UP Board is a Raspberry Pi Clone with an Intel Atom X5 Processor (Crowdfunding)

Many ARM based “insert-fruit-name-here” Pi boards are available on the market, and they all look like the Raspberry Pi board to some extends, but thanks Emutex we’ll soon get the “UP board” powered by Intel Atom x5-Z8300 and in Raspberry Pi form factor including the ubiquitous 40-pin Raspberry Pi headers, DSI and CSI connectors, and mostly the same port placements, with some extra goodies like a USB 3.0 port and Gigabit Ethernet. Up Board specifications: SoC – Intel Atom x5-Z8300 “Cherry Trail” quad core processor @ 1.44 GHz (Burst frequency: 1.84 GHz) with Intel Gen8 HD graphics @ 500 MHz System Memory –  1 GB DDR3L-1600 Storage – 16 or 32 GB eMMC Video Output / Display – HDMI, DSI connector Audio I/O – HDMI Connectivity – Gigabit Ethernet USB – 4x USB 2.0 host ports, 1x USB 2.0 pin header, 1x micro USB 3.0 port (under the board) Camera […]

MeLE PCG03 Plus mini PC Gets Cherry Trail x5-Z8300 Processor

Beside MeLE PCG02 TV stick with Ethernet, MeLE also showcased an upgraded version of its MeLE PCG03 mini PC with MeLE PCG03 Plus replacing Atom Z3735F processor with a more recent Intel Atom “Cherry Trail” x5-Z8300 processor. MeLE PCG03 Plus specifications show they’ve only changed the processor: SoC – Intel Atom x5-Z8300 “Bay Trail” quad core processor @ 1.44 GHz (Bust freq: 1.84 GHz) with Intel HD Gen8 graphics System Memory – 2 GB DDR3L Storage – 32 GB eMMC + SD card slot Video Output – HDMI 1.4, and VGA Audio I/F – HDMI, 3.5mm earphone jack Connectivity – 10/100M Ethernet, 802.11 b/g/n Wi-Fi, and Bluetooth 4.0 USB – 3x USB 2.0 host Misc – Power Button, power LED, Kensington security lock Power Supply – 12V/1A Dimensions – 150 x 120 x 40 mm There should be some performance improvements over the previous model, but nothing phenomenal. MeLE PCG03 […]

MagicStick TV Sticks Powered by Intel Atom x5 or x7 Processors Feature up to 8GB RAM, HDMI 2.0, 802.11ac… (Crowdfunding)

Several Cherry Trail Atom x5 MegooPad TV sticks are on the way, but they mostly have similar specs to the previous generation Bay Trail sticks, except with a slightly faster processor, and in some models, USB 3.0 support. An Indian company is currently developing some Cherry Trail TV sticks with impressive specifications including processors such as Intel Atom x7-Z8700, up to 8GB RAM, up to 64GB storage, 802.11ac connections, HDMI 2.0, and USB 3.1 type-C connector. These products are called MagicSticks, and three models will soon be available. [Update 30/9/2015: The indiegogo campaign is up, but the Wave is not shown, and instead MagicStick Power has been renamed to Wave, changes are reflected in the table below] MagicStick One MagicStick Wave MagicStick Power Wave Processor Intel Atom x5-Z8300 processor up to 1.83 GHz, with 12 core Gen8 GPU Intel Atom x5-Z8500 processor up to 2.24 GHz, with 12 core Gen8 […]

Asus VivoStick PC is a Cherry Trail HDMI TV Stick Running Windows 10

We’ve had many Bay Trail-T HDMI TV stick in the past year, but recently some Cherry Trail low power mini PCs such as Tronsmart Ara X5 and MeegoPad T04 have started to hit the virtual shelves, and now Asus is the first company to announce a Cherry Trail HDMI TV Stick, and it’s pretty good looking, although its shaper reminds me of fluorescent markers… Asus VivoStick PC specifications: SoC – Unamed Intel Cherry Trail processor Memory & Storage – Single eMCP chip with 2GB DDRL3 and 32GB eMMC (no micro SD slot) Video Output – HDMI Audio Output – HDMI, 3.5mm audio jack Connectivity – WiFi 802.11 b/g/n and Bluetooth 4.0 USB – 1x USB 3.0 port, 1x USB 2.0 port, 1x micro USB port (for power) Power Supply – 5V via micro USB port Dimensions – 138 x 15 x 14 mm Weight – 70 grams The stick will […]

