Texas Instruments MSP432 LaunchPad Development Board Sells for $4.32 (Promo)

Texas Instruments has started the year by offering a deal on their 32-bit MSP432 LaunchPad Development Kit, dropping the cost from $12.99 to $4.32 for a limited time with coupon code [email protected] MSP432 Launchpad’s key features: MCU – Texas Instruments MSP432P401R ARM Cortex M4F MCU @ 48 MHz with FPU and DSP, 256KB flash, 64KB RAM Expansion – 40 pin BoosterPack Connector, and support for 20-pin BoosterPacks Misc – 2 buttons and 2 LEDs for user interaction Debugging – Back-channel UART via USB to PC, Onboard XDS-110ET emulator featuring EnergyTrace+ Technology Power – Micro USB connector The kit includes the board, micro USB cable and a quick start guide. There’s plenty of technical documentation for the board, although for some unknown reasons,  I can’t download any PDF documents from TI website tonight. The coupon is still working, but free shipping on TI eStore seems to be a thing of the past, as the total price adds $7 for shipping and […]

Texas Instruments Introduces MSP432 ARM Cortex-M4F MCU Family

Texas Instruments has just launched a successor for its 16-bit MSP430 MCU family with MSP432 MCU series featuring a 32-bit ARM Cortex-M4F core, a DSP, up to 256 KB flash, up to 64 KB SRAM, and according to the company ” delivering a ULPBench score of 167.4 outperforming all other Cortex-M3 and -M4F MCUs on the market”. The new MCU family targets  consumer & portable electronics, building & factory automation & control, smart grid & energy,  healthcare & fitness, and wearables applications. Key features listed for MSP432P4xx: MCU – 32-bit ARM Cortex-M4F up to 48 MHz with FPU and DSP. Delivers 3.4 Coremark/MHz Memory – Up to 64 KB RAM;  Selectable RAM retention Storage – Up to 256 KB Flash; dual bank for simultaneous reading and writing Security – 256-bit AES encryption, JTAG access lock, 4 IP Protection regions EnergyTrace Technology Real-time power measurement and debugging Generate application energy profiles including current and CPU state Ultra-Low Power Consumption: 95 uA/MHz active […]

Embedded Systems Conference 2015 Schedule – May 6-7, 2015

The Embedded Systems Conference took the name “Design West” for a couple of years, but this year, there’s no mention of Design West, and the Embedded System Conference 2015 will take place in Boston, MA, US on May 6-7, 2015. The 2-day event will have a demo hall, and well as sessions divided into 8 tracks: Connected Devices and the IoT Embedded Software Design Hardware: Design, I/O and Interfacing Prototyping Embedded Systems Design Software: Design, Languages, & Quality Fantastical Theater Teardowns The full schedule has now been posted, and I’ll build a virtual schedule with some of the sessions provided. Wednesday May 6, 2015 8:00 – 8:45 – Understanding Google/Nest Thread by Michael Anderson, Chief Scientist, The PTR Group, Inc. The IoT will live or die based on its connectivity. In examining existing wireless protocols, Google/Nest found most of them lacking. In order to address the needs for low-power wireless communications in the home, Thread was created. Thread is an […]

Texas Instruments Tiva C Series TM4C1294 Connected Launchpad Sells for $20

There are now many ultra low cost MCU development kit selling for $15 to $25 such as STMicro Discovery Board, but for this price, they’ll usually just feature the MCU, a micro USB, pin header, maybe and maybe some sensors, and they usually lack any form of connectivity, at least without extra hardware. With Tiva C Series TM4C129 Connect Launchpad, Texas Instruments brings a board that can be used for IoT application out of the box thanks to the addition of an Ethernet port. The board sells for just $19.99, which means you could easily make something like a connected 4-relay control system for about $25. Connected LaunchPad evaluation kit specifications: MCU – Texas Instruents TM4C1294NCPDT ARM Cortex-M4 @ 120MHz with floating point, 1MB Flash, 256KB SRAM, 6KB EEPROM, Integrated 10/100 Ethernet MAC+PHY, data protection hardware, 8x 32-bit timers, dual 12-bit 2MSPS ADCs, motion control PWMs, USB H/D/O, and many additional serial communication interfaces Connectivity – 10/100M Ethernet Expansions Dual […]

