Raspberry Pi releases PCIe FFC connector specifications, new HAT+ standard

Raspberry Pi 5 PCIe pinout and FFC cable

Raspberry Pi has released two new specifications one for the PCIe FFC connector and related cable and the other for the new Raspberry Pi HAT+ (HAT Plus) standard that’s simpler, takes into account new features in Raspberry Pi 4/5, and has fewer rules around mechanical dimensions. PCIe FFC connector specifications The Raspberry Pi 5 was announced over 2 months ago with a new PCIe FFC connector, and people may been playing around with it and even launching products such as an M.2 HAT for the Raspberry Pi 5 since then even though the pinout and specifications were not available. But Raspberry Pi has now released the specifications (PDF) for the PCIe FFC found in the Raspberry Pi 5 and likely future models as well. The 16-pin 0.5mm pitch FFC connector features a single lane PCIe interface, something we knew already, but the pinout diagram and recommendations for the FFC cable […]

FCC and NIST unveils the Cyber Trust Mark, a voluntary US IoT security label

Cyber Trust Mark

Representatives of the Federal Communications Commission (FCC) and the National Institute of Standards and Technology (NIST) have recently unveiled a U.S. national IoT security label at the White House called the “U.S. Cyber Trust Mark” to inform consumers about the security, safety, and privacy of a specific IoT and Smart Home device. IoT security has been a problem for years with routers shipping with telnet enabled with default usernames and passwords, vulnerabilities in SDKs, unencrypted passwords transmitted over the network, millions of devices with older microcontrollers without built-in hardware security features, etc… There have been industry efforts to solve this such as the Arm PSA initiative, as well as regulations to prevent default usernames/passwords in new devices, but nothing about IoT security that can help a consumer find out if a device is supposed to be secure or not. The Cyber Trust Mark is supposed to address this issue. The […]

LiFi 802.11bb standard uses light for in-room data transmission up to 224GB/s

LiFi 802.11bb

The 802.11bb WiFi-like standard, also called LiFi, was ratified in June 2023. It enables data transmission up to 224GB/s at a few meters range within a room using light instead of RF signals used in most other wireless standards. The technology has been worked on for many years, and we first covered (a version of) LiFi in 2014 that was still part of the IEEE 802.15 standard with speeds up to 1 Gbps. But the Light Communications 802.11bb Task Group was only formed in 2018 chaired by pureLiFi and supported by Fraunhofer HHI, and led to be ratification of the IEEE 802.11bb standard last month. In a typical LiFi setup, you’d have a LiFi-capable router connected to your local network and the Internet, a LiFi-enabled light bulb on a ceiling, and one or more LiFi receivers. From the end-user perspective, it would work like accessing a WiFi access point. We’re […]

Bluetooth 5.4 adds electronic shelf label (ESL) support

Bluetooth 5.4

The Bluetooth Special Interest Group (SIG) has just adopted the Bluetooth 5.4 Core Specification with features such as PAwR and EAD designed for Electronic Shelf Label (ESL) systems. The Bluetooth 5.3 Core Specification was adopted in August 2021 with various improvements, and Bluetooth 5.4 now follows with features that appear to be mainly interesting for large-scale Bluetooth networks with support for bi-directional communication with thousands of end nodes from a single access point, as would be the case for Electronic Shelf Label or Shelf Sensor systems. Four new features have been added to Bluetooth 5.4: Periodic Advertising with Responses (PAwR) – PAwR is a new Bluetooth Low Energy (LE) logical transport that provides a way to perform energy-efficient, bi-directional, communication in a large-scale one-to-many topology with up to up to 32,640 devices. Devices can also be allocated to groups allowing them to listen only to their group’s transmissions. An Electronic […]

The Wi-R protocol relies on body for data communication, consumes up to 100x less than Bluetooth

Wi-R vs Bluetooth

The Wi-R protocol is a non-radiative near-field communication technology that uses Electro-Quasistatic (EQS) fields for communication enabling the body to be used as a conductor and that consumes up to 100x less energy per bit compared to Bluetooth. In a sense, Wi-R combines wireless and wired communication. Wi-R itself only has a wireless range of 5 to 10cm, but since it also uses the body to which the Wi-R device is attached, the range on the conductor is up to 5 meters. While traditional wireless solutions like Bluetooth create a 5 to 10-meter field around a person, the Wi-R protocol creates a body area network (BAN) that could be used to connect a smartphone to a pacemaker, smartwatch, and/or headphones with higher security/privacy and longer battery life.   One of the first Wi-R chips is Ixana YR11 with up to 1Mbps data rate, and they are working on a YR21 […]

Credit card-sized COM-HPC Mini modules to support PCIe Gen4 and Gen5 interfaces


PICMG has announced that the COM-HPC Mini form factor’s pinout and dimensions definitions were finalized, with the tiny credit card-sized modules able to handle PCIe Gen4 and Gen5 interfaces, of course, depending on whether the selected CPU supports those. The COM-HPC “High-Performance Computing” form factor was created a few years ago due to the lack of interfaces on the COM Express form factor with “only” 440 pins and potential issues to handle PCIe Gen 4 clock speeds and throughputs. So far, we had COM-HPC Client Type modules from 95 x 120mm (Size A) to 160 x 120mm (Size C) and Server Type modules with either 160 x 160mm (Size D) or 200 x 160mm (Size E) dimensions. The COM-HPC Mini brings a smaller (95 x 70 mm) credit card-sized form factor to the COM-HPC standard. The way they cut the size of the COM-HPC Size A form factor by half […]

Bluetooth LE to support 6 GHz frequency band

Bluetooth 6 GHz

So far, the popular Bluetooth wireless communication protocol would only rely on the 2.4 GHz frequency band, but this may change in the future, as the Bluetooth Special Interest Group (SIG) has recently announced a new “specification development project” to add the 6 GHz frequency band to Bluetooth LE. Mark Powell, CEO of the Bluetooth SIG “explains” the move: The Bluetooth SIG community is constantly evolving the technology to meet ever expanding market demands for wireless communications. Expanding into the 6 GHz spectrum band will ensure the community can continue to make the enhancements necessary to pave the way for the next twenty years of Bluetooth innovation. I get it that’s a long-term move, but it does not explain exactly why the additional 6 GHz (and 5 GHz) bands may be necessary. I’d just suspect as more devices such as BLE sensors get more widely added that adds to the […]

USB4 Version 2.0 to enable speeds of up to 80 Gbps, introduce “active” USB cables

USB4 Version 2 80Gbps

The USB Promoter Group has just pushed a press release about the “pending release” of the USB4 Version 2.0 specification that promises up to 80 Gbps of data performance over the USB Type-C cable and connector. The group also explains both the USB Type-C and USB Power Delivery (USB PD) specifications will also be updated, and everything will be published right before the USB DevDays developer events planned for November 2022 in the US and South Korea. So that’s basically an announcement about a future announcement, but we were still provided with some highlights of the upcoming USB4 v2 specification: Up to 80 Gbps operation based on a new physical layer architecture, using existing 40 Gbps USB Type-C passive cables and newly-defined 80 Gbps USB Type-C active cables. Updates to data and display protocols to better use the increase in available bandwidth. USB data architecture updates now enable USB 3.2 […]
