November 19, 2013November 19, 2013 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

iMX6 Rex Open Source Hardware SoM and Baseboard Designed to Teach Schematic and PCB Layout Design

Voipac, a Slovakian manufacturing company, has recently unveiled iMX6 Rex module and iMX6 Rex development baseboard, which have mainly been developed in order to support FEDEVEL Academy Schematic Design and Advanced PCB Layout courses, but can also be used for other purposes. The module is powered by Freescale i.MX6 Dual (Solo and Quad also available on request), and comes with 512MB RAM (upgradeable to 4GB), and up to 32MB SPI flash. The complete hardware will be released under an open source hardware license, but with some caveats as I’ll explain later. iMX6 Rex module specifications (basic configuration): SoC – Freescale iMX6 processor up to 1.2GHz / 2 cores (1 and 4 cores also available) System Memory – 512MB DDR3-1066 (533MHz), up to 4GB Storage – 2MB On board SPI Flash, up to 32MB 10/100/1000 Mbps Ethernet PHY 2 high speed board to board connectors (only one required) with signals for HDMI, […]

November 18, 2013November 18, 2013 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Binwalk Utility Helps You Analyze and Reverse-Engineer Firmware Files

Binwalk is a “firmware analysis tool designed for analyzing, reverse engineering and extracting data contained in firmware images”. This tool written in python supports Linux, and somewhat Mac OS X, can scan firmware files for files signature, and can be useful for hacking firmware files, and finding hidden information. Let’s install binwalk first. It’s very easy in a Debian or Ubuntu machine, as you just have to download the package, and run a script for installation:

wget https://binwalk.googlecode.com/files/binwalk-1.2.2-1.tar.gz
tar xzvf binwalk-1.2.2-1.tar.gz
cd binwalk-1.2.2-1/src
sudo ./debian_quick_install.sh

wget https://binwalk.googlecode.com/files/binwalk-1.2.2-1.tar.gz

tar xzvf binwalk-1.2.2-1.tar.gz

cd binwalk-1.2.2-1/src

sudo ./debian_quick_install.sh

If you have another Linux ditributions, it’s just a little more complicated. You still need to download and extract the release package as above, but you’ll have to install the following package depending on the features your need: Minimal installation – python 2.6 or greater, and python-magic To generate entropy plot graphs – python-matplotlib For automated extraction: Packages – mtd-utils zlib1g-dev liblzma-dev gzip bzip2 tar unrar arj p7zip p7zip-full openjdk-6-jdk Build and install […]

November 18, 2013May 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Olimex Announces 30 Euros A10-OLinuXino-LIME Development Board for December

The Raspberry Pi, Beaglebone Black and Cubieboard are probably the best selling ARM Linux boards in the sub $50 category, but they’ll soon be joined by Olimex A10-OLinuXino-LIME powered by AllWinner A10 ARM Cortex A8 SoC with 512MB RAM that will sell for 30 Euros (About $40) when it becomes available in December. Another version of the board based on AllWinner A20 dual core Cortex A7 SoC, called A20-OLinuXino-LIME will also be sold, adding Gigabit Ethernet, and scheduled for Q1 2014. Pricing has yet to be disclosed for the A20 version. A10-OLinuXino-LIME specifications: SoC – AllWinner A10 ARM Cortex-A8 @ 1GHz with Mali-400 GPU System Memory – 512MB DDR3 Storage – microSD card slot, SATA, and optional 4GB NAND Flash Video Output – HDMI 1080p USB – USB-OTG + 2x USB Hosts Connectivity – 10/100Mbit Ethernet Expansions – 200 GPIOs on 0.05″ connectors Misc – Lipo battery management and connector, […]

November 18, 2013November 21, 2013 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

