December 3, 2015May 12, 2016 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Wio Link is an ESP8266 Board Designed to Make IoT Projects Easier (Crowdfunding)

There are already plenty of board or modules based on Espressif ESP8266 WiFi SoC, but if you don’t like soldering, or would rather avoid breadboards and some cables for your or your kids’ projects, Wio Link may be interesting, as all you need to is to connect Grove modules required for your applications to get started, and Seeed Studio also took care of the low level software part and a drag-and-drop mobile app is provided, so software programming has been made easy too. Wio Link hardware specifications: SoC – Espressif ESP8266EX Tensila SoC Storage – 4MB flash Connectivity – 802.11b/g/n WiFi, with WEP/TKIP/AES encryption support Expansion – 6x Grove connectors: 3x digital, 1x analog, 1x UART and 1x I2C (3.3V I/Os) Power Supply 5V via micro USB port 3.4 ~ 4.2V via external battery Output DC Current – 1000mA MAX Charge Current: 500mA MAX Dimensions – 55mm*48mm Weight – 26g […]

December 1, 2015December 1, 2015 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

Quick Start Guide for LinkIt Smart 7688 (Duo) Board

Mediatek Labs has announced LinkIt Smart 7688 development boards powered by Mediatek MT7688 WiSoC earlier today, but I was selected for a close beta several weeks before the launch, and I’ve had time to play a little with the boards, so today I’ll report my experience getting started with LinkIt Smart 7688 amd 7688 Duo by writing a Quick Start Guide showing how to setup the boards, upgrade firmware, access the serial console, run “Blink LED” sample applications with Python and JavaScript, as well as the Arduino IDE, and connect to the Internet. Initial Setup You’ll only need a micro USB cable and a computer with WiFi and USB ports to get started with the board. The green LED (top) for the MCU will turn on immediately, while the red LED (bottom) for WiFI will blink once, and only turn on continuously after 5 seconds, and within 30 seconds after […]

November 6, 2015November 6, 2015 by Jean-Luc Aufranc (CNXSoft) - No Comments

$5 Add-on Board for Raspberry Pi Supports Arduino Shields and Grove Modules (with Caveats)

If you have several Arduino shields, you can use them on your Raspberry Pi B+/ Pi 2 board with Cooking Hacks’ Raspberry Pi to Arduino shields connection bridge supported by arduPi library to control I2C, SPI, GPIO, analog inputs, etc.., and sells for $65 on Amazon. Seeed Studio Grove modules have also become more popular, with several new boards integrating 4-pin Grove connectors such as Beaglebone Green. Raspberry Pi boards also support Grove modules, up to 15 of these!, using Grove Pi+ add-on board which the company sells for around $30. But I’ve just discovered a Raspberry Pi to Arduino Expansion Board V2.0 on DealExtreme, selling for $7.97 that’s allows the latest Raspberry Pi boards with a 40-pin headers to take both Arduino shields and 2 Grove modules. After some investigations, I found out it was made by ITead Studio, where they sell it for $5 + shipping. The Wiki […]

September 23, 2015 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

RePhone Kit Create is a DIY Phone and Cellular Development Kit (Crowdfunding)

Seeed Studio has design a modular and open source phone it calls RePhone Kit Create. The kit allows you, or/and your kid(s), to assemble their own phone based on building blocks including a 2G or 3G core module, a touchscreen display module, an audio module, and pre-cut, seawable, washable, and easily drawable Kraft paper to make the case. The kit can also be used for IoT applications using cellular and Bluetooth connectivity, and extra Xadow modules GPS, NFC, motion sensors, camera and more.. Two cellular “core” module can be used: RePhone GSM + BLE module with the “world’s smallest System-on-Chip (SOC) for Wearables and Internet Of Things”, GSM, GPRS and Bluetooth 2.1 and 4.0 support. RePhone Core Module 3G with a “powerful microcontroller”,a standard Xadow interface (USB, GPIO, I2C, SPI, UART, EINT), support for speaker, two microphones and a headset, a Nano SIM, and support for HSPA/WCDMA:850/1900 and GPRS/EDGE:850/1900. Voltage: […]

July 17, 2015August 19, 2016 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

MXCHIP EMW3165 is an $8 CE/FCC Certified WiFi Module with an STM32F4 Cortex M4 MCU

