April 28, 2025April 28, 2025 by Debashis Das - 4 Comments

Jetway B420PADN1 – A compact, fanless embedded box PC with Intel N97/N200 SoC, M.2 sockets, COM ports

B420PADN1 Fanless Compact Box PC with Intel N series SoC Processors

The Jetway B420PADN1 is a compact, fanless box PC built around an Intel N97 or N200 Alder Lake-N SoCs. The computer system features a Pico-ITX motherboard and operates in a wide -20°C to 50°C temperature range for industrial, commercial, and embedded applications where reliable and silent operation are important. The PC comes pre-installed with 8GB DDR5 4800MHz SO-DIMM memory (expandable up to 32GB) and supports 4K display output via an HDMI 2.0b port. For storage and expansion, it offers M.2 B+M Key and E-Key slots, along with a Nano SIM slot for cellular connectivity. Other features include two serial ports, USB 3.2 Gen1 and USB 2.0 ports, Gigabit Ethernet, and VESA/wall mounting options. These features make this embedded box PC suitable for applications such as digital signage, industrial automation, edge computing, IoT gateways, kiosks, and smart retail. Jetway B420PADN1 box PC specifications: Alder Lake-N SoC (one or the other) Intel […]

January 9, 2025January 10, 2025 by Debashis Das - 20 Comments

Qualcomm QCS6490-based Rubik Pi 3 AI SBC supports Android, Linux, and LU operating systems

Thundercomm has officially launched the Rubik Pi 3 SBC built around the Qualcomm QCS6490 SoC with a 12.5 TOPS AI accelerator. The SBC comes in a “PI-CO ITX” form factor that combines the Pico-ITX standard and the 40-pin GPIO header found on Raspberry Pi SBCs. The SBC comes with a standard set of interfaces, including USB, HDMI out, MIPI-CSI camera support, Ethernet, Wi-Fi 5, Bluetooth 5.2, and much more. Additionally, the SBC features a 40-pin header for GPIO, UART for debugging, audio output, and RTC battery support. The company mentions that it is the first Pi-based system using Qualcomm’s AI platforms, hence it supports Raspberry Pi HAT/HAT+ expansion boards, making it suitable for various AI, IoT, and edge computing projects. Rubik Pi 3 SBC specifications: SoC – Qualcomm QCS6490 CPU – Octa-core Kryo 670 with 1x Gold Plus core (Cortex-A78) @ 2.7 GHz, 3x Gold cores (Cortex-A78) @ 2.4 GHz, 4x […]

December 20, 2024December 20, 2024 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

STM32MP135 Pico-ITX SBC features 38x32mm EBYTE CPU module with 512MB RAM, 512MB NAND flash

EBYTE STM32MP135 Cortex-A7 Pico-ITX single board computer

EBYTE ECB10-135A5M5M-I is a pico-ITX single board computer (SBC) equipped with a small STM32MP135 Arm Cortex-A7 CPU module from the company equipped with 512MB DDR3L, 512MB NAND flash, a Gigabit Ethernet PHY, and power circuitry. The industrial-grade SBC itself features RGB and HDMI 2.0 connectors supporting up to 1366×768 resolution, 3.5mm Line in and out jacks, several USB connectors, and two “UIO” expansion ports with RS485, RS485, CAN Bus, GPIO, and other I/Os. These features make the board suitable for industrial automation, smart cities, display and control terminals, and other industrial applications. EBYTE ECB10-135A5M5M-I specifications: EBYTE ECK10-135A5M5M-I core board SoC – STMicro STM32MP135AAF3 single-core Arm Cortex-A7 core clocked at 650MHz System Memory – 512MB DDR3L Storage – 512MB SLC NAND flash Networking – Gigabit Ethernet PHY Host interface – 128-pin stamp holes Power Management 3.3V/1A power input PMIC – STPMIC1APQR 2x 1.7-3.0V LDO with 350mA max current Dimensions – 38 […]

October 30, 2024 by Tomisin Olujinmi - No Comments

MSI MS-CF16 fanless Alder Lake-N/Amston Lake Pico-ITX single board computer features up to 16GB LPDDR5 RAM

MSI MS-CF16 Pico-ITX single-board computer

MSI MS-CF16 is a fanless single board computer (SBC) in the Pico-ITX form factor powered by low-power Intel Alder Lake-N or Amston Lake series processors. It features up to 16GB LPDDR5 RAM, offers dual independent display support via HDMI and LDVS/eDP connectors, and integrates other peripherals such as 2.5GbE and 1GbE LAN ports, multiple USB 3.2 and USB 3.0 ports, and two M.2 (B-Key and E-Key) sockets. The MS-CF16 is a smaller and more power-efficient alternative to the MS-CF17 3.5-inch SBC which we covered previously. It is perfect for industrial and embedded applications such as industrial automation, edge computing, medical devices, outdoor signage, and general computing in demanding conditions. It’s far from the first Alder Lake-N or Amston Lake Pico-ITX single board computer we’ve written about, and competing solutions include Jetway’s JPIC-ADN1, AAEON’s PICO-ASL4, DFI’s RPP051, and Kontron 2.5”-SBC-AML/ADN Alder Lake-N/Amston Lake Pico-ITX SBC covered by Sayantan earlier today. MSI […]

