CNX Software Giveaway Week 2022 Winners

Giveaway Week 2022 winners announced!

CNX Software’s Giveaway Week 2022 has just ended, and it’s time to announce the winners. Just like last year, some companies added to the review samples I offered with Rakwireless and ELECFREAKS offering a LoRaWAN devkit and an educational robot respectively. If you check out the photo of the items given away below you’ll find quite more than seven because the SONOFF NSPanel kit includes four Zigbee modules, and more importantly, we also organized a parallel giveaway week on CNX Software Thailand with small boards such as the Raspberry Pi Zero W or XIAO BLE. We had eight winners on CNX Software: NanoPi R5S gateway – Ingmar, GERMANY e-con Systems e-CAM20_CURB camera – Johnny, ESTONIA Pico:ed Smart Cutebot Kit –  jednorozec, CZECH REPUBLIC Pico:ed V2 board – Leonardo, BRAZIL Sonoff NSPanel Pro and Zigbee modules – Tim, CANADA RAK Developer Kit (Air Quality Kit) – Magnus, SWEDEN GL.iNet GL-S10 BLE […]

RAK Developer Kit Air Quality Kit

Giveaway Week – RAK Developer Kit (Air Quality Kit)

RAKwireless joined CNX Software’s Giveaway Week last year with the WisBlock Kit 2 LoRa-based GPS Tracker with Solar Panel, and the company is back for Giveaway Week 2022 with the RAK Developer Kit (Air Quality Kit) with LoRaWAN connectivity. The kit includes everything to get started to build an indoor air quality monitor and send the air quality information over LoRaWAN to the cloud/LoRaWAN server. It notably comes with a WisGate gateway and a Wisblock Node with an indoor enclosure. The kit contents and main specifications are as follows: RAK7246 WisGate Developer D0 with: Raspberry Pi Zero W board with Broadcom BCM2835 ARM11 processor @ 1GHz, 512MB RAM Storage – 16GB MicroSD card Connectivity 802.11 b/g/n WiFi and Bluetooth 4.0 via Cypress CYW43438 module found on RPi Zero W board RAK2246 Pi HAT LoRaWAN concentrator module with SX1308 baseband processor Frequency bands – RU864, IN865, EU868, US915, AU915, KR920, AS923 […]

ArmSoM RK3588 AIModule7 NVIDIA Jetson Nano-compatible SOM
Wisblock power modules

RAKwireless introduces WisBlock modular power supply, IP65 enclosures, and more sensor modules

RAKwireless Wisblock modular IoT prototyping system will get new modules about once every quarter and the latest Wisblock Summer 2022 event brings some RAK190xx base boards and power modules to support various power sources from solar panels to PoE, two IP65-rated “Unify” enclosures, as well as four new Wisblock sensor modules. Wisblock RAK190XX base boards and power modules The company has launched three base boards designed to take one of the five Wisblock power modules: RAK19009 – A small (47×30 mm) base board with only 2 sensor slots. RAK19010  – The “standard” base board with 4 sensor slots and 1 I/O slot RAK19011 – Version of the Dual IO base board with a power slot RAK19012 – WisBlock power module with USB, battery, and solar panel supply RAK19013 – WisBlock power module for rechargeable batteries and solar panel supply without the USB, for applications where you do not want to […]

Notkia Nokia 168x MIPS Linux

Nokia 1680 phone gets new PCB with MIPS SoC, runs mainline Linux

Reimu NotMoe has designed the “Notkia” PCB based on Ingenic X1000E MIPS processor with 64MB built-in RAM and following the exact same dimensions as the PCB found in Nokia 168x phones (1680, 1681, 1682), and allowing the phone to run mainline Linux. The board also comes with 32MB NOR flash, a 4GB SLC NAND flash, and supports LoRa, 2.4 GHz WiFi, Bluetooth, and GNSS connectivity, but no cellular modem. Combining Nokia 168x phone with Notkia PCBA creates a phone with the following specifications: SoC – Ingenic X1000E single-core XBurst MIPS processor @ 1.0 GHz (2200+ CoreMark) with 64MB RAM Storage – 32MB NOR flash + 4GB SLC NAND flash Display – 2.0-inch 240×320 IPS LCD, 3/4 visible (Replaces the original 128×160 TFT screen in the phone) Camera – 5MP camera with auto focus (only available in the Nokia 1680 case) Audio – Yamaha MA-3 (YMU762) music synthesizer and regular I2S […]

