Digi ConnectCore 8M Mini SOM and Mini Development Kit for Industrial IoT Applications

Digi ConnectCore 8M Mini SOM

Digi International has announced the Digi ConnectCore 8M Mini System-on-Module (SOM) which is an addition to its ConnectCore family modules. We saw the Android application development kit featuring earlier Digi Wireless modules based Freescale i.MX51 (ConnectCore Wi-i.MX51) and i.MX53 (ConnectCore Wi-i.MX53) in early 2012. The new Digi ConnectCore 8M Mini comes with a built-in Video Processing Unit specialising in vision use cases. The Digi ConnectCore 8M Mini SOM is an industrial i.MX 8M Mini quad-core system-on-module that comes with Arm Cortex-A53 cores, one Cortex-M4 core, and the Cortex-M0-based Digi Microcontroller Assist. This enables optimal power consumption while simultaneous maintenance of highly efficient performance. Main benefits of Digi Connect Core 8M Mini SOM Digi SMTplus form factor (40 x 45 mm) for flexibility and reliability while designing. Power management with both hardware and software support for low-power designs. Display and camera capabilities with graphics and video hardware acceleration make it suitable […]

Digi IX15 IoT Gateway & Cellular Router features a Zigbee & BLE XBee module

Digi IX15 IoT Router Cellular Gateway

Digi International has just announced the Digi IX15 IoT gateway and cellular router with Ethernet and 4G LTE connectivity as well as support for Zigbee, Bluetooth 5.0, 2.4 GHz proprietary via an XBee module. The IoT gateway complies with Class 1 Division 2 (C1D2) certification for environments with flammable vapors or gases, as found in industries such as oil and gas, water/wastewater, energy, and agriculture. It is also programmable through a Python API to enable customers’ specific requirements. Digi IX15 IoT Gateway & Cellular Router specifications: Connectivity 10/100M Ethernet RJ45 port 4G LTE Cat 4 cellular connectivity Supported bands 4G – B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B38, B39, B40, B41 3G: B1, B2, B4, B5, B6, B8, B19 2G EDGE / GPRS: 850 / 900 / 1800 / 1900 MHz Antenna connector – 50 Ω SMA (center pin: female) 2x […]

Actinius launches nRF9160 SoM and XBee module with NB-IoT, LTE Cat-M, and GPS

nRF9160 Xbee Module

Last year, Actinius launched Icarus IoT Board equipped with nRF9160 SiP providing GPS & NB-IoT connectivity in Adafruit Feather form factor. The company is now back with more compact Nordic Semi nRF9160 hardware, namely the tiny 28×18.5mm Icarus SoM with built-in eSIM, as well as Icarus Bee XBee module that incorporates Icarus SoM plus a nano-SIM slot, as well as an RGB LED and a user button. Icarus SoM The module comes with the following specifications: SiP – Nordic Semi nRF9160-SICA system-in-package with Arm Cortex-M33 MCU, 1024 KB flash, 256 KB SRAM, and LTE-M (eMTC), NB-IoT, and GPS  connectivity Storage – 64Mbit SPI flash On-board eSIM Antennas – 2x u.FL connectors for LTE and GPS Sensor – Accelerometer I/Os – 2x 20 castellated holes with GPIOS, I2C, SWD, Reset, SIM card signals, and power pins Supply Voltage – 3.3V Dimensions  – 28 x 18.5 mm The multi-layer module is designed […]

SuperB XBee Compatible Module Features ESP32 WiFi & Bluetooth SoC (Crowdfunding)

SuperB XBee ESP32

Digi XBee is an ecosystem of standardized wireless module found in various development boards, and Espressif Systems ESP32 is by far the most popular WiFi and Bluetooth solution in the maker market. Somebody designed ESP32Bee combining ESP32 with  XBee form factor a couple of years ago, but it was never commercialized, and I’m not aware of alternatives, except for SuperB module based on ESP32-WROOM-32 module that has just launched on Crowd Supply. SuperB modules specifications: Wireless Module – ESP32-WROOM-32 with ESP32 dual core WiSoC clocked at up to 240 MHz 4MB flash (potentially upgraded to 16MB) Connectivity – 802.11 b/g/n WiFi, and Bluetooth Classic + LE Expansion – 3.3 V levels, UART, SPI and GPIOs broken out to headers Misc – 1x user LED Power Consumption – Sleep current is less than 5 μA Dimensions – XBee form-factor compatible Certifications – Fully certified with integrated antenna and software stacks The […]

