Posted on by Debashis Das - No Comments on Boardcon PICOT536 SoM and EMT536 SBC feature Allwinner T536 Edge AI processor

Boardcon PICOT536 SoM and EMT536 SBC feature Allwinner T536 Edge AI processor

EMT536 Development Board

Back in April last year, Allwinner released the T536 SoC, and since then, we’ve seen MYiR Tech and Forlinx introduce SoM and SBC based on it. The latest to join the lineup is Boardcon, which has recently launched the PICOT536 SoM and EMT536 SBC for industrial HMI, machine vision, robotics, and other edge computing applications. As a reminder, the Allwinner T536 SoC features a quad-core Arm Cortex-A55 CPU, XuanTie E907 and E902 RISC-V coprocessors, and a 2 TOPS NPU for edge AI. The module comes with up to 8GB LPDDR4/LPDDR4X memory, up to 64GB eMMC flash, an optional WiFi 6 and Bluetooth 5.4 module, and a 314-pin MXM edge connector exposing I/Os such as MIPI DSI and LVDS, camera inputs, audio inputs and outputs, Gigabit Ethernet, PCIe, USB 3.0, and more. PICOT536 System-on-Module PICOT536 specifications: SoC – Allwinner T536 CPU – Quad-core Arm Cortex-A55 at up to 1.6GHz, RISC-V XuanTie […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Rockchip RK3326-S quad-core Cortex-A35 SBC targets smart audio devices

Rockchip RK3326-S quad-core Cortex-A35 SBC targets smart audio devices

Rockchip RK3326S SBC

Boardcon EM3326S is a single board computer powered by a Rockchip RK3326-S quad-core Cortex-A35 processor paired with up to 4GB LPDDR4 memory and 128GB eMMC flash. With a 3.5mm audio jack and a speaker connector, Fast Ethernet, WiFi, and Bluetooth connectivity, the company says the board mainly targets smart audio applications. But it could certainly be used for a wider range of applications with RGB LCD and MIPI DSI display interfaces, MIPI CSI and DVP camera interfaces, an RS485 terminal block, a mini PCIe socket plus a SIM card slot for 4G LTE connectivity, and more. Boardcon EM3326S specifications: SoC – Rockchip RK3326-S CPU – Quad-core Cortex-A35 @ 1.5GHz with 512KB L2 cache GPU – Arm Mali G31-2EE with support for OpenGL ES 1.1/2.0/3.2, DirectX 11 FL9_3, OpenCL 2.0, and Vulkan 1.0 VPU Video Decoder – MPEG-4, H.264, H.265/HEVC, VP8, VC-1 up to 1080p60 Video Encoder – H.264 video encoder […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Boardcon Tiny1126B is a smaller and lighter Rockchip RV1126B system-on-module, yet with more I/Os

Boardcon Tiny1126B is a smaller and lighter Rockchip RV1126B system-on-module, yet with more I/Os

Tiny Rockchip RV1126B system-on-module

Boardcon Tiny1126B shrinks the company’s MINI1126B-P Rockchip RV1126B system-on-module (SoM) from 38x30mm to 34x30mm, targeting even more compact AI vision systems such as smart cameras, smart door locks, inspection cameras, cleaning/logistics robots, DMS (Driver Monitoring Systems), BSD (Blind Spot Detection) solutions, and smart displays. Despite its smaller size, the Tiny1126B features two 0.4mm pitch 100-pin connectors, instead of two 0.5mm pitch 80-pin connectors for its predecessors, offering even more I/Os. It’s notably gaining a USB 3.0 DRD (Dual-Role Device) interface, an extra SDMMC interface, one additional SPI and I2C interfaces, Fast Ethernet, and more. The rest of the specifications, including memory capacity (up to 4GB LPDDR5) and storage (up to 256GB eMMC flash), remain the same. Boardcon Tiny1126B system-on-module Boardcon Tiny1126B specifications: SoC – Rockchip RV1126B CPU – Quad-core Arm Cortex-A53 up to 1.6 GHz with 32KB L1 I-Cache and 32KB L1 D-Cache, unified 512KB L2 Cache GPU – 2D […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Rockchip RV1126B-P quad-core Cortex-A53 SoC shows up in AI Vision system-on-module

Rockchip RV1126B-P quad-core Cortex-A53 SoC shows up in AI Vision system-on-module

Boardcon MINI1126B P system on module

Boardcon MINI1126B-P is a system-on-module (SoM) powered by a Rockchip RV1126B-P 64-bit Arm SoC with a 3 TOPS NPU and a 4K H.264/H.265 encoder and decoder designed for AI vision applications. Rockchip RV1126 quad-core Arm Cortex-A7 camera SoC with a 2 TOPS AI accelerator has been around since 2021, but the RV1126B(-P) is a new chip with four Cortex-A53 cores and a 3 TOPS NPU. The MINI1126B-P SoM is one of the first hardware platforms with the new SoC, and an update to the company’s MINI1126 with the RV1126 SoC, so let’s have a closer look. Rockchip RV1126B-P AI camera SoC Since Boardcon has released the datasheet of the new Rockchip processor, we can list the RV1126B-P key features and specifications: CPU – Quad-core Arm Cortex-A53 up to 1.6 GHz with 32KB L1 I-Cache and 32KB L1 D-Cache, unified 512KB L2 Cache for Cortex-A53 GPU – 2D Graphics Engine VPU […]

Posted on by Debashis Das - 1 Comment on Boardcon Compact3576 – A feature-rich Rockchip RK3576 SBC with Android 14 and Debian 12 support