Ubuntu 14.04 / 15.04 Tested in Tronsmart Ara X5 Cherry Trail Mini PC

After reviewing Tronsmart Ara X5 with Windows 10, I decided to give a try at Ubuntu. Initially I downloaded Ubuntu 15.04 Desktop 64-bit ISO image, and prepare a bootable USB drive with UNetbootin in my computer running Ubuntu 14.04. But after inserting the USB flash drive into Ara X5, and pressing F7, there was no options to select the drive, so I went to UEFI settings, and the drive was clearly detected, but not available as a bootable device. Finally, having heard one company booted Ubuntu on MeegoPad T04 using Rufus, and Tronsmart confirming Ubuntu 14.04 could boot on Ara X5 using Pendrive Linux USB installer, I decided to try again with Windows tools, and prepared an Ubuntu 15.04 image with Rufus. Great! Pressing F7 would show the USB flash drive, and I could boot Ubuntu 15.04. But unfortunately audio output is not working (only Dummy output), nor is WiFi […]

Review of Tronsmart Ara X5 Windows 10 mini PC with Intel Atom X5 Processor

Tronsmart Ara X5 is one of the first mini PC featuring a Cherry Trail processor, more exactly Atom x5-Z8300 quad core processor manufactured with 14nm process. Price and max TDP are similar to Atom Z3735F Bay Trail-T processor found in many mini PCs designed in China, so it will interesting to compare the two platforms. Yesterday, I took some photos of the device, and found out the design was comprised of a baseboard and system-on-module, but today, I’ll focus on testing the device in Windows 10, checking everything works as it should, as well as running some benchmarks, verifying the Windows license status, test H.265 video playback in Kodi, and more. Tronsmart Ara X5 Setup I had not much to do the first time I booted the device, as it was already configured to use English, and the system logged in with user “User” without password. I still double checked […]

Intel Atom Z3735F vs Atom x5-Z8300 Benchmarks Comparison

I’m in the process of reviewing Tronsmart Ara X5 mini PC with Intel Atom x5-Z8300 “Cherry Trail” processor, and while testing is not complete yet, I’ve already run PCMark8 benchmarks in the Windows 10 device, so I’ve decided to compare the results I got with MeLE PCG03 mini PC running Windows 10 based on an older Z3735F Bay Trail-T processor that’s about the same price, and with the same 2W TDP. This post can be considered a work in progress, as I may update it latter to add more benchmarks results in Windows or/and Linux (Phoronix). Th exact test I ran was “PCMark 8 Home 3.0 Conventional 3.0”. Both system resolutions were set to 1920×1080, however one noticeable difference is that MeLE PCG03 ran Windows 10 Home 32-bit, while Tronsmart Ara X5 ran Windows 10 Home 64-bit. Benchmark MeLE PCG03 Intel Atom Z3735F Bay-Trail @ 1.33 GHz / 1.83 GHz […]

Tronsmart Ara X5 Cherry Trail mini PC Unboxing and Teardown

Tronsmart Ara X5 is one of the first Intel Atom X5 mini PCs available on the market, and should provide a decent update to the many Intel Atom Z3735F based devices with its Atom x5-Z8300 quad core processor. GeekBuying sent me one sample for review, and today I’ll take a few pictures, and take it apart to find out more about the components used and its thermal design, before doing a review in the next few days. Tronsmart Ara X5 Unboxing I received the fanless computer by DHL in the following package together with a EU to US plug adapter. Ara X5 ships with a 5V/3A power adapter, an HDMI cable, and a user’s manual in English. The front panel has two USB 2.0 host ports, a 3.5mm headset jack, and the power button, while the rear panel features the power jack, a Fast Ethernet RJ45 port, HDMI output, a […]