RAK12014 ToF module Wisblock

How to use a ToF laser ranging sensor with Arduino and Wisblock

Laser ranging has many applications in production and life, such as ranging, positioning, obstacle avoidance, and so on. Time-of-Flight (ToF) ranging, as a type of laser ranging technology, is often used for real-time object detection in robots, autonomous vehicles, and traffic management because of its accuracy, fast response, and low power consumption. The face detection function of mobile phones also uses this technology. This article will introduce the WisBlock RAK12014 ToF laser ranging sensor module, and use the WisBlock development board to demonstrate how the module works. What is a ToF laser ranging sensor module? A ToF laser ranging sensor module uses laser pulses to measure the distance between itself and a target object. The WisBlock RAK12014 ToF laser ranging sensor module is based on STMicro VL53L0X, the smallest ToF ranging sensor in the world. The WisBlock RAK12014 provides accurate distance measurement and can measure distances up to 2 meters. […]

RAK3172-SIP and RAK4630 Wisduo modules

RAKwireless adds more Wisduo and Wisblock modules, launches WisToolBox configuration tool for IoT devices

RAKwireless have launched several Wisduo wireless modules, a dozen of Wisblock modules for IoT prototyping, updated WisDM, WisGateOS, and RUI3 software, and introduced WisToolBox mobile/desktop configuration tool for IoT devices as part of their spring launch 2022 even entitled “Empowering the Innovators: Making IoT your own”. Three new Wisduo modules RAK3172-SIP WisDuo SIP based on STM32WLE5 Wireless SoC with LoRa connectivity. Compared to the original RAK3172, it offers more IO pins, integrates a TCXO, and comes in a smaller size. The module supports LoRa P2P and complies with Class A, B, & C of LoRaWAN 1.0.3 specifications. Cost: $5.99. WisDuo RAK3272-SiP – That’s a breakout board for the RAK3172-SiP System-in-a-Package module for LoRaWAN and allows easy access to all pins via 2.54mm pitch headers. RAK4630 WisDuo Stamp Module – This module supports both LoRa/LoRaWAN and BLE 5.0, and comes with RUI V3 (RUI3) firmware. It can be deployed as an […]

Rockchip RK3568, RK3588 and Intel x86 SBCs and SoMs in 2025
cnx software happy new year 2022

Year 2021 in review – Top 10 posts and statistics

As per tradition, we’ll look back at what happened during the year in the last post, and see what 2022 may have in store, plus the usual statistics from CNX Software website. The biggest story of 2021 has to be the worsening of semiconductors shortages with extremely long lead times, prices of some components going up multiple folds, constant complaints on Twitter about availability and prices. I think I even saw a website, hopefully misconfigured, showing an estimated availability of a specific STM32 MCU in 2037. This also gave rise to opportunities and board redesigns, with MotorComm Ethernet chips replacing some Realtek chips in SBCs such as NanoPi R2C and  Orange Pi R1S Plus LTS, and CH9102F showing up as a replacement for CP2104 in some IoT boards. We also got some interesting Arm processors, but sadly the high-expected Rockchip RK3588 got delayed by another year, although it’s getting really […]

AM64x GP EVM development platform

TI AM64x 7-core processor is made for PLC’s, motor drives, industrial robots

Texas Instruments AM64x is a family of 64-bit Arm processors with functional safety designed for Programmable Logic Controllers (PLC), motor drives, remote I/O, and industrial robots. The top-end processor of the family, AM6442, comes with seven cores including two Cortex-A53 application cores, four Cortex-R5F real-time cores, and one Cortex-M4F isolated core. AFAICT, while the documentation is dated January 2021 and TI announced the processor in February in a blog post with a cryptic title, it was only first picked up by Embedded Computing in early May. Besides the processor itself, TI also provides an AM64x starter kit and a full-featured AM64x evaluation kit, and several companies are already preparing development boards and modules as we’ll see further below. TI AM64x processor AM64x key features & specifications: CPU cores Dual-core Arm Cortex-A53 processor @ 1.0 GHz with 256KB L2 shared cache with SECDED ECC, 32KB L1 D-cache, 32KB L1 I-cache Up […]

Boardcon CM3588 Rockchip RK3588 System-on-Module designed for AI and IoT applications