A few months ago, Seeed Studio started selling MXCHIP EMW3162 Wi-Fi module with a STM32F2 Cortex M3 MCU clocked at 120Mhz for $9.95. It’s more capable than ESP8266 modules but also around 3 times more expensive. The company has now launched another WiFi module called MXCHIP EMW3165 with an STM32F4 Cortex M4 MCU @ 100 MHz, FCC certification, and listed for $7.95. EMW3165 module specifications: MCU – STMicro STM32F411CE ARM Cortex M4 micro-controller @ 100 MHz with 512KB flash, 128KB RAM, DSP, and FPU Storage – 2MB SPI flash Wi-Fi connectivity 802.11b, 802.11g, 802.11n (single stream) WEP, WPA/WPA2 PSK/Enterprise 16.5dBm@11b; 14.5dBm@11g; 13.5dBm@11n Receiver Sensitivity – 87 dBm Station, Soft AP and Wi-Fi direct Support EasyLink On-board PCB antenna (EMW3165-P model) or IPEX connector for external antenna (EMW3165-E model) CE & FCC compliant Peripherals: 22 GPIOs USART, I2C ADC, DAC Timer/PWM JTAG/SWD debug interface Connectors – 1×20 + 1x 21 half-through […]

May 7, 2015 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Seeed Studio Introduces Automation and Wearable Kits for Intel Edison

Intel Edison is a $50 module with a dual core Atom processor @ 500Mhz and a single core Quark MCU @ 100 Mhz, Wi-Fi and Bluetooth 4.0, as well as headers for I/Os that’s destined to be used in wearables and IoT applications. Seeed Studio has now launched two kits for the Intel module for home automation and wearables. Grove Indoor Environment Kit for Intel Edison The automation kit comes in a small blue box with the following parts (Intel Edison and baseboard not included): 1x base shield v2 that plugs into Edison baseboard and allows Grove modules connections 11 grove modules – temperature & humidity, LCD RGB backlight, relay, moisture sensor, servo, light sensor, buzzer, UV sensor, PIR motion sensor, encoder and button. 2x 26 AWG Grove Cables 9V to barrel jack adapter 1x USB cables 1x User guide Programming is done with Edison Arduino IDE as explained in […]

April 10, 2015 by Jean-Luc Aufranc (CNXSoft) - No Comments

Mediatek LinkIt Assist 2502 Open Source Hardware Board Targets Wearables and IoT Applications

After LinkIt ONE, Mediatek Labs has introduced a new IoT development kit based on their Aster M2502 ARM7 processor with LinkIt Assist 2502 comprised of AcSiP MT2502A IoT SiP Core module, a 802.11b/g/n module, a GNSS module, and an exchangeable 240×240 16-bit color capacitive touch LCM Board. The AcSiP module can also be purchased separately, so you could use LinkIt Assist 2502 board for early development, because moving to your custom hardware based on AcSiP MT2502A module. LinkIt Assist 2502A specifications: MCU – AcSiP AI2502S05 module with MT2502A (Aster) ARM7 EJ-STM processor @ 260MHz, 4MB RAM, 16MB flash Display – 240×240 LCD module; 16-bit color depth; transflective; based on ST7789S driver IC. Connectivity Wi-Fi 802.11 b/g/n via AcSiP CW01S module based on MT5931 SoC Bluetooth 2.1 SPP and 4.0 GATT dual mode (part of MT2502A) GPS via AcSiP CW03S module based on MT3332 chip supporting GPS, GLONASS, and BeiDou. GSM […]

March 4, 2015May 29, 2017 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Mixtile LOFT-Q Allwinner A31 Board with SATA Can Now be Purchased for $90

Mixtile LOFT-Q and LOFT Kit were unveiled nearly a year ago, the first being a development board based on Allwinner A31 processor with 2GB RAM, 16GB RAM, SATA connector, Gigabit Ethernet, etc.., while the second is a kit with an enclosure and power supply. The kit does not appear to be available yet, but the board has recently been listed on SeeedStudio for $90. Mixtile LOFT-Q specifications: SoC – Allwinner A31 quad core ARM Cortex-A7 processor with PowerVR SGX544 MP2 GPU System Memory – 2GB DDR3 Storage – 8GB eMMC, SATA III connector for 2.5″ drives, and SD card Slot Video Output – HDMI 1.4 up to 1080p60 Video Decoding – H.264 4Kx2K video decoding, multi-format FHD video decoding, including Mpeg1/2, Mpeg4 SP/ASP GMC, H.263, H.264,etc Audio I/O – HDMI, 1 S/PDIF, high definition microphone Camera I/F Integrated Parallel & MIPI I/F sensor Integrated powerful ISP, supporting Raw Data CMOS […]
