23 responses

  1. davef
    July 10, 2012

    10Watts! Or is 2A the power supply rating?

  2. cnxsoft
    July 10, 2012

    @ davef
    Yes, it’s the power supply rating, it’s the same as the Mele A1000 I think.

  3. misko
    July 10, 2012

    @ cnxsoft
    Hi cnxsoft
    can you plz modify your build scripts to support MX/XX/??X802 devices :)
    kernel always crash if I use same A1000 server image.
    I can post you kernel booting dump dump if you want

  4. cnxsoft
    July 10, 2012

    @ misko
    The build should not need modification, just adding the MK802 evb.fex or script.fex should be OK, unless there is a bug in the kernel. If you have an MK802 devices, can you provide a link to evb.bin ?

    Yes, you can post the kernel log somewhere (e.g. paste bin) and put the link here.

  5. misko
    July 11, 2012
  6. misko
    July 11, 2012

    And one more think
    don’t wast you time with mali400 x.org drivers
    I own snowball http://igloocommunity.org/
    It has working EGL/openGL on x.org and it is so slow. x.org process take 80% cpu time if I play video on fullscreen
    I would try wayland or pure EGL/openGL to framebuffer
    but it need recompile mali drivers original DDK.
    But I don’t know anybody who have source codes

  7. cnxsoft
    July 11, 2012

    @ misko
    Great! That means nothing is wrong! It’s just the hardware configuration is different between MK802 and Mele A1000. So I would just need your evb.bin to add mk802.fex (text version of your evb.bin) to https://github.com/cnxsoft/a10-config/tree/master/script.fex. Can you send it to me or provide a link ?

  8. cnxsoft
    July 11, 2012

    @ misko
    EGL/OpenGL is not to play video, but for 2D/3D acceleration. If you run glmark2-es2 on your snowball, I assume it would be very smooth, compared to software rendering, you should also be able to run Ubuntu 12.04 Unity3D with low CPU usage, unless GPU support is broken. To play video requires another library for hardware acceleration.

  9. misko
    July 11, 2012

    @ cnxsoft
    Sorry I mean it little different.
    software video decoding(totem+gstreamer) toke 30% cpu time on my snowball board.
    Scene composnition x.org + unity take 80%
    But problem is that unity3d(it was not optimalized for gpu. look at desktop) do a lot of opengl calls that is not ok with mali 400 gpu.
    Let say on desktop computer gpu drivers collect all opengl draw calls and pack it and optimalize.

    I did some benchmarks
    I run glmark2-es2 to render output to offload texture. glmark2-es took 15% cpu time and most time 120fps
    I really good FPS. Not as good as on my desktop nvidia :)
    But after I start glmark2-es to render on screen x.org+compiz cca 80% cpu time and glmark fps at 25fps

    Some guys on snowball IRC talk about this problem and it is problem on mali400 x.org drivers.
    TI SGX do much better work (pandaboard, beagleboard).

    I don’t want to say that mali is bad gpu. I want to say unity is really shit. I do opengl couple years on embeded and it is crazy what you can do if you do it proper way. But unity and x.org is stuff for desktop. They never optimalize if it is not important.

  10. cnxsoft
    July 11, 2012

    @ misko
    Thanks for detailed answer, and sorry to have misunderstood your first message.
    Now if I move the mouse in Ubuntu 12.04 (Mele) over the left bar, I get 100% CPU usage and the cursor gets very choppy because of compiz, so even if Mali-400 X11 support is not as good as we could expect, hopefully, that will make Ubuntu + Unity3D usable.

    Are you subscribed to arm-netbook mailing list? You may want to give them your feedback, and see if they’d consider using wayland instead of x. AllWinner (Tom Cubie) is on the mailing list, and they apparently paid ARM for support with Mali-400.

  11. Onebir
    July 11, 2012

    “Here are the specifications of the device partially taken from Dealextreme, so there must be an error somewhere, we just need to find out where.”
    :D Maybe it’s the letter A ;-)

    Does it have the same power supply shortcuts as the MK802?

  12. misko
    July 12, 2012

    cnxsoft :@ misko Thanks for detailed answer, and sorry to have misunderstood your first message. Now if I move the mouse in Ubuntu 12.04 (Mele) over the left bar, I get 100% CPU usage and the cursor gets very choppy because of compiz, so even if Mali-400 X11 support is not as good as we could expect, hopefully, that will make Ubuntu + Unity3D usable.Are you subscribed to arm-netbook mailing list? You may want to give them your feedback, and see if they’d consider using wayland instead of x. AllWinner (Tom Cubie) is on the mailing list, and they apparently paid ARM for support with Mali-400.

