T4-S3 ESP32-S3 smart AMOLED display
Posted on

LILYGO T4-S3 board combines 2.41-inch AMOLED touchscreen display with ESP32-S3R8 microcontroller

LILYGO T4-S3 is yet another ESP32-S3 board with an integrated display, but the main difference here is the 2.41-inch AMOLED touchscreen display with brighter colors than typical TFT displays. It’s actually not the first ESP32-S3 board with an AMOLED display from LILYGO as we previously covered the T-Track and T-Display-S3 AMOLED boards from the company, but the new T4-S3 has a larger 2.41-inch display with touchscreen function and an aspect ratio that may make it more suitable for a wider range of HMI applications.   LILYGO T4-S3 specifications: SoC – Espressif ESP32-S3R8 CPU – Dual-core Tensilica LX7 microcontroller up to 240 MHz with vector instructions for AI acceleration Memory – 8MB PSRAM Wireless – WiFi 4 and Bluetooth 5.0 LE + Mesh connectivity Storage – 16MB SPI flash, MicroSD card socket Display – 2.41-inch RGB AMOLED touchscreen display with 600×450 resolution (QSPI controller) with 800cd/m2 brightness, 36.2 x 48.96mm active […]

GlowStitch LEDs and battery holder
Posted on

GlowStitch LEDs – A machine-sewable LED board for adding lights to wearables and crafts (Crowdfunding)

GlowStitch LEDs is an innovative new project that is aimed at making machine-sewable LEDs for wearable tech and special crafts of all forms. The LEDs are made from flexible circuit boards which makes them sewable with a machine and usable for various creative projects by makers, cosplayers, fashion designers, and hobbyists. Until now, sewing LEDs to clothing and soft circuits (e-textiles) had to be done by hand with conductive thread, an arduous process that requires a lot of patience. With the GlowStitch LEDs, creative projects can be prototyped using conductive tape and actualized with a sewing machine. This project has a focus on education and the kit is designed to be used by makers of all skill levels. The LED strips can be machine-washed. However, the maker recommends hand-washing with no tumble dry. The battery should always be removed before washing. Although this is not a kit that requires coding […]

ArmSoM RK3588 AIModule7 NVIDIA Jetson Nano-compatible SOM
8devices Noni M.2 WiFi 7 module
Posted on

8Devices Noni M.2 WiFi 7 module supports FirmUx embedded Linux distribution

8Devices Noni is a family of M.2 A+E-Key WiFi 7 modules built on the QCN9274/QCN6274 chipsets, delivering up to 11 Gbps link rate in 4×4 MIMO or split 2×2 + 2×2 configurations, and supporting FirmUX embedded Linux OS. The Noni modules support Multi-Link Operation (MLO) for simultaneous communication on different frequencies and adaptive interference puncturing in order to maintain performance in various environments and the QCN9274-based variants also support advanced features such as Provisioned Multi-Link, Dense deployment, and Location and RF sensing. 8devices Noni specifications: All the Noni modules support a 2-lane PCIe Gen 3 interface connection to the host device. 8devices Noni modules support the FirmUX embedded Linux platform that provides developers a choice between fully open-source or proprietary Qualcomm drivers. The OS enables WPA3 security, comes with a responsive UI dashboard, supports Wireguard VPN, and the company claims up to 34 percent improvement over OpenWrt on the earlier […]

Cyboboard R1 SBC
Posted on

Youyeetoo R1 – A feature-rich Rockchip RK3588S SBC with M.2 sockets, NFC, etc.. for $99 and up

Youteetoo Cyboboard R1, or just Youyeetoo R1 for shorts, is a Rockchip RK3588S SBC that packs quite a lot of features in a 100×69.3mm form factor with two M.2 sockets for NVME/SSD or 4G LTE, and WiFi and Bluetooth connector, support for NFC, four display interfaces, two MIPI CSI camera interfaces and more. The board is offered with up to 32GB RAM and 256GB eMMC flash, and also comes with a gigabit Ethernet port, five USB interfaces, a built-in microphone, several audio inputs/outputs, a 30-pin header for expansion, and it can support HDMI input via an adapter connected to one of the MIPI CSI ports. Youyeetoo R1 specifications: SoC – Rockchip RK3588S CPU – Octa-core processor with 4x Cortex-A76 cores @ up to 2.2-2.4 GHz, 4x Cortex-A55 cores @ up to 1.8 GHz GPU –  Arm Mali-G610 GPU with OpenGL ES 3.2,  OpenCL 2.2, and Vulkan 1.2 support VPU – […]

