May 2, 2017May 2, 2017 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

MQMaker MiQi & ASUS Tinker Boards Get Linux 4.11 with 3D Graphics Acceleration

One day after the release of Linux 4.11, developer “Miouyouyou” has released Linux 4.11 for Rockchip RK3288 platforms such as MQMaker MiQi and ASUS Tinker boards with some patchsets for ARM Mali r16p0 kernel drivers, ARM fbdev, and to improve performance. The kernel has been tested with the Mali User-space r12p0 drivers for fbdev and wayland written for Firefly-RK3288, and some OpenGL ES 3.1/3.2 samples could successfully run on the board. 3D graphics acceleration does not work in X11 however. Miouyouyou also plans to add support for Rockchip VPU code, as well as ARM gator, and document how to use ARM DS-5 Streamline for OpenGL ES 2.x/3.x debugging. If you have a MiQi or Tinker board running Debian, you can try the kernel by adding beta.armbian.com Debian repository to your apt source file, and installing the following packages:

apt install linux-image-dev-rockchip linux-headers-dev-rockchip linux-dtb-dev-miqi

1	apt install linux-image-dev-rockchip linux-headers-dev-rockchip linux-dtb-dev-miqi

Via linux-rockchip G+ community. Jean-Luc Aufranc (CNXSoft)Jean-Luc started CNX Software in […]

March 31, 2017March 31, 2017 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

MQMaker Koala is a Features-Packed Development Board Powered by Rockchip RK3288 Processor

MQMaker launched MiQi board based on Rockchip RK3288 quad core Cortex A17 processor last year with the hardware aimed at hobbyists and makers, but the company has been developing a higher-end board – named Koala – based on the same processor, featuring many more ports and features, and geared towards the enterprise market. Koala board preliminary specifications: SoC – Rockchip 3288 quad core ARM Cortex A17 up to 1.8 GHz with Mali-T764 GPU supporting OpenGL ES 1.1/2.0 /3.0, and OpenCL 1.1 System Memory – 2GB DDR3 (default) Storage – 16 GB eMMC flash (default) + micro SD slot Video Output / Display Interface – HDMI 2.0, header for eDP, MIPI, LVDS, LCD backlight header, touch panel header Audio – HDMI out, optical S/PDIF, 3.5mm analog stereo audio jack, microphone header, audio L/R header Connectivity – Gigabit Ethernet, WiFi or WiFi + Bluetooth module, mini PCIe slot for 3G/4G card + SIM card slot USB – 4x […]

January 5, 2017May 20, 2019 by Jean-Luc Aufranc (CNXSoft) - 58 Comments

ASUS Tinker Board is a Raspberry Pi 3 Alternative based on Rockchip RK3288 Processor

Regular readers may remember MQMaker MiQi board, a $35 (and up) development board powered by Rockchip RK3288 quad core ARM Cortex A17 processor, based on Raspberry Pi 3 form factor, but much faster according to benchmarks. Sadly, the board’s crowdfunding campaign was not that successful, possibly because of the “its’ a 2-year old processor” syndrome. But now, Minimachines has found that ASUS has designed a very similar board, dubbed Tinker Board, with an extra WiFi and Bluetooth LE module, audio jack, MIPI DSI connector, and a few other modifications. Asus Tinker Board specifications (bold highlights and strike-through show differences with MiQi board): SoC – Rockchip 3288 quad core ARM Cortex A17 up to 1.8 GHz with Mali-T764 GPU supporting OpenGL ES 1.1/2.0 /3.0, and OpenCL 1.1 System Memory – 2GB LPDDR3, dual channel Storage – 8 or 32 GB eMMC flash + micro SD slot Video output & Display I/F 1x HDMI 2.0 up to 3840×2160@60p […]

May 13, 2016May 13, 2016 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

MiQi Dual Boot Android & Ubuntu Development Board Crowdfunding Campaign Has Launched

MiQi is a development board using a form factor similar to Raspberry Pi boards, but based on a more powerful Rockchip RK3288 Cortex A17 processor combined with 1 or 2 GB. I had the change to test an early sample pre-loaded with a dual boot image with Android 5.1 and Lubuntu 14.04, and found it to be one the fastest sub $100 development board in Linux, behind Hardkernel ODROID-XU4, as well as better CPU & GPU performance compared to recent Android TV boxes based on Amlogic S905, Rockchip RK3368, and so on. MQMaker has now launched a flexible funding crowdfunding campaign on Indiegogo to raise funds for mass production. Let’s remind us of MiQi hardware specifications first: SoC – Rockchip 3288 quad core ARM Cortex A17 up to 1.8 GHz with Mali-T764 GPU supporting OpenGL ES 1.1/2.0 /3.0, and OpenCL 1.1 System Memory – 1 or 2G DDR3 depending on model Storage – 8 or 32 […]