$90 JynxBox M1 Pure Linux XBMC Network Media Streamer

After The Little Black Box (TLBB), there’s now another ARM based media player that comes pre-installed with XBMC Linux: Jynxbox M1 Pure Linux. The device is based on AMLogic AML8726-M1 single core Cortex A9 processor @ 800MHz, and comes with 2GB flash, Wi-Fi and Ethernet connectivity, HDMI output, and more. Jynxbox M1 Pure Linux specifications: SoC – AMLogic AML8726-M1 single core Cortex A9 @ 800MHz with ARM Mali-400 GPU System Memory – N/A (but likely 512 MB) Storage – 2 GB Nand Flash + micro SD/SDHC memory slot (Up to 32GB) Video Output – HDMI 1.3 Audio Output – HDMI Video container formats – AVI, RM/RMVB, MKV, WMV, MOV, MP4, WEBM, DAT(VCD format), VOB(DVD format), MPEG, MPG, FLV, ASF, TS, TP, 3GP Audio formats – MP3, WMA, WMV, APE, OGG, FLAC, AAC, etc… Connectivity – 10/100M Ethernet + 802.11 b/g/n Wi-Fi USB – 3x USB 2.0 host ports Misc – […]

November 17, 2013 by Jean-Luc Aufranc (CNXSoft) - 20 Comments

ZGPAX S5 Android 4.0 SmartWatch Features a Dual Core Processor, a SIM Card Slot

The newly introduced Samsung Galaxy Gear and Sony SmartWatch all work as a smartphone companion, and have limited use if you don’t carry your smartphone with you. The Samsung watch also requires a recent smartphone running Android 4.3 and supporting Bluetooth Low Energy, which current seriously reduces the list of compatible smartphones. There are already standalone smartwatches in the market that include a SIM card slot, and allow you to make phone calls without a phone such as Z1 watch and WiMe NanoWatch. However, these watches feature low-end hardware with ARM9 processor, so the interface may feel a bit sluggish. ZGPAX S5 smartwatch with its Mediatek MT6577 dual core Cortex A9 processor, and 512 MB RAM, will be much more snappier. It runs Android 4.04 with Google Play Store, and comes with features such as a camera, GPS, as well as Wi-Fi and Bluetooth connectivity. SGPAX S5 Specifications: SoC – […]

November 16, 2013 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

$80 SJ1000 Waterproof Sports Camera is a Low Cost Alternative to GoPro Hero Cameras

I’ve recently learned about GoPro action cameras, waterproof cameras with lots of mounting options and a wide angle lense which allows to shot amazing action full HD videos, and the best selling cameras in the world. Since yesterday I wrote about low cost waterproof smartphone, I thought It might be a good idea to write about other waterproof devices, and look at low cost alternatives to the GoPro. The GoPro Hero3 comes in 3 editions: White Edition, Black Edition, and Silver Edition with prices ranging from $199.99 to $399.99. All camera can record @1080p and come with WiFi connectivity. The more expensive model, Gopro Hero3+ Silver Edition, can also record in UHD, and comes with a WiFi remote. The original GoPro still seem to be good values, but if you have a tight budget, SJ1000 action camera (aka F10) offers similar functionalities (1080p30 recording, wide angle, mounting options, waterproofness, but […]

November 15, 2013November 18, 2013 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

Low Cost Rugged, Waterproof and Dustproof Smartphones Powered by Mediatek Processors

If you need a truly waterproof and dustproof smartphone, the Samsung Galaxy S4 Active, compliant with IP67 standard, is probably the most popular phone with this particular feature. However, the phone sells for nearly $600 on site like Amazon, and it may be nice to have some lower cost options. Today, I’ve come across two smartphones powered by Mediatek dual and quad core SoC that are both compliant with IP67 standard, and although their specs do not match the Galaxy S4 Active, the features found in these phones are still pretty good, and they can be purchased at a much lower price. The smartphones I’ll feature in this post are also rugged, which is not really the case for the Samsung device. IP67 standard? What does that mean in practice? The IP Code, Ingress Protection Rating, aka International Protection Rating, classifies and rates the degree of protection provided against the […]

November 15, 2013November 15, 2013 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

Coin is a Smart Card that Replaces All Your Other Cards (Credit, Debit, Loyalty…)

You may have a few cards in your wallet: credit cards, debit cards, gift cards, membership cards, … and it’s just convenient to carry them around all the time. There will soon be a solution with Coin, a smart card where you can store all your other cards data, and use this smart card instead. In order to register your physical cards (up to 8 cards for one Coin), you’ll need to install an application in your Android smartphone, or your iPhone, take a picture of both sides of the cards, and swiping the Coin though a small device provided with the card. Then, when you want to make a purchase, you just click on the button of the Coin to select the card to use, and carry on with your purchase are you would normally do. You may worry about security concerns, but the company behind the Coin has […]
