CYCLONE F100 Tegra K1 Fanless Embedded Computer Supports up to 8GB RAM, SATA, and Various Networking Options

Calao Systems has added a new member to the their rugged embedded computers family with Cyclone F100 powered by Nvidia Tegra K1 quad core Cortex A15 processor with up to 8GB RAM, optional industrial grade SATA Nandrive, and mSATA, dual Gigabit Ethernet, and mPCIe connectivity options for IoT and M2M with LoRA, WiFi, RF radios, etc… Target applications include surveillance, identification, transport, robotic, graphic enhanced digital signage, and medical equipment. Cyclone F100 specifications: SoC – Nvidia Tegra K1 quad-core ARM Cortex A15 processor @ 2.3 GHz with 192-core Kepler GPU supporting OpenGL 4.4, OpenGL ES 3.1 and CUDA/GPGPU System Memory – 2 GB DDR3L (Options for 4 and 8GB on request) Storage – 8 GB eMMC, 8 MB SPI flash and  micro SD card slot. Optional: Industrial grade SATA Nandrive, mSATA socket Video Output – HDMI, options: LVDS and DisplayPort Audio I/O – HDMI, optical S/PDIF out, Mic In / Headphone Out Connectivity Wired – 2x Gigabit Ethernet or 10/100M […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Calao Systems SMC-NTEK1 is a SMARC System-on-Module Powered by Nvidia Tegra K1

Calao Systems has introduced a new system-on-module compliant with SGET SMARC specifications, and powered by Nvidia Tegra K1 quad core Cortex A15 processor, that targets embedded systems for vision, video, data analytic and high computing applications. Calao SMC-NTEK1-IXX module specifications: SoC – Nvidia Tegra K1 quad core Cortex A15 processor with a Kepler GPU System Memory – 2GB DDR3L Storage – 8 GB e-MMC, 8 MB SPI Flash, 1x EEPROM with unique S/N and MAC address Security – 1x Trusted Platform Module (TPM), 1x Crypto Authentication I/Os via MXM3 edge connector: Storage – SATA 3Gb/s, 1x SDIO Video Output – 1x LVDS, 1x HDMI Video Input / Camera – 2x CSI Audio I/F – 1x I2S, 1x S/PDIF Out Debugging – 1x JTAG Network connectivity – 1x Gigabit Ethernet USB – 2x USB 2.0 Host, 1x USB 2.0 OTG 1x PCIe x1 4x UART, 1x SPI, 3x I2C, 12x GPIO Sensors – 1x Temperature, Humidity & Pressure Sensor, 1x 3 […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Baseball Nano-ITX i.MX6 Board Targets Secure Industrial M2M and IoT Products

Calao Systems has introduced a new Freescale i.MX6 single board computer with Baseball embedded platform, targetting network-connected industrial M2M and Internet of Things (IoT) applications requiring a high-level of security achieved with an FIPS 140-2 trusted platform module, and Crypto Authentication chip. The board is comprised of a Nano-ITX based board and a Freescale.iMX6 (Solo, Dual or Quad) SMARC 1.1 module with the following combined specifications: SoC – Freescale iMX6 Solo, Dual or Quad Cortex A9 processor @ up to 1GHz with Vivante GPU System Memory – 2 GB DDR3L, Storage On Module: 8 GB e-MMC, 8 MB SPI Flash, 1x EEPROM with unique S/N and MAC address On Baseboard: 1x Micro-SD socket, 1x Industrial Grade eMMC NANDrive (optional), 1x Industrial Grade SATA Nandrive (optional), Video Output – HDMI Audio Output – HDMI and optical S/PDIF Connectivity – 2x Gigabit Ethernet, 1x SIM card slot USB – 3x USB 2.0 Host, 1x USB OTG Expansion 3x Expansion connectors with AFB, […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Calao Systems Introduces Linux based DIN Rail Home and Building Automation Systems

