Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Kneron KL720 Arm Cortex-M4 AI SoC Delivers 1.5 TOPS at 1.2 Watts

Kneron KL720 Arm Cortex-M4 AI SoC Delivers 1.5 TOPS at 1.2 Watts

We first came across Kneron AI processors last year, when we covered AAEON M.2 & mPCIe AI accelerator cards powered by Kneron KL520 dual-core Cortex-M4 processor and delivering 0.3 TOP AI acceleration performance at 0.5 Watt. The company has now introduced a more powerful processor with Kneron KL720 single Arm Cortex-M4 AI processor delivering up to 1.5 TOPS at 1.2 Watts, or 0.9 TOPS for 1 Watt. The company does not provide much other information in terms of specifications, but Kneron KL720 is said to be two to four times more power-efficient than competitors at a lower cost and is best suited for high-end IP cameras, Smart TVs, AI glasses & headsets, as well as AIoT Gateways. The processor can process 4K images, full HD videos, and 3D sensing data for facial recognition and gesture control for gaming, shopping kiosks, etc.. Besides computer vision, the chip can also handle natural language processing (NLP) for translators and AI assistants. If you […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 7 Comments on STMicro STM32MP1 Cortex A7/M4 MPU Supports Linux and Android

STMicro STM32MP1 Cortex A7/M4 MPU Supports Linux and Android

STM32MP157 STM32MP153 STM32MP151

When Linux 4.17 was released last June, we discovered an interesting new STM32 part: STM32MP157C dual core Cortex-A7 processor. It was the first time I saw an STM32 IC not based on Arm Cortex-M microcontroller core, but we knew only very little details at the time. STMicro has now made it official, and introduced STM32MP1, the first STM32 MPU (Microprocessor Unit) that features one or two Arm Cortex-A7 cores running Linux, as well as an Arm Cortex-M4 real-time core that allows to re-use code from existing STM32 projects. STM32MP1 key features and specifications: Cores Single or Dual Cortex-A7 core(s) running at 650 MHz with 32-Kbyte L1 Instruction cache, 32-Kbyte L1 Data cache, 256-Kbyte Level 2 cache Cortex-M4 core running at 209 MHz with single-precision floating point unit (FPU), digital signal processor (DSP) instructions, and memory protection unit (MPU) GPU (STM32MP157 only) – Vivante 3D GPU with OpenGL ES 2.0 support; up to 26 Mtriangle/s, 133 Mpixel/s Memory External – Up […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on STMicro Introduces Ultra-efficient STM32L4+ Series MCUs with Better Performance, Chrom-GRC Graphics Controller

STMicro Introduces Ultra-efficient STM32L4+ Series MCUs with Better Performance, Chrom-GRC Graphics Controller

STMicroelectronics has announced an upgrade to their STM32L4 series Cortex-M4 micro-controllers with STM32L4+ series upping the maximum frequency from 80 MHz to 120 MHz delivering up to 150 DMIPS (233 ULPMark-CP) , and ultra low power consumption as long as 33 nA in shutdown mode without RTC. The new family also adds Chrom-GRC graphics controller (GFXMMU) that can handle both circular and square TFT LCD displays together with a MIPI DSI interface and displayer controller, making it ideal for wearables, Chrom-ART 2D accelerator for better graphics performance, two Octo SPI interfaces, and more memory (640KB max) and storage (up to 2MB flash). If you want to know all differences between STM32L4 and STM32L4+, and/or learn how to use peripherals, STMicro has setup a nice free STM32L4+ online training page, which allow you to do just that either by downloading PDF documents, or following e-Presentations with slides and audio. STM32L4+ appears to have the same power modes as STM32L4, except that […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Microchip SAM D5x and SAM E5x ARM Cortex-M4 Micro-Controllers Launched with Optional Ethernet and CAN Bus

Microchip SAM D5x and SAM E5x ARM Cortex-M4 Micro-Controllers Launched with Optional Ethernet and CAN Bus

Microchip has just introduced two new families of micro-controllers based on ARM Cortex-M4F with SAM D5x and SAM E5x series sporting up to 1 MB of dual-panel flash and 256 KB of SRAM both with ECC support. Both families also support QSPI flash with XIP (eXecute In Place) support, features an SD card controller and a capacitive touch controller, with SAM E5x family also adding support for two CAN-FD ports and Ethernet. Microchip SAM A5x/E5x key features and specifications: MCU Core – ARM Cortex-M4F core running at 120 MHz with single precision Floating Point Unit (FPU) Memory – Internal memory architecture with user configurable Tightly Coupled Memory, System memory, Memory Protection Unit and 4KB Combined I-cache and D-cache; up to 256KB ECC SRAM, up to 1MB ECC flash Storage I/F – Quad Serial Peripheral Interface(QSPI) with Execute in Place (XIP) Support Peripherals Up to 2x Secure Digital Host Controller (SDHC) Peripheral Touch Controller (PTC) supporting up to 256 channels of […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Qorvo GP695 “Smart Home” SoC Integrates 802.15.4, Zigbee 3.0, Thread, and Bluetooth LE

