Posted on by Debashis Das - No Comments on Allwinner T153-based industrial SoM and SBC feature a mix of Arm Cortex-A7 and RISC-V cores

Allwinner T153-based industrial SoM and SBC feature a mix of Arm Cortex-A7 and RISC-V cores

Forlinx FET153 S Allwinner T153 System on Module

Forlinx has recently introduced the Allwinner T153-based FET153-S SoM and the OK153-S SBC. The Allwinner T153 processor features a hybrid architecture that combines a quad-core Arm Cortex-A7 CPU with an XuanTie E907 RISC-V core. The board features up to 1GB DDR3 RAM, 8GB eMMC, triple Gigabit Ethernet, dual CAN-FD, RS-485, and a Local Bus for PSRAM or FPGA expansion. Display options include support for RGB, LVDS, and MIPI DSI interfaces, and camera inputs are offered via parallel or MIPI CSI. Additional I/O include multiple UART, I²C, SPI, I²S, GPADC, and GPIO options, along with Wi-Fi/Bluetooth, a USB Type-C OTG port, and a Mini PCIe socket for 4G modules. Target applications include real-time control and edge computing, industrial automation, IoT gateways, and embedded systems. Forlinx FET153-S system-on-module Specifications: SoC – Allwinner T153 CPU 4x Arm Cortex-A7 cores @ up to 1.6GHz XuanTie E907 RISC-V core @ up to 600MHz GPU – 2D […]

Posted on by Debashis Das - 7 Comments on Raspberry Pi-like Allwinner A527/T527 industrial SBC features dual camera support and AI acceleration

Raspberry Pi-like Allwinner A527/T527 industrial SBC features dual camera support and AI acceleration

CDEBYTE ECB32 Series Multi core Heterogeneous Allwinner T527 SBC

EBYTE has recently released an Allwinner A527/T527-based Raspberry Pi-like industrial SBC with dual camera and AI features, with a design very similar to the Walnut Pi 2B, and to a lesser extent, the Orange Pi 4A. It is designed for embedded, IoT, and smart commercial applications. The board supports up to 4GB LPDDR4 RAM, 32GB eMMC storage, and MicroSD card expansion. Display options include HDMI 2.0 and a 4-lane MIPI DSI interface enabling dual 4K output, while two 4-lane MIPI CSI connectors allow simultaneous camera inputs. Connectivity options include Gigabit Ethernet, Wi-Fi 4, Bluetooth 4.2, and a PCIe 2.1 x1 slot for high-speed expansion. It also features four USB 2.0 ports, a Type-C power interface, and a 40-pin Raspberry Pi-compatible GPIO header. EBYTE Allwinner A527/T527 SBC specifications: SoC – Allwinner T527 (industrial) / Allwinner A527 (commercial) CPU Octa-core Arm Cortex-A55 processor with four cores @ 1.80 GHz (T527) or 2.0 […]

Posted on by Debashis Das - No Comments on EMAC SoM-35D1F industrial SO-DIMM SoM features NuvoTon MA35D1 SoC, two GbE interfaces

EMAC SoM-35D1F industrial SO-DIMM SoM features NuvoTon MA35D1 SoC, two GbE interfaces

SoM 35D1F ARM64 System on Module

EMAC SoM-35D1F is an industrial-grade SoM built around the NuvoTon NuMicro MA35D1 dual-core Cortex-A35/M4 SoC with a 200-pin SO-DIMM edge connector. The module comes with 512MB DDR3L RAM and up to 16GB eMMC flash, and targets applications such as edge gateways, HMI systems, industrial automation, and smart energy systems. The SoM-35D1F also features dual Gigabit Ethernet, 4x serial interfaces (RS485/RS232), 2x CAN-FD, multiple USB 2.0 interfaces, I2S audio, SPI, I2C, and 14x GPIO. It also supports CSI camera input, a 24-bit LCD controller with resistive touch, and 12-bit ADCs for analog sensing. Additionally, it comes with security features like TrustZone, Secure Boot, and TSI (Trusted System Identity). EMAC SoM-35D1F specifications: SoC – Nuvoton NuMicro MA35D1 CPU 2x Arm Cortex-A35 cores at up to 800 MHz Arm Cortex-M4 processor core at  up to 180 MHz GPU – 2D Graphic Engine (GFX) VPU – H.264 video decoder up to 1920×1080 @ 45 Hz; […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 21 Comments on Walnut Pi 2B is an Allwinner T527 octa-core SBC with Raspberry Pi 5 form factor and interfaces

Walnut Pi 2B is an Allwinner T527 octa-core SBC with Raspberry Pi 5 form factor and interfaces

Walnut Pi

Walnut Pi 2B is a single board computer (SBC) powered by an Allwinner T527 octa-core Cortex-A55 SoC with a built-in 2 TOPS AI accelerator that closely follows the Raspberry Pi 5 design for compatibility with most HAT+ expansion boards and accessories. The Walnut Pi 2B SBC ships with 1GB to 4GB LPDDR4 RAM, an optional 32GB eMMC flash, and features a microSD card slot, gigabit Ethernet, four USB ports, a WiFI and Bluetooth module, MIPI DSI/CSI connectors, and the same PCIe FFC connector as found on the Raspberry Pi 5, and a 40-pin GPIO. One of the most obvious differences is that it only comes with one micro HDMI port instead of two on the Pi 5. Let’s check out the specifications to find other changes. Walnut Pi 2B specifications: SoC – Allwinner T527 CPU Octa-core Arm Cortex-A55 processor with four cores @ 1.80 GHz and four cores @ 1.42GHz […]

