Infineon XENSIV PAS CO2 Shield2Go board
Posted on

Infineon XENSIV PAS CO2 Shield2Go board enables carbon dioxide measurements

Infineon has added new a shied to its Shield2Go ecosystem with the XENSIV PAS CO2 Shield2Go board integrating the company’s XENSIV PAS CO2 sensor capable of measuring carbon dioxide levels. We first wrote about the Shield2Go module with the OPTIGA Trust-M evaluation kit integrating a security module, but the family also includes various sensors shield and microcontroller boards notably the XMC 2Go board. The new Shield2Go board can be used for both air quality monitoring and controlled ventilation for energy savings.     XENSIV PAS CO2 Shield2Go board specifications: XENSIV PAS CO2 sensor: Accuracy – ±30 ppm ±3% “Advanced compensation and self-calibration algorithms” Host interfaces – UART, I2C, PWM Dimensions – 14 x 13.8 x 7.5 mm 19x through holes and castellated holes with I2C, UART, PWM, interrupt, 5V, 3.3V, GND, plus SWD interface Power Supply 5V DC input 12V DC DCDC boost converter to power the IR transmitter in […]

SyncBot educational mobile robot RBX-I2000 controller
Posted on

SyncBot educational mobile robot supports NVIDIA Xavier NX or Intel Tiger Lake controller

Syncbotic Syncbot is a four-wheel autonomous mobile robot (AMR) platform for research and education that can be fitted with an NVIDIA Xavier NX or an Intel Apollo Lake/Tiger Lake-based controller running Ubuntu 20.04 operating system with ROS 2 framework, and comes with an motion control MCU board with an EtherCat master and running Zephyr OS. The robot comes with four 400W TECO servo motors, can handle up to 80kg payloads for sensors and a robotic arm, features 12V and 24V power output for sensors, four USB 3.0 ports, and can also be equipped with an eight-camera kit with Intel RealSense and ToF cameras. Syncbot AMR specifications: Robot Controller Platform (one or the other) SyncBotic A100 evaluation ki (Apollo Lake E3940) SyncBotic SBC-T800 series (Intel Tiger Lake UP3) SyncBotic SBC W series (Intel Tiger Lake UP3, waterproof version) SyncBotic NSync-200 series (NVIDIA NX) Dimensions – 200 x 190 mm STM32-based Motion […]

Graperain Samsung, Rockchip, and Qualcomm CPU modules, SBCs, and carrier boards
Lolin S3 ESP32-S3 board
Posted on

$7 Lolin S3 ESP32-S3 board ships with MicroPython firmware

Lolin S3 is the first ESP32-S3 board from the company, but instead of using the more compact D1 mini form factor, the board features a longer design with two rows of 20 pins offering up to 31 GPIOs. Based on ESP32-S3-WROOM-1 module, the board features 16MB QSPI flash, 8MB SPRAM, two USB Type-C OTG and UART ports, a Lolin I2C port, an RGB LED, as well as Reset and user buttons. Lolin S3 specifications: Wireless module – ESP32-S3-WROOM-1 module with: Espressif Systems ESP32-S3 dual-core Tensilica LX7 @ up to 240 MHz with vector instructions for AI acceleration, 512KB RAM, 2.4 GHz WiFi 4 and Bluetooth 5.0 LE with support for long-range, up to 2Mbps data rate, mesh networking 16MB QSPI flash 8MB PSRAM PCB antenna USB – 2x USB Type-C ports, one OTG port, one UART port for programming and debugging Expansion 2x 20-pin headers with up to 31x GPIO, […]

UP Squared V2
Posted on

UP Squared 2 is a compact Elkhart Lake SBC with Celeron N6210 or Pentium J6426 processor

UP Squared 2 is a compact single board computer powered by either an Intel Celeron N6210 or Pentium J6426 “Elkhart Lake” processor with up to 16GB RAM, 64GB eMMC flash, 4K capable HDMI and DisplayPort video outputs, two Gigabit Ethernet ports, and more. Slightly smaller than two business cards, the UP Squared 2 is an upgrade of the UP Squared SBC introduced in 2016 with Intel Celeron N3350 or Pentium N4200 “Apollo Lake” processor. The new board offers virtually the same features, except the two HDMI ports, have been replaced by one HDMI port, and one DisplayPort connector, the mini PCIe slot is gone in favor of an M.2 NVMe socket, the Altera FPGA has been removed, and the new system provides overall better specifications in terms of CPU/GPU performance. UP Squared V2 specifications: Elkhart Lake SoC (one or the other) Intel Celeron N6210 dual-core processor up to 2.6 GHz […]

StarFive VisionFive 2
Posted on

StarFive VisionFive 2 quad-core RISC-V SBC launched for $46 and up (Crowdfunding)

