Seaberry Mini-ITX carrier board for Raspberry Pi CM4 exposes 11 PCIe slots and sockets

SeaBerry mini-ITX motherboard Raspberry Pi CM4

The Raspberry Pi CM4 may only have a one PCIe x1 Gen 2 interface, but this has not stopped ALFTEL from designing Seaberry, a mini-ITX carrier board for the Raspberry Pi Compute Module 4 with eleven slots and sockets making use of the single 5 Gbps PCIe Gen 2 interface. The board also offers two SATA ports, one Gigabit Ethernet port, one RJ45 console port, two HDMI ports, a micro SD card slot, two USB 2.0 ports, as well as the usual 40-pin GPIO expansion header, besides the PCIe x16 slot, a PCIe x1 side slot, and M.2 and mPCIe sockets. Seaberry carrier board specifications: Compatible systems-on-module Raspberry Pi CM4 module (Regular or Lite) Radxa CM3 Pine64 SoQuartz Storage – 1x MicroSD card for Raspberry Pi CM4 Lite, 1x M.2 socket for NVMe SSD (See PCIe expansion section) Video Output – 2x HDMI output ports, 1x MIPI DSI connector Camera […]

November 24, 2021November 24, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

AMD Ryzen V1000/R1000 Mini-ITX board is made for game arcades, slot machines

Axiomtek GMB140 Ryzen R1000/V1000 mini-ITX board

Axiomtek GMB140 is a compact Mini-ITX motherboard powered by AMD Ryzen Embedded V1000/R1000 processor and mostly designed for gaming applications, as well as medical imaging, interactive kiosks, control rooms, and video surveillance. But when we’re not talking about your kids playing games at home here, but instead slot machines, arcade systems, and electronic gaming machines (EGM) powered by the GMB140 board with a PCIe interface for gaming I/O modules, and optional support for a 9-bit serial port for the SAS 6.02 protocol. Axiomtek GMB140 mini-ITX board specifications: SoC – AMD Ryzen Embedded V1000/R1000 quad-/dual-core “Zen” processor with Radeon Vega graphics either: AMD Ryzen Embedded V1807 w/ VEGA 11 graphics AMD Ryzen Embedded V1756 w/ VEGA 8 graphics AMD Ryzen Embedded V1605 w/ VEGA 8 graphics AMD Ryzen Embedded V1202 w/ VEGA 3 graphics AMD Ryzen Embedded R1606 w/ VEGA 3 graphics AMD Ryzen Embedded R1505 w/ VEGA 3 graphics System […]

September 8, 2021September 25, 2021 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

iBASE MI989 – 5G-ready Ryzen V2000 Mini-ITX motherboard offers PCIe x16 & M.2 expansion

We’ve written about Ryzen Embedded V2000 mini-ITX motherboards in the past, but here’s another one with iBASE MI989 equipped with four 4K-capable DisplayPort 1.4 video output, two Gigabit Ethernet ports, three M.2 sockets including a 5G-ready M.2 3052 socket, and a PCIe x16 slot for expansion. iBASE MI989 also supports up to 64GB ECC memory, one SATA III port, multiple USB 3.1/2.0 ports, four serial ports, and more, for embedded applications in retail, healthcare, industrial automation, casinos, and smart cities. iBASE MI989 specifications: SoC – AMD Ryzen V2000 Series Processors either: AMD Ryzen Embedded V2748, 8C/16T up to 2.9GHz (4.25GHz) with 4MB cache, 7 CU Radeon Vega graphics; 45W TDP AMD Ryzen Embedded V2718, 8C/16T up to 1.7GHz (4.15GHz), with 4MB cache, 7 CU Radeon Vega graphics; 15W TDP System Memory – Up to 64GB dual-channel DDR4-3200 (ECC/non-ECC) via 2x SODIMM sockets Storage – 1x SATA 3.0 (up to 6GB/s) […]

August 26, 2021August 26, 2021 by Jean-Luc Aufranc (CNXSoft) - 17 Comments

Turing Pi V2 mini-ITX cluster board takes four Raspberry Pi CM4 or NVIDIA Jetson SoMs

The Turing Pi V2 is a mini-ITX cluster board that builds on the Turing Pi mini-ITX cluster board taking up to 7 Raspberry Pi Compute Modules introduced in 2019, but instead supports up to four Raspberry Pi CM4 (Compute Modules 4) or NVIDIA Jetson Nano/TX2 NX/Xavier NX SO-DIMM system-on-modules. The Turing Pi 2 board is equipped with two Mini PCIe sockets, two Gigabit Ethernet ports, two SATA III ports, four USB 3.0 ports, a 40-pin GPIO header, and a 24-pin ATX connector for power. Since board-to-board connectors – as found in Raspberry Pi Computer Module 4 – are not ideal for density, the company went with a design including 260-pin SO-DIMM connectors plus CM4 adapter boards, a design that allows them to also integrate other SoMs like the NVIDIA Jetson SO-DIMM modules. Turing Pi V2 specifications: SoM interface – 4x 260-pin SO-DIMM slot for up to four Raspberry Pi CM4 […]

August 20, 2021August 21, 2021 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Qualcomm QRB5165 system-on-module is made for robotics applications

