Raspberry Pi 3 Board is Powered by Broadcom BCM2837 Cortex A53 Processor, Sells for $35

Raspberry Pi 3 board was first found on the FCC website, and thanks to various other leaks we had a pretty good idea of the board specifications including a Broadcom 64-bit ARM processor coupled with 1GB RAM, WiFi and Bluetooth, as well as basically the same features and ports as Raspberry Pi 2 Model B. But with the fourth anniversary of the Raspberry Pi Model 1 board, Raspberry Pi 3 has now officially been launched, and you can now purchase the board for $35. Raspberry Pi 3 specifications: SoC – Broadcom BCM2837 64bit ARMv8 quad core Cortex A53 processor @ 1.2GHz with dual core VideoCore IV GPU @ 400 MHz supporting OpenGL ES 2.0, hardware-accelerated OpenVG, and 1080p30 H.264 high-profile decode. Capable of 1Gpixel/s, 1.5Gtexel/s or 24GFLOPs with texture filtering and DMA infrastructure System Memory – 1GB LPDDR2 Storage – micro SD slot Video & Audio Output – HDMI 1.4 […]

Variscite DART-SD410 Snapdragon 410 SoM Comes with WiFi 802.11 b/g/n, Bluetooth 4.1 & GPS

Qualcomm Snapdragon 410 is the 64-bit ARM processor used in DragonBoard 410c 96Boards platform, but it’s also found in several phones, some single board computers such as Inforce 6309, and we’ve also seen it in system-on-modules includes Graperain G8916 and Intrinsyc Open-Q 410. Variscite has developed their DART-SD410 system-on-module based on the processor with up to 2GB RAM, up to 16GB storage, and on-board 802.11b/g/n WiFi and Bluetooth 4.1. DART-SD410 module specifications: SoC – Qualcomm Snapdragon 410 quad core Cortex A53 processor @ 1.2GHz with Adreno 306 GPU @ 400 MHz System Memory – 1 to 2GB LPDDR3 @ 533 MHz Storage – 8 to 16 GB eMMC 4.5 flash Connectivity – WiFi 802.11 b/g/n + Bluetooth 4.1 LE (WCN3620), GPS (WGR7640), and two u.FL antenna connectors Audio – PM8916 PMIC/Audio codec I/Os available via 2x 90-pin board-to-board connectors: Display 4-lane DSI up to 720p60/1080p30, 24-bit On-carrier DSI to HDMI […]

Intel Celeron N3060 based Industrial Fanless Touch Panel Computer Supports SATA Drives

Axiomtek GOT5103W-845 is a new IP65 industrial touch panel PC with a 10.1″ display, an Intel Celeron N3060 dual core processor, up to 8GB RAM, dual Gigabit Ethernet, USB 3.0, and support for half-slim SATA and mSATA SSD drives. Specifications: SoC – Intel Celeron N3060 dual core processor @ 1.6GHz / 2.48 GHz (Turbo) with Intel HD graphics 400 with 12EU @ 320/600 MHz System Memory – 1 x 204-pin SO-DIMM DDR3L-1600 up to 8 GB Storage – 1x mSATA, 1x optional half-slim SATA SSD Display – 10.1″ WXGA TFT LCD with LED and projected capacitive touch screen; 350 nits; 1280 x 800 resolution Video Output – 1x HDMI port Audio – 1x Line Out, HDMI, 2x speakers Connectivity – 2x 10/100/1000Mbps (Intel i211AT), optional WLAN antenna USB – 2x USB 2.0, 2 x USB 3.0 COM ports – 1 x RS-232; 1 x RS-232/422/485 Expansion for storage, Wifi, GPRS/GSM, […]

GPD Win Windows 10 Portable Gaming Console Launched on Indiegogo for $299

We already knew that GPD HK was working on a Windows 10 handheld gaming console powered by an Intel Atom x5-Z8500 Cherry Trail processor, and the company has now decided to launch what they now call “GPD Win” on Indiegogo for $299, and advertise it as a “5.5” Game Handheld Laptop”.GPD Win specifications: SoC – Intel Atom x5-Z8500 quad-core Cherry Trail processor @ 1.44/2.24 GHz (Burst) with Intel HD Gen8 graphics @ up to 600MHz System Memory – 4GB LPDDR3-1600 Storage – 64GB eMMC 4.51 flash + micro SD slot up to 128GB Display – 5.5″ capacitive touch IPS screen; 1280×720 resolution; Corning Gorilla Glass 3; full lamination technology Video Output- mini HDMI Audio – mini HDMI, 3.5mm headset jack, microphone and speaker; Realtek ALC5645 audio codec Connectivity – WiFi 802.11 b/g/n and Bluetooth 4.0 USB – 1x USB 3.0 port, 1x micro USB port HID – QWERTY keyboard with […]

