March 29, 2023 by Ian W MORRISON (Linuxium) - 9 Comments

iKOOLCORE R1 review – A quad 2.5GbE mini PC tested with Windows 11, Ubuntu 22.04, Proxmox

When I first saw the iKOOLCORE R1 I was fascinated that a mini PC of similar size to the smallest fully functional ones available (think Chuwi LarkBox, GMK NucBox or ECS LIVA Q Series) could be equipped with four 2.5 gigabit Ethernet (2.5GbE) ports. I approached iKOOLCORE who kindly provided an R1 for review and I’ve looked at performance running both Windows 11 and Ubuntu 22.04 and dabbled with using hypervisors on this mini PC through Proxmox virtual environment. iKOOLCORE R1 specifications iKOOLCORE list the R1 specifications on their website as: Of note are the ‘EC, FCC, RoHS’ certifications indicating both European conformity and approval for use in the US. Technically ‘EC’ refers to an ‘EC declaration of conformity’ which is not a certificate, however, the ‘EC declaration of conformity’ is called a ‘CE statement’ or ‘CE certificate’ which is why you often see this abbreviated as ‘CE’. The rest […]

March 21, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

OnLogic Helix 401 – A compact fanless industrial computer powered by an Alder Lake Embedded processor

OnLogic Helix 401 is a fanless industrial computer with a compact design powered by a choice of Alder Lake Embedded processors from Celeron 7305E to Core i7-1270PE designed for edge computing, Industry 4.0, Internet of Things (IoT), and more. The computer supports up to 64GB DDR5 memory, SATA or NVMe storage via two M.2 sockets, and offers up to four video outputs via DisplayPort and USB4 ports, dual Gigabit Ethernet, optional WiFi and/or 4G or 5G cellular connectivity, COM and CAN bus ports, and Digital Input/Output (DIO) connector. OnLogic Helix 401 (HX401) specifications: Alder Lake SoC Intel Celeron 7305E penta-core processor @ 3.10GHz / 4.20GHz (Turbo) with 48EU Intel UHD graphics – PBP: 15W, up o 55W MTP Intel Core i3-1220PE 8-core/12-thread processor @ 3.10GHz / 4.20GHz (Turbo) with 48EU Intel UHD graphics – PBP: 28W, up to 64W MTP Intel Core i5-1250PE 12-core/16-thread processor @ 3.20GHz / 4.40GHz (Turbo) […]

March 14, 2023March 14, 2023 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

DFI PCSF51 – An 1.8-inch industrial SBC with AMD Ryzen R2000 processor

DFI PCSF51 is a 1.8-inch single board computer (SBC) powered by an AMD Ryzen Embedded R2000 processor with up to 8GB DDR4 memory and 128GB eMMC flash designed for space-constraints industrial applications, robotics, edge computing, AI vision systems, and more. The business card-sized board comes with HDMI 1.4 video output, Gigabit Ethernet networking, two USB 3.2 Gen 1 ports, and an M.2 Key-E socket for wireless expansion, as well as eight digital I/Os. Other features include a watchdog and an RTC, and the SBC takes 12V DC input on a 2-pin terminal block. DFI PCSF51 specifications: AMD Ryzen Embedded R2000 SoC (one or the other) AMD Ryzen Embedded R2514 quad-core processor @ 2.1/3.7 GHz (Turbo) with 2MB Cache, 8 CU AMD Vega GPU; 12W TDP AMD Ryzen Embedded R2314, quad-core processor @ 2.1/3.5 GHz (Turbo) with 2MB Cache, 6 CU AMD Vega GPU; 12W TDP AMD Ryzen Embedded R2312 […]

March 11, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

V600 Alder Lake Mini PC features Thunderbolt 4 port, dual 2.5GbE, up to Core i9-12900H CPU

V600 mini PC is equipped with an Alder Lake processor from Core i5-1240P up to a Core i9-12900H, up to 64GB RAM, and high-speed interfaces such as Thunderbolt 4 and dual 2.5GbE networking. The mini PC also comes with two M.2 NVMe sockets, one PCIe Gen 4, one Gen 3, and support for SATA drives up to 7mm thick, offers three 4K-capable video outputs with HDMI and DisplayPort video interfaces, and several other USB 3.2/2.0 ports. V600 specifications: Alder Lake-P/H SoC (one or the other) Intel Core i7-1260P 4P+8E (16 threads) processor @ 3.40/4.70GHz with Intel Xe graphics; 28W PBP Intel Core i5-1240P 4P+8E (16 threads) processor @ 3.30/4.40GHz with Intel Xe graphics; 28W PBP Intel Core i7-12700H 6P+8E (20 threads) processor @ 3.5 /4.7 GHz with 96EU Intel Xe graphics; 45W PBP Intel Core i9-12900H 6P+8E (20 threads) processor @ 3.8/5.0 GHz with 96EU Intel Xe graphics; 45W PBP […]

