din rail

Posted on by Debashis Das - No Comments on Sfera Labs Strato Pi Max DIN rail industrial controllers are built around Raspberry Pi CM4 or Zymbit SCM module

Sfera Labs Strato Pi Max DIN rail industrial controllers are built around Raspberry Pi CM4 or Zymbit SCM module

Sferalabs Strato Pi Max XL & Pi Max XS

Sfera Labs has recently introduced two new Pi Max DIN rail industrial controllers – the Strato Pi Max XS and Strato Pi Max XL configured with a Raspberry Pi CM4 or the Zymbit Secure Compute Module (SCM). Both have options for different RAM and eMMC flash configurations and can come with or without wireless connectivity. The module also features a Raspberry Pi RP2040 microcontroller that manages tasks such as power management and boot sequence control. Additionally, it enables connections to the CM4 module through I²C, USB, and UART. Strato Pi Max industrial controller specification Base Module – Raspberry Pi Compute Module 4 or Zymbit SCM options. Microcontroller – Raspberry RP2040 dual ARM Cortex-M0+ at 133 MHz. Storage – eMMC, microSD (dual for XL), M.2 PCIe SSD. Connectivity – Wi-Fi, BLE, dual Ethernet ports (GbE and 100MbE). USB – 2x USB 2.0 ports with power control and fault detection. Sensors – 3-axis accelerometer. Cooling – Internal […]

Posted on by Tomisin Olujinmi - 8 Comments on The EQSP32 is a no-code, no-solder Industrial Internet of Things Controller powered by a generative AI assistant (Crowdfunding)

The EQSP32 is a no-code, no-solder Industrial Internet of Things Controller powered by a generative AI assistant (Crowdfunding)

eqsp32 industrial controller

The EQSP32 controller is a complete, end-to-end solution for IoT applications that recently launched on Kickstarter. It is a compact, wireless Industrial IoT controller based on the ESP32-S3 wireless SoC with a 250MHz dual-core processor, 512KB of RAM, and 8MB of flash memory. The product leverages artificial intelligence and code for automation projects can be generated automatically by the bundled generative AI programming assistant. The EQSP32 controller features 16 terminals that can be configured as analog or digital inputs, or as digital outputs. Switches, pushbuttons, keypads, LED strips, sensors, servos, potentiometers, etc., can be connected to these terminals. It is similar to the EdgeBox-Edge-100 we covered a while back but lacks an Ethernet port and uses less power overall. EQSP32 specifications: SoC: Espressif Systems ESP32-S3 dual-core Tensilica LX7 microcontroller @ 240 MHz, 512KB RAM Memory – 8MB flash Network Connectivity: Bluetooth, WiFi USB – USB-C programming port I/O: 16 multipurpose […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on DIN rail mount works with all Raspberry Pi boards and compatible SBC’s with a 40-pin GPIO header

DIN rail mount works with all Raspberry Pi boards and compatible SBC’s with a 40-pin GPIO header

DINPi Rack Raspberry Pi DIN Rail mount

DIN rail mounts or mountable enclosures for the Raspberry Pi have been available for years with products such as the RailPi 2.0 enclosure or TerraPi’s DIN rail mount, but PlasmaDan’s DINPi RACK adds another option that happens to be compatible with any Raspberry Pi board, be it model A, model B or Zero. Since there’s no software involved, it will also with other SBCs with a 40-pin Raspberry Pi GPIO header and the same mounting holes as the Raspberry Pi SBCs, and DINPi RACK also supports one Raspberry Pi HAT or up to two Raspberry Pi pHATs, also known as uHATs (Micro HAT), plus there’s an extra 40-pin right angle for further example. The board received CE & UKCA certifications, is RoHS compliant (lead-free), and is manufactured by a UL 796 certified manufacturer. This is what the DINPi RACK looks like with a Raspberry Pi Zero W and a Raspberry […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on DIN-Rail mountable industrial 4G LTE router takes 9V to 36V DC power input

DIN-Rail mountable industrial 4G LTE router takes 9V to 36V DC power input

DIN Rail 4G router VPN

Waveshare WS-431E is an industrial-grade 4G LTE router with three Ethernet ports, WiFi 4, wall and DIN-Rail mounting options, and support for a wide power input range between 9V and 36V DC. The router is said to be based on two Qualcomm chips without further details provided, support various VPN protocols, and be suitable for networked medical equipment, Smart Agriculture, Smart Cities, robots, and security monitoring applications. Waveshare WS-431E specifications: SoC – “Dual Qualcomm chips” for WiFi and 4G LTE Networking Ethernet 1x 10/100Mbps Ethernet RJ45 WAN port (can be configured as LAN) with auto MDI/MDIX, 1.5KV electromagnetic isolation protection 2x 10/100Mbps Ethernet RJ45 LAN ports with auto MDI/MDIX, 1.5KV electromagnetic isolation protection 2.4 GHz 802.11b/g/n WiFi 4 2×2 MIMO up to 300 Mbps, and 500-meter LoS range 4G LTE cellular 4G TDD-LTE – B38/40/41 4G FDD-LTE – B1/3/7/8/20/28A 3G WCDMA – B1/8 2G GSM/EDGE – B3/8 Nano SIM card […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on EDATEC ED-IPC2010 – A compact DIN Rail mountable industrial computer based on Raspberry Pi CM4

