reTerminal – A Raspberry Pi CM4 based 5-inch HMI Terminal

reTerminal Raspberry Pi CM4 console

Seeed Studio has just unveiled reTerminal HMI terminal that reminds me of the company’s Wio Terminal based on Microchip SAMD51 Arm Cortex-M4F microcontroller with a 2.4-inch display. But as we’ll look into the details, reTerminal is quite a different beast as a Linux-capable device powered by a Raspberry Pi CM4 module with up to 8GB RAM, equipped with a 5-inch capacitive touchscreen display, and supporting plenty of connectivity options from GIgabit Ethernet to WiFi to LoRaWAN. reTerminal specifications: SoM – Raspberry Pi Computer Module 4 with Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5 GHz, up to 8GB RAM, up to 32GB flash Display – 5-inch capacitive touchscreen display with 1280×720 resolution Video Output – Micro HDMI port up to 4Kp60 Camera I/F – 2-lane MIPI CSI inteface Connectivity Gigabit Ethernet with optional PoE support 802.11 b/g/n/ac WiFi and Bluetooth 5.0 BLE (on Raspberry Pi CM4 module) Optional 5G, 4G LTE, LoRa, Sub-GHz wireless, etc… USB – 2x USB 2.0 ports […]

Rugged, fanless quad-camera system brings AI and Machine Vision to rolling stock and automotive applications

quad-camera system automotive AI & machine vision

Eurotech BoltGPU 10-31 is a rugged fanless embedded system powered by NVIDIA Jetson Xavier NX module, equipped with four FAKRA connectors for GMSL camera, and designed to bring Edge AI and machine vision to rolling stock (e.g. trains) and automotive applications. The BoltGPU 10-31 also features 16 GB of eMMC flash, NVMe SSD support, three Gigabit Ethernet interfaces, WiFI 6 and Bluetooth 5.1, two USB3.1 ports, as well as isolated CAN-FD,  optoisolated DIO,  video out, and GNSS with optional RTK. BoltGPU 10-31 specifications: System-on-Module – NVIDIA Jetson Xavier NX with hexa-core NVIDIA Carmel ARM v8.2 64-bit CPU with 6MB L2 + 4MB L3 cache, 384-core NVIDIA Volt GPU with 48 Tensor Cores (up to 21 TOPS of accelerated computing), 8 GB LPDDR4x RAM, 16GB eMMC 5.1 flash Storage MicroSD card socket Optional 512 GB NVMe SSD on M.2 Key M socket 256 Kbit Serial EEPROM Video Output – 1x Mini DisplayPort Camera Input – 4x GMSL (1.5Gbps to CSI-2) FAKRA […]

Edge AI and robotics embedded computers feature NVIDIA Jetson TX2 NX module

NVIDIA Jetson TX2 NX computers

NVIDIA unveiled a cost-down version of the Jetson TX2 module with the Jetson TX2 NX SO-DIMM system-on-module last month, and AAEON is one of the first companies to have updated some of their products with the new module. AAEON’s BOXER-823x-series of fanless embedded computers feature the NVIDIA Jetson TX2 NX module, and multiple Ethernet ports, including some PoE capable for the development of edge AI and robotics applications. BOXER-8230AI AI Edge Fanless Embedded Box PC This model offers a mid-range alternative between the Jetson Xavier AGX NX-based BOXER-8250AI embedded box PC and the Jetson Nano-powered BOXER-8220AI mini PC both of which offer the same ports. BOXER-8230AI specifications: SoM (CPU/Memory/Storage) – NVIDIA Jetson TX2 NX with dual-core NVIDIA Denver 2 64-Bit CPU and quad-core Arm Cortex-A57 MPCore processor @ up to 2.0 GHz, 256-core NVIDIA Pascal GPU @ up to 1.3 GHz, 4GB LPDDR4, 16GB eMMC flash Storage – MicroSD card slot, SATA III port for 2.5-inch drive (for high version) […]

Linux and Memory Performance on an Intel NUC 11 Enthusiast Phantom Canyon NUC11PHKi7C

nuc11phki7c Linux

I’ve already looked at Windows performance on the NUC11PHKi7C Enthusiast Phantom Canyon which is Intel’s latest NUC 11 flagship product specifically targeting gamers as it includes an NVIDIA RTX 2060 GPU. Now it is the turn of Linux and like before I will compare performance against Intel’s previous NUC with a discrete GPU: the NUC 9 Extreme Ghost Canyon. I will also briefly revisit Windows performance by looking at the impact of using 3200MHz memory as opposed to the 2400MHz used during the previous review. Hardware Overview As a reminder, the NUC11PHKi7C physically consists of a 221 x 142 x 42 mm (8.70 x 5.59 x 1.65 inches) rectangular plastic case. It is an actively cooled mini PC and uses Intel’s 10 nm Core i7-1165G7 Tiger Lake processor which is a quad-core 8-thread 2.80 GHz processor boosting to 4.70 GHz with Intel’s Iris Xe Graphics and the NUC also includes an NVIDIA N18E-G1-B notebook graphics card which is a GeForce […]