Lantronix Open-Q 5165RB is a tiny System-on-Module (SoM) based on the same Qualcomm QRB5165 octa-core IoT processor we’ve just seen in Qualcomm Flight RB5 5G Platform high-end drone reference design. The ultra-compact (50x29mm) module comes with 8GB LPDDR5, 128GB UFS flash, multiple MIPI camera and display ports, WiFi 6 and Bluetooth 5.1, and various I/Os. Lantronix Open-Q 5165RB module specifications: SoC – Qualcomm QRB5165 SoC built on 7nm technology with Octa-core CPU with 1x Kryo Gold prime @ 2.84 GHz, 3x Kryo Gold @ 2.42 GHz, 4x Kryo Silver @ 1.81 GHz Hexagon 698 DSP with quad Hexagon Vector eXtensions Adreno™ 650 GPU @ up to 587 MHz Spectra 480 Image Signal Processor Adreno 665 Video Processing unit – Decode up to 4K240/8K60, Encode up to 4K120/8K30, Concurrent 4K60 decode & 4K30 encode for wireless display NPU230 Neural Processing unit SPU240 Secure Processing unit Up to 15 TOPS of combined […]

August 20, 2021 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

ASUS N5105I-IM-A – A Jasper Lake mini-ITX motherboard with Celeron N5105 SoC

ASUS has unveiled, or rather inadvertently leaked, what may be the first Jasper Lake mini-ITX motherboard. following Intel Jasper Lake processors launch last January and a few mini PCs and 2-in-1s were introduced in recent months. ASUS N5105I-IM-A mini-ITX industrial motherboard is equipped with an Intel Celeron N5105 quad-core Jasper Lake processor with two SO-DIMM slots, VGA, HDMI, LVDS, PCIe 3.0/2.0 x1, mini PCIe, eight USB interfaces, six serial interfaces, as well as 12V DC input and output. ASUS N5105I-IM-A specifications: SoC – Intel Celeron N5105 quad-core processor @ 2.0GHz / 2.9GHz (Turbo) with Intel UHD graphics 605; 10W TDP System Memory – 2x SO-DIMM sockets Storage – 2x SATA ports Video Output HDMI 2.0 DisplayPort LVDS colay with eDP VGA Triple independent display support Audio – 3.5mm Line In and Line Out jacks; 3W amplifier; integrated buzzer Networking – Gigabit Ethernet port USB – 4x USB 3.2 Type-A ports, […]

August 13, 2021August 13, 2021 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

MiTAC introduces Intel Elkhart Lake & Comet Lake thin Mini-ITX motherboards

MiTAC has unveiled three industrial thin mini-ITX motherboards based on Elkhart Lake and Comet Lake processors with respectively MiTAC PD10EHI with a choice of low-power Intel Atom, Celeron and Pentium Elkhart Lake processors, and two more powerful motherboards with MiTAC PH11CMI & PH12CMI based on up to an Intel Core i9 Comet Lake processor, and which are virtually identical except for a different chipset allowing vPro features and RAID support. MiTAC PD10EHI Elkart Lake thin mini-ITX motherboard Specifications: Elkhart Lake SoC (one or the other) Intel Atom x6413E quad-core processor @ 1.5 GHz / 3.0 GHz (Turbo) with 16EU Intel UHD graphics; 9W TDP Intel Celeron N6210 dual-core processor @ 1.2 GHz / 2.6 GHz with 16EU Intel UHD graphics; 6.5W TDP Intel Celeron N6211 dual-core processor @ 1.2 GHz / 3.0 GHz with 16EU Intel UHD graphics; 6.5W TDP Intel Celeron J6413 quad-core processor @ 1.8 GHz / 3.0 […]

June 4, 2021June 4, 2021 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Ryzen Embedded V2000 mini-ITX industrial motherboard offers four DP++ video ports

AMD Ryzen Embedded V2000 mini-ITX motherboard

DFI RNO171 is a mini-ITX industrial motherboard powered by an AMD Ryzen Embedded V2000 processor with up to 64GB RAM, two SATA ports, four DisplayPort++ video outputs, and plenty of I/Os including dual GbE, a PCIe x16 expansion slot, multiple USB and serial ports, and more. DFI RNO171 mini-ITX SBC specifications: SoC – AMD Ryzen V2000 Series Processors either: AMD Ryzen Embedded V2748, 8C/16T up to 2.9GHz (4.25GHz) with 4MB cache, 7 CU Radeon Vega graphics; 45W TDP AMD Ryzen Embedded V2546, 6C/12T up to 3.0GHz (3.95GHz), with 3MB cache, 6 CU Radeon Vega graphics; 45W TDP AMD Ryzen Embedded V2718, 8C/16T up to 1.7GHz (4.15GHz), with 4MB cache, 7 CU Radeon Vega graphics; 15W TDP AMD Ryzen Embedded V2516, 6C/12T up to 2.1GHz (3.95GHz), with 3MB cache, 6 CU Radeon Vega graphics; 15W TDP System Memory – Up to 64GB dual-channel DDR4 (ECC/non-ECC) via 2x 260-pin SODIMM sockets Storage […]