March 1, 2023 by Jean-Luc Aufranc (CNXSoft) - 13 Comments

Intel Processor N100 mini PC with 8GB LPDDR5 memory sells for $156 and up

Topton is selling a mini PC based on the Intel Processor N100 Alder Lake-N quad-core processor with 8GB LPDDR5 RAM for $156.44 and up depending on the selected SSD capacity. But despite its low price, the specifications are not too bad with dual 4K video output thanks to HDMI 2.0 and DisplayPort interfaces, two Gigabit Ethernet ports, WiFi 5 and Bluetooth 4.2 connectivity, four USB ports including one USB 3.0 port, and an audio jack. Specifications: SoC – Intel Processor N100 Alder Lake-N quad-core processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel HD graphics @ up to 750 MHz; TDP: 6W System Memory – 8GB LPDDR5 4800MHz RAM Storage M.2 socket for M.2 2280 SATA SSD Support for 2.5-inch SATA SSD / HDD up to 7mm thick MicroSD card slot Video Output 1x HDMI 2.0 up to 4Kp60 1x DisplayPort up to 4Kp60 Audio – 3.5mm […]

February 24, 2023February 24, 2023 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

KC12 Alder Lake-P mini PC supports up to 64GB RAM, four displays, and dual 2.5GbE

Alder Lake-P Mini PC quad display dual 2.5GbE

KC12 is a mini PC powered by either an Intel Core i5-1240P or Core i7-1260P Alder Lake-P hybrid processor with up to 64GB DDR4, SATA and NVMe storage options, HDMI and DisplayPort for up to four 4K displays, as well as two 2.5GbE networking interfaces. The actively-cooled computer also comes with six USB ports, four of which are USB 3.x, audio jacks for a headphone and a microphone, an optional WiFi 6 and Bluetooth 5.0 module, an RS232 COM port, and a Kensington lock slot. KC12 mini PC specifications: Alder Lake-P SoC (one or the other) Intel Core i7-1260P 4P+8E (16 threads) processor @ 3.40/4.70GHz with Intel Xe graphics; 28W TDP Intel Core i5-1240P 4P+8E (16 threads) processor @ 3.30/4.40GHz with Intel Xe graphics; 28W TDP System Memory – Up to 64GB RAM via 2x SO-DIMM DDR4-2666/3200 sockets Storage M.2 2280 SSD slot for SATA or NVMe PCIe Gen4 SSD […]

February 18, 2023February 18, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

IoT Prototype Kit is powered by an Alder Lake-H COM Express module with up to Core i5-12600HE CPU

IoT Prototype Kit Intel Alder Lake-P module

ADLINK has launched an IP-i IoT Prototype Kit based on their Express-ADP COM Express Type 6 Basic “Alder Lake-H” module with either an Intel Core i5-12600HE 12-core (4P+8E) processor clocked at up to 4.5 GHz or a Core i3-12300HE 8-core (4P+4E) processor reaching up to 4.3 GHz. The kit also includes the Express-BASE6 R3.1 carrier board, a thick heatsink with an active fan, a debug board (DB30 x86), and various cables for SATA storage, a DB9 COM port, and I/Os, and the kit can be used to develop applications for industrial automation and control, medical ultrasound, image processing and analysis, high-speed video encoding and streaming, predictive traffic analysis, multi camera-based AI, etc… The Express-ADP module supports up to 64GB DDR5 memory, optional on-module NVMe storage, up to 4x 4K displays, multiple PCIe Gen4 and Gen3 interfaces, SATA 3.0, and so on. You’ll find detailed Express-ADP COM Express module specifications in […]

February 14, 2023February 21, 2025 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

KiCad 7.0.0 release – Custom fonts, text boxes, SpaceMouse, crash reporting, and much more

KiCad 7.0.0 open-source EDA software has just been released with a range of new features from custom fonts to 3Dconnexion SpaceMouse integration to opt-in Sentry crash reporting, and many more changes. It took over three years between KiCad 5.0.0 and KiCad 6.0.0 announcements, but only a little over a year for the release of KiCad 7.0.0. Did KiCad developers acquire superhuman abilities or did AI get involved in the development somehow? Most probably not, and instead they change the release schedule to a yearly one, so we should get annual releases of the open-source EDA suite going forward, with KiCad 8.0.0 to be released in Q1 2024. Some notable changes to KiCad 7.0 include: Custom Fonts support is now available in the schematic, PCB, and worksheet editors to allow the use of any system font. Text box support was added in both the schematic and PCB editors. 3Dconnexion SpaceMouse support […]
