Over the year, The maker community has designed several platforms to monitor vital signs with boards like Healthy Pi v4 or HeartyPatch both of which are powered by an ESP32 WiFi & Bluetooth wireless SoC. WallySci has designed another all-in-one wireless bio-sensing platform, called E3K, that also happens to be powered by Espressif Systems ESP32 chip, and can be connected to an electromyography (EMG) sensor to capture muscle movements, an electrocardiography (ECG) sensor to measure heart activity, and/or an electroencephalography (EEG) sensor to capture brain activity. The board also has an extra connector to connect a 9-axis IMU to capture motion. E3K main board which the company refers to as “Data Communication and Processing Unit” (DCPU) comes with the following specifications: Supported wireless board – ESP32-DevKitC with ESP32-D0WD-V3 dual-core 32-bit LX6 microprocessor, up to 240 MHz, Integrated 520 KB SRAM, 16 MByte SPI flash. 2.4 GHz WiFI 4, and Bluetooth […]
SwarmDrive is an ESP32 motor driver board for brushless motors (Crowdfunding)
Netherlands based NickStick BV has developed a motor driver board powered by an ESP32 dual-core WiFI and Bluetooth module and capable of controlling brushless DC motors. The SwarmDrive board targets users who want to start experimenting with motor control, and learn about commutation strategies, PID for balance plateau or balance robots, cartesian gantries and spatial navigation, drive by wire and wireless, swarm intelligence experiments, etc. SwarmDrive specifications: Wireless module – Espressif Systems ESP32-WROOM-32D module with ESP32 dual-core processor @ 240 MHz, 4 Mbit flash Connectivity 2.4 GHz 802.11 b/g/n WiFi up to 150 Mbps Bluetooth v 4.2 BR/EDR and BLE Motor Control L6234 triple half-bridge motor driver, 5 A peak current 3-pin terminal block for motor output 3x enable pins are broken out to a bridging connector Programming and debugging – Micro USB serial port via USB to UART bridge, Misc – Boot and reset push-buttons Power Supply Supply Voltage – […]
ESP32 CNC Controller Board Supports Grbl Arduino Firmware
Grbl_ESP32 CNC development board is a breakout board for NodeMCU 32S board that also takes three stepper motor drivers, and designed to run Grbl open-source Arduino firmware to control wireless CNC machines. Grbl_ESP32 CNC breakout board specifications: Socket for NodeMCU 32S board with ESP32 WiFi and Bluetooth dual-core SoC 3 sockets for stepper motor drivers such as TI DRV8825 types and others. Micro-step selection jumpers included. MicroSD card socket Home/Limit switch connections for XY and Z axes. Control switch input connections for Feed Hold, Cycle Start, Reset, and Door. Spindle output for PWM to control speed. 3A DC-DC power supply to run the ESP32 if it is not connected to USB Grbl CNC firmware was initially developed for the Arduino UNO and basic 3 axis CNC routers around 10 years ago, but has since then been ported to other CPUs and is now found in other types of CNC machines […]
Petoi Bittle Palm-sized Robot Dog uses Arduino and Raspberry Pi for STEM education (Crowdfunding)
You’ve probably already watched a video featuring Boston Dynamics Spot, a headless robot dog used in various industries including healthcare, public safety, construction, oil & gas, etc.. It could also be yours if you wanted a robotic pet dog at home, as long as you have $75,000 US to spare. Petoi Bittle looks eerily similar, but it’s much smaller as it fits in your palm, and could be yours for $225 on KickStarter as a kit to assemble yourself that you may get as soon as December. Bittle robot dog is designed for STEM education and can be programmed using the Arduino IDE, Python, or even Codecraft visual programming IDE. Bittle is comprised of 4 main hardware components: Plastic parts and fixtures – Body, four legs, head (which can be used to hold Arduino modules), springs, screws, etc… Actuators – 9x P1S servo with a controllable angle of 270 degrees, […]
FeatherS2 Board Brings ESP32-S2 to Adafruit Feather Form Factor