STMicro Unveils $10 mbed-enabled and Arduino Compatible Nucleo Development Boards

STMicro already announced a $24 NFC development kit a few days ago, and they’ve now announced new ultra low cost STM32 development boards. STMicro Nucleo development boards are based on different STM32 MCU based on ARM Cortex M0, M3 and M4, feature Arduino headers, and are supported by mbed platform. There are currently four boards available: NUCLEO-F401RE – Based on STM32F401RET6 ARM Cortex M4 MCU @ 84 MHz with 512KB flash memory, 96 KB SRAM NUCLEO-F030R8 – Based on STM32F030R8T6 ARM Cortex M0 MCU @ 48 MHz with 64KB flash memory, 8KB SRAM NUCLEO-F103RB – Based on STM32F103RBT6 ARM Cortex M3 MCU @ with 128KB flash memory, 20 KB SRAM NUCLEO-L152RE – Based on STM32L152RET6 ARM Cortex M3 MCU @ 32MHz with 512KB flash memory, 32KB SRAM All four boards share the following specifications: STM32 microcontroller with LQFP64 package Two types of extension resources Arduino Uno Revision 3 connectivity STMicroelectronics Morpho extension pin headers for full access to all STM32 […]

Free Online Courses & Workshops For ARM Cortex-M Microcontrollers

STMicroelectronics and Digikey are co-sponsoring an EE Times University online training course entitled “Fundamentals of Microcontrollers (MCUs): Hands-On Workshop”. The first two 45-minutes sessions will be theoretical and provide and overview of micro-controllers, and explain methods to select an MCU for a given project. The first 1,000 persons based in the US or Canada, who attended the first 2 sessions, will receive a free STM32F4 Discovery Board (ARM Cortex M4). The three next sessions, conveniently taking place about a week later, hopefully after you’ve received your board, will be an actual workshop with STM32F429 Discovery Board. Here’s the detailed schedule for the training: December 2, 2013, 12PM (Eastern Time) –  Session 1 – Introduction to Microcontrollers Common microcontroller architectures Pipelining Peripherals: Timers, Communication, Analog December 3, 2013, 12PM (Eastern Time) – Session 2 – Selecting the Right Microcontroller 10 Steps to Selecting a microcontroller What to look for in a development kit Tool setup lab December 11, 2013, 12PM (Eastern […]

Energy Micro Launches EFM32 Wonder Gecko Cortex M4 MCUs and Starter Kit

After having announced EFM32 Wonder Gecko MCU family in February, Energy Micro has just officially launched their new family of high performance, low power MCUs. These micro-controllers come with an ARM Cortex-M4 CPU with floating-point unit (FPU) and DSP instruction set that helps reduce the processing time of your application in active mode. All MCUs come with 32KB SRAM, and between 64 to 256KB flash. Energy Micro expects their new chips to be used in applications such as gas metering, energy metering, water metering, smart metering, alarm and security systems, health and fitness applications, and industrial and home automation. One key advantage of this new MCU family is the implementation of TSMC’s eLL (Extreme Low Leakage) technology that dramatically reduces power consumption at high temperatures. There top of range MCUs (EFM32WG995FXXX) feature the following specifications: ARM Cortex-M4 CPU platform @ up to 48 MHz with DSP instruction support and floating-point unit, and memory protection unit Memory – 32KB RAM, 64/128/256KB […]

Infineon Hexagon Application Kit (XMC4500 Enterprise Edition) Overview and Quick Start Guide

A few months ago, Infineon sent me XMC4500 Relax Lite Kit for review, and I wrote a short Getting Started Guide about this 10 Euros Cortex M4 devkit. This month, I’ve received another XMC4500 kit with more features and expansion abilities: XMC4500 Enterprise Edition which is one of their Hexagon Application Kit. I received two packages: CPU Board XMC4500 General Purpose (CPU_45A-V2) with accessories (55 Euros) – This is what you get when you order to Basic Kit. J-Link Lite Cortex-M Debugger (40 Euros) Let’s open the packages and see what’s inside. In the first package, we’ve got XMC4500 CPU board, a pin extension board that can be used on any of the 3 extension connectors of the CPU board to access the signals easily, and a microUSB to USB cable for power. The JLink debugger comes with a 10-pin ribbon cable, and a microUSB to USB cable to connect to the CPU board and start debugging. A closer look at the […]
