Rockchip RK835 & RK837 fast charger chips support USB PD 3.0, QC4+, and VOOC

Rockchip is better known for its application processors for TV boxes (RK3328), Chromebooks and other higher-end hardware (RK3399), AIoT applications (RK3566), and more, but the company has recently introduced the RK83x family with RK835 and RK837 chips designed for fast chargers compatible with USB PD 3.0 and/or Qualcomm Quick Charge 4+ and BBK Electronics’ VOOC. RK835 Specifications MCU sub-system – Arm Cortex-M0 with 60KB flash, 1KB RAM USB PD 2.0/3.0 and PSS with TID number 4325 USB Type-C and Vconn power source Supports proprietary protocols 8-channel 10-bit, 500Hz converter speed ADC sensing voltage and 1-channel 10-bit current ADC All GPIOs can be configured as ADC input or edge triggering input DP/DM pins can be configured as UART, BC 1.2, or GPIO mode High-voltage endurance DP/DM and CC1/2 pins I2C interface with slave and master modes Low-power RC oscillator, 3 timers, one watchdog Discharge N-MOSFETs for VCC and VBUS Power – […]

PinePower 120W desktop power supply features display, USB PD, QC 3.0 and wireless charging

Desktop Power Supply Qi Wireless Charging

Pine64’s January update includes the launch of PinePhone with Mobian operating system, some limited details about the upcoming Quartz64 RK3566 SBC that will ship with 4 to 8GB RAM, and other news about all their products. There’s not enough details yet to write a post about Quartz64, but another product caught my eyes: PinePower. Yes, Pine64 is now offering power supply, and last month they presented PinePower 65W GaN power adapter that looks similar to MINIX NEO P1 power supply, albeit slightly larger. But I find the desktop version of the power supply even more interesting with an integrated display that shows voltage and current for each port, and also adds Qi wireless charging. PinePower “Desktop” version specifications: Display – Shows individual port voltage and current status USB charging ports 1x USB Type-C PD port up to 65W output with support for 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25A 1x QC 3.0 […]

MINIX NEO P1 tiny 66W GaN USB-C power supply can handle up to 3 devices

I’m now using MINIX NEO P2 GaN USB-C charger for all review using USB powered devices. But with four-ports and up to 100W of power, it’s a bit over-powered for one or two Raspberry Pi 4 or equivalent SBCs, and it also costs around $60. So the Hong Kong company has now introduced a new model with MINIX NEO P1 being a tiny 66W GaAN USB-C power adapter with two USB-C ports and one USB Type-A port and international plug adapters that make ideal to use on the go. MINIX NEO P1 key features and specifications: Power Input – 100-240V AC input with 2-prong US plug and adapters for EU, UK, and AU Power Output Up to 66 W in total 2x USB Type-C ports support up to 65 W with USB PD 3.0 (5-15V/3A, 20V/3.25A) 1x USB Type-A port supports up to 36 W with QC 3.0 (5V/3A, 9V/3A, […]

QC-MINI QC 2.0/3.0 USB fast charging board sells for $2

QC-MINI USB Fast Charging Board

QC-MINI is a USB fast charging board that can take 6V to 32V DC input from a power source such as solar panel, and outputs 3 to 12V via a USB port using QC 2.0/3.0 and other fast charging standards. The board can be useful to implement fast charging in any project, and it won’t break the bank as I’ve just come accross the module on IC Station for just $1.99. QC-MINI key features and specifications: Input voltage – 6.0V to 32V DC Output 5V DC up to 3.4A by default Fast Charging QC 2.0, QC 3.0 with 9V @ 2.5A and 12V @ 2A support BC1.2 protocol Apple protocol Samsung protocol MTK PE1.1/PE2.0 Huawei Fast Charge Protocol FCP, does not support mate9 (SCP) Spreadtrum Fast Charge Protocol SFCP Safety – Overvoltage protection, undervoltage protection, overcurrent protection, short circuit protection, over temperature protection. Misc – LED load indicator with brightness […]

YC-CDA19Q is an 8-Port Quick Charge 3.0 Capable USB Charger with a Display Showing Power Consumption

