Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on RK628D adds HDMI input, extra video outputs to Rockchip processors

RK628D adds HDMI input, extra video outputs to Rockchip processors

If I’m asked about a Linux or Android platform with HDMI input, I would immediately think about Realtek RTD1295 SoC with products like Zidoo X9S or X2 TV stick which enabled picture-in-picture (PiP), UDP/TCP broadcast of HDMI input, or PVR functions. Some Rockchip boards such as Orange Pi RK3399 SBC do come with both HDMI output and HDMI input, with the latter relying on a Toshiba TC358749XBG HDMI interface bridge IC. But Rockchip has decided to design its own HDMI input chip with Rockchip RK628D supporting HDMI, parallel RGB or BT.1120 as input and dual MIPI, dual LVDS, GVI (general video interface), parallel RGB, or BT.1120 as outputs. The new chip would enable PCB designers to add display output ports to application processors such as RK3288 or RK3399, or add an HDMI input interface. Rockchip RK628D key features and specifications: Video input interfaces HDMI 1.4/2.0 RX interface up to 4Kp60 (yuv420) – Support 8-/10-bit, RGB888/YUV420, EDIC and CEC. Parallel RX […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on UP Xtreme Smart Surveillance Combines Whiskey Lake SBC, Myriad X VPUs, and Video Management & Analytics Software

UP Xtreme Smart Surveillance Combines Whiskey Lake SBC, Myriad X VPUs, and Video Management & Analytics Software

We’re seeing more and more computer vision products with built-in artificial intelligence accelerated features like face recognition or object detection including AI cameras, facial recognition systems, and AI NVR systems. It’s great as a consumer because of less frequent and more accurate alerts in security camera systems but more worrying as a citizen due to mass surveillance. But the trend is here to stay, and AAEON has just announced the UP Xtreme Smart Surveillance solutions powered by UP Extreme Whiskey Lake SBC with either an Intel Core i5-8365UE or Intel Core i7-8665UE processor, as well as two Intel Movidius Myriad X VPUs using OpenVINO SDK. The system also leverages Milestone video management software (VMS) and SAIMOS video analytics software. Based on the photo above, the hardware looks to be UPX-Edge Embedded Computer which we previously covered in details at launch last December. Instead of hardware, the focus of Up Xtreme Smart Surveillance is to provide a turnkey solution combining AAEON […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Advantech Edge AI Computer and PoE NVR Feature NVIDIA Jetson Xavier NX SoM

Advantech Edge AI Computer and PoE NVR Feature NVIDIA Jetson Xavier NX SoM

Following the launch of NVIDIA Jetson Xavier NX SoM last year, we noted several third-party carrier boards and embedded PCs had been announced, and we expected more to come soon. Advantech has now unveiled two systems based on NVIDIA latest module with respectively  MIC-710AIX edge AI computer and MIC-710IVX NVR system equipped with eight PoE ports. MIC-710AIX edge AI computer Specifications: SoM – NVIDIA Jetson Xavier NX with 6-core NVIDIA Carmel ARM v8.2 64-bit CPU, 6MB L2 + 4MB L3 caches 384-core NVIDIA Volta GPU with 48 Tensor Cores 2x NVDLA deep learning accelerators System Memory – 8GB 128-bit LPDDR4x Storage – 16 GB eMMC 5.1 flash Storage – M.2 2280 Key-M socket for SSD; SD card socket Video Output – HDMI up to 3840×2160 @ 60 Hz Networking – 2x Gigabit Ethernet (RJ45) via Intel i210IT controller USB – 1x USB 3.0 host port, 1x USB 2.0 host port, 1x USB 2.0 internal interface, 1x Micro USB OTG port […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on AI Network Video Recorder Combines Intel Atom X5 E3940 SoC, Two Myriad X VPUs, and Five Ethernet Ports

AI Network Video Recorder Combines Intel Atom X5 E3940 SoC, Two Myriad X VPUs, and Five Ethernet Ports

AAEON seems to launch a new “AI Embedded Box PC” monthly either equipped with an NVIDIA Jetson module or a solution combining an Intel processor and a Myriad X VPU card. Here’s another one with AAEON VPC-3350AI AI edge computer powered by an Intel Atom X5 E3940 Apollo Lake processor, as well as two Myriad X VPUs for AI acceleration, and equipped with five Ethernet ports – four of which supporting PoE – to get video data from IP cameras or other networked video sources that makes it especially suitable as an AI network video recorder. VPC-3350AI specifications: SoC – Intel Atom X5-E3940 quad-core Apollo Lake processor @ 1.6 GHz / 1.8 GHz with 2 MB cache, 12 EU Intel UHD graphics; 9.5W TDP; Option for Celeron N4200/N3350 and X5-E3950) System Memory – Up to 8GB, DDR3L via 204-pin SODIMM socket Storage – 1x SATA port for 2.5″ drives AI Accelerator – 2x Intel Myriad X Vision Processing Unit (up […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on HeimVision HM241 NVR Review – Part 2: Installation Tips, Video Interface, Android App