Dragino NB-IoT Bee is a $23 Xbee Compatible NB-IoT Add-on Board

Several companies are already offering XBee NB-IoT add-on board including Digi International themselves, and SODAQ with their NB-IoT Bee N211 module going for 69 Euros. Dragino NB-IoT Bee is another option for NB-IoT connectivity using Xbee form factor,  and the board should be cheaper than most as it goes for $23.00 on Tindie with an external antenna. NB-IoT Bee specifications: NB-IoT module Quectel BC95-B5 for B5:850Mhz, B8:900Mhz, or B20:800Mhz in respectively Nb-IoT Bee QB05, QB08, QB20 models (i.e. one frequency is supported by model) Quectel BG96 for  LTE Cat M1 & Cat NB1 & EGPRS in Nb-IoT Bee QG96 model Output Powe  – 23dBm Sensitivity – -129dBm Micro SIM Slot Input voltage – 4.5v ~ 5.5V Temperature Range – -40°C ~ +85°C Typical applications for such board include smart metering, facility management services, security & fire alarms, asset tracking, smart city infrastructure and so on. If you are looking specifically […]

Digi Introduces XBeeX3 IoT Modules with New Micro Form Factor, RF and Cellular IoT Connectivity

Digi International has just announced the Digi XBee3 series of RF modules and cellular IoT modules. The modules will be available in the existing Digi XBee SMT amd through-hole form factor, as well as a new micro form factor (19×13 mm) that’s about a third of the size of the original XBee RF module. The RF modules will first come with ZigBee 3.0 and IEEE 802.15 support, but Bluetooth LE will be available through a firmware update later on, and WiFi and DigiMesh version will be brought to markets too. The first cellular module supports LTE Cat.1, but the company will eventually launch NB-IoT and eMTC (LTE Cat M) versions for Europe and the US respectively. Some of the shared key capabilities listed by the company: Over-the-air (OTA) changes to devices in the field for bug fixes and new features Dynamically reconfigurable, based upon situation Establish business rules to aggregate, store, […]

Evive is an Arduino Compatible Platform with Enclosure, Lots of I/Os, Buttons, and an 1.8″ Display (Crowdfunding)

Engineers at Agilo Technologies, an Indian startup based in Kanpur, Uttar Pradesh, felt that the wire mess often produced while learning or prototyping with Arduino boards could be an issue, and it was easy to mis-wire your setup, so they’ve decided to create a user and student friendly Arduino compatible system with many of the items you’d normally use with Arduino board such as buttons, probes inputs, an 1.8″ color display, headers for ESP8266, Bluetooth, and XBEE moduels, etc.. and all of that enclosed in a neat case. Evive was born. Evive specifications: MCU – Atmel ATmega2560 8-bit AVR MCU @ 16 MHz with 256KB flash, 4KB EEPROM, 8KB SRAM Storage – micro SD slot up to 32GB Display – 1.8″ TFT display; 160×128 resolution; 18-bit color User inputs – Tactile and slide switches, joysticks, and potentiometers Probes inputs – Voltage / Intensity sensing inputs USB – USB device port Expansion Headers […]

TinySine Bluetooth, WiFi and USB Relays Come with an Optional Enclosure, Support Android and iOS Smartphones

It’s now fairly easy to find the hardware to create WiFi or Bluetooth controlled relays, but you usually have to design your own enclosure and Android app, and if you’d like something that’s ready to use out of the box TinySine wireless relays such as TSRB430 (Bluetooth) or TSRW430 (WiFi) might be an interesting option. There;s also a version with USB control. TSRB430 / TSRB430 / TSRU430 specifications: 4x Omron G8P 30A/250VAC | 20A/28VDC relay; SPST-NO (normally open) types. Connectivity – XBEE module either: Bluetooth Bee module based on CSR BC417143 Bluetooth 2.0 chipset Roving Networks WiFi Bee module with 802.11 b/g radio USB Bee module with a CP2102 USB to UART chip Power Supply – 12V/1A via 2.1mm jack with positive core polarity Dimensions – 122mm x 87mm x  x 31mm (board) There are also versions with 2 and 8 relays. I kind of wish they had models taking 220V AC input instead […]
