HICAT.Livera Machine Vision Board and Robot Kit Feature HiSilicon Hi3518 SoC (Crowdfunding)

HiSilicon Hi3518 ARM9 processor is mostly being used in IP cameras, but Hicat startup decided to combined the camera processor with an Atmel MCU and a MT7601 WiFi module to create a wireless camera board to be used with OpenCV, and even provide a complete affordable robot kit with the board. Hicat.livera board specifications: Vision Core – Hisilicon Hi3518 ARM9 processor @ 440 MHz Storage – 16MB flash + micro SD card MCU – Atmel ATmega32U4 AVR micro-controller Connectivity – 802.11 b/g/n WiFi via Mediatek MT7601 module + u.FL antenna connector Camera interface with provided 140 deg. camera using Omnivision OV9712 720p (1280×720) sensor USB – 1x micro USB port for power and programming Audio – Built-in microphone, speaker header Sensors – MPU6050 accelerometer and gyro Expansion – 2x GPIO headers with GPIOs, I2C, SPI, serial, PWM, digital, analog and power signals. Misc – MCU reset and Linux reset buttons, […]

Hisilicon Hi3798M V200 SoC to Allow for Cheaper 4K TV Boxes with Gigabit Ethernet, SATA, and/or USB 3.0

One year after Hisilicon Hi3798C V200 processor was unveiled at IBC 2015, Hisilicon has now introduced a cost down version named Hisilicon Hi3798M V200 at IBC 2016 with a lower-end Mali-450 GPU, only 2 TS input interfaces, one less USB 3.0 interface, and only 1x GMAC (Gigabit Ethernet MAC) or 1x Fast Ethernet PHY, instead of two GMAC interfaces. The processor also adds 1080p30 H.265 video encoding. Hisilicon Hi3798M V200 key features: CPU – Quad core Cortex A53 processor (15K DMIPS) GPU – ARM Mali-450 + Hisilicon dual-core GPU Memory I/F – 32-bit DDR3/3L/4 Storage I/F – eMMC/NAND/SPI, 1x SATA 3.0, 2x SDIO Video Engine (VPU) HiVXE 2.0 video engine supporting 4Kp60 10-bit H.265 and VP9 decoding, 4Kp30 H.264, MPEG-2, MPEG-4, VC1, VP6/VP8, Real Media 8/9/10 Encoder – H.264/H.265 @ 1080p30 or dual 720p30 Imprex 2.0 processing engine with support for HDR10 & HLG high dynamic range, BT.709/BT.2020, etc.. Peripherals: […]

ARM announces “premium IP” for VR and AR with Cortex-A73 Processor and Mali-G71 GPU

Today ARM has revealed the first details of its latest mobile processor and GPU, both said to be optimized for VR (Virtual Reality) and AR (Augmented Reality) applications. Starting with the ARM Cortex-A73, we’re looking at an evolution of the current Cortex-A72 with ARM claiming 30 percent “sustained” performance over the Cortex-A72 and over twice the performance over the Cortex-A57. ARM is already talking about clock speeds of up to 2.8GHz in mobile devices. Other improvements include an increase up to 64k L1 instruction and data cache, up from 48 and 32k respectively for the Cortex-A72, as well as up to 8MB of L2 cache. The Cortex-A73 continues to support ARM’s big.LITTLE CPU design in combination with the Cortex-A53 or the Cortex-A35. It’s also the first ARM core to have been designed to be built using 10nm FinFET technology and it should be an extremely small CPU at around 0.65 […]

$15 RobinCore WiFi IoT Module Runs OpenWrt, Supports 720p Video Encoding (Crowdfunding)

Do you remember VoCore? It was a low cost OpenWrt WiFi IoT module based on Mediatek RT5350 processor, that had a very successful crowdfunding campaign managed by a single developer, and the project is still going strong with VoCore2 being in the works. Another developer had the idea of doing something similar but based on HiSilicon Hi3518 ARM9 processor with more memory and support for 720p video encoding making it suitable for HD drone camera, compact video cameras, and so on. Meet RobinCore. RobinCore specifications: SoC – Hisilicon Hi3518E ARM926 processor @ 440MHz with H.264 encoder([email protected]) System Memory – 64MB DDR2 Storage – 16 MB NOR flash Connectivity – 802.11 b/g/n WiFi via Mediatek MT7601U with on-board chip antenna Debugging – micro USB port Expansion – 2x 30-pin 2.0mm pitch through holes with access to 10/100M Ethernet, UART, I2C, SPI, SDIO, ADC, PWM, JTAG and GPIOs Power Support – 5V […]

