 TOPS AI power, the CSB1-N10 servers can handle the demands of large AI models, including language models like Gemma-2B and Llama3, as well as visual models like EfficientVIT and Stable Diffusion. CSB1-N10 series specifications All CSB1-N10 AI servers have the same interfaces, and the only differences are the CPU, memory, storage, multimedia, AI capabilities, and related software support. So it’s likely Firefly has made Rockchip system-on-modules compatible with NVIDIA Jetson SO-DIMM form factor, and indeed we previously noted that Firefly designed Core-1688JD4, Core-3576JD4, or Core-3588JD4 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 10 Comments on iKOOLCORE R2 Max Alder Lake-N mini PC/server features two 10GbE and two 2.5GbE ports

iKOOLCORE R2 Max Alder Lake-N mini PC/server features two 10GbE and two 2.5GbE ports

iKOOLCORE R2 Max

The iKOOLCORE R2 Max is an Alder Lake-N-powered firewall/gateway/server/mini PC that is offered with either an Intel Processor N100 or Core i3-N305 CPU, and equipped with two 10GbE ports and two 2.5GbE ports. It builds upon the iKOOLCORE R2 mini PC and router which we reviewed with Promox VE, Ubuntu 22.04, and pfSense and features four 2.5GbE ports in a smaller form factor. The new R2 Max model uses the N100/Core i3-N305 CPU instead of the N95/Core i3-N300, supports up to 48GB SO-DIMM memory, features a wider yet thinner design, and provides support for both 10GbE and 2.5GbE networking. iKOOCORE R2 Max specifications: Alder Lake-N SoC Intel Processor N100 quad-core processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel UHD graphics; TDP: 6W Intel Core i3-N305 octa-core processor @ up to 3.8 GHz (Turbo) with 6MB cache, 32EU Intel UHD Graphics; TDP: 15W System Memory – 8GB, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 7 Comments on $20 Zigbee & Z-Wave mPCIe module targets Home Assistant gateways

$20 Zigbee & Z-Wave mPCIe module targets Home Assistant gateways

Mixtile Zigbee Z Wave mini PCIe module

Mixtile’s “2-in-1 Zigbee & Z-Wave mPCIe module” is a relatively inexpensive way to add Zigbee and Z-Wave connectivity to a Home Assistant server without having USB dongles sticking out of the server and taking some of its spare USB ports. The module is compatible with any computer, gateway, or SBC with a spare mini PCIe socket featuring a USB 2.0 interface such as Rockchip RK3568-powered Mixtile Edge 2 Kit gateway. You’ll also need some way of mounting the antennas after connecting them to the IPEX-1 antenna connectors on the module, the Edge 2 Kit comes with multiple antenna holes. Mixtile 2-in-1 Zigbee & Z-Wave mPCIe module specifications: Wireless MCUs Silabs EFR32MG24 Arm Cortex-M33 @ 78.0 MHz with 256 kB RAM, 1536 kB flash Radio Frequency – 2.4 GHz (802.15.4 radio) TX Power – up to +19.5 dBm RX sensitivity – -105.4 dBm at 250 kbps Protocols – Zigbee, Matter, Thread […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Simply NUC extremeEDGE fanless edge computing servers are powered by Intel Celeron N5105 up to AMD Ryzen 7 Pro 8840U CPUs

Simply NUC extremeEDGE fanless edge computing servers are powered by Intel Celeron N5105 up to AMD Ryzen 7 Pro 8840U CPUs

Simply NUC extremeEdge servers

Simply NUC has unveiled the extremeEDGE fanless servers designed with edge computing with a wide range of processors starting with an Intel Celeron N5105 and going up to an AMD Ryzen 7 Pro 8840U SoCs with options for Intel Processor N100 and AMD Ryzen Embedded CPUs. All models feature a NANO-BMC (Baseboard Management Controller) for out-of-band management in a small form factor to monitor, control, and manage hardware health and performance, and come with at least two 2.5GbE ports for networking. The top-end edgeExtreme 3000 series can operate in the industrial-grade -40 to +85°C temperature range, and offers extra features such as 10GbE, up to 96GB RAM, multiple USB 3.2 ports, and more. The extremeEDGE lineup offers three series, and eight models, designed to meet specific needs: extremeEDGE 1000 Series for Edge applications such as IoT gateways EE-1000 Series – Intel Celeron N5105 with up to 32 GB RAM, up […]