October 30, 2024October 30, 2024 by Sayantan Nandy - No Comments

Kontron 2.5”-SBC-AML/ADN Pico-ITX SBC features Alder Lake-N or Amston Lake SoC up to Intel Atom X7835RE

Kontron has launched its new Amston Lake Pico-ITX SBC, the 2.5”-SBC-AML/ADN series, optimized for low-power, real-time computing in industrial automation, smart cities, energy, retail, and healthcare applications. This compact SBC series supports Intel’s energy-efficient processors, including the Intel Atom x7000E Series, Intel Core i3 N-Series, Intel N-Series (Alder Lake-N), and the Intel Atom x7000RE Series (Amston Lake). With Intel UHD Graphics (Gen12) featuring up to 32 execution units, these Amston Lake Pico-ITX SBCs enhance graphics processing and support concurrent AI inference. Powered by Intel Deep Learning Boost, they achieve faster AI inference, which is ideal for efficient edge computing, while meeting the stringent demands of real-time, low-latency applications. Previously, we covered several Pico-ITX SBCs, including the AAEON PICO-ASL4, Jetway JPIC-ADN1, AAEON PICO-IMX8PL, and AAEON RICO-MX8P, among others. Feel free to explore these reviews if you’re interested in similar SBCs. Kontron 2.5”-SBC-AML/ADN specifications: CPU Standard Intel Atom x7211RE dual-core processor up […]

October 7, 2024October 7, 2024 by Debashis Das - No Comments

Jetway JPIC-ADN1 fanless, industrial Pico-ITX SBC features Intel N97 or N200 CPU, dual display support

Jetway JPIC-ADN1 is a fanless pico-ITX SBC powered by an Intel N97 or N200 Alder Lake-N processor and targeted at industrial robotics applications. The JPIC-ADN1 supports up to 32GB of memory via a single-channel SO-DIMM slot. The SoC comes with UHD Graphics, supporting dual-display outputs via HDMI 2.0b and a 24-bit dual-channel LVDS interface. For storage, it features an M.2 B+M-Key socket and a SATA 3 port, plus an E-Key 2230 socket for wireless expansion. Gigabit Ethernet networking is handled by the RTL8111H GbE controller. Additionally, it has a serial header, 8-bit GPIO, SMBUS, watchdog timer, and much more. JPIC-ADN1 fanless SBC specification Alder Lake-N SoC (one or the other) Intel Processor N97 quad-core Alder Lake N-series processor with Intel UHD graphics; 12W TDP Intel Processor N200 quad-core processor @ up to 3.7 GHz (Turbo) with 6MB cache, 32EU Intel HD graphics @ up to 750 MHz; TDP: 6W Additional compatible CPUs available via regional sales […]

September 14, 2024September 14, 2024 by Debashis Das - No Comments

AAEON PICO-ASL4 industrial Pico-ITX SBC ships with Intel Atom x7000RE, up to 16GB DDR5, 2.5GbE LAN

AAEON PICO ASL4 Rev.B Intel Atom x7000RE Pico ITX SBC

AAEON PICO-ASL4 is a fanless, latency-sensitive Pico-ITX single board computer (SBC) built around the Intel Atom x7000RE-series “Amston Lake” SoCs and configurable with up to 16GB of DDR5 memory. The SBC supports dual display outputs via HDMI and LVDS/eDP and features four serial ports: two RS232/422/485 and two RS232. For networking, it provides dual Ethernet connectivity with Intel i226 2.5GbE and Realtek RTL8111H 1GbE controllers, both supporting TSN and TCN. Additionally, it offers a variety of expansion options, including a full-sized mSATA/mPCIe slot and an M.2 2230 E-Key socket for WiFi and Bluetooth. For further connectivity, there are four USB 2.0 ports, two USB 3.2 Gen 2 ports, as well as GPIO and SMBus/I2C headers. AAEON PICO-ASL4 (Rev.B) specifications SoC – Intel Amston Lake (one or the other) Intel Atom x7433RE, 4 cores, 1.5GHz, 9W TDP Intel Atom x7835RE, 8 cores, 1.3GHz, 12W TDP System Memory – Up to 16GB DDR5 […]

September 10, 2024September 8, 2024 by Debashis Das - No Comments

AAEON introduces NXP i.MX 8M Plus Pico-ITX SBC and mini PC designed for Edge AI industrial applications

AAEON PICO-IMX8PL is a Pico-ITX SBC built around the NXP i.MX 8M Plus Edge AI processor which the company has also released in an enclosed form as the SRG-IMX8PL mini-PC. Both are designed for industrial AIoT/IoT applications. The SBC features various connectivity options including dual Gigabit Ethernet, Wi-Fi/Bluetooth, 4G LTE, CAN-FD, Audio, LVDS, and support for popular protocols like Modbus, MQTT, and OPCUA. Whereas the mini PC sacrifices some I/O interfaces and the LVDS display output to enable wall or DIN rail mounting. Both products have wide operating temperature ranges, fanless designs, and compact form factors making them ideal for deployment in harsh industrial environments. All these features make this device useful for industrial automation, transportation, and digital signage. AAEON PICO-IMX8PL Pico-ITX SBC and RG-IMX8PL mini-PC specifications SoC – NXP i.MX 8M Plus AI SoC CPU Quad-core Arm Cortex-A53 processor @ up to 1.6 GHz Arm Cortex-M7 real-time core @ 800 […]