    I will do it

  13. misko
    July 12, 2012

    cnxsoft :@ misko Great! That means nothing is wrong! It’s just the hardware configuration is different between MK802 and Mele A1000. So I would just need your evb.bin to add mk802.fex (text version of your evb.bin) to https://github.com/cnxsoft/a10-config/tree/master/script.fex. Can you send it to me or provide a link ?

    here is it
    https://www.miniand.com/forums/forums/2/topics/82

  14. cnxsoft
    July 12, 2012

    @ Onebir
    After seeing the discussion over DX forums, at one point I thought they got the RAM wrong. (512 MB instead of 1GB), but it seems to be OK.

    As for power supply shortcuts, somebody needs to open the thing to see what’s inside.

  15. cnxsoft
    July 12, 2012

    @ misko
    Thanks, I added mk802.fex to a10-config in github.

    Maybe I misunderstood your message (again), when you said it works when you replace script.bin by evb.bin (mk802) in my server image. I’ve told your solution to other people, and it did not seem to work for them: https://github.com/amery/linux-allwinner/issues/46#issuecomment-6900968

  16. misko
    July 12, 2012

    cnxsoft :@ misko Thanks, I added mk802.fex to a10-config in github.Maybe I misunderstood your message (again), when you said it works when you replace script.bin by evb.bin (mk802) in my server image. I’ve told your solution to other people, and it did not seem to work for them: https://github.com/amery/linux-allwinner/issues/46#issuecomment-6900968

    Just change of script.bin by evb.bin didn’t help sorry :)

  17. misko
    July 12, 2012

    I found one nice stuff in linaro kernel.
    But I hope you will know how we can enable this in a10 kernel.
    Maybe it is not related to kernel config.

    uboot + kernel boot output show on UART but after kernel boot done I can log in with UART.
    It will be fine on Mx802 as it has only wifi.
    I can do some basic setup over console on my snowball (get current ip address).
    I just bought rasbery pi and raspberry debian don’t have it too

  18. cnxsoft
    July 12, 2012

    @ misko
    You can connect the UART to the Mele A1000 or MK802, but I guess you have done this already since you could provide the kernel log.

    If you want to add login in UART, you can try to modify /etc/inittab.

  19. misko
    July 12, 2012

    cnxsoft :@ misko You can connect the UART to the Mele A1000 or MK802, but I guess you have done this already since you could provide the kernel log.If you want to add login in UART, you can try to modify /etc/inittab.

    But all your build scripts are base on linaro files.
    That means inittab should be same.
    Or some people from snowball made some changes, because they use same linaro sw package as you for A1000

  20. cnxsoft
    July 12, 2012

    misko :

    But all your build scripts are base on linaro files.
    That means inittab should be same.
    Or some people from snowball made some changes, because they use same linaro sw package as you for A1000

    You could compare your inittab on both board. Snowball must have an initramfs, which the image does not have yet. Peter is working on that (http://www.j1nx.nl/2012/07/12/linaro-build-quick-update/), and I may have a try if I can find the motivation to do it…

  21. misko
    July 13, 2012

    cnxsoft :

    misko :But all your build scripts are base on linaro files. That means inittab should be same. Or some people from snowball made some changes, because they use same linaro sw package as you for A1000

    You could compare your inittab on both board. Snowball must have an initramfs, which the image does not have yet. Peter is working on that (http://www.j1nx.nl/2012/07/12/linaro-build-quick-update/), and I may have a try if I can find the motivation to do it…

    What do you expected from you A1000 ??
    Some kind of media center?? that is reason why I bought my MX802 :)
    Lets be ones you didn’t expect desktop stile experience from A1000. Firefox/Chrome is useless on this kind of devices

    I have idea how we can make media center from A1000.
    do you know qtmediahub ?? it is/was nokia qt demo aplication.
    And this guys made theme that looks exactly like XBMC :)
    But we need 2 thinks. Mali400 drivers with rendering to framebuffer.
    No x11 and build qt5.
    But I have only one problem a that is mali drivers :(

  22. cnxsoft
    July 13, 2012

    @ misko
    The real reason I bought the Mele is to have an ARM board to tinker with (trying things, play with Linux on ARM…), without having to pay hundreds of dollars. Where I live a Beagleboard would cost me nearly $250, and even the beaglebone would be close to $200.

    If you want a media player, you can try XBMC, it’s part of Linaro, but you have to make sure OpenGL ES is working. I’ve tried it already (without mali support) and I get 0.3 fps in the main menu. Once you get the menu, I suppose NEON software decoding would also you to play 720p videos, but maybe not 1080p. 1080p would probably require hardware video decoding.

    I did not know qtmediahub, but if it skips X11 it should be faster. The OpenGL ES libraries (ARMHF) are available at https://dl.dropbox.com/u/65312725/mali_opengl_hf_lib.tgz. I basically don’t know anything about OpenGL/ OpenGL ES, but you seem to be a specialist, so you may be able to find a way to use that :).