We’ve covered a fair number of development boards following Adafruit Feather form factor in the last year or so with products such as QuickFeather Cortex-M4 + FPGA board, OrangeCrab (Lattice FPGA), nRF9160 Feather providing LTE IoT & GPS connectivity, and other boards. But here’s yet another Adafruit Feather themed board that has just launched: FeatherS2. The tiny board is equipped with the latest Espressif Systems ESP32-S2 WiFi SoC, 16 MB SPI Flash, 8 MB PSRAM, several I/O, and a USB-C port for power and programming. FeatherS2 key features and specifications: SoC – ESP32-S2 single-core Tensilica LX7 processor @ 240 MHz, RISC-V ultra-lower power co-processor, 320 kB SRAM, 128 kB ROM Memory – 8 MB extra PSRAM Storage – 16 MB SPI Flash Connectivity – 2.4 GHz Wi-Fi – 802.11b/g/n with 3D antenna USB – 1x USB-C port for power and programming Sensor – ALS-PT19 Ambient Light Sensor Expansion 16 + […]
M5StickC PLUS ESP32-PICO Devkit Comes with 1.14-inch LCD, 120 mAh Battery and Buzzer
Shortly after introducing the Core2 ESP32 IoT Development Kit with a 2-inch touch display, 390 mAh battery earlier this week, M5Stack has announced the availability of another ESP32 WiFi & Bluetooth IoT devkit, with the more compact M5StickC PLUS featuring a 1.14-inch display, a 120mAh battery, motion, sensor, a buzzer and the usual Grove connector for expansion. M5StickC PLUS is an upgrade to the original M5StickC that lacks the buzzer and features a smaller 0.96-inch display and a lower capacity 96 mAh battery. The new model can be purchased now for $13.95 plus shipping on Aliexpress, while the original device, that happens to be M5Stack top-selling product, is still available for $9.95. M5StickC PLUS key features and specifications: SiP – Espressif Systems ESP32-PICO-D4 system-in-package with ESP32 dual-core WiFI and Bluetooth IoT processor @ up to 240 MHz, 4MB SPI flash Display – 1.14-inch Color TFT LCD with 135×240 resolution (ST7789v2 […]
M5Stack Launches Core2 ESP32 IoT Development Kit with 2-inch Touch Display
M5Stack has just launched an upgrade to its M5Stack Core development with M5Stack Core2 based on the same Espressif ESP32 WiFI + Bluetooth SoC, but adding capacitive touchscreen support to the 2-inch TFT LCD, as well as a motion sensor and a microphone. The new version also adds 8MB PSRAM, a larger 390 mAh battery, and targets IoT terminals for Smart Home, industrial automation or robotics, STEM Education, and DIY prototyping. M5Stack Core2 specifications: SoC – Espressif ESP32-D0WD-V3 dual-core Xtensa LX6 processor clocked at up to 240MHz with 520KB SRAM, Wi-Fi, and dual-mode Bluetooth connectivity External Memory – 8MB PSRAM Storage – 16MB flash storage, MicroSD card slot up to 16GB Display – 2-inch IPS LCD screen with 320×240 resolution (ILI9342C driver), and touchscreen support (via FT6336U controller) Audio – 1W speaker (1W-0928), SPM4123 microphone, NS4168 I2S power amplifier Antenna – 2.4GHz 3D antenna USB – 1x USB Type-C port […]
Espressif Unveils ESP32-S2-MINI Modules, ESP32-S3 and ESP32-C3 SoC’s Coming Soon
Espressif Systems has unveiled two new ESP32-S2 WiFi modules part of the new MINI series modules, namely ESP32-S2-MINI-1U with IPEX antenna, and ESP32-S2-MINI-1 with a PCB antenna. The press release also mentions upcoming ESP32-S3 and ESP32-C3 processors with few details. Let’s have a look. ESP32-S2-MINI modules Preliminary specifications: SoC – Espressif ESP32-S2FH4 single-core 32-bit LX7 microcontroller @ up to 240 MHz, RISC-V ultra-low-power co-processor, 320 kB SRAM, 128kB ROM, 2.4 GHz WiFi 4 connectivity, 4MB flash Antenna ESP32-S2-MINI-1 – PCB antenna ESP32-S2-MINI-1U – IPEX antenna connector Dimensions ESP32-S2-MINI-1 – 20 x 15.4 x mm ESP32-S2-MINI-1U – 15.4 x 15.4 x mm The company states the exact processor SKU used in the module is ESP32-S2FH4, but initially I could not find out it differed from ESP32-S2 since it has the same specs include a single-core processor, ULP core, up to 43 GPIOs, and USB-OTG support. It turns out the flash appears […]
