March 9, 2016March 9, 2016 by Jean-Luc Aufranc (CNXSoft) - 23 Comments

10-bit H.264 and H.265 Video Playback in MXQ-4K Rockchip RK3229 TV Box

Rockchip RK3229 is an exciting media processor because it’s found in ultra low cost TV Boxes such as MXQ-4K, outputs up to 4K @ 60 Hz, and supports 4K video decoding of 10-bit H.264, 10-bit H.265 and VP9, including videos with very high bitrates (200+ Mbps). That’s the theory, which I’ve put to the test with MXQ-4K TV box. Since the network interfaces of the device are limited to 100M Ethernet and 802.11n WiFi, and some videos are well above 100 Mbps, I’ve decided to test video playback from a USB hard drive instead. I’ve tried the three pre-installed video player apps: Kodi 15.1, “Video”, and “Video Player” , and they all have similar capabilities except Kodi is a little less stable on this device. The system detected my 4K TV (LG ) and automatically set the resolution to 3840×2160 @ 60 Hz, which I used for the remainder of […]

March 9, 2016March 9, 2016 by Jean-Luc Aufranc (CNXSoft) - 28 Comments

WeTek Hub Android & OpenELEC TV Box Features Amlogic S905-H Revision C Processor

WeTek has been working not on one, but two four new devices recently. I’ve already covered WeTek Play 2S (previously known as WeTek Play+) based on Amlogic S905 Rev. C , running Android 5.1 or OpenELEC, and featuring digital TV tuners (ATSC, DVB-S2, DVB-T2/C), which should become available in Q2 2016. The company has unveiled another model called WeTek Hub with features closer to the ones found in other Amlogic S905 TV boxes I’ve reviewed so far, except it is based on Amlogic S905-H revision C, comes with Widewine and Microsoft PlayReady DRM, and supports both Android 5.1.1 and OpenELEC. WeTek Hub specifications: SoC – Amlogic S905-H revision C quad core ARM Cortex-A53 @ up to 2.0GHz with penta-core Mali-450MP GPU @ 750 MHz System Memory – 1 GB DDR3 Storage – 8 GB eMMC flash + micro SD card slot Video & Audio Output – HDMI 2.0 up to […]

Graperain Samsung, Rockchip RK3588, and Qualcomm CPU modules, SBCs, and carrier boards

March 8, 2016March 21, 2016 by Jean-Luc Aufranc (CNXSoft) - 20 Comments

How to Resize Partitions and Update Firmware in MXQ-4K TV Box (Rockchip RK3229)

Since I’ve received MXQ-4K Android TV box yesterday, I have started to play with it, and so far I can’t say I’m impressed, as while the device automatically detected the maximum resolution (3840×2160 @ 60 Hz) for my television, I could not play any of my 4K samples smoothly with either the pre-installed Kodi 15.2, Video and Video Player apps, there’s no power off mode (only standby), and the “internal partition” is only 0.96GB large which can quickly become an issue if you plan on installing several apps. Since GeekBuying has released the stock firmware, I decided to try to adapt the method to resize the partitions for GeekBox (RK3368) to MXQ-4K. Rockchip RK3229 Firmware Modding I’ve used a computer running Ubuntu 14.04, and assume you have most tools pre-installed. The first step is to download the firmware (MXQ-4K_ota_ok_20160127.img update.img), and install the tools to extract it :

git clone https://github.com/geekboxzone/utils
cd utils/rockdev
mv MXQ-4K_ota_ok_20160127.img update.img
./unpack.sh

git clone https://github.com/geekboxzone/utils

cd utils/rockdev

mv MXQ-4K_ota_ok_20160127.img update.img

./unpack.sh

The […]

March 8, 2016March 8, 2016 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Run Android Apps in Linux with Shashlik Android Emulation Layer

There are already ways to run Android apps in Linux distributions such as Ubuntu or Debian, including the Android SDK emulator, running Android-x86 or Remix OS in a virtual machine, or using Genymotion, but those solutions are a little cumbersome to setup. Shashlik Android emulation layer aims to simplify the process of running Android apps in their own window within Linux desktop distributions. The Android apps can be started from the start up menu or dash like any Linux program. The apps are currently running inside an emulator so you actually boot a stripped down version of Android each time you start the app, which means they’ll take a little while to start. OpenGL and graphics are all rendered on the host for better performance. In the future, the emulator (virtual machine) may be dropped, and instead Shashlik could simply become a container, which requires rewriting libbinder in userspace There […]

March 8, 2016March 15, 2016 by Jean-Luc Aufranc (CNXSoft) - 14 Comments

$61 Xiaomi Mi Box 3 2016 Enhanced Edition is Powered by Mediatek MT8693 Hexa-core Cortex A72 + A53 Processor

