Posted on by Jean-Luc Aufranc (CNXSoft) - 11 Comments on Giveaway Week 2023 winners announced!

Giveaway Week 2023 winners announced!

CNX Software Giveaway Week 2023 Prizes

CNX Software’s Giveaway Week 2023 is now over and we’re ready to announce the winners. We offered some of the review samples we tested (or not) in the last year, and like the last two years, we were also joined by RAKwireless who offered two IoT development kits. All items given away are shown in the photo below, minus some accessories, and if you count more than seven you’d be right, as some are kits with multiple items like the GL.iNet GL-S200 Thread Border router which comes with three development boards, and more importantly, we also organized Giveaway Week on CNX Software Thailand for the second year running. We had seven winners on CNX Software: VOIPAC iMX8M industrial development kit – Kraingsak, Thailand TBS7901 mini PCIe DVB-S2X/S2 module  – Frank, Singapore RAKWireless WisBlock IoT Starter Kit – Andy, Russia GL.iNet GL-S200 Thread Border router kit – Augustin, Argentina WCH CH583M-R0-1v1 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 135 Comments on Giveaway Week 2023 – VOIPAC iMX8M industrial development kit

Giveaway Week 2023 – VOIPAC iMX8M industrial development kit

VOIPAC IMX8M Industrial Development Kit Review

The 10th edition of CNX Software giveaway week is on! We’ll have seven items to give away this time around: six items that I will send myself from my review samples and one from a company that will offer one of its own IoT development kits… We’ll start this year’s giveaway week with the VOIPAC iMX8M industrial development kit equipped with an “iMX8M Industrial Pro” system-on-module powered by an NXP i.MX 8M quad-core Cortex-A53 processor, fitted with 2GB RAM, 16GB eMMC flash, and a WiFi and Bluetooth module. The VOIPAC iMX8M industrial development kit is quite a feature-rich development board whose main purpose is to evaluate the company’s system-on-module for integration into final products. I tested it last summer showing how to get started with the Yocto BSP by building the image from scratch, booting from the eMMC flash or a microSD card, and testing several features such as networking, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Getting started with VOIPAC IMX8M Industrial development kit (Yocto Linux SDK)

Getting started with VOIPAC IMX8M Industrial development kit (Yocto Linux SDK)

VOIPAC IMX8M Developer Kit Audio Testing

Last month I went through an unboxing of the VOIPAC iMX8M Industrial Development Kit with some specs and a quick try with the pre-loaded Yocto 3.1 Linux image. The kit is quite versatile with plenty of interfaces and headers, and eventually, it will support Android 12 and Ubuntu 22.04 LTS. but in the meantime, I played a bit with the Yocto Linux SDK for the NXP i.MX 8M board and will report by experience getting started with VOIPAC IMX8M Industrial development kit. WiFi antennas installation But before checking out Yocto Linux, I will install the two WiFi antennas since I did not do it last time around. We can attach the SMA connectors to the two metal plates on the side of the board securing them with the provided nuts and spacers. The other side of the antenna’s cable comes with a tiny u.FL (or is it MHF4) connector and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on OpenRex Open Source Hardware NXP i.MX6 Board Launched for 199 Euros and Up

OpenRex Open Source Hardware NXP i.MX6 Board Launched for 199 Euros and Up

OpenRex is an open source hardware board powered by NXP i.MX6 Cortex A9 processor designed by Fedevel for their hardware design course, and manufactured by Voipac, both companies based on Slovakia. The schematics, PCB layout, gerber files and other manufacturing files were released in February, but the company has only started selling the board a few days ago with OpenRex Basic SBC and OpenRex Max SBC boards. OpenRex Basic and Max boards specifications: SoC OpenRex Basic – NXP i.MX 6Solo single core Cortex A9 processor @ 1 GHz with 2D and 3D GPU OpenRex Max – NXP i.MX 6Quad quad core Cortex A9 processor @ 1 GHz with 2D and 3D GPU MCU – NXP LPC1345FHN33 ARM Cortex-M3 micro-controller @ 72 MHz System Memory Basic – 512 MB DDR3-1066 (400MHz) Max – 2GB DDR3-1066 (533 MHz) Storage Basic – micro SD slot, 1x 2Kbit I2C EEPROM, 1x 32Mbit SPI flash Max […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 12 Comments on OpenRex NXP I.MX6 Open Source Hardware Board Design Files Released