USB charger doctor is a cheap and easy way to monitor the voltage and current from a USB 2.0 port or charger, but you may have more than one device to monitor, and USB 3.0  type C ports as well as fast charger are now quite common, so it may not be suitable for all situations. Bakeey YC-CDA19Q USB charger hub could be an interesting power monitoring device with 7 USB ports, including one supporting Quick Charge 3.0 fast charging, and an extra USB type C port. Specifications: 8x USB Ports 7x USB type A ports including 6x red USB 2.0 port up to 5V/2.4A each 1x blue USB port supporting QC 3.0 (3.6-6.5V/3A, 6.5-9V/2A or 9-12V/1.5A) 1 USB type C port up to 5V/3A Max Power – 40 Watts (5V/8A) Display – LCD display showing – real-time current and voltage, active charging ports, and charge status Power Supply – […]

Qualcomm Officially Unveils Snapdragon 835 Octa-core Processor for Smartphones, Mobile PCs, Virtual Reality…

Qualcomm first mentioned Snapdragon 835 processor in November, but at the time, they only disclosed it would be manufactured using 10nm process technology in partnership with Samsung, and claimed the obvious “faster and lower power consumption” compared the previous generation. The company has now provided much more info ahead of CES 2017. Snapdragon 835 key features and specifications: Processor – 8x Kryo 280 cores used into two clusters: performance cluster with 4x cores @ up to 2.45 GHz with 2MB L2 cache efficient cluster with 4x cores @ up to 1.9 GHz with 1MB L2 cache GPU – Adreno 540 GPU with support for OpenGL ES 3.2, OpenCL 2.0 full, Vulkan, DX12 DSP – Hexagon 682 DSP with Hexagon Vector eXtensions and Qualcomm All-Ways Aware technology Memory I/F – dual channel LPDDR4x Storage I/F – UFS2.1 Gear3 2L, SD 3.0 (UHS-I) Display – UltraHD Premium-ready , 4K Ultra HD 60 […]

Qualcomm Introduces Three New LTE Cat. 7 SoCs with QC 3.0 and Dual Camera Support: Snapdragon 427, 626, and 653

Qualcomm has announced three new Snapdragon 400 & 600 SoCs for entry-level and mid-range LTE smartphones that share Quick Charge 3.0 and dual camera support, as well as an a Snapdragon X9 LTE CAT 7 modem capable of 300Mbps downlink, 150Mbps uplink. Snapdragon 427 Snapdargon 427 quad core Cortex A53 processor is a pin-to-pin compatible update to Snapdragon 425 processor with a faster Cat 7 modem. The Snapdragon 427 is also the first in the Snapdragon 400 family to offer TruSignal antenna tuning for 802.11ac WiFi, includes a 16MP dual ISP, and supports displays up to 1280×800 resolution. You’ll find more details on the product page. Snapdragon 626 Snapdragon 626 octo-core ARM Cortex A53 processor up to 2.2 GHz features a “PC-class” Adreno Adreno 506 GPU,  a 24MP dual ISP, also supports TruSignal, 4K @ 30 fps video recording, and displays up to 1920×1200 resolution. It’s a pin-to-pin compatible upgrade […]

Qualcomm Unveils Octa-core Cortex A53 Snapdragon 430 and 617 Processors

Qualcomm has unveiled two new octacore 64-bit ARM processors for mid-range smartphones with Snapdragon 430 and Snapdragon 617 Cortex A53 SoCs, both of which support the recently announced Quick Charge 3.0 standard and embed LTE connectivity. Snapdragon 430 Snapdragon 430 key features and specifications: CPU – 8x ARM Cortex A53 up to 1.2 GHz GPU – Qualcomm Adreno 505 GPU supporting up to OpenGL ES 3.1+ DSP – Qualcomm Hexagon 536 DSP Memory –  LPDDR3 800MHz Storage –  eMMC 5.1, SD 3.0 (UHS-I) Modem – Snapdragon X6 LTE – LTE Cat 4 (up to 150 Mbps DL/75 Mbps UL) Wireless Connectivity – WiFi 802.11n/ac  (Qualcomm VIVE 2-stream with MU-MIMO),  Bluetooth 4.1 + BLE, GPS (Qualcomm IZat Gen8C) Display – Up to 1080p on device and output Video – Up to 1080p at 30 FPS; Codecs: H.264 (AVC), H.265 (HEVC) Audio – Fluence HD noise cancellation technology Camera – Up to […]