Posted on by Tomisin Olujinmi - 4 Comments on Haasoscope Pro open-source, real-time sampling USB oscilloscope supports up to 2GHz bandwidth (Crowdfunding)

Haasoscope Pro open-source, real-time sampling USB oscilloscope supports up to 2GHz bandwidth (Crowdfunding)

Haasoscope Pro USB oscilloscope

The Haasoscope Pro is an open-source hardware, high-bandwidth, and real-time sampling USB oscilloscope. Building upon its predecessor, the Haasoscope, the new Pro model offers a bandwidth of 2GHz, 12-bit resolution, and a 3.2GS/s sampling rate. The Haasoscope Pro USB oscilloscope is “designed to be low cost, while maintaining super-fast performance.” While it only comes with 2 channels, the flexible design makes it possible to combine and sync multiple devices (using Cat5 cables) to double the sample rate or add more channels. The oscilloscope works with standard x10 passive probes but a custom active probe, the Haasoscope Pro-be, is also offered. It supports the full 2GHz analog bandwidth and is priced much cheaper than similar probes. The Haasoscope Pro USB oscilloscope’s high sampling rate and bandwidth make it ideal for radio frequency signal analysis and high-speed digital debugging. It is similar to the ThunderScope Thunderbolt and PCIe oscilloscope which offers more […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Graperain G3562 – A Rockchip RK3562 system-on-module and development board

Graperain G3562 – A Rockchip RK3562 system-on-module and development board

Rockchip RK3562 development board

Graperain G3562 is a Rockchip RK3562 quad-core Cortex-A53 system-on-module (SoM) with up to 8GB LPDDR4, up to 128GB eMMC flash suitable for Edge AI, IoT, automation, and consumer electronic applications. The company also provides the G3562 development board for the SoM with an M.2 socket for NVMe SSD, dual Ethernet, WiFi 5 and Bluetooth 5.0, and optional 4G LTE/3G cellular connectivity, plus a MIPI DSI/LVDS display connector, two MIPI CSI camera connectors, three USB 2.0 ports, audio interfaces, and expansion through a 30-pin GPIO header and UART connector. Graperain G3562 SoM GrapeRain G3562 specifications: SoC –  Rockchip RK3562 CPU – Quad-core Arm Cortex-A53 quad-core @ 2.0 GHz GPU – Mali-G52-2EE with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.0/1.1 AI accelerator – 1 TOPS (INT8) NPU VPU Encoder – H.264 1920×1080 @ 60fps Decoder – H.265/VP9 4096×2304 @ 30fps; H.264 1920×1080 @ 60fps RAM – 2GB LPDDR4 by default […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Firefly EC-R3576PC FD is an Embedded Large-Model Computer based on Rockchip RK3576 processor

Firefly EC-R3576PC FD is an Embedded Large-Model Computer based on Rockchip RK3576 processor

Firefly RK3576 Embedded Large Model Computer

Firefly EC-R3576PC FD is described as an “Embedded Large-Model Computer” powered by a Rockchip RK3576 octa-core Cortex-A72/A53 processor with a 6 TOPS NPU and supporting large language models (LLMs) such as Gemma-2B, LlaMa2-7B, ChatGLM3-6B, or Qwen1.5-1.8B. It looks to be based on the ROC-RK3576-PC SBC we covered a few weeks ago, and also designed for LLM. But the EC-R3576PC FD is a turnkey solution that will work out of the box and should deliver decent performance now that the RKLLM toolkit has been released with NPU acceleration. However, note there are some caveats doing that on RK3576 instead of RK3588 that we’ll discuss below. Firefly EC-R3576PC FD specifications: SoC – Rockchip RK3576 CPU 4x Cortex-A72 cores at 2.2GHz, four Cortex-A53 cores at 1.8GHz Arm Cortex-M0 MCU at 400MHz GPU – ARM Mali-G52 MC3 GPU clocked at 1GHz with support for OpenGL ES 1.1, 2.0, and 3.2, OpenCL up to 2.0, and […]

Posted on by Debashis Das - 10 Comments on Firefly ROC-RK3576-PC low-profile Rockchip RK3576 SBC supports AI models like Gemma-2B, LlaMa2-7B, ChatGLM3-6B

Firefly ROC-RK3576-PC low-profile Rockchip RK3576 SBC supports AI models like Gemma-2B, LlaMa2-7B, ChatGLM3-6B

Firefly ROC RK3576 PC SBC

Firefly ROC-RK3576-PC is a low-power, low-profile SBC built around the Rockchip RK3576 octa-core Cortex-A72/A53 SoC which we also find in the Forlinx FET3576-C, the Banana Pi BPI-M5, and Mekotronics R57 Mini PC. In terms of power and performance, this SoC falls in between the Rockchip RK3588 and RK3399 SoCs and can be used for AIoT applications thanks to its 6 TOPS NPU. Termed “mini computer” by Firefly this SBC supports up to 8GB LPDDR4/LPDDR4X memory and 256GB of eMMC storage. Additionally, it offers Gigabit Ethernet, WiFi 5, and Bluetooth 5.0 for connectivity. An M.2 2242 PCIe/SATA socket and microSD card can be used for storage, and the board also offers HDMI and MIPI DSI display interfaces, two MIPI CSI camera interfaces, a few USB ports, and a 40-pin GPIO header. Firefly ROC-RK3576-PC specifications SoC – Rockchip RK3576 CPU 4x Cortex-A72 cores at 2.2GHz, four Cortex-A53 cores at 1.8GHz Arm Cortex-M0 MCU at 400MHz GPU […]