Boardcon Compact3576 – A feature-rich Rockchip RK3576 SBC with Android 14 and Debian 12 support

Boardcon Compact3576 SBC

Boardcon has recently introduced the Compact3576, a modular SBC with a Boardcon CM3576 SoM based on a Rockchip RK3576 octa-core Cortex-A72/A53 SoC with a 6 TOPS NPU for AI computing tasks, up to 8GB of RAM, and up to 128GB eMMC flash storage. Key features include two HDMI video outputs, one HDMI input (HDMI to MIPI CSI), Gigabit Ethernet, a WiFi 5 & Bluetooth 5.0 module, three USB 3.0 ports, a microSD card slot, and M.2 and mPCIe sockets for storage and cellular expansion. The board is powered by 12V DC via USB-C PD port, and offers features such as a real-time clock, IR receiver, debug port, reset/recovery keys, and more. Compact3576 SBC specifications: SoC – Rockchip RK3576 CPU 4x Cortex-A72 cores at 2.2GHz, 4x Cortex-A53 cores at 1.8GHz Arm Cortex-M0 MCU at 400MHz GPU – ARM Mali-G52 MC3 GPU clocked at 1GHz with support for OpenGL ES 1.1, 2.0, and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Boardcon LGA3576 – A Rockchip RK3576 LGA system-on-module with UFS storage and LPDDR5 memory

Boardcon LGA3576 – A Rockchip RK3576 LGA system-on-module with UFS storage and LPDDR5 memory

Rockchip RK3576 LGA system-on-module

Boardcon has just introduced the LGA3576 system-on-module with a 330-pad LGA design powered by Rockchip RK3576 AI SoC and the Idea3576 single board computer (SBC) based on the module. The 6TOPS AI-capable system-on-module ships with up to 8GB LPDDR5, integrates 32GB to 512GB UFS storage, while an RK806S-5 PMIC takes care of power management, and all I/Os such as HDMI, PCIe, Ethernet, and GPIO signals are exposed through LGA pads. Boardcon LGA3576 – A Rockchip RK3576 LGA system-on-module Specifications: SoC – Rockchip RK3576 CPU Octa-core  CPU with 4x Cortex-A72 cores at 2.2GHz, 4x Cortex-A53 cores at 1.8GHz Single-core Cortex-M0 real-time core GPU – Arm Mali-G52 MC3 GPU with support for OpenGL ES 1.1, 2.0, and 3.2, OpenCL up to 2.0, and Vulkan 1.1 NPU – 6 TOPS (INT8) AI accelerator with support for INT4/INT8/INT16/BF16/TF32 mixed operations. VPU Video Decoder H.265, VP9, AV1, and AVS2 up to 8Kp30 or 4Kp120 H.264/AVC up […]

Posted on by Debashis Das - No Comments on Boardcon EM1103B AIoT SBC for video surveillance applications features PIR sensor, fingerprint interface, and dual camera support

Boardcon EM1103B AIoT SBC for video surveillance applications features PIR sensor, fingerprint interface, and dual camera support

EM1103B Rockchip RV1103B SBC

Boardcon EM1103B is an AIoT SBC powered by a Rockchip RV1103B SoC designed for surveillance applications with dual camera, fingerprint, and a PIR sensor. This unique combination makes it suitable for vision-based applications such as smart cameras, doorbells, and battery-powered surveillance devices. The SBC consists of a compact core board that mounts to a large baseboard, which gives access to all the necessary I/O modules and also provides power. The SBC together features 100 Mbps Ethernet, Wi-Fi, USB 2.0 OTG, UART, GPIO, and interfaces for speakers, microphones, fingerprint sensors, and PIR motion sensors. It also features PoE (5V) support and expandable storage via microSD. Additionally, it integrates two MIPI CSI camera interfaces mad the RV1103B’s 8MP hardware ISP with enables advanced image processing features such as HDR, 3A (AE/AF/AWB), and 3DNR. The chip also supports H.264/H.265 video encoding for local and cloud streaming. Boardcon EM1103B specifications: Core Board – Boardcon […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Boardcon SBC3576 – A feature-rich Rockchip RK3576 SBC with HDMI, mini DP, dual GbE, WiFi 6, optional 5G/4G LTE module, and more

Boardcon SBC3576 – A feature-rich Rockchip RK3576 SBC with HDMI, mini DP, dual GbE, WiFi 6, optional 5G/4G LTE module, and more

Boardcon SBC3576 SBC

Boardcon SBC3576 is a feature-rich single board computer (SBC) based on the MINI3576 system-on-module powered by a Rockchip RK3576 AI SoC and equipped with two 100-pin and one 44-pin board-to-board connectors for interfacing with the carrier board. The carrier board is equipped with up to 8GB RAM, 128GB eMMC flash, two gigabit Ethernet ports, a WiFi 6 and Bluetooth 5.3 module, 4K-capable HDMI 2.1 and mini DP video outputs, a mini HDMI input port, a USB 3.0 Type-A port, RS485 and CAN Bus terminal block, and more. The Rockchip RK3576 SoC comes with the same 6 TOPS NPU found in the Rockchip RK3588/RK3588S SoC and can be used as a lower-cost alternative with less performance. Boardcon SBC3576 specifications: SoC – Rockchip RK3576 CPU 4x Cortex-A72 cores at 2.2GHz, four Cortex-A53 cores at 1.8GHz Arm Cortex-M0 MCU at 400MHz GPU – ARM Mali-G52 MC3 GPU clocked at 1GHz with support for OpenGL […]