ASRock Industrial NUC Ultra 100 Motherboard
Posted on

ASRock Industrial NUC Ultra 100 Meteor Lake-H motherboards feature Core Ultra 5 125H and Core Ultra 7 155H processors

ASRock Industrial has just announced two NUC Ultra 100 motherboards powered by Intel Core Ultra Meteor Lake-H processors namely the Core Ultra 5 125H and Ultra 7 155H with up to 16 cores and 22 threads, and integrating Intel ARC Graphics and the new Intel NPU AI engine. As the name implies, the NUC Ultra 100 Motherboard Series are designed in NUC form factor, support up to 96GB dual-channel DDR5-5600 MHz memory, three storage interface, up to four 4K displays, and offer two 2.5GbE networking ports, one USB4/Thunderbolt, and four USB 3.2 Gen 2 ports. ASRock Industrial says those features make the motherboards suitable for smart retail, kiosks, digital signage, smart cities, embedded industries, Edge AIoT applications, etc… NUC Ultra 100 motherboards specifications: Meteor Lake-H SoC (one or the other) Intel Core Ultra 7 T4 155H 16-core (6P+8E+2LPE) processor @ 1.4 / 4.8 GHz with 24MB cache, Intel 8Xe LPG […]

Raspberry Breadstick on a breadboard
Posted on

Raspberry Breadstick – A RP2040-based development board in a quirky form factor

The Raspberry Breadstick is a breadstick-shaped development board that is designed for ease of use. Unlike other development boards, the Breadstick is built to fit directly on your breadboard and interface with the other electronic components in your project without the need for lengthy jumper wires. It serves to deliver a prototype that is neat, straightforward, and easy to troubleshoot. It is based on Raspberry Pi’s debut microcontroller, the RP2040, which is the same MCU chip that powers the Raspberry Pi Pico and several other boards. We recently covered the Waveshare RP2040-PiZero that comes in the Pi Zero’s form factor. The RP2040 is cheap and supports C/C++, MicroPython, and CircuitPython. The Breadstick has other interesting features such as a lineup of 24 addressable RGB LEDs with fast refresh rates, a 6-axis inertial measurement unit for collecting acceleration and rotation data, as well as 16MB of external flash storage for your […]

Rockchip RK3568, RK3588 and Intel x86 SBCs and SoMs in 2025
T-Keyboard-S3
Posted on

T-Keyboard-S3 4-key USB mechanical keyboard features keycaps with 0.85-inch color display

LILYGO T-Keyboard-S3 is an ESP32-S3 powered USB mechanical keyboard with four keys each equipped with a keycap featuring a 0.85-inch 128×128 color display to show different icons or characters. We have already covered several programmable small mechanical keyboards/keypads or macropads, so the first time I saw the T-Keyboard-S3 I did not think much of it until I read the $65 price tag on Aliexpress which I found excessive for this type of device. That’s only until I realized that each resin keycap has its own color display that the price made sense, and it makes quite a versatile macropad as you could easily program multiple layouts depending on the use case. T-Keyboard-S3 specifications: Wireless module ESP32-S3-WROOM-1 MCU – ESP32-S3R8 dual-core LX7 microprocessor @ up to 240 MHz with Vector extension for machine learning Memory – 8MB PSRAM Storage – 16MB SPI flash Connectivity – WiFi 4 and Bluetooth 5 with LE/Mesh […]

ODROID-M1S review with UPS module and V8uS module
Posted on

ODROID-M1S review – Part 1: Ubuntu 20.04, Vu8S touchscreen display, UPS Kit, and WiFi Module 5BK

Hardkernel ODROID-M1S single board board was recently launched to celebrate the company’s 15th anniversary. While the ODROID-M1 board was introduced with the Rockchip RK3568 SoC last year, the new ODROID-M1S board is smaller and cheaper starting at just $49 and comes with a Rockchip RK3566 SoC. Hardkernel sent us a sample of the ODROID-M1S board for review with 8GB of memory and 64GB of storage as well as accessories. Let’s unpack the box before trying it out with Ubuntu 20.04 Desktop and testing each accessory. ODROID-M1S unboxing with ODROID-Vu8S display, UPS kit, and WiFi dongle The review package we received from Hardkernel included the ORDROID-M1S SBC in its plastic enclosure, the VU8S 8-inch touchscreen display, a UPS board, and a dual-band WiFi 5 USB dongle. The UPS module comes without a battery, so we had to find an 18650 battery to use it. As we’ll see further below, the UPS […]

Boardcon CM3588 Rockchip RK3588 System-on-Module designed for AI and IoT applications