HeimVision HM241 NVR Review – Part 2: Installation Tips, Video Interface, Android App

A coupled of weeks ago, I received HeimVision HM241 HD NVR kit, and in the first part of the review, I showed the content of the kit, installed an internal 3.5″ hard drive, and did a teardown of both the NVR and one camera. I’ve now had time to test the device for about two weeks. I have plans to install it permanently in another location, but for testing, I temporarily installed the camera for testing in several strategic locations: 3 outdoors, one indoors. Back inside, I connected the NVR device (black box below) to an Ethernet switch for Internet connectivity, a 4K TV to access the user interface, a USB mouse, and the power supply. First Boot and Configuration I was quite surprised during the first boot as I did not have to set up anything and the cameras were automatically detected. The first screen shows QR code for the Android and iOS apps, as well as the Cloud […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on HeimVision HM241 HD NVR Kit Review – Part 1: Unboxing, Teardown and HDD Installation

HeimVision HM241 HD NVR Kit Review – Part 1: Unboxing, Teardown and HDD Installation

I’ve reviewed a few solar-powered security cameras in the last year, and from time to time, I’m being asked to review more from time to time, but I asked for a change, and instead, I wanted to look into security network video recorders (NVR). HeimVision offered this opportunity with its HM241 HD NVR Kit which they also call a “wireless security camera system”, and comes with 4 Full HD security cameras besides the NVR itself. In the first part of the review, I’ll check out the hardware, and take the opportunity to install a 3.5″ hard drive, before doing a proper installation, and report my experience about the software in one or two extra articles. HM241 HD NVR Kit Unboxing People working at customs seem to be fond of larger packages, checked it out in details hence the “Opened and Releases” sticker on the package,  and I had to pay customs duties. Let’s check out the NVR first. The front […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on Amazon Fire TV Recast DVR Records up to 150 Hours of Video

Amazon Fire TV Recast DVR Records up to 150 Hours of Video

Amazon has a hardware event yesterday where the company announced new Alexa smart speakers with better audio, Echo Input similar to ChromeCast audio and to be plugged into your own speakers, a new revision of Amazon Echo Show smart display, and some completely new Alexa powered products like Echo Wall Clock, Echo Auto connecting to your smartphone and your car’s speakers, and even an Alexa Microwave selling for $59.99. But I’m going to focus in another of their new product in this post: Amazon Fire TV Recast digital video recorder and media streamer with up to four ATSC tuners. Amazon Fire TV Recast will be available in two configurations: 500GB storage with two tuners, or 1TB storage with four tuners. Specifications: SoC – Unnamed dual core processor System Memory – 2GB RAM Storage 500 GB hard drive storing up to 75 hours of HDTV OR 1TB hard drive storing up to 150 hours of HDTV Connectivity Ethernet – Gigabit Ethernet […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on Realtek RTD1295 based X2 Android TV Stick Comes with HDMI Output, HDMI Input

Realtek RTD1295 based X2 Android TV Stick Comes with HDMI Output, HDMI Input

Realtek RTD1295 processor is found in mid to high end 4K HDR TV boxes with interfaces like SATA, USB 3.0, as well as HDMI input used for PiP or video recording features. Devices equipped with the processor that come to mind include Zidoo X9S or EWEAT R9 Plus TV Box + NAS, both of which are full featured and fairly large devices, running Android 6.0 and OpenWrt. Shenzhen Tomato has unveiled another type of device based on RTD1295 processor: X2 HDMI TV dongle that features both HDMI output & HDMI input ports, and runs Android 6.0 (but not OpenWrt). X2 TV stick specifications: SoC – Realtek RTD1295 quad core Cortex A53 processor @ 1.40 GHz with ARM Mali-T820MP3 GPU System Memory – 1 or 2GB DDR4 Storage – 8 or 16GB eMMC flash + micro SD slot Video & Audio I/O – HDMI 2.0a output, and HDMI 1.4 input Video Codec – 10-bit HEVC/H.265 up to 4K @ 60fps, H.264 […]