Station P2 Arm mini PC offers dual GbE, M.2 & SATA SSD, up to 8GB RAM (Crowdfunding)

Rockchip RK3568 mini PC

Last week, we noted Firefly launched the first RK3568 system-on-module with Core-3568J AI Core and a corresponding full-featured development kit. But the company has been working on another interesting Rockchip RK3568 based device with Station P2 mini PC. Most Arm mini PCs need to make compromises when it comes to interfaces having to rely on USB bridges, but Station P2 feels very much like standard x86 based mini PC, albeit with a slower processor, thanks to native interfaces, or implemented through PCIe, with M.2 and SATA 3.0 SSD/HDD, dual Gigabit Ethernet, as well as WiFi 6, several USB 3.0/2.0 ports, and support for up to 8GB RAM among other features. Station P2 mini PC specifications: SoC – Rockchip RK3568 quad-core Cortex-A55 processor @ up to 2.0 GHz with Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, 0.8 TOPS NPU for AI acceleration, 4Kp60 H.265/H.264/VP9 video decoding, and 1080p100 H.265/H.264 video encoding System Memory – […]

Raspberry Pi CM4 Panel PCs offer IP67 protection, 7-inch display

Raspberry Pi CM4 Panel PC

We just have covered Raspberry Pi CM4 in CutiePi 8-inch tablet, but I don’t think I’ve seen the latest Raspberry Pi Compute Module inside a panel PC that typically offers additional interfaces such as Ethernet, RS232, or CAN bus for industrial applications. But today I’m here to write not about just one Raspberry Pi CM4 panel PC, but two from Chipsee and WIN Enterprises all with a 7-inch display, and features like Ethernet, opto-isolated GPIOs, RS485 terminal blocks, etc…, and the Win Enterprises’ model also adds dust and waterproofness with IP67 ingress protection rating. Chipsee CM4-70 Industrial Pi  7-inch Panel PC Chipsee panel PC is offered in two versions with CM4-70-EM model meant to be integrated into the customer’s own chassis, and CM4-70-PA integrating the board and display into a fully assembled panel. Specifications: SoM – Raspberry Pi Compute Module 4 (CM4) with Broadcom BCM2711 quad-core Cortex-A72 processor, 2GB RAM, and 16GB eMMC flash (default) Storage – 2x MicroSD cards, […]

Firefly unveils Core-3568J AI Core Rockchip RK3568 system-on-module & devkit

RK3568 devkit

Firefly has unveiled a new 314-pin SO-DIMM system-on-module (SoM) with Core-3568J AI Core powered by Rockchip RK3568 processor and equipped with up to 8GB RAM, 128GB eMMC flash with interfaces including PCIe, SATA, dual Gigabit Ethernet, HDMI 2.0, eDP 1.3, MIPI DSI and more. The company also provides a development kit for the module with all those interfaces plus an M.2 socket for 5G or WiFi 6 connectivity, and PoE support among other features. Core-3568J AI Core system-on-module Specifications: SoC – Rockchip RK3568 quad-core Cortex-A55 processor @ 2.0 GHz with Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, 0.8 TOPS NPU for AI acceleration, 4Kp60 H.265/H.264/VP9 video decoding, and 1080p100 H.265/H.264 video encoding System Memory – 2GB, 4GB, or 8GB LPDDR4 ECC RAM up to 1600 MHz Storage – 32GB, 64GB, or 128GB eMMC flash 314-pin SO-DIMM edge connector with: Storage – SATA 3.0 interface, SD card interface Display I/F HDMI 2.0 up to […]

Zymbit HSM4 & HSM6 security modules work with embedded Linux hardware, Raspberry Pi, Jetson Nano

Zymbit HSM4

Zymbit Zymkey security modules, now called Zymkey4i, were first introduced several years ago. Based on the Microchip ATECC508A CryptoAuthentication chip, the modules were available as a USB stick, an I2C module for Raspberry Pi boards, or an SMT component, and designed to enable multifactor device ID & authentication, data encryption & signing, key storage & generation, and physical tamper detection. The company has now informed CNX Software they had launched HSM4 cryptographic protection module and HSM6 hardware wallet with a different form factor for easy integration into embedded applications, and devkits compatible with Jetson Nano and Raspberry Pi SBCs. Zymbit HSM4 cryptographic protection module & devkit HSM4 crypto module key features and specifications: HSM4 is built upon Zymkey4i module, and integrates an Arm Cortex-M0 microcontroller, as well as a secure element likely to be Microchip ATECC508A, or the more recent ATECC608B CryptoAuthentication chip if the company upgrade System Identity & Authentication Unique ID created from multiple device-specific measurements. Authentication required […]