EDATEC ED-IPC2010 – A compact DIN Rail mountable industrial computer based on Raspberry Pi CM4

DIN Rail Raspberry Pi CM4 industrial computer

EDATEC has launched yet another Raspberry Pi CM4-powered industrial computer with the ED-IPC2010 offering a more compact design than the company’s CM4 Industrial and CM4 Sensing models, and an aluminum alloy enclosure that can easily be mounted to a DIN Rail. Most of the specifications of the new ED-IPC2010 are pretty common with a choice of Raspberry Pi Compute Modules 4 with up to 8GB RAM, 32GB flash, and optional WiFi 5 and Bluetooth 5.0, as well as a full-size HDMI video output, a Gigabit Ethernet port, and a few USB ports. What’s a little different is one FPC connector on the mainboard with both HDMI and USB for touchscreen displays. ED-IPC2010 specifications: SoM – Raspberry Pi CM4 SoC – Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5GHz with VideoCore VI GPU System Memory –  1GB, 2GB, 4GB, or 8GB RAM Storage – 8GB, 16GB, or 32GB eMMC flash Wireless – […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on DSBOX-NX2 – An NVIDIA Jetson Xavier NX Industrial Fanless PC

DSBOX-NX2 – An NVIDIA Jetson Xavier NX Industrial Fanless PC

Jetson Xavier NX industrial fanless PC

Turkish company Forecr has launched DSBOX-NX2 NVIDIA Jetson Xavier NX based industrial fanless PC equipped with the company’s own DSBoard-NX2 carrier board and designed for “multi-stream deep learning edge analytics” and IIoT applications. The compact embedded computer comes with 8GB RAM, up to 2TB SSD storage, as well as HDMI 2.0 output, Gigabit Ethernet, two USB 3.1 ports for high resolution cameras, serial ports, and some GPIOs among other features. Forecr DSBOX-NX2 specifications: System-on-Module – NVIDIA Jetson Xavier NX module with hexa-core NVIDIA Carmel ARM v8.2 64-bit processor, NVIDIA Volta GPU with 384 CUDA core & 48 Tensor Cores, 8 GB 128-bit LPDDR4x, 16GB eMMC flash Storage – M.2 Key M SSD slot, MicroSD card slot Video Ouput – 1x HDMI 2.0 up to 3840×2160 at 60 Hz Networking Gigabit Ethernet Wireless – WiFi, Bluetooth, 4G LTE, 5G connectivity by extension sockets USB – 2x USB 3.1 Type-A Expansion 1x […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 10 Comments on Terminal Block modules for Raspberry Pi Pico come with screw or DIN rail mounting option

Terminal Block modules for Raspberry Pi Pico come with screw or DIN rail mounting option

Terminal block raspberry-pi-pico din rail mount

if you’d like to use terminal blocks with your Raspberry Pi Pico, or compatible board,  instead of soldering wires to the MCU board, HCDC’s Terminal Block Breakout Module may meet your requirements with variants for either screw or DIN rail mounting. Description/specifications: PCB mount Terminal Block with 5 mm pitch, 7mm strip length, M2.5 screws – Wire range 28AWG ~ 12AWG / 2.5mm square. FR-4 fiber glass PCB, dual copper layers. Mounting options Screw version – “Taiwan high-quality” fireproof nylon material mount carrier (“not China low-quality carrier”). DIN rail version – “High-quality Taiwan” DINKLE fireproof nylon material DIN rail mount carrier (“not China low-quality carrier”); supports 35mm wide rail. I have not mentioned it in the introduction, but after reading the specifications, it appears (Xuken) HCDC may be based in Taiwan. 🙂 The company explains its Terminal Block Breakout Module for Raspberry Pi Pico is best suited to industrial control, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on ClusBerry 9500-CM4 – A Raspberry Pi CM4 cluster, industrial style

ClusBerry 9500-CM4 – A Raspberry Pi CM4 cluster, industrial style

ClusBerry Industrial Raspberry Pi CM4 Cluster

Raspberry Pi cluster boards / solutions pop-up from time to time. But so far, I think we’ve seen only one based on Raspberry Pi CM4 modules with the upcoming Turing Pi 2 mini-ITX cluster board supporting four of those. TECHBASE has now unveiled a different kind of Raspberry Pi CM4 cluster with ClusBerry 9500-CM4 integrating up to eight Raspberry Pi Computer Module 4 in a DIN-Rail housing for industrial applications. ClusBerry 9500-CM4 is designed to be customizable with a choice of Raspberry Pi CM4 based modules and I/O cards: Standard 9500-CM4 cluster module with Compute Module 4 and a selection of configuration that include: I/O Controller with DI, DO, AI, 1-Wire, RS-232/485 and CAN interfaces Communication Gateway with up to 2x Ethernet, serial ports, wireless connectivity: LTE-cat.M1, 4G, 5G, LoRa, ZigBee, Z-Wave, Wireless M-Bus AI Gateway with Coral Edge TPU via PCIe M.2, or up to 4x Coral Edge TPU […]