Intel Compute Stick with Atom x5 Processor is Now available for $150 in the US

Intel unveils five new Compute Stick models last month, including three models with Core-M Skylake processors, and two models with Intel Atom x5-Z8300 processor: one with Windows 10 (STK1AW32SC), one without operating system (STK1A32SC). The Skylake model are not available yet, but the Windows 10 version can now be purchased for around $150 on Amazon, Newegg, and CDW. The specifications have not changed since the announcement, but it’s always good to refresh once memory: SoC – Intel Atom x5-Z8300 Quad-Core “Cherry Trail” processor @ 1.44 GHz/1.84 GHz and Intel HD Gen8 Graphics System Memory – 2 GB DDR3L @ 1600MHz Storage – 32 GB eMMC + micro SDXC v3.0 slot with UHS I-Support up to 128GB Video & Audio Output – HDMI 1.4b Connectivity – 802.11 b/g/n/ac Wi-Fi  and Bluetooth 4.0 (via Intel Dual Band Wireless-AC 7265) USB – 1x USB 3.0 port, 1x USB 2.0 port, 1x micro USB […]

Voyo V3 Intel Atom x7-Z8700 mini PC Review with Windows 10

Voyo V3 is one of the first Cherry Trail mini PCs based on Intel Atom x7-Z8700 quad processor that promises both higher CPU and GPU performance, and more I/O connectivity compared to Intel Atom x5 platforms.  I’ve already posted pictures of the device and its guts in the first part of the review,  so today in part 2 of the review, I’ll focus on testing how the device perform with its pre-installed operating system: Windows 10 Home. Setup and System Information There’s no much to say about setup for this device, since all you have to do is to connect the cable, and press the button to access Windows 10 desktop. There are however two interesting aspect of the boot process: As you connect the power supply, you’ll see the power button blue LED lit, but it does not mean it has started. I could see the power consumption was […]

NexDock is a 14″ Lapdock Alternative for mini PCs, Development Boards, Smartphones and Tablets (Crowdfunding)

Motorola once launched the Lapdock, a device that looks like a laptop with a 11.6″ screen and a keyboard, but without processor or memory since it was instead designed to connect to the company’s Atrix 4G smartphone. Motorola eventually pulled the plug on this concept, and maybe it was just ahead of its time, as a startup has now developed NexDock, a device similar to Lapdock with a 14″ display, built-in battery and Bluetooth keyboard. NexDock technical specifications: Display – 14.1″ TN screen; 1366×768 resolution; 16:9 display ratio Bluetooth 4.0 keyboard and touchpad Video input – mini HDMI port Audio Output – 3.5mm headphone port Storage – micro SD card slot USB – 2x USB ports Battery – 3.8V / 10000mAh Li-ion battery Power – 5V/2.5A via 3.5mm power barrel Dimensions – 351 mm x 233 mm x 20 mm Weight – 1490 grams NexDock is operating system agnostic and would […]

Voyo V3 mini PC Unboxing and Teardown

Voyo V3 is one of the first Intel Atom x7-Z8700 based mini PC announced so far, comes with 4GB RAM, and a 128 GB SSD. It was announced at the very beginning of the year, at the time it was not shipping yet. The good news is that the device is now available, as GearBest sent me one sample for review. I’ll start by checkout the hardware inside and out today, before publishing a full review in a few days. Voyo V3 Unboxing I’ve received the computer in its retail packaging. Everything is in Chinese, and the model is called MiniPC-Box_V3. A 12V/2A power supply, mini HDMI to HDMI cable (80 cm), a warranty card, a “qualified certificate”, and MiniPC-Box_V3 user’s manual are also included in the package. There’s something different with the power supply: it features a USB Type-C connector since that’s what the box is powered with. Voyo […]