There are few ARM Cortex-A72 “class” mini PCs available on the market, and the only one I can think of is Amazon Fire TV 2015, powered by Mediatek MT8173 hexa-core processor, and priced decently at $99.99, but hard or expensive to source if you don’t live in the US. There will soon be one more choice, as Xiaomi has upgraded its Mi Box 3 to use Mediatek MT8693 processor with two Cortex-A72 cores, and four Cortex-A53 cores combined with PowerVR GX6250 GPU. Xiaomi Mi Box 3 Enhanced / 2016 Edition specifications: SoC – Mediatek MT8693 hexa-core processor with two Cortex-A72 cores @ 2.0GHz, four Cortex-A53 cores @ 1.6 GHz, and Imagination PowerVR GX6250 GPU System Memory – 2GB 64-bit LPDDR3 memory Storage – 8GB eMMC 5.0 flash Video Output – HDMI 2.0 up to 4K/2160p @ 60 Hz Video and Audio Features – 10-bit H.265, Dolby and DTS audio Connectivity […]

March 7, 2016March 7, 2016 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Firefly-RK3288 Reload Board Features a SoM + Baseboard Design, Supports SATA, Three HDMI Ports, and More

Firefly-RK3288 was one the first boards powered by Rockchip RK3288 quad core Cortex A17 processor, and now Firefly team, part of T-Chip technology, has provided a new version called Firefly-RK3288 Reload with the same processor, but more features, and thanks to design comprised of a carrier board and system-on-module (SoM) – connected via an MXM connector – suitable to people or companies wanting to create their own board without handing the complexity of the processor, memory, and storage part. The table below shows Firefly-RK3288 and Firefly RK3288 Reload specifications side-by side. Parameter Firefly-RK3288 (Plus) Firefly-RK3288 Reload SoC Rockchip RK3288 ARM Cortex-A17 quad core processor up to 1.8GHz with ARM Mali-T760 MP4 GPU RAM 2GB Dual-Channel DDR3 (Plus version is 4GB) 2GB Dual-Channel DDR3 Storage 16GB eMMC (Plus version is 32GB) MicroSD (TF) Card Slot 16GB eMMC MicroSD (TF) Card Slot SATA 2.0 (Suggest 2.5 inch SSD or HDD) PMU ACT8846 […]

Rockchip RK3568, RK3588 and Intel x86 SBCs and SoMs in 2025

March 7, 2016March 8, 2016 by Jean-Luc Aufranc (CNXSoft) - 48 Comments

MXQ 4K Rockchip RK3229 Android TV Box Unboxing and Teardown

MXQ 4K TV box list of features is rather impressive, as the 4K media player packs support for high bitrate (200 Mbps+) 10-bit H.265 and H.264, as well as VP9 at 4K resolution, 4 USB ports, Ethernet, and HDMI 2.0 for just $30. That price includes shipping. We just don’t know how it performs, but we’ll soon find out as GeekBuying sent me a sample for review. I’ll start by checking out the hardware, before testing it over a few days, and write a complete review. MXQ 4K Unboxing The retail package shows MXQ-4K “OTT TV Box” and some of the key selling points like Kodi support, 4K, HEVC/H.265, and son on. You’ll also find the Android 4.4 Kitkat logo since strangely Rockchip did not provide an Android 5.x SDK for their low cost processor. The device ships with an IR remote control, a 5V/2A power supply, an HDMI cable, […]

March 7, 2016March 7, 2016 by Jean-Luc Aufranc (CNXSoft) - 18 Comments

LeMaker Cello 96Boards EE Board Powered by AMD Opteron A1120 Processor Targets Server Applications

There are two versions of Linaro’s 96Boards specifications the Consumer Edition (CE) and the Enterprise Edition (EE) with higher hardware requirements, and while several boards mostly compliant with 96Boards CE are available such as DragonBoard 410c and Hikey boards, the only board announced to be compliant with 96Boards EE specifications was AMD Huskyboard based on Opteron A1100 series processor and is yet to be available for sale. LeMaker has now designed a similar EE boards called Cello. LeMaker Cello board specifications: Processor – AMD Opteron A1120 quad core Cortex A57 processor @ 1.7 GHz with 2MB L2 cache, 8MB L3 cache System Memory – 2x DDR3 SO-DIMM sockets Storage – 2x SATA 3.0 ports, micro SD slot Connectivity – 1x Gigabit Ethernet RJ45 port USB – 2x USB 3.0 ports Expansions x16 PCIe G3 slot 40-pin Low Speed (LE) expansion header Debugging – micro USB port for console access, 10-pin […]