Qorvo GP695 “Smart Home” SoC Integrates 802.15.4, Zigbee 3.0, Thread, and Bluetooth LE

GreenPeak Technologies ultra-low power, short range RF communication technology company was acquired by Qorvo last year, and Qorvo has recently announced a GP695 system on chip (SoC) for smart home devices part of GreenPeak’s previous family of devices, and supporting multiple short range RF protocols. GP695 key features: MCU Core – ARM Cortex M4 Connectivity IEEE 802.15.4 ZigBee 3.0 Thread Bluetooth Low Energy (BLE) Qorvo Wi-Fi interference mitigation technology GP695 has been designed to be used in device such as a door locks, smart HVAC, smart security systems, connected video doorbells and intercoms, lightbulbs, smoke alarms, and leak detectors, and complements GP712 multi-protocol SoC designed for smart home gateways. Qorvo will feature live demonstrations of its smart home and IoT solutions at its booth during CES 2017, at Sands Expo, Halls A-D Booth #42114. There’s very limited public information, and no product page could be found in their website. Jean-Luc Aufranc (CNXSoft)Jean-Luc started CNX Software in 2010 as a part-time […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Ambiq Micro Introduces Ultra-Low Power Apollo 2 Cortex-M4F MCU Consuming Less than 10 μA/MHz

Ambiq Micro Introduces Ultra-Low Power Apollo 2 Cortex-M4F MCU Consuming Less than 10 μA/MHz

Last year Ambiq Micro unveiled their Apollo Cortex-M4F MCU with Cortex M0+ energy efficiency thanks to operation in sub-threshold voltage (< 0.5 V), and the MCU is said found in Matrix Powerwatch, a fitness tracker powered by body heat that you never need to charge. The company has recently announced a new version of the micro-controller with Apollo 2 MCU with better maximum performance thanks to a higher maximum clock speed (48 MHz vs 24 MHz), and higher efficiency (10 μA/MHz vs 30 μA/MHz @ 3.3V). Apollo 2 MCU key features and specifications: Ultra-low supply current <10 μA/MHz executing from flash at 3.3 V <10 μA/MHz executing from RAM at 3.3 V ARM Cortex-M4 Processor up to 48 MHz with FPU, MMU, wake-up interrupt controller with 32 interrupts Ultra-low power memory Up to 1 MB of flash memory for code/data Up to 256 KB of low leakage RAM for code/data 16kB 1 or 2-way Associative Cache Ultra-low power interface for […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on NXP LPC Microcontrollers Roadmap for 2017 – LPC800 and LPC54000 Series

NXP LPC Microcontrollers Roadmap for 2017 – LPC800 and LPC54000 Series

With the acquisition of Freescale, NXP now has both Kinetis and LPC ARM Cortex M micro-controller families. The company has kept selling both so far, but it’s unclear whether they’ll keep developing new Kinetis MCU family in the future. There’s no such doubt about LPC family with the company having published a 2017 roadmap for ARM Cortex M0+ based LPC 800 series, and ARM Cortex M4 based LPC54000 series. LPC800 series MCUs are promoted as 8-bit MCU alternatives, and three new models are expected next year: LPC84x ARM Cortex M0+ @ 30 MHz with 64KB flash, 8 to 16KB RAM available in QFN and LQFP packages. LPC802 ARM Cortex M0+ @ 15 MHz with 16KB flash, 2KB RAM available in TSSOP packages LPC804 ARM Cortex M0+ @ 15 MHz with 32KB flash, 4KB RAM available in QFN or TSSOP packages There will be new models of the more powerful LPC54000 series: LPC546xx ARM Cortex-M4 @ 180 MHz with 256 to […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on SiLabs Wireless Gecko SoCs Support Bluetooth 4.2, Zigbee, Thread, and 2.4GHz Proprietary Protocols

SiLabs Wireless Gecko SoCs Support Bluetooth 4.2, Zigbee, Thread, and 2.4GHz Proprietary Protocols

Silicon Labs has introduced three new Wireless SoC families with Blue Gecko for Bluetooth Smart, Mighty Gecko for Thread & Zigbee, and Flex Gecko for proprietary 2.4 GHz protocols. All three families provides up to 19.5 dBm output power & hardware cryptography, and are pin-to-pin and software compatible. SiLabs Wireless Gecko SoC highlights: MCU Core – ARM Cortex-M4 @ 40 MHz with FPU, up to 256 KB flash, and up to 32KB SRAM. Mighty Gecko also adds a DSP Peripherals AES256/128 Hardware Crypto Accelerator ADC (12-bit, 1 Msps, 286 µA) Current DAC (4-bit, Current Source or Sink) 2x Analog Comparator Low Energy UART 2x USART (UART, SPI, IrDA, I2S) I2C (Address recognition down to EM3) Timers : RTCC, LE Timer & Pulse Counter 12-channel Peripheral Reflex System Up to 31 GPIO EFR32BG Blue Gecko Family Bluetooth Smart (Bluetooth Low Energy or “BLE”) 4.2 specification as well as proprietary wireless protocols Supported by Silicon Labs’ Bluetooth Smart software stack and BGScript […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples
