Semtech AirLink XR60 is the world’s smallest rugged 5G router

Airlink XR60 world smallest rugged 5G router

Semtech AirLink XR60 is a tiny 5G router powered by a quad-core Cortex-A53 processor with up to two Ethernet ports (1Gbps and 5 Gbps), WiFi 6 connectivity, GNSS navigation, and an optional RJ45 serial port. Semtech is better known for its LoRa low-power transceivers, but the company acquired Sierra Wireless last year, so they’ll now have a wider range of wireless products to offer, and the AirLink XR60 5G gateway is the first we cover here on CNX Software since the merger between the two companies. Semtech Airlink XR60 specifications: SoC – Quad-core Arm Cortex-A53 processor Memory – 1.2 GB RAM (that should be the free memory) Storage – 1.7 GB (available storage) Networking 5G cellular Sierra Wireless EM9291 5G NR Sub-6 M.2 module Peak downlink – 2800 Mbps Peak uplink – 300 Mbps 4×4 MIMO 4x SMA antenna connectors Dual SIM (Nano-4FF) Carrier – AT&T, FirstNet 4G, T-Mobile, Verizon, […]

April 14, 2022September 22, 2022 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Semtech LR1120 enables global asset tracking with multi-band LoRa, WiFi, and GNSS

Semtech LoRa Edge LR1120 is an ultra-low-power multi-band chip designed for global geolocation and asset tracking applications including direct satellite-connected Internet of Things (IoT) applications in supply chain management and logistics. Not only does the LR1120 features the usual sub-GHz LoRa radio found in most other chips from the company, but also comes with 2.4GHz LoRa and SATCOM S-Band support for satellite, as well as a GNNS radio compatible with GPS and Beidou, and a WiFi radio for indoor positioning (but no WiFi RTT/802.11mc support). Semtech LR1120 key features and specifications: Low-power high-sensitivity LoRa/(G)FSK half-duplex RF transceiver Worldwide ISM frequency bands support in the range 150 – 960MHz (Sub-GHz) and 2.4GHz, as well as 1.9-2.1GHz (S-Band) Low Noise Figure RX front-end High power PA path +22dBm in the Sub-GHz band Up to +11.5dBm in the 2.4GHz band LR-FHSS modulator Integrated PA regulator supply selector to simplify dual power +15/+22dBm with […]

February 29, 2020 by Ayo Ayibiowu - 6 Comments

Semtech LoRa Edge Uses LR1110 Single Chip with LoRa, WiFi, and GNSS

Semtech, a leader in LoRa and RF technology, is continuing its support for the LoRa ecosystem with the launch of a new portfolio of solutions called LoRa Edge to simplify and accelerate IoT applications for the Edge. LoRa Edge is a new highly versatile and low power software-defined LoRa-based platform that will enable a wide portfolio of applications for indoor and outdoor asset management, targeting industrial, building, home, agriculture, transportation, and logistics markets. The LoRa Edge platform is launching with a geolocation solution targeted to IoT applications for asset management. It features an ultra-low power LoRa transceiver, GNSS sniffing capabilities, Wi-Fi scanning technologies all in one single package called Semtech LR1110. “Semtech continually delivers Internet of Things (IoT) solutions that simplify and accelerate the development of LPWAN applications,” said Pedro Pachuca, Director of IoT Wireless in Semtech’s Wireless and Sensing Products Group. “LoRa Edge and LoRa Cloud geolocation services enable customers […]

January 30, 2020January 30, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

Semtech LoRa Asset Tracking Reference Kit Includes one LoRaWAN Gateway, Six Waterproof GPS Trackers

LoRa Asset Tracking Reference Kit Gateway

The Things Conference is taking place now until January 31, so we should expect a few LoRaWAN announcements, and yesterday we covered Semtech LLCC68 LoRa transceiver for smart home applications, but the company also introduced a LoRa asset tracking reference kit to ease the deployment and evaluation of LoRa based tracking solutions. The kit is comprised of one LoRaWAN gateway, and six waterproof trackers with GPS and LoRa connectivity which everything supposed to work out of the box. The gateway, as shown above, comes with LoRa, cellular and GPS antennas, as well as a PoE power supply. It ships with a pre-configured SIM card to connect to the cloud platform over 3G/4G. Six industrial LoRaWAN-based GPS trackers are also included with the kit. Each comes with a battery but the trackers need to be activated by the user. Interestingly they are not using a button to turn on and off […]