April 20, 2016April 20, 2016 by Jean-Luc Aufranc (CNXSoft) - 25 Comments

Android and Linux Benchmarks on MiQi Development Board

MiQi is an upcoming low cost development board powered by Rockchip RK3288 SoC that will sell for $35 with 1GB RAM and 8GB storage, and $69 for the version with a 2GB / 32GB combination. Since Rockchip RK3288 was launched in 2014, most available benchmarks were made on Android 4.4, and since MiQi is the first low cost board based on the processor, other RK3288 based board such as FireFly have not been that popular. So I’ve decided to run updated benchmarks in MiQi both in Android 5.1 and Linux (Lubuntu 14.04), which was easy since a dual boot image is pre-installed. But since I received an early sample without heatsink, I found a spare heatsink added some thermal paste and placed it on top of the processor and partially on RAM and eMMC flash. MiQi Board Android 5.1 Benchmarks I ran Antutu both using 1080p60 and 2160p30 video output, […]

April 18, 2016April 19, 2016 by Jean-Luc Aufranc (CNXSoft) - 31 Comments

MiQi Rockchip RK3288 Development Board using Raspberry Pi Form Factor to Sell for $35 and Up

Rockchip RK3288 processor may have launched in 2014, but it’s still one of the most powerful processor found in TV boxes for example, and in the past we’ve seen higher end board based on the processor such as Firefly-RK3288 or Radxa Rock 2 Square selling for well above $100. But MQMaker, the company that previously made WiTi router board, is bringing a smaller and cheaper RK3288 development board with MiQi, which definitely looks similar to the Raspberry Pi. MiQi board specifications: SoC – Rockchip 3288 quad core ARM Cortex A17 up to 1.8 GHz with Mali-T764 GPU supporting OpenGL ES 1.1/2.0 /3.0, and OpenCL 1.1 System Memory – 1 or 2G DDR3 depending on model Storage – 8 or 32 GB eMMC flash depending on model + micro SD slot Video & Audio output – HDMI 2.0 up to 3840×2160@60p Connectivity – Gigabit Ethernet USB – 4x USB 2.0 host ports, 1x micro USB port Debugging […]

December 17, 2015May 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

ADBoard 3G/4G Digital Signage Board is Powered by Allwinner A83T Octa-Core Processor

MQMaker officially launched their WiTi router board earlier this week, but the company has also introduced ADBoard, an octa-core board specifically designed for digital signage with a connector for LVDS display including backlight, an RTC with backup battery, and a mini PCIe connector for 3G/4G connectivity combined with a SIM card slot. ADBoard specifications: SoC – Allwinner A83T octa-core ARM Cortex-A7 @ 2.0 GHz with PowerVR SGX544MP GPU @ 700 MHz supporting OpenGL ES 2.0/1.1, OpenCL 1.1, and DX 9.3. System Memory – 1 GB DDR3 Storage – 16 GB eMMC + micro SD slot Display Interfaces / Video Output HDMI up to 1080p60 with HDCP 1.2 and CEC support connector LVDS connector, LCD backlight control header and capacitive touch panel header Audio – HDMI, 3.5mm audio output, speaker connector, microphone connector Connectivity – Gigabit Ethernet, 802.11 b/g/n Wi-Fi and Bluetooth 4.0 USB – 1x USB 2.0 host port, 1x […]

December 14, 2015December 14, 2015 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

WiTi Router Board Powered by Mediatek MT7621A SoC Now Sells for $79

MQmaker launched their WiTi router on Indiegogo in early August, and they raised close to $30,000, enough to go into production. However, some people are understandably wary of crowdfunding campaigns, and likely postponed their decision to see how the project would progress. The good news is that the AC1200 board is now available for $79 + shipping ($9.05 in my case) on Aliexpress. WiTi router specifications have not changed much: Processor – Mediatek MT7621A dual core MIPS 1004Kc processor @ 880Mhz System Memory – 256MB RAM Storage – 16MB SPI NOR flash for firmware, 1x micro SD slot, and 2x SATA 3.0 ports supporting 3.5″ hard drives. Connectivity 2.4 GHz WiFi 802.11b/g/n up to 300Mbps 5 GHz WiFi 802.11a/n/ac up to 867Mbps 2x Gigabit Ethernet WAN ports 4x Gigabit Ethernet LAN ports 2x RF Antenna Connectors USB – 1x USB3.0 port Expansion – 30-pin header including USB, I2S, JTAG, UART, and GPIO […]