OpenRex NXP I.MX6 Open Source Hardware Board Design Files Released

OpenRex is an open source hardware board powered by NXP i.MX6 designed by Fedevel, and the company has announced the release of Altium project design files including both schematics and PCB layout source files, as well as manufacturing documentation. OpenRex board specifications: SoC – NXP i.MX6 processor @ up to 4 cores @ 1.2GHz with 2D and 3D GPU MCU – NXP LPC1345FHN33 ARM Cortex-M3 micro-controller System Memory – DDR3-1066 (533MHz) up to 4GB Storage – SATA, micro SD slot, 1x I2C EEPROM, 1x SPI FLASH Video Output / Display I/F – 1x HDMI up to 2048×1536 resolution, LVDS, parallel RGB display output, touchscreen connector (Optional 4x Analog input) Audio – HDMI output, 3.5mm stereo headphone jack, Camera – 1x Parallel CSI camera (shared with RGB output), 1x MIPI CSI connector compatible with Raspberry Pi (shared with LVDS) Connectivity – 1x 10/100/1000 Mbps Ethernet USB – 2x USB 2.0 host […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on iMX6 TinyRex Module and Development Board Support HDMI Input in Linux (Video Demo)

iMX6 TinyRex Module and Development Board Support HDMI Input in Linux (Video Demo)

A couple of years ago, I wrote about iMX6 Rex open source hardware project combining a Freescale i.MX6 SoM and baseboard that aimed a teaching hardware design (schematics and PCB layout). I had not followed the project very closely since then, until I watched a video showcasing HDMI input capabilities in Linux using the new version of the module and baseboard called i.MX6 TinyRex. i.MX6 Tiny Rex module specifications: SoC – Freescale iMX6 processor up to 1.2GHz and 4 cores System Memory – Up to 4GB DDR3-1066 (533MHz) Storage – EEPROM Connectivity – 10/100/1000 Mbps Ethernet PHY I/Os via 3 board to board connectors: Display / Video Output 1x HDMI (up to QXGA 2048×1536) 1x LVDS (up to WUXGA 1920×1200) 1x 20-bit parallel LCD display (up to WXGA 1366×768) or 1x Video Input (CSI) 1x MIPI DSI differential display output (up to XVGA 1024×768) Video Input 1x 20-bit parallel video input […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 10 Comments on iMX6 Rex Open Source Hardware SoM and Baseboard Designed to Teach Schematic and PCB Layout Design

iMX6 Rex Open Source Hardware SoM and Baseboard Designed to Teach Schematic and PCB Layout Design

Voipac, a Slovakian manufacturing company, has recently unveiled iMX6 Rex module and iMX6 Rex development baseboard, which have mainly been developed in order to support FEDEVEL Academy Schematic Design and Advanced PCB Layout courses, but can also be used for other purposes. The module is powered by Freescale i.MX6 Dual (Solo and Quad also available on request), and comes with 512MB RAM (upgradeable to 4GB), and up to 32MB SPI flash. The complete hardware will be released under an open source hardware license, but with some caveats as I’ll explain later. iMX6 Rex module specifications (basic configuration): SoC – Freescale iMX6 processor up to 1.2GHz / 2 cores (1 and 4 cores also available) System Memory – 512MB DDR3-1066 (533MHz), up to 4GB Storage – 2MB On board SPI Flash, up to 32MB 10/100/1000 Mbps Ethernet PHY 2 high speed board to board connectors (only one required) with signals for HDMI, […]