As expected, StarFive has officially unveiled the JH7110 quad-core RISC-V processor with 3D GPU and the VisionFive 2 SBC. I just did not expect the company to also launch a Kickstarter campaign for the board, and the version with 2GB RAM can be had for just about $46 for “early birds”. The VisionFive 2 ships with up to 8GB RAM, HDMI 2.0 and MIPI DSI display interfaces, dual Gigabit Ethernet, four USB 3.0/2.0 ports, a QSPI flash for the bootloader, as well as support for eMMC flash module, M.2 NVMe SSD, and microSD card storage. VisionFive 2 specifications: SoC – StarFive JH7110 quad-core 64-bit RISC-V (SiFive U74 – RV64GC) processor @ up to 1.5 GHz with Imagination BXE-4-32 GPU supporting OpenGL ES 3.2, OpenCL 1.2, Vulkan 1.2 4Kp30 H.265/H.264 video decoder 1080p30 H.265 video encoder System Memory – 2GB, 4GB, or 8GB LPDDR4 Storage – MicroSD card slot, eMMC flash […]

Raspberry Pi Zero 2 W CM3 adapter
Posted on

Raspberry Pi Zero 2 W board gets Raspberry Pi CM3 adapter

A couple of months ago, we wrote about the Raspberry Pi Compute Module 3E (CM3E) equipped with the Raspberry Pi RP3A0 SiP found in the Raspberry Pi Zero 2 W board. It looks like an OEM product from Raspberry Pi trading, and as such is close to impossible to purchase. But if somehow, you’d like to have the guts of the Pi Zero 2 W into CM3 module form factor, Waveshare has designed the Zero-to-CM3 adapter for the Raspberry Pi Zero 2 W that should be compatible with most carrier boards designed for Raspberry Pi CM3 or CM3+. As you can see, it is also using pogo pins to connect to the test points on the Raspberry Pi Zero 2 W board in order to route the USB, USB OTG, and SD card signals, so it will not work on older Pi Zero boards since the test points are in […]

Rockchip RK3568, RK3588 and Intel x86 SBCs and SoMs in 2025
Thin Mini-ITX networking board with 6x 2.5GbE
Posted on

Thin Mini-ITX networking board features six 2.5GbE ports, Celeron J6412 Elkhart Lake SoC

Powered by an Intel Celeron J6412 quad-core Elkhart Lake processor, the Jetway MI05-0XK thin mini-ITX networking board is equipped with six 2.5GbE ports, up to 16GB RAM via a single SO-DIMM socket, as well as M.2 sockets for storage, WiFi and/or cellular connectivity, some serial ports, and an optional HDMI port for video output. Four variants are offered: the standard MI05-00K model without eMMC flash nor TPM, the MI05-02K with a TPM 2.0 chip, the MI05-03K with a 32GB eMMC flash, and finally the MI05-07K with both the TPM 2.0 security chip and 32GB eMMC flash. Jetway MI05-0XK specifications: SoC – Intel Celeron J6412 quad-core Elkhart Lake processor @ 2.0 GHz / 2.6GHz (Burst frequency) with 1.5MB cache, 16 EU Intel UHD Graphics; 10W TDP System Memory – Up to 16GB DDR4-3200 via SO-DIMM socket Storage 1x SATA III (6 Gb/s) port 1x M.2 M-key 2242 SATA/PCIe Gen.3 x2 interface […]

Intel Xeon SBC
Posted on

AAEON EPIC-TGH7 SBC supports up to Intel Xeon W-11865MRE (Tiger Lake H) processor

It’s not often we come across an Intel Xeon SBC, but that’s just what AAEON EPIC-TGH7 single board computer offers thanks to a choice of Intel Tiger Lake H processors up to the Xeon W-11865MRE octa-core/16-thread processor. So far, we had only written about Tiger Lake H-based COM Express and COM HPC modules from companies such as ADLink, Congatec, and Portwell, and the EPIC-TGH7 is the first proper SBC we’ve seen with the industrial processors. It supports up to 64GB RAM through two SO-DIMM sockets, SATA and NVME storage, offers 2.5GbE and Gigabit Ethernet ports, five video interfaces, eight USB 3.2/2.0 interfaces, and more. AAEON EPIC-TGH7 specifications: Tiger Lake-H SoC (one or the other) Intel Xeon W-11865MRE 8-core/16-thread @  2.60GHz / 4.70GHz (Turbo) with 32 EU Intel UHD Graphics; TDP: 35-45W Intel Core i7-11850HE 8-core/16-thread processor @ 2.60GHz / 4.70GHz (Turbo) with 32 EU Intel UHD Graphics; TDP: 35-45W Intel […]