Calao Systems is an embedded systems company that I came to know thanks to their Snowball development boards based on the now defunct ST Ericsson Nova A9500 processor. The company has now launched new products for building and home automation powered by Atmel AT91SAM9G20 ARM9 processor clocked at 400 MHz housed in a DIN Rail enclosure. Two products are now available HABA-KNX-EXPLORER and HABA-KNX-LITE that share the following specifications: Processor – Atmel ARM926EJ-S @ 400MHz System Memory – 128MB SDRAM Storage – 256MB NAND Flash, 16 Mbit serial flash, 2Kbit EEPROM with MAC address, and Micro SD slot Connectivity Lite – 1x Ethernet 10/100Mbits Explorer – 2x Ethernet 10/100Mbits USB –  2x USB Host FS (12Mbits), 1x USB Device FS (12Mbits) Serial (Explorer only) – 1x RS-232 (isolated), 2x RS-485 (isolated) Automation I/F – 1x KNX/TP1 (isolated) Expansion – 1x RF Expansion Connector Debugging – JTAG and DBGU interfaces Misc – RTC battery backup Power Supply – 9-36V DC Power […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

CALAO Systems Introduces PInBALL Industrial Board Based on Raspberry Pi Compute Module

CALAO Systems has just launched an industrial single board computer (SBC) for professional Raspberry Pi developers called PiNBALL or, if you prefer, PAC-1210-S200-B2835-EXX…. The board is powered by the Raspberry Pi Compute Module, features interfaces such as two mini PCIe slots (for USB, I2C, GPIOs,…), fast Ethernet, HDMI, opto-isolated inputs and outputs, etc., +6 to +36V power input, and can operate in -20°C to +70°C temperature range. PInBALL industrial SBC specifications (Items marker with ‘*’ are optional, and depend on model): SoC / Memory / Storage  – Via Raspberry Pi Compute Module – Broadcom BCM2835, 512MB RAM, 4GB eMMC Flash. Other Storage – 1x 2Kb I²C EEPROM with EUI-48 MAC Address & 128 bit Serial Number (AT24MAC402). Video Output – 1x HDMI Out, 1x CVBS Out (BCM2835) Audio Output – 1x HDMI, 2x S/PDIF Out / Optical & RCA (WM8804), Connectivity – 1x Fast Ethernet (LAN9514), 1x Micro-SIM Socket USB – 2x USB 2.0 Host (LAN9514), 1x USB Device, Serial […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Snowball Board Phased Out, and Offered at a Discount

Snowball is a mobile development board based on ST Ericsson Nova A9500 dual core ARM Cortex A9 SoC , which was officially supported by Linaro (they still released Android and Ubuntu images), and designed by Calao Systems, but since ST-Ericsson venture fell apart, support for the board has been discontinued, and the developer’s community (igloocommunity) has recently been closed down. The last message of the mailing list (now not accessible) reads as follows: A small team of passionate ST-Ericsson people have dreamed about Snowball and they makes it possible. Since December 2011 after a management change, it has been difficult to maintain the program, but with your support, we succeed until this time. Nevertheless, you have been able to demonstrate the pertinence of this program, and its great potential with impressive realizations. In December 2012, STMicroelectronics announced a new strategic plan, where STM takes the decision to exit ST-Ericsson. Then both companies Ericsson and STM agreed to split-up the joint […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Linaro Development Board “Snowball” by ST Ericsson

ST Ericsson unveiled a development board based on Nova A9500 (dual ARM Cortex A9 processor and MALI 400 GPU) at MWC 2011 called Snowball (or SKY-S9500-ULP-CXX) for the embedded Linux community and professional developers. This board was designed by CALAO Systems and can be pre-ordered on their website for 200 USD (SKY-S9500-ULP-C11 / Software Development Kit – SDK) or 300 USD (SKY-S9500-ULP-C01 / Production development Kit – PDK). The difference between the SDK and PDK is that the former has no expansion connectors, no battery backup for RTC and only support serial over USB port (for Linux console). First, some pictures with description of the snowball development board. The full documentations for Snowball development board can be found in Calao Systems File Repository, where you’ll get the bottom and top assembly diagrams for both C01 and C11, the major components datasheet, documentation and some photos. The specifications of the boards: – ARM Dual Cortex A9 @ 1GHz, – 1x Serial Port […]
