din rail News - Page 2 of 3 - CNX Software

August 8, 2023August 9, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

DIN-Rail mountable industrial 4G LTE router takes 9V to 36V DC power input

Waveshare WS-431E is an industrial-grade 4G LTE router with three Ethernet ports, WiFi 4, wall and DIN-Rail mounting options, and support for a wide power input range between 9V and 36V DC. The router is said to be based on two Qualcomm chips without further details provided, support various VPN protocols, and be suitable for networked medical equipment, Smart Agriculture, Smart Cities, robots, and security monitoring applications. Waveshare WS-431E specifications: SoC – “Dual Qualcomm chips” for WiFi and 4G LTE Networking Ethernet 1x 10/100Mbps Ethernet RJ45 WAN port (can be configured as LAN) with auto MDI/MDIX, 1.5KV electromagnetic isolation protection 2x 10/100Mbps Ethernet RJ45 LAN ports with auto MDI/MDIX, 1.5KV electromagnetic isolation protection 2.4 GHz 802.11b/g/n WiFi 4 2×2 MIMO up to 300 Mbps, and 500-meter LoS range 4G LTE cellular 4G TDD-LTE – B38/40/41 4G FDD-LTE – B1/3/7/8/20/28A 3G WCDMA – B1/8 2G GSM/EDGE – B3/8 Nano SIM card […]

May 12, 2023September 23, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

EDATEC ED-IPC2010 – A compact DIN Rail mountable industrial computer based on Raspberry Pi CM4

DIN Rail Raspberry Pi CM4 industrial computer

EDATEC has launched yet another Raspberry Pi CM4-powered industrial computer with the ED-IPC2010 offering a more compact design than the company’s CM4 Industrial and CM4 Sensing models, and an aluminum alloy enclosure that can easily be mounted to a DIN Rail. Most of the specifications of the new ED-IPC2010 are pretty common with a choice of Raspberry Pi Compute Modules 4 with up to 8GB RAM, 32GB flash, and optional WiFi 5 and Bluetooth 5.0, as well as a full-size HDMI video output, a Gigabit Ethernet port, and a few USB ports. What’s a little different is one FPC connector on the mainboard with both HDMI and USB for touchscreen displays. ED-IPC2010 specifications: SoM – Raspberry Pi CM4 SoC – Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5GHz with VideoCore VI GPU System Memory – 1GB, 2GB, 4GB, or 8GB RAM Storage – 8GB, 16GB, or 32GB eMMC flash Wireless – […]

May 18, 2021 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

DSBOX-NX2 – An NVIDIA Jetson Xavier NX Industrial Fanless PC

Turkish company Forecr has launched DSBOX-NX2 NVIDIA Jetson Xavier NX based industrial fanless PC equipped with the company’s own DSBoard-NX2 carrier board and designed for “multi-stream deep learning edge analytics” and IIoT applications. The compact embedded computer comes with 8GB RAM, up to 2TB SSD storage, as well as HDMI 2.0 output, Gigabit Ethernet, two USB 3.1 ports for high resolution cameras, serial ports, and some GPIOs among other features. Forecr DSBOX-NX2 specifications: System-on-Module – NVIDIA Jetson Xavier NX module with hexa-core NVIDIA Carmel ARM v8.2 64-bit processor, NVIDIA Volta GPU with 384 CUDA core & 48 Tensor Cores, 8 GB 128-bit LPDDR4x, 16GB eMMC flash Storage – M.2 Key M SSD slot, MicroSD card slot Video Ouput – 1x HDMI 2.0 up to 3840×2160 at 60 Hz Networking Gigabit Ethernet Wireless – WiFi, Bluetooth, 4G LTE, 5G connectivity by extension sockets USB – 2x USB 3.1 Type-A Expansion 1x […]

April 20, 2021April 20, 2021 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

Terminal Block modules for Raspberry Pi Pico come with screw or DIN rail mounting option

Terminal block raspberry-pi-pico din rail mount

if you’d like to use terminal blocks with your Raspberry Pi Pico, or compatible board, instead of soldering wires to the MCU board, HCDC’s Terminal Block Breakout Module may meet your requirements with variants for either screw or DIN rail mounting. Description/specifications: PCB mount Terminal Block with 5 mm pitch, 7mm strip length, M2.5 screws – Wire range 28AWG ~ 12AWG / 2.5mm square. FR-4 fiber glass PCB, dual copper layers. Mounting options Screw version – “Taiwan high-quality” fireproof nylon material mount carrier (“not China low-quality carrier”). DIN rail version – “High-quality Taiwan” DINKLE fireproof nylon material DIN rail mount carrier (“not China low-quality carrier”); supports 35mm wide rail. I have not mentioned it in the introduction, but after reading the specifications, it appears (Xuken) HCDC may be based in Taiwan. 🙂 The company explains its Terminal Block Breakout Module for Raspberry Pi Pico is best suited to industrial control, […]