January 29, 2020February 16, 2020 by Ayo Ayibiowu - No Comments

Semtech launches LLCC68 LoRa Transceiver for Smart Home Applications

Semtech, a leader in LoRa and RF technology, is continuing its support for the LoRa ecosystem with the launch of a LoRa Smart Home transceiver called the LLCC68. The device is designed for deploying existing and new LPWAN technologies for smart homes, community, and consumer applications. The LoRa Smart Home (LLCC68) is like every other sub-GHz LoRa RF transceiver but mostly targeted to indoor and medium outdoor applications. The device is hardware compatible with the SX126x series like the: SX1261, SX1262, and SX1268. The LLCC68 transceiver is optimized for battery-powered applications with multi-year life expectancy. It consumes as little as 600nA of sleep current, 4.6 mA of active receive current and can transmit at +22 dBm thanks to highly efficient integrated power amplifiers. According to SemTech, The new LoRa® Smart Home device offers a unique opportunity to accelerate the consumer adoption of smart home connected solutions. As an end-to-end solution, […]

October 16, 2019October 16, 2019 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Semtech SX1302 LoRa Transceiver to Deliver Cheaper, More Efficient Gateways

After our interview with Rak Wireless CEO, we received a comment inquiring about the availability of SX1302 gateways. Semtech so far had two LoRa transceivers for gateways namely SX1301 and SX1308, but I had never heard about a third one. Semtech SX1302 is brand new, the latest generation of baseband LoRa chip for gateways that is said to reduce current consumption in order to simplify the thermal design of gateways, as well as the BoM (bill of materials) costs), while being capable of handling a higher amount of traffic. Semtech SX1302 LoRa Transceiver Key features: Up to -141 dBm sensitivity with SX1250 Tx/Rx front-end 125 kHz LoRa reception with: 8 x 8 channels LoRa packet detectors 8 x SF5-SF12 LoRa demodulators 8 x SF5-SF10 LoRa demodulators 125 /250 / 500 kHz LoRa demodulator (G)FSK demodulator Direct interface to Semtech transceivers SX1255, SX1257 and SX1250 SPI host interface Single 32 MHz […]

May 2, 2019 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Semtech Releases Open Source Software for LoRa Gateways & Devices

Semtech has released open source software for LoRa-based gateways including LoRa Basic Station packet forwarder for Linux-based gateways, LoRa Basic MAC implementation of the LoRa Alliance’s LoRaWAN specification, and LoRa Basic loader bootloader capable of handling firmware updates. All three components are available for free under a revised 3-Clause BSD license. LoRa Basic Station supports LoRaWAN Classes A, B, and C, presents a unified radio abstraction layer supporting Concentrator Reference Designs v1.5 and v2, and implements various backend protocols. Apart from mbedTLS and libloragw/-v2, it does not rely on external dependencies, the code is written in C language only, and easily portable to Linux gateways and embedded systems. LoRa Basic MAC is a fork of IBM’s LMiC library, also implemented in C language, supports multiple regions selectable at compile and/or run time, and can handle Class A, Class B, and Class C devices. Basic MAC uses LoRa Basic loader to […]

June 20, 2018 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Semtech SX1261/SX1262 LoRa Development Kit Now Available for $305

Semtech announced SX1261, SX1262 and SX1268 LoRa chips in January as updates to their current LoRa solutions with a lower footprint, better efficiency, and even longer range. Mass production and development kits were expected in March 2018, and today I found out Semtech SX1261/SX1262 development kit is sold on Mouser for $305. The SX126xDVK1CAS kit comes with the following items: 2x SX126xMB1xAS RF modules including an ST Nucleo Mbed board and a touchscreen 2x Mini-USB / USB connection cables 2x 868/915MHz antennas 2x Mini-USB cables 2x touchscreen styluses Read-Me Note The SX1261/SX1262 LoRa Transceivers offer continuous frequency coverage from 150MHz to 960MHz. You’ll find information to get started in the user guide. Basically, the two boards will show a menu on the touchscreen with radio test modes, settings and utilities (e.g. firmware update) as well as two demos: DEMO Ping Pong performs a bidirectional range test between the two radio […]