Hisilicon HI3798C V200 64-bit ARM Processor Supports HDMI 2.0, 10-bit HEVC, USB 3.0, SATA and More

There have been several Cortex A53 processors announced or released on the market such as Rockchip RK3368, Allwinner A64, or Amlogic S905, but in many cases I can read comments complaining about the lack of high speed interface, incomplete code support, or a weak GPU. Hisilicon Hi3798C V200 offers better features than its competitor, as beside four Cortex A53 cores, it includes a Mali-720 GPU, supports HDMI 2.0 output up to 4K at 60 HZ, 10-bit HEVC / H.265 and VP9 video decoding at 3840×2160 resolution at 60 fps, and integrates SATA and USB 3.0 interfaces. Hisilicon Hi3798C V200 key features and specifications: CPU – Quad core Cortex A53 processor (15K DMIPS) GPU – ARM Mali-T720 supporting OpenGL ES 3.1/2.0, OpenVG1.1, EGL, and Imprex 2.0 PQ engine Memory I/F – DDR3 or DDR4 Video Engine (VPU) Codecs – HEVC, H.264, VP9, VC1, MPEG2 Decoder – 10-bit up to 4Kp60 Encoder – […]

Linaro 15.07 Release with Linux 4.2 and Android 5.1

Linaro 15.07 has been released with Linux 4.2-rc3 (Baseline), Linux 3.10.83, 3.14.45 and 3.18.17 (LSK), and Android 5.1.1_r8. The Linux kernel got various bug fixes, and a power reduction technique has been implemented for Qualcomm processor. Progress has been made to boot Android with UEFI on Hikey board, and work is still on-going on 96boards including Hisilicon Hikey, Qualcomm DragonBoard 410c, and an upcoming and yet-to-be-formally-announced Marvell PXA1928 board called Helium. Highlights of this release: Linux Linaro 4.2-rc3-2015.07 linaro-android topic updated to 4.2-rc3 and recent AOSP/android-3.18 included GATOR version 5.21.1 llct-misc-fixes topic: “HACK: of: Limit FDT size for CRC check on arm64” has been dropped. FVP model was the last target to require this hack, but the new FVP firmware doesn’t need it anymore updated integration-linaro-vexpress64 topic by ARM LT: Versatile Express TC2 support is back, HDLCD display now works on TC2, the topic will be renamed to integration-linaro-vexpress next […]

HiSilicon D02 Server Board Supports up to 64 ARM Cortex A57 Cores

HiSilicon has showcased their latest server SoC and board at Linaro Connect Hong Kong 2015, with up to two processors with 32 Cortex A57 cores @ 2.1GHz, 8 DIMM DDR3 slots (up to 128 GB RAM), 12 SATA ports, 4 PCIe slots, 10GbE / GbE ports. D02 board specifications: SoC – Hisilicon PhosphorV660 Hip05 with 16 to 32 ARM Cortex-A57 cores @ up to 2.1GHz and 1MB L2 cache/cluster, 32MB L3 cache System Memory – 2x Memory channel 4x DDR3 DIMM(4x DIMM per processor) Storage 12x SAS 3.0 ports @ 12 Gbps (8 for the first processor, 4 for the second).  SAS port are compatible with SATA drives. You may want to read SAS vs SATA post for more details about SAS. 2x SPI Flash 158Mb BIOS/UEFI 1Gb NorFlash Connectivity – 2×10/100/1000Mbit/s Gigabit Ethernet ports, 2x xGE SFP+ ports (10Gb/s) Expansion – 2x 8x PCI express interfaces per processor (4 […]

ARM Unveils Cortex A72 Processor and Mali-T880 GPU

ARM has just announced their new Cortex A72 ARMv8 core with 3.5 times the performance of Cortex A15 ARMv7 cores, together with Mali-T880 GPU delivering 1.8 times the performance of  Mali-T760, and CoreLink CCI-500 Cache Coherent Interconnect to link the new CPU, GPU and I/Os together. ARM Cortex A72 Some of the key features of the new core include: Architecture – ARMv8-A Multicore – 1-4x SMP within a single processor cluster, and multiple coherent SMP processor clusters through AMBA 5 CHI or AMBA 4 ACE technology ISA Support AArch32 for full backward compatibility with ARMv7 AArch64 for 64-bit support and new architectural features TrustZone security technology NEON Advanced SIMD DSP & SIMD extensions VFPv4 Floating point Hardware virtualization support Cache – 48KB I-cache, 32KB D-cache, and 512 KB to 2MB L2 cache with ECC Debug & Trace – CoreSight DK-A57 Process – 16nm FinFET A cluster can support up to […]