January 18, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

ClusBerry 9500-CM4 – A Raspberry Pi CM4 cluster, industrial style

ClusBerry Industrial Raspberry Pi CM4 Cluster

Raspberry Pi cluster boards / solutions pop-up from time to time. But so far, I think we’ve seen only one based on Raspberry Pi CM4 modules with the upcoming Turing Pi 2 mini-ITX cluster board supporting four of those. TECHBASE has now unveiled a different kind of Raspberry Pi CM4 cluster with ClusBerry 9500-CM4 integrating up to eight Raspberry Pi Computer Module 4 in a DIN-Rail housing for industrial applications. ClusBerry 9500-CM4 is designed to be customizable with a choice of Raspberry Pi CM4 based modules and I/O cards: Standard 9500-CM4 cluster module with Compute Module 4 and a selection of configuration that include: I/O Controller with DI, DO, AI, 1-Wire, RS-232/485 and CAN interfaces Communication Gateway with up to 2x Ethernet, serial ports, wireless connectivity: LTE-cat.M1, 4G, 5G, LoRa, ZigBee, Z-Wave, Wireless M-Bus AI Gateway with Coral Edge TPU via PCIe M.2, or up to 4x Coral Edge TPU […]

October 26, 2020October 27, 2020 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Modberry 500 CM4 DIN Rail Industrial Computer Features Raspberry Pi Compute Module 4

We’ve been writing about Techbase Modberry industrial embedded computers with DIN-Rail enclosures such as Modberry M500 or M2000 for several years. Most of their systems are powered by SBC’s like Raspberry Pi 4 or AAEON Up Squared, but they’ve also made models based on Raspberry Pi Compute Module 3+, and with the launch of Raspberry Pi CM4, the company has now introduced Modberry 500 CM4 industrial computer powered by Raspberry Pi Compute Module 4 with up to 8GB RAM and 32GB eMMC flash. Modberry 500 CM4 key features and specifications: SoM – Raspberry Pi Compute Module 4 with Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5 GHz, 1 to 8GB RAM, up to 32GB eMMC flash. Storage – Optional NVMe SSD via PCIe 2.0 (mini PCIe or optional M.2 slot) Video Output – Optional HDMI port Connectivity Optional Gigabit Ethernet port Optional Wi-Fi (IEEE 802.11 b/g/n/ac) & Bluetooth 5.0 Optional 5G, […]

September 29, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

Raspberry Pi CM3+ based Iono Pi Max industrial controller comes with an impressive number of I/Os

As the Raspberry Pi Compute Module 4 is only expected for next year, companies are still launching products based on Raspberry Pi Compute Module 3+ (CM3+), and Sfera Labs has just introduced Iono Pi Max industrial computer powered by a Raspberry Pi CM3+ system-on-module. Housed in a DIN rail enclosure, the Linux controller offers Fast Ethernet, three USB ports, isolated CAN and serial boards, some analog I/Os, a relay, as well as a real-time clock (RTC), integrated UPS, and more. Iono Pi Max specifications: SoM compatibility Iono Pi Max 3+ – Already fitted with Raspberry Pi Compute Module 3+ (Lite, 8GB, 16GB, or 32GB eMMC version) Iono Pi Max Solo – Barebone model compatible with Raspberry Pi Compute Module 3, CM3 Lite, CM3+ 8GB/16GB32GB, and CM3+ Lite MCU – Microchip SAME54 Cortex-M4F microcontroller with 1 MB flash, 256 KB RAM connected to the Raspberry Pi module via I2C, USB and […]

February 5, 2020February 5, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

Pi-oT MKR Module Enclosure Routes Raspberry Pi GPIO’s to Screw Terminals, includes a Breadboard (Crowdfunding)

Last summer Pi-oT introduced a Raspberry Pi add-on board of the same name targeting commercial & industrial IoT automation. The project was launched on Kickstarter and backers should have received their rewards. The DIN-rail enclosure included with the RPi HAT was popular, so they decided to work on a Pi-OT MKR module enclosure with a similar form factor but instead of using screw terminals for ADC input and relays, they routed some of Raspberry Pi GPIO pins to the terminal, added a breadboard to the case for prototyping, as well as a fan for cooling. Pi-oT MKR module key features: Features: Compatible with any Raspberry Pi board with 40-pin GPIO header Screw terminals – 21 GPIO’s including the I2C pins, 5V, 3.3V and GND from Raspberry Pi header routed to screw terminals Integrated Breadboard Integrated Cooling – 5V header for included fan Circuit Protection Port protection – 330 Ohm resistor […]
